Parents’ Guide

This guide contains important information. Please keep it for future reference.

91-003970-001 UK

INTRODUCTION

Thank you for purchasing the LeapLand Adventures™ learning video

game! Hunt for the four missing keys to unlock Clever Castle and learn

about letters, shapes, numbers and colours along the way.

INCLUDED IN THIS PACKAGE

• 1 wireless controller

• 1 HDMI game stick

• 1 micro USB power cable

• 1 HDMI extender cable

• Parents’ guide

WARNING

All packing materials such as tape, plastic sheets, packaging locks,

removable tags, cable ties, cords and packaging screws are not part of

this toy and should be discarded for your child’s safety.

NOTE

Please keep this parent’s guide as it contains important information.

Unlock the Packaging Locks

Rotate the packaging lock anticlockwise for 90

degrees

Pull out the packaging locks.

D-Pad B Button

A Button

Home Button Help Button

HDMI Game Stick

Micro USB

Power Cable

HDMI

Extender Cable

GETTING STARTED

INITIAL SETUP

For your child’s safety, the following steps must be assembled by an adult.

1. Plug the USB B Connector end of the Micro USB

Power Cable into the USB B port on the HDMI

Game Stick.

2. Plug the HDMI Game Stick into an HDMI port on

your television.

3. Plug the USB A Connector end of the Micro USB

Power Cable into a USB port on your television

or other qualified DC 5V adapter with output no

less than 500mA.

Note: If the HDMI Extender Cable is needed, plug the HDMI Game Stick

into the HDMI Extender Cable. Plug the HDMI Extender Cable

into an HDMI port on your television.

BATTERY REMOVAL AND INSTALLATION

1. Find the battery cover located on the back of the

Wireless Controller, use a coin or screwdriver to

loosen the screw and then open the battery cover.

2. Remove old batteries by pulling up on one end

of each battery.

3. Install 2 new AA (AM-3/LR6) batteries following

the diagram inside the battery box.

4. Replace the battery cover and tighten the screw

to secure.

WARNING:

Adult assembly required for battery installation.

Keep batteries out of reach of children.

IMPORTANT: BATTERY INFORMATION

• Insert batteries with the correct polarity (+ and -).

• Do not mix old and new batteries.

• Do not mix alkaline, standard (carbon-zinc) or rechargeable batteries.

• Only batteries of the same or equivalent type as recommended are

to be used.

• Do not short-circuit the supply terminals.

• Remove batteries during long periods of non-use.

• Remove exhausted batteries from the toy.

• Dispose of batteries safely. Do not dispose of batteries in fire.

Disposal of batteries and product

The crossed-out wheelie bin symbols on products and

batteries, or on their respective packaging, indicates they

must not be disposed of in domestic waste as they contain

substances that can be damaging to the environment and

human health.

The chemical symbols Hg, Cd or Pb, where marked, indicate

that the battery contains more than the specied value of

mercury (Hg), cadmium (Cd) or lead (Pb) set out in the

Batteries and Accumulators Regulation.

The solid bar indicates that the product was placed on the

market after 13th August, 2005.

Help protect the environment by disposing of your product or

batteries responsibly.

LeapFrog®cares for the planet.

Care for the environment and give your toy a second life by disposing

of it at a small electricals collection point so all its materials can be

recycled.

In the UK:

Visit www.recyclenow.com to see a list of collection points near you.

In Australia & New Zealand:

Check with you local council for kerbside collections.

Safety information when using power supply for toys

LeapFrog recommend a power supply (AC/DC adaptor) of the below

specification:

Power rating: 5V/500mA or 5V/1A DC output

• Use Leapfrog or any standard adaptor Comply with EN61558

• This toy shall only be used with a power supply for toys.

• The power supply is not a toy.

• This toy is not intended for use by children under 3 years old.

• Do not connect the toy to more than the recommended number of

power supplies.

• Never clean a plugged in toy with liquid.

• Please examine the power supply periodically for conditions that

may result in the risk of fire, electric shock, or injury to persons (such

as damage to the supply cord, output cord, plug, blades, housing,

or other parts) and that, in the event of such conditions, the power

supply should be scrapped.

• Power supplies for toys are not intended to be used as toys, and the

use of these products by children shall be under the full supervision

of parents.

Warning! Not suitable for children under 36 months. Transformer toy.

Electric shock hazard.

RECHARGEABLE BATTERIES

• Remove rechargeable batteries from the toy before charging.

• Rechargeable batteries are only to be charged under

adult supervision.

• Do not charge non-rechargeable batteries.

NOTE

If the Wireless Controller powers down or if the light fades out during

play, please install a new set of batteries.

