Leica RTC360 Manual de usuario

Leica RTC360/RTC360 LT

Quick Guide

Version 2.0

Quick Guide 5

Quick-guide 21

Quick Guide 37

Guía Rápida 53

Kiirjuhend 69

Pikaopas 85

Guide abrégé 101

Guida rapida 117

Trumpas vadovas 133

Īsā pamācība 149

Korte handleiding 165

Hurtigveiledning 181

Skrócona instrukcja obsługi 197

Guia de Consulta Rápida 213

Snabbguide 229

Leica RTC360/RTC360 LT

Quick Guide

Version 2.0

English

1 Important Information about your Instrument

Read and follow the User Manual on the accompanying data storage device

before using the product.

Keep for future reference!

To ensure safety when using accompanying battery charger, also observe the dir-

ections and instructions contained in the User Manual of the battery charger.

•Measuring horizontal and vertical angles.

•Measuring distances.

•Scanning objects.

•Capturing and recording images.

•Recording measurements.

•Computing with software.

•Remote control of product.

•Data communication with external appliances.

☞

Intended use

6 Important Information about your Instrument

The RTC360/RTC360 LT instrument contains the following laser product:

Laser product Laser class

EDM (Electronic Distance Measurement) module Class 1

The classication is in accordance with IEC 60825-1 (2014-05).

60°

0°

360°

90° b

0016195_003

a Laser beam

b Vertical laser scanning area

c Horizontal laser scanning area

Laser products

Locations of laser

apertures

7 Important Information about your Instrument

The product must not be disposed with household waste.

For the AC power supply:

WARNING

If unit is not connected to ground, death or serious injury can occur.

Precautions:

▶To avoid electric shock power cable and power outlet must be grounded.

8 Important Information about your Instrument

For the AC/DC power supply and the battery charger:

WARNING

Electric shock due to use under wet and severe conditions

If unit becomes wet it may cause you to receive an electric shock.

Precautions:

▶If the product becomes humid, it must not be used!

▶Use the product only in dry environments, for example in buildings or

vehicles.

▶Protect the product against humidity.

9 Important Information about your Instrument

For the AC/DC power supply and the battery charger:

WARNING

Unauthorised opening of the product

Either of the following actions may cause you to receive an electric shock:

•Touching live components

•Using the product after incorrect attempts were made to carry out repairs.

Precautions:

▶Do not open the product!

▶Only Leica Geosystems authorised service centres are entitled to repair

these products.

•FCC Part 15 (applicable in US)

•Hereby, Leica Geosystems AG declares that the radio equipment type

RTC360/RTC360 LT is in compliance with Directive 2014/53/EU and other

applicable European Directives.

The full text of the EU declaration of conformity is available at the fol-

lowing Internet address: http://www.leica-geosystems.com/ce.

Class 1 equipment according to European Directive 2014/53/EU

(RED) can be placed on the market and be put into service without

restrictions in any EEA member state.

Conformity to

national regula-

tions

10 Important Information about your Instrument
