Lenovo A328 Manual de usuario
Read this guide carefully before using your smartphone.
Quick Start Guide v1.0
Lenovo A328
Lenovo A328 QSG EN 110_74mm V1.01 1 6/20/2014 6:44:58 PM
Model: Lenovo A328 System: Android
Bluetooth 4.0; WLAN 802.11 b/g/n; WCDMA, GSM; GPS
Battery: 2000 mAh
Model and system
①Depending on the measuring method, the dimensions and weight
might vary slightly.
Display
Battery
Processor
①Dimensions and weight
Camera
Wireless Communication
Height: 132 mm (5.2 inches) Width: 68.5 mm (2.69 inches)
Depth: 10.8 mm (0.425 inch) Weight: 140 g (0.328 lb)
Processor: MTK MT6582M
,
Quad Core
,
1.3GHz
Type: CMOS
Pixels: 5.0 megapixels (back) + 2.0 megapixels (front)
Size: 4.5 inches Screen: 2-touch
Resolution: 854 × 480 pixels LCD type: TN
Technical specifications
Lenovo A328 QSG EN 110_74mm V1.02 2 6/20/2014 6:44:58 PM
First glance
Microphone
Flashlight
Micro USB
connector
Speaker On/Off button
Volume buttons
Receiver
1
4
7
10
2
5
8
3
6
9
12
3
4
6
5
7
8
9
10
Front-facing
camera
Rear-facing
camera
Headset
connector
Lenovo A328 QSG EN 110_74mm V1.03 3 6/20/2014 6:44:58 PM
You must insert the SIM card provided by your carrier to use cellular
services. Set up your smartphone as shown.
SIM1
SIM2
Step 1. Open the back cover.
Step 2. Insert the SIM cards and
the memory card.
Tip: Insert the (U)SIM card into
SIM1 slot and SIM card
into SIM2 slot.
Step 3. Install the battery.
a. Align the battery
connectors on the battery
with the pins in the
battery compartment.
b. Push the battery down
into place.
Step 4. Install the back cover.
Always turn off your smartphone first before you insert or remove a
SIM card. Insert or remove a SIM card with your smartphone on may
damage your SIM card or smartphone permanently.
SIM2
SIM1
a
b
SIM1
SIM2
Preparing your smartphone
Lenovo A328 QSG EN 110_74mm V1.04 4 6/20/2014 6:44:58 PM
Turning on or turning off your smartphone
Turn on: Press and hold the On/Off button until
the Lenovo logo appears.
Turn off: Press and hold the On/Off button for a
few seconds, then tap Power off.
Restart: Press and hold the On/Off button for a
few seconds, then tap Restart.
Your smartphone has a rechargeable battery. For more information
about battery safety, see the “Rechargeable battery notice” in the
Important Product Information Guide shipped with your smartphone.
Low battery power Fully charged Charging
Charge the battery as shown.
Method 1.
Method 2.
Connect your smartphone to a power outlet using the
cable and USB power adapter that come with your
smartphone.
Connect your smartphone to a computer using the cable
that comes with your smartphone.
Charging the battery
2
1
Lenovo A328 QSG EN 110_74mm V1.05 5 6/20/2014 6:44:58 PM
Radio and Telecommunications Terminal Equipment
Directive
This product is in compliance with the essential requirements
and other relevant provisions of the Radio and Telecommuni-
cations Terminal Equipment Directive, 1999/5/EC.
European Union conformity
HQ60111132000
Printed in China
First Edition (August 2014) © Copyright Lenovo 2014.
Learning more
Legal notices
Lenovo and the Lenovo logo are trademarks of Lenovo in the
United States, other countries, or both.
Other company, product, or service names may be
trademarks or service marks of others.
To learn more information about your Lenovo smartphone and
obtain the latest smartphone manuals, go to:
http://support.lenovo.com/.
Getting support
For support on network service and billing, contact your
wireless network operator. For instructions on how to use your
device, go to: http://support.lenovo.com/.
Lenovo A328 QSG EN 110_74mm V1.06 6 6/20/2014 6:44:58 PM
