Lbx WB-S Manual de usuario

WB-S Multifunctional Water Bath Shaker

Please read the User Manual carefully before use, and follow all operating and safety instructions!

user manual

english, español

User manual

WB-S Multifunctional Water Bath Shaker

Preface

Thank you for purchasing our Water Bath. Users should read this manual carefully, follow the instructions and

procedures, and beware of all the preventive measures when using this instrument.

Service

If help is needed, you can always contact your dealer or Labbox via www.labbox.com

Please, provide the customer service representative with the following information:

▪Serial number (on the back side)

▪Description of the problem

▪Your contact information

Warranty

This instrument is guaranteed to be free from defects in materials and workmanship under normal use and

service, for a period of 12 months from the date of invoice. The warranty is extended only to the original

purchaser. It shall not apply to any product or parts that have been damaged due to improper installation,

improper connections, misuse, accident or abnormal conditions of operation.

For claim under the warranty, please contact your supplier.

1. Safety Instructions

Connect the device to an earthed socket to ensure the safety of the machine

and the experiment. Make sure the voltage is the same as required by the

device.

The use of this instrument in flammable, explosive, poisonous, or highly

corrosive environments or with hazardous substances is forbidden.

Place the incubator on a horizontal, flat, clean, non-slip and stable surface.

Adjust the feet so that the device is leveled.

This item must only be used by qualified staff that has read the instructions

manual and knows how to operate it.

Do not place the device near any heat source. Keep away from high

magnetic fields. Do not put volatile, flammable and explosive materials in

the machine, otherwise it could cause an explosion or a fire.

Non-professionals must not disassemble or repair this machine.

Read the instructions manual before using this device.

·When working, wear the necessary personal protective equipment to avoid the risk of:

-Burns caused by contact with hot surfaces or materials

-Burns caused by splashing and evaporation of liquids

-Intoxication caused by release of toxic or flammable gases

·The device and accessories must be checked prior to every use. Do not use damaged

components.

·Beware of hazards due to:

-Flammable materials or media with a low boiling temperature

-Overfilling of vessels

-Unsafe vessel

·Do not cover the device.

·Do not expose the device to rain, moisture or splashing as this might result in electrical leakage,

short-circuit or electric shock.

·In case the device is let idle or unsupervised, ensure the door is completely closed.

·Unplug by pulling always from the plug. Never pull from the wire.

·Do not connect the power cord to the middle section.

·Ensure that the main cable does not touch the surface.

·Do not damage the power cord and always use the specified one. In case of damage, the

power cord must be replaced.

·Do not unplug the power cord during operation.

·Unplug the cord before maintenance, after use, and if the instrument is running abnormally.

·Do not touch the power plug with wet hands.

·Wear gloves when repairing and maintaining the instrument.

Other necessary considerations:

·When touching the inner wall of the door, do it carefully, as it may be hot.

·The internal parameters must be set by the specific management person to prevent the function

of the controller program from being disturbed by an unknown setting.

·The equipment must be placed at least 20cm away from the wall and from any objects.

·Open and close the door gently to prevent damage to the equipment.

·Do not expose the equipment surface to volatile chemicals.

·Keep the equipment clean, both the inside and the outside.

Safety alarms:

·In case of a controller block, Holzer error, busbar under voltage, busbar over voltage or

communication failure, the speed bar will show the fault code and the controller will

automatically stop.

·In case of a temperature or speed alarm, the identifier ALM1 will light up and the buzzer

sound will go off. Stop it by pressing any key.

·When turning off the equipment, always press to stop any ongoing functions before

turning off the device.

·In case of a fault of the temperature sensor or the controller itself, the indicator –will display.

Carefully check the temperature sensor and its wiring.

