Lehner Lifttechnik Delphin Documento técnico

Poollift Delphin

_______________________________________________________________________

Version: February, 2015

MANUAL

AND

OPERATING INSTRUCTIONS

_______________________________________________________________

Poollift Delphin page 2

________________________________________________________________

Content

1. Introduction ....................................................................................................................................... 3

2. Technical Specifications .................................................................................................................. 3

Used materials ............................................................................................................................... 3

3. Installation Instructions ..................................................................................................................... 4

Fastening possibilities ................................................................................................................... 4

Setting up....................................................................................................................................... 4

Installation..................................................................................................................................... 4

4. Start-up Operation ............................................................................................................................. 8

Locking (lock) ............................................................................................................................... 8

Carriage ......................................................................................................................................... 8

5. Operating........................................................................................................................................... 9

6. Diagnostics ........................................................................................................................................ 9

7. Cleansing and Maintenance .............................................................................................................. 9

8. Packaging, Delivery and Storage .................................................................................................... 10

9. Attachments..................................................................................................................................... 11

List of parts.................................................................................................................................. 12

Mechanical scheme ..................................................................................................................... 13

Instructions for seal- and piston-replacement ............................................................................. 14

Maintenance list .......................................................................................................................... 15

Poollift Delphin page 3

1. Introduction

Thank you for choosing our product Poollift Delphin. The Poollift serves as a valuable support for

entering and exiting a swimming pool. It enables disabled persons or wheelchair users to refresh

themselves or e.g. to perform medicative water aerobics.

Your Poollift has been developed and constructed by experienced professionals and therefore its

functionalty is ensured.

Please read this manual carefully before using the Poollift.

2. Technical Specifications

Description

The Poollift Delphin is powered by water pressure.

The required water pressure at a load of 85 kg is 0,3 Mpa. For a maximum load of 120 kg it is

necessary to have a water pressure of min. 0,4 MPa. In most homes the water pump provides the

necessary amount of 0,4 MPa.

The fastening of the Poollift is suitable for different types of swimming pools.

The Poollift is deliverd with a recessed or a screwed panel. Both options can be accomplished with a

extended C-tube, if the distance between the edge of the pool and the fastening point of the panel is

wider than 350 mm.

The seat rotates automatically 90° to the entry and the exit point.

The operating lever on the entry level as well as on the exit level (in the water) ensures that the

access and the exit is possible without any further help by another person

Used materials

•Stainless steel AISI 316L V4A (cylinder, tube, pillars, sockets, outlet)

•Polypropylen (seat)

•Rubber (seat)

Poollift Delphin page 4

3. Installation Instructions

Fastening possibilities

Recessed panel

A drill-hole with a diameter of at least 120 mm and a depth of 160 mm has to be executed. Concrete

or a appropriate glue ought to be used for the fastening. Ensure that the panel is fixed vertically and

that the upper edge is on one level with the floor before gluing.

If the Poollift has to be dismantled before winter (e.g. outdoor installation), it is possible to blind the

hole in the floor with a screw cap.

Screwed panel

Six small drill-holes have to be executed for that kind of panel. Heavy duty anchors or dowels should

be used for the fastening.

If the Poollift has to be dismanteld, it is possible to simply unscrew the panel.

Setting up

A minimum water depth of 1050 mm is necessary. Furthermore it is important to ensure, that the

entry point is easily accessible for users and that also a water supply has to be possible.

When using a standard C-tube, the center of the panel should be at least 130 mm to max. 350 mm

away from the edge of the pool. If the distance of 350 mm is exceeded it is possible to use an

extended C-tube (special order).

Installation

Recessed panel:

Execution of a core hole (diameter at least 120 mm) and

then gluing the sleeve (see picture)

Screwed Konsole:

Screwing the panel with 6 screws on the floor

safety ring

Measuring out the place where the panel will be

Poollift Delphin page 5

Measuring out the overhanging of

the pool edge

Setting of the overhanging of the

pool edge on the spacer

Removal of the screws to fasten the

C-tube

Applying the C-tube and screwing it

together

Inserting the safety ring (see first

picture) into the panel

Poollift Delphin page 6

Placing the Poollift at the pool edge

Implementing the additional pillar and screwing

it to the panel using the union nut

Attaching the water hose

Unhooking the Poollift lock (if needed)

Poollift Delphin page 7

Mounting the seat into the provided holder

Tightening the seat bracket (seat height is adjustable)

Checking the immersion depth (lower landing)

and entry height (upper landing)

Poollift Delphin page 8

4. Start-up Operation

1. After installing the Poollift please check if all screw connections are tightened.

2. Open the water supply line to let the air escape from the pressure water hose. Then shut the

water supply again.

3. Move the operating lever upwards and push the cylinder downwards to let the air escape from

the cylinder.

4. Connect the pressure water hose to the valve. Always use drinking water for the operation

and never water from the pool!

5. Adjust the entry height according to the customer’s request.

Locking (lock)

The Poollift can be bolted and locked if it is in the upper landing. That way it is protected against

unauthorized use.

ATTENTION!

The Poollift must be unlocked before it can be moved!

Carriage

There are transport wheels optionally at one’s disposal.

Poollift Delphin page 9

5. Operating

The operating lever on the entry level as well as on the exit level (in the

water) ensures that the access and the exit is possible without any further help

by another person.

The movement direction is controlled by the 3-way-valve. To go upwards you

have to pull the operating lever down and if you want to go downwards you

have pull the operating lever up. Particular parts are shown in the attachment

„Mechanical scheme“.

6. Diagnostics

Poollift holders can check their installation for flaws on their own accord with the help of the

following points. Apart from that they can contact the service company if malfunctions occur.

By no means it is allowed to manipulate, change or remove any components of the installation.

The Poollift does not move (or too slow) upwards?

Check:

•The pressure water supply must be opened and the pressure water hose must be flawless

•The valve must be in the end position (turned down)

•Appropriate water pressure is necessary.

•There must not be any defect on the seal of the cylinder

The Poollift does not move (or too slow) downwards?

Check:

•The drain hose must be in good condition.

•The valve must be in the end position (turned up)

•There must not be any defect on the seal of the cylinder

7. Cleansing and Maintenance

The Poollift is very easy to clean. The installation has to be cleaned from eventual organic and

inorganic sediments regularly. Appropriate care ensures a problem-free operation over the long term.

Please check all screw connections regularly and tighten loose screws.

The Poollift uses drinking water as a lubricant, that is why it is not necessary to lubricate the

installation.

Picture 1: 3-way-valve

Poollift Delphin page 10

If the Poollift is out of service for extended periods of time (e.g. in winter), it is recommended to

damp the seal of the cylinder before it is commissioned again.

Don’t keep the Poollift outside during winter, because remaining water in the cylinder could damage

the installation. Seperate the pressure water hose from the Poollifte after dismantling and turn the

operating lever in the upper position.

Afterwards push the cylinder in the upper and the lower position until the whole amount of the water

inside the cylinder has leaked out. After draining the cylinder keep the cylinder in the upper position.

If necessary close the Poollift in that position using the lock.

It is absolutely required to maintain your Poollift regularly.

How to replace the seals and pistons is described in the the document „Instructions for seal- and

piston-replacement“.

8. Packaging, Delivery and Storage

In some cases the Poollift will be deliverd disassembled in two wooden boxes.

The assemblage is carried out on the spot.

Please protect the Poollift from falling down, overturning and intense vibrations during the transport.

Store the Poollift in a dry, clean and dust-free interior at temperatures between 5° and 40°C and a

humidity of max. 80%.

The Poollift must not be exposed to the effects of chemicals!
