Lenovo A7010 Manual de usuario

Quick Start Guide

Read this guide carefully before using your smartphone.

Lenovo A7010

Lenovo A7010a48

Reading before using your smartphone

For your safety

Before assembling, charging or using your mobile device for the ﬁrst

time, please read the important product safety and legal information

provided with your product. If your mobile device becomes

unresponsive, try a reboot—press and hold the On/Off button until the

screen goes dark and your device restarts.

Usage

This phone supports apps and services that may use a lot of data, so

make sure your data plan meets your needs. Contact your service

provider for details. Certain apps and features may not be available in

all countries.

Electronic label

Your mobile device may use an electronic label that provides some

regulatory information about the device. To see the electronic label, go

to Settings > About phone > Regulatory information on your

device.

First glance

Light/Proximity sensor

Receiver/Speaker

1Front-facing camera

On/Off button

Fill Light

4Volume buttons

Back button

Touch screen

7Speaker

Rear-facing camera

Home button

10 Multitask button

Fingerprint

13 14 Microphone

Flash

16 Micro USB connector

16 15

1 2 3

11 10

Step 1. Insert the Micro SIM

cards into SIM1 slot

and SIM2 slot.

Tips:

Both of the card slots

support 2G, 3G and

4G data services.

When two cards are

inserted at the same

time, the system

supports only one of

them to register for 3G

or 4G data service.

If you want to change

the data service type of

the card, go to

Settings > SIM

management > Data

connection.

Step2 . Insert the microSD card.

Installing the Micro SIM and microSD cards

Only Micro SIM cards work with your smartphone.

Always turn off your smartphone ﬁrst before you insert or remove a

Micro SIM card. Insert or remove a Micro SIM card with your

smartphone on may damage your Micro SIM card or smartphone

permanently.

Micro SIM Micro SIM

Micro SIM

A Micro SIM card provided by your carrier is required in order to use

cellular services. Install the Micro SIM and microSD cards as shown.

Micro SIM

Charging the battery

Low battery power Fully charged Charging

Charge the battery as shown.

Turning on or turning off your smartphone

Tur n on: Press and hold the On/Off button until

the Lenovo logo appears.

Tur n of f: Press and hold the On/Off button for a

few seconds, then tap Power off.

Restart: Press and hold the On/Off button for

about 10 seconds.

Method 1.

Method 2.

Connect your smartphone to a power outlet using the

cable and USB power adapter that come with your

smartphone.

Connect your smartphone to a computer using the cable

that comes with your smartphone.

Certain features, services and applications are network dependent

and may not be available in all areas; additional terms, conditions

and/or charges may apply. Contact your service provider for details.

All features, functionality, and other product speciﬁcations, as well as

the information contained in this guide, are based upon the latest

available information and believed to be accurate at the time of

printing. Lenovo reserves the right to change or modify any

information or speciﬁcations without notice or obligation.

Note: The images in this guide are examples only.

Lenovo and the Lenovo logo are trademarks of Lenovo in the United

States, other countries, or both.

Manufactured under license from Dolby Laboratories. Dolby, Dolby

Atmos, and the double-D symbol are trademarks of Dolby

Laboratories.

Android, Google and other trademarks are owned by Google Inc. The

Android robot is reproduced or modiﬁed from work created and

shared by Google and used according to terms described in the

Creative Commons 3.0 Attribution License. All other product or

service names are the property of their respective owners.

Product ID: Lenovo A7010 (Model A7010a48)

Manual Number: 68XXXXXXXX-X

RF Exposure Information (SAR)

This phone is designed and manufactured not to exceed the emission

limits for exposure to radio frequency (RF) energy set by the Federal

Communications Commission of the United States.

During SAR testing, this device was set to transmit at its highest

certiﬁed power level in all tested frequency bands, and placed in

positions that simulate RF exposure in usage against the head with no

separation, and near the body with the separation of 10 mm. Although

the SAR is determined at the highest certiﬁed power level, the actual

SAR level of the device while operating can be well below the

maximum value. This is because the phone is designed to operate at

multiple power levels so as to use only the power required to reach

the network. In general, the closer you are to a wireless base station

antenna, the lower the power output.

The exposure standard for wireless devices employing a unit of

measurement is known as the Speciﬁc Absorption Rate, or SAR.

The SAR limit set by the FCC is 1.6W/kg.

This device is complied with SAR for general population /uncontrolled

exposure limits in ANSI/IEEE C95.1-1992 and had been tested in

accordance with the measurement methods and procedures speciﬁed

in IEEE1528.

The FCC has granted an Equipment Authorization for this model

phone with all reported SAR levels evaluated as in compliance with

the FCC RF exposure guidelines. SAR information on this model

phone is on ﬁle with the FCC and can be found under the Display

Grant section of www.fcc.gov/oet/ea/fccid after searching on FCC ID:

YCNA7010A48.

For this device, the highest reported SAR value for usage against the

head is 1.12 W/kg, for usage near the body is 1.06 W/kg.

While there may be differences between the SAR levels of various

phones and at various positions, they all meet the government

requirements.

SAR compliance for body-worn operation is based on a separation

distance of 10 mm between the unit and the human body. Carry this

device at least 10 mm away from your body to ensure RF exposure

level compliant or lower to the reported level. To support body-worn

operation, choose the belt clips or holsters, which do not contain

metallic components, to maintain a separation of 10 mm between this

device and your body.

RF exposure compliance with any body-worn accessory, which

contains metal, was not tested and certiﬁed, and use such body-worn

accessory should be avoided.

FCC Regulations

This mobile phone complies with part 15 of the FCC Rules. Operation

is subject to the following two conditions: (1) This device may not

cause harmful interference, and (2) this device must accept any

interference received, including interference that may cause undesired

operation.

This mobile phone has been tested and found to comply with the

limits for a Class B digital device, pursuant to Part 15 of the FCC

Rules. These limits are designed to provide reasonable protection

against harmful interference in a residential installation. This equipment

generates, uses and can radiated radio frequency energy and, if not

installed and used in accordance with the instructions, may cause

harmful interference to radio communications. However, there is no

guarantee that interference will not occur in a particular installation If

this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment off and

on, the user is encouraged to try to correct the interference by one or

more of the following measures:

-Reorient or relocate the receiving antenna.

-Increase the separation between the equipment and receiver.

-Connect the equipment into an outlet on a circuit different from that

to which the receiver is connected.

-Consult the dealer or an experienced radio/TV technician for help.

FCC Note:

Caution: Changes or modiﬁcations not expressly approved by the

party responsible for compliance could void the user‘s authority to

operate the equipment.

Learning more

Getting support

To get support on network service and billing, contact your wireless

network operator. To learn how to use your smartphone and view its

technical speciﬁcations, go to http://support.lenovo.com/.

Downloading publications

To obtain the latest smartphone manuals, go to:

http://support.lenovo.com/

Accessing your User Guide

Your User Guide contains detailed information about your

smartphone. To access your User Guide, go to http://support.leno-

vo.com and follow the instructions on the screen.
