OPERATING AND INSTALLATION MANUAL

CONVERTER

HML 210

Release number: 210_EN_LC_R9_3.91.0XXX.docx – The characters of file name in bolt

type indicate the software version which the manual refers to; it is visualized at the instrument

start up, or by specific function on DIAGNOSTIC menu.

HML 210

Introduction_________________________________________________4

Safety informations ___________________________________________4

Safety conventions___________________________________________________5

Technical characteristics _______________________________________6

Electric characteristics ________________________________________________6

Environmental use conditions __________________________________________6

Ambient temperature_________________________________________________6

Data plate__________________________________________________________6

Overall dimensions___________________________________________________7

Electrical connections _________________________________________8

Grounding instructions________________________________________________8

Converter power supply_______________________________________________8

Compact/separate version M1 terminal block ______________________________9

Panel version M1 terminal block ________________________________________9

Converter to sensor electrical connections _______________________________10

Optional modules____________________________________________11

Inputs/outputs _____________________________________________13

Digital input _______________________________________________________13

Input operation stage (generic functions)___________________________ 14

Operation stage on input 1 or 2 (batch function) __________________________ 15

Operation stage on input 1 and 2 (batch function)_________________________16

Output wirings _____________________________________________________17

Converter access ____________________________________________18

Flags and led interpretation___________________________________________18

Keyboard __________________________________________________19

Blind version_______________________________________________________19

Start-up visualization pages___________________________________________20

Flow rate visualization _______________________________________________21

Access codes ______________________________________________________22

Block dip-switch____________________________________________________22

Quick start menu _________________________________________________23

Access to the configuration menu ______________________________________24

Examples _________________________________________________________25

Programming functions _______________________________________27

Functions description________________________________________________30

Batch function confuguration___________________________________38

Alarm messages_____________________________________________40

Appendix: Display rotation procedure ____________________________41

INDEX

HML 210

converter

sensor

INTRODUCTION

These operating instructions and description of device functions are provided as part of the

scope of supply. They could be modified without prior notice. The improper use, possible

tampering of the instrument or parts of it and substitutions of any components not original,

renders the warranty automatically void.

The converter is to be used only to be coupled with a sensor to realize a measuring device,

flow meter, that is to be used for measuring the flow of conductive liquids in closed pipes with

conductivity greater than 5µS/cm.

The converter could be coupled directly on the sensor (compact version) or coupled to the

sensor by cable supplied with it (remote version).

The reproduction of this manual and any supplied software is strictly forbidden.

SAFETY INFORMATIONS

Any use other than described in this manual affects the protection provided by the

manufacturer and compromises the safety of people and the entire measuring system and is,

therefore, not permitted.

The manufacturer is not liable for damaged caused by improper or non-designated use.

1) Transport the measuring device to the measuring point in the original packaging. Do

not remove covers or caps until immediately before installation. In case of cartons

packaging it is possible to place one above the other but no more than three cartons.

In case of wooden packaging do not place one above the other.

2) Disposal of this product or parts of it must be carried out according to the local public

or private waste collection service regulations.

3) The converter must only be installed, connected and maintained by qualified and

authorized specialists (e.g. electrical technicians) in full compliance with the

instructions in these Operating Instructions, the applicable norms, legal regulations

and certificates (depending on the application).

4) The specialists must have read and understood these Operating Instructions and must

follow the instructions it contains. The Operating Instructions provide detailed

HML 210

information about the converter. If you are unclear on anything in these Operating

Instructions, you must call the service.

5) The converter should only be installed after have verified technical data provided in

these operating instructions and on the data plate.

6) Specialists must take care during installation and use personal protective equipment as

provided by any related security plan or risk assessment.

7) Never mount or wire the converter while it is connected to the power supply and avoid

any liquid contact with the instrument’s internal components. To connect remove the

terminals from the terminal block.

8) Before connecting the power supply check the functionality of the safety equipment.

9) Repairs may only be performed if a genuine spare parts kit is available and this repair

work is expressly permitted.