PRODUCT FEATURES

1. D-Pad

Press the D-Pad on the Wireless Controller to select an item on the

Menu screen. While playing the game, press the D-Pad left and right

to move the character around the screen. Press down on the D-Pad

to make the character crouch and press left or right on the D-Pad

to make the character walk while crouching.

2. Home Button

Press the Home Button on the Wireless Controller to quit a level,

quit the game, or return to the previous Menu screen.

3. Help Button

Press the Help Button on the Wireless Controller to hear hints and

tips on how to play the game or navigate the Menu screen.

4. A Button

• Press the A Button on the Wireless Controller to select the

highlighted objects on the Menu screen.

• Press the A Button to make the character jump.

• Press the A Button a second time while the character is in the air

to make the character double-jump.

• Press the A Button repeatedly to get the character out of a

bubble trap.

• When two treasure chests appear on the screen, press the A Button

to select the treasure chest on the left.

5. B Button

• Press the B Button on the Wireless Controller to return to the

previous Menu screen, or to change the playable character while

on the Map Menu screen.

• If a B Button icon appears above a Curricular Character’s head,

press the B Button to interact with that character.

• When two treasure chests appear on the screen, press the B Button

to select the treasure chest on the right.

6. Menu Screens

The following Menu screens appear in

the game.

Save Selection Screen

• Create or delete a saved profile on

the Save Selection screen.

• To recover a saved file that has been

accidentally deleted, highlight a New

save slot and press the following

buttons on the Wireless Controller: Home + Home + Help + Help

+ B + B + Help + Home + B. This will recover the deleted file.

• To unlock all the castle rewards in the game, highlight an existing

saved profile and press the following buttons on the Wireless

Controller: Home + Home + Help + Help + B + B + Help + Home + B.

Map Menu Screen

• Access the different areas of the

game from the Map Menu screen.

• The player will need to find at least

one key before the castle area can

be accessed.

• To change the playable character,

press the B Button.

• To exit the game, press the Home Button.

• View castle rewards on the Map Menu

screen after every Gem Festival.

Learning Centre

• Access the learning curriculum

content from the Learning Centre.

Level Select Screen

• Use the arrow buttons on the D-Pad

to highlight an unlocked level.

• Press the A Button to select a

highlighted level.

• Levels can only be unlocked once a

previous level has been successfully

completed.

7. In-Game Items

The following in-game items appear throughout the game.

Gems

• Players can collect Gems in every level.

• Players can also find Gems in treasure chests.

• When all of the levels in an area are completed, stars are rewarded

to the player for the total number of Gems that they have collected.

• The game can be completed multiple times using a saved profile.

• Each completion will present the player with different Gems

to collect.

Cleverberries

• Players can collect Cleverberries in every level.

• Players can also find Cleverberries in treasure chests.

• Cleverberries give the playable character one heart of health.

8. In-Game Obstacles

The following are some of the in-game obstacles that players will

encounter. These in-game obstacles remove one heart of health if

the playable character touches them.

Thorns

Flytrap

Spiked Flower

Cactus

Spiked Cactus

Electric Box

Large Floating Bubble

Wooden Log

Rubbish Bin

Thorned Tumbleweed

Fire Plant Projectiles

9. In-Game Characters

The following are some of the in-game characters that players will

interact with.

Curricular Characters

• The Curricular Characters teach fun facts about themselves.

• The Letter Curricular Characters can be found in the Letterland

area of the Map Menu screen, or in the Learning Centre.

• The Number Curricular Characters can be found in the Numberville

area of the Map Menu screen, or in the Learning Centre.

• The Shape Curricular Characters can be found in the Shapetown

area of the Map Menu screen, or in the Learning Centre.

• The Colour Curricular Characters can be found in the Colour Springs

area of the Map Menu screen, or in the Learning Centre.

Pixies

• The Pixies are silly and mischievous, and they do their best to

prevent the player from finding the keys to Clever Castle.

• Some of the Pixies will remove one heart of health if the playable

character touches them.

• The Pixies appear in many different shapes and colours; some fly,

some swim, and some pop up from underground.

10. Automatic Shut-Off

To preserve battery life, the Wireless Controller will automatically

go into sleep mode after approximately 1 minute without input. The

unit can be turned on again by pressing the D-Pad, Home Button,

A Button or B Button.

11. Screen Saver Mode

LeapLand Adventures™ will automatically save and quit the current

game, then go into Screen Saver mode after approximately 20

minutes without input. To exit Screen Saver mode, press the D-Pad,

Home Button, A Button or B Button on the Wireless Controller.

CARE & MAINTENANCE

1. Keep the unit clean by wiping it with a slightly damp cloth.

2. Keep the unit out of direct sunlight and away from any direct

heat sources.

3. Remove the batteries if the unit will not be in use for an extended

period of time.

4. Do not drop the unit on hard surfaces and do not expose the unit to

moisture or water.

