Lenovo A526 Manual de usuario

Lenovo A526

Quick Start Guide v1.0

Read this guide carefully before using your phone.

GPS

Model: Lenovo A526 System: Android 4.2.2

Battery: 2000 mAh

Wireless communication

Display

Model and system

Power and battery

CPU

① Size and weight

Camera

①Based on actual measurements.

② Launch with Android 4.2 which only supports BT 4.0 PXP proﬁle.

Size: 4.5” FWVGA Screen: 1 point touch

Resolution: 854 × 480 LCD type: TN

CPU: MT6582M Quad Core 1.3GHz

Height: 132 mm Width: 67.6 mm Depth: 11.1 mm

Weight: 145 g

②Bluetooth 4.0 WLAN WCDMA, GSM, EDGE

Type: CMOS

Pixels: 5.0 MP (back) + 0.3 MP (front)

Technical speciﬁcations

For more information about Lenovo Mobile Phone functions,

Regulatory Notices and other useful manuals, go to

http://support.lenovo.com/.

Micro USB

Earphone jack

Receiver

MicrophoneOn/Off button

Speaker

Volume key

10 11

Back button

Home button Menu button

Front camera

Back camera

First glance

SIM1

3G/2G

SIM2

SIM1

SIM2

SIM1

3G/2G

SIM2

SIM1

SIM2

You need to insert the SIM card provided by your carrier to use cellular

services. Install your phone as shown.

DO NOT insert or remove the SIM cards while your phone is turned on.

Doing so can permanently damage your SIM card or your phone.

Step 3. Install the battery.

Step 1. Open the back cover.

Step 2. Insert the SIM cards and

the memory card.

Tip: Insert (U)SIM card into

SIM 1 slot and SIM card

into SIM 2 slot.

Step 4. Install the back cover.

Preparing your phone

Method 1. Connect your phone to a power outlet using the included

cable and USB power adapter.

Method 2. Charge the battery using a computer.

Low battery Fully charged Charging

For more information about battery safety, see the Important Product

Information Guide.

Charge the battery as shown.

Charging the battery

8306LV8001W

Printed in China

Legal notices

Lenovo and the Lenovo logo are trademarks of Lenovo in the

United States, other countries, or both.

Other company, product, or service names may be trademarks

or service marks of others.

First Edition (January 2014)

Learn more

For more information about Lenovo Mobile Phone functions,

Regulatory Notices and other useful manuals, go to

http://support.lenovo.com/.