10) For the cleaning of the device use only a damp cloth, and for the maintenance/repairs

contact the service center.

Before starting up the equipment please verify the following:

Power supply voltage must correspond to that specified on the data plate

Electric connections must be completed as described

Ground (earth) connections must be completed as specified

Verify periodically (every 3-4 months):

The power supply cables integrity, wiring and other connected electrical parts

The converter housing integrity

The suitable tightness of the sealing elements

The front panel integrity (display and keyboard)

The mechanical fixing of the converter to the pipe or wall stand.

SAFETY CONVENTIONS

DANGER

Warning indicates an action or procedure which, if not performed correctly,

can result in injury or a safety hazard. Comply strictly with the instructions

and proceed with care.

WARNING

Caution indicates an action or procedure which, if not performed correctly, can

result in incorrect operation or destruction of the device. Comply strictly with

the instructions.

NOTES

Note indicates an action or procedure which, if not performed correctly, can

have an indirect effect on operation or trigger an unexpected response on the

part of the device.

HML 210

TECHNICAL CHARACTERISTICS

ELECTRIC CHARACTERISTICS

ENVIRONMENTAL USE CONDITIONS

Data plate

On the data plate there is the followings technical information:

•MODEL: Converter Model

•S/N: Serial Number of the converter

•PW.TYPE: Not used

•PW.SUPPLY: Power Supply

•MAX.POWER: Maximum power consumption

•Hz: Frequency (AC)

•T: Operating temperature

•IP: Protection grade

•COUPLING: Serial number of sensor coupled

•ITEM: free for user

Min. *

Max

°C

-20

60**

°F

-4

140**

The instrument can be installed inside or outside buildings

Altitude: from –200m to 5000m (from -656 to 16400 feet)

Humidity range: 0-100% (IP67/IP65), 0-90% without condensation (IP40) for panel

mounting version

If the converter is supplied in compact version to the sensor, consider the ambient

temperatures more restrictive, otherwise refer to the respective manuals.

*For discontinuous use, a thermostat heat source installation may be necessary.

** For panel mounting version the maximum operating temperature is +40°C (104°F)

Instrument classification: class I, IP67 for compact/separate version, IP40 for panel

version (IP65 with optional transparent frontal cover), installation category II, rated

pollution degree 2.

Power supply

versions

Power supply

voltage

Power supply

frequency

Pmax

100-240V~

44-66Hz 25VA

18-45V~

18-45V

// 20W

LLV

10-35V

Voltage variations must not exceed ±10% of the nominal one.

All instrument versions can be equipped with all power supply versions.

Input/output are insulated up to 500V

The output 4-20 mA (optional) and the output 24V are electrically connected.

AMBIENT TEMPERATURE

HML 210

144.0

145.0

67.0

137.0

IP65, TRASPARENT FRONTAL COVER

(OPTIONAL)

72.0

160.0

80.0

OVERALL DIMENSIONS

CABLE GLAND

IF2 CAP

COVER SCREW

138

170

138

146

138

170

146

230

138

SEPARATE VERSION

WEIGHT

Compact

Separate

INOX AISI 304

3kg

3.5kg

Alluminum

2.5kg

3kg

To guarantee the compact/separate

housing’s IP degree the following torques

are required:

cover screws: 1.5Nm

cable glands: 4Nm (in reference

conditions)

IF2 cap: 4Nm

TORQUES

COMPACT VERSION

PANEL VERSION

Weight: 0.5kg

HML 210

(+) N

(-)

(+) (-)

ELECTRICAL CONNECTIONS

GROUNDING INSTRUCTIONS

CONVERTER POWER SUPPLY

Compact/separate version

Panel version

ALWAYS ensure that the converter and the sensor are grounded (earthed) correctly. The

grounding of the sensor and converter ensures that the equipment and liquid are

equipotential.



Before connecting the power supply, verify that the mains voltage is within the limits

indicated on data plate.