5. Always keep the Wireless Controller and HDMI Game Stick away

from water.

6. Examine the Micro USB Power Cable and the HDMI Extender Cable

regularly, checking for damage to the cables, plugs and other parts.

Do not use the Micro USB Power Cable or HDMI Extender Cable if

there is any damage.

7. This toy is only to be connected to equipment bearing either of the

following symbols: or

TROUBLESHOOTING

If you are unable to insert the HDMI Game Stick directly into the HDMI

port on your television due to clearance issues, use the included HDMI

Extender Cable.

If for some reason the unit stops working or malfunctions, please follow

these steps:

HDMI Game Stick

1. Interrupt the power supply by unplugging the USB A Connector end

of the Micro USB Power Cable from the USB port on your television

or other qualified DC 5V adapter with output no less than 500mA.

2. Unplug the HDMI Game Stick from the HDMI port on your television.

3. Wait for 10 Seconds, then plug the HDMI Game Stick into the HDMI

port on your television.

4. Plug the USB A Connector end of the Micro USB Power Cable into

the USB port on your television or other qualified DC 5V adapter

with output no less than 500mA. The unit will now be ready

to play again.

Otros manuales para leapland Adventures

Tabla de contenidos

Otros manuales de Juguete de LeapFrog

LeapFrog

LeapFrog Purrfect Counting Handbag Instrucciones de montaje

LeapFrog

LeapFrog Colourful Counting Red Panda Instrucciones de montaje

LeapFrog

LeapFrog Learn and Roll Chickens Instrucciones de montaje

LeapFrog

LeapFrog Prep for Preschool Activity Book Manual de usuario

LeapFrog

LeapFrog LeapStory Instrucciones de montaje

LeapFrog

LeapFrog Touch & Learn Nature ABC Board Manual de usuario

LeapFrog

LeapFrog LeapBuilders Nickelodeon Blue's Clues & You! 81-Piece Jumbo Blocks... Instrucciones de montaje

LeapFrog

LeapFrog LeapBuilders ABC Smart House Instrucciones de montaje

LeapFrog

LeapFrog 2-in-1 LeapTop Touch Instrucciones de montaje

LeapFrog

LeapFrog LeapGlobe Touch Manual de usuario

LeapFrog

LeapFrog LeapBuilders Soar Zoom Vehicles 6057 Instrucciones de montaje

LeapFrog

LeapFrog Learn & Groove Shakin Colors Maracas Instrucciones de montaje

LeapFrog

LeapFrog Cook & Play Potsy Manual de usuario

LeapFrog

LeapFrog Tapping Colours 2-in-1 Xylophone Manual de usuario

LeapFrog

LeapFrog Busy Learning Bot Instrucciones de montaje

LeapFrog

LeapFrog My Discovery House Manual de usuario

LeapFrog

LeapFrog My Own Leaptop Manual de usuario

LeapFrog

LeapFrog Lets Record Music Player Manual de usuario

LeapFrog

LeapFrog Learn & Groove Rainbow Lights Piano Manual de usuario

LeapFrog

LeapFrog Learning Path My Own Leaptop Manual de usuario

LeapFrog

LeapFrog 100 English-Chinese Words Book Instrucciones de montaje

LeapFrog

LeapFrog Fix & Learn Speedy Manual de usuario

LeapFrog

LeapFrog Safari Learning Station Instrucciones de montaje

LeapFrog

LeapFrog Peek-A-Shoe Manual de usuario

Manuales populares de Juguete de otras marcas

marklin

marklin 37321 Manual de usuario

Canon

Canon PAPER CRAFT Manual de usuario

GREAT PLANES

GREAT PLANES Pitts M-12S Manual de usuario

NOCH

NOCH 14261 Manual de usuario

Hausler

Hausler 450 SE V2 Manual de usuario

Dynaflite

Dynaflite Daydream Manual de usuario

MiniacRC

MiniacRC MIGHTY MINI P40 WARHAWK Manual

Kenner

Kenner Batman 63651 Manual de usuario

LEGO

LEGO 8527 Manual de usuario

iKarus

iKarus ECO 8 Manual de usuario

Multiplex

Multiplex EasyStar II Manual de instrucciones

Walkera

Walkera 38 Manual de instrucciones

Hasbro

Hasbro TRANSFORMERS BUMBLEBEE Manual de usuario

MD MXION SWD Manual de usuario

Mattel

Mattel Disney Pixar Cars Cozy Cone Spiral Rampway Manual de usuario

marklin

marklin 39671 Manual de usuario

Meccano

Meccano 15103 Manual de usuario

LEGO

LEGO TECHNIC 8735 Manual de usuario

LeapFrog leapland Adventures Instrucciones de montaje

Manuales populares de Juguete de otras marcas