For the connections use only approved conductors, with fire-proof properties, whose

section varies from 0.25mm2to 2.50mm2, based on distance/power; additionally fix

the power supply wires with a additional fastening system located close to the

terminal.

The power supply line must be equipped with an external protection for overload

current (fuse or automatic line breaker).

Provide in close proximity the converter a circuit breaker easily accessible for the

operator and clearly identified; whose symbols must conform to the electrical safety

and local electrical requirements.

Ensure that the component complies with the requirements of the standard for

electrical safety distance.

Check chemical compatibility of materials used in the connection security systems in

order to minimize electrochemical corrosion.

The sensor, hardwired inputs and outputs are connected to the converter through a

terminal blocks located inside the converter.

To locate the compact/separate version terminal block loosen the 4 screws on the

back cover. When the front cover is lifted, the terminal block is visible. The terminal

block is the hardwire connection of the converter to external equipment, including

the sensor.

The following pages give informations on the terminal block numbering, and the

respective connecting of the sensor cables, and inputs/outputs.

HML 210

20 19 18 17 16 15 14 13 12 11

10 9 8 7 6 5 4 3 2 1

32 31 30 29 28 27

26 25 24 23 22 21

12345678910

11 12 13 14 15 16 17 18 19 20

LOCK

COMPACT/SEPARATE VERSION M1 TERMINAL BLOCK

Dangerous voltage on block 12-13:

- 60V Max

- 250V Max on commutation coils

Dip switch, when the switch is ON, there is NO

more access to the programming functions

Signalling LED: see display flags and led warning

interpretation section

IF2 socket shall be used only by authorized

persons (risck of electrical shock)

Power supply

PANEL VERSION M1 TERMINAL BLOCK

Power supply

Dangerous voltage on block positions 12-13:

- 60V Max

- 250V Max on commutation coils

IF2 socket shall be used only by authorized

persons (risck of electrical shock)

Dip switch, when the switch is ON, there is NO

more access to the programming functions

HML 210

CONVERTER TO SENSOR ELECTRICAL CONNECTIONS

1 (E1)

10 (preamp.)

9 (preamp.)

8 (preamp.)

7 (preamp.)

6 (preamp.)

2 (E2)

3 (C)

4 (SH)

11 (SH)

12 (B1)

13 (B2)

12345678910

11 12 13 14 15 16 17 18 19 20

E1 E2 CSH +-BA+-

ELECTRODES INPUT RS485 4-20mA

SH OUT2

OUT1

24VCOILS 24V

ALL SENSORS

WITH PREAMPLIFER

Max cable length: 500m

SENSOR WITH PREAMPLIFIER

Sudden movements of the electrodes

cable, can cause noise on measure.

Max cables length: 20m.

SEPARATE VERSION

TERMINAL BLOCK M1

Tabla de contenidos

Manuales populares de Convertidor de medios de otras marcas

SoundTraxx

SoundTraxx Blunami BLU-2200 Manual de usuario

SPROLINK

SPROLINK VA1 Manual de usuario

Acclaim Lighting

Acclaim Lighting DDC-1-AC Manual de usuario

Nikon

Nikon AF-S TC-20E III Manual de usuario

Axis

Axis AXIS Q7406 Manual de usuario

Omega

Omega TAC80B-J Manual de usuario

Zoom

Zoom Thunderbolt TAC-2R Manual de usuario

OST

OST iConverter 10/100M Manual de usuario

Vertiv

Vertiv Netsure Manual de usuario

birddog

birddog MINI Manual de usuario

Roland

Roland GI-10 Manual de usuario

Wallenstein

Wallenstein WX310 Manual de usuario

Pace

Pace MSS 200-1 Manual de usuario

Solar Converters

Solar Converters EQ 12/24-50 Manual de usuario

CYP

CYP EL-7400V Manual de usuario

TIE

TIE MIDI 1i1o Manual de usuario

DCS

DCS Vivaldi Upsampler Manual de usuario

Westermo

Westermo MCW-211 SERIES Manual de usuario