2. Description

2.1. Technical specifications

Mode

Reciprocating oscillation +

thermostatic water bath

Function

Operating Temp Range

RT～100℃

Temperature Resolution Ratio

0.1℃

Temperature Motion

±0.1℃

Temperature Uniformity

±0.2℃

Reciprocal Oscillation Amplitude

16 or 24mm (Ex-factory is 24mm)

Reciprocating Frequency Range

20～200（r/min）

Reciprocating Frequency Accuracy

±1rpm

Structure

Water Tank

Mirror stainless steel

Outer Shell

Cold rolling steel electrostatic

spraying exterior

Upper Cover

Mirror stainless steel

Insulating Layer

Polyurethane

Heater

Stainless Steel Heater

Driving Mode

Crankshaft+ double link + four wheels

Shelf

Mirror stainless steel

Power rating

1.5kW

Controller

Temperature Control Mode

LCD PID Intelligent control

Reciprocating Control Mode

Setting Mode

Touch button setting

Temp. Display Mode

LCD Display

Speed Display Mode

Timer

0～9999 min

Operation Function

·fixed value operation

·timing function

·auto stop

·quick stop-start

Temperature Sensor

Pt100

Speed Sensor

Hoare

Additional Functions

·deviation correction

·menu keys lock

·power-off memory

Device safety

·over-temperature alarm

·menu lock

·full water tank or water shortage protection

·motor shaft lock protection

Specificatio

Water Tank Size (W*L*H) (mm)

500*310*200

Exterior Size (W*L*H) (mm)

828*360*425

Packing Size (W*L*H) (mm)

908*440*505

Spring Shock Basket Size (mm)

395*250

Shock Basket Largest Single Size

(ml /piece)

100ml*12/250*8/500*6

Inside Volume

31L

Shock Basket Bearing

5kg/layer

Current Rating （50Hz）

AC220V/6.8A

NW/GW (kg）

20/30

Accessories

·water bath flask seat

·tube rack

2.2. Control Keys

-Press to increase the parameter value by one.

Keep pressed to continuously increase the

value.

-Press to reduce the parameter value by one.

Keep pressed to continuously reduce the value.

-Press to navigate through the parameters.

-Press to enter time value setting mode. Press

again to return to home screen.

-Press to enter temperature value setting mode.

Press again to return to home screen.

-Press to enter speed value setting mode. Press

again to return to home screen.

-Press to start running the device functions. Press

again to stop.

3. Temperature internal parameter settings mode

3.1. How to use

In order to enter the temperature internal parameter setting mode, the user must introduce the

password. To do that, follow these steps:

1. Press for 3 seconds.

-The screen will display Lc

-The speed area of the screen will display the password value

2. Use to choose the required password value. See password values below.

3. Press to enter the value.

If the password is incorrect, the display will return to the home screen.

If the password is correct, the display will show the temperature internal parameter settings mode.

Then:

1. Press to modify each parameter.

2. Use to choose desired value.

3. Press for 3 seconds to return to the home screen.

If no key is pressed for 1 minute, the display will return to the home screen.

3.2. Internal parameters tables

INDICATOR

NAME

FUNCTION DESCRIPTION

(RANGE)

DEFAULT VALUE

Password

The password to modify the parameters in this

table is Lc = 3

ALH

Upper deviation

over temperature

alarm

THEN

·the alarm light is turned on

·the buzzer calls

·the heating output is disconnected.

(0～20.0℃)

5.0

Control cycle

Heating control cycle.

(1～60s) 5

Proportional

band

Time proportional adjustment.

(0.1～50.0)

15.0

Integration time

The integral function is adjusted.

(1～2000s) 380

Differential time

Differential action regulation.

(0～2000s) 100

Floodlight

time

Time the floodlight stays ON every time.

When Lt=0, the delay is invalid and the lights

need to be turned off manually.

(0～9999min)

temperature

measurement

temperature

set value

St-

Sterilization lamp

off-delay

Time the sterilization lamp stays ON every time.

When St=0, the delay is invalid and the lights

need to be turned off manually.

(0～9999min)

Temperature

correction

Correction of errors caused by sensor low

temperature measurement.

(-99.9～99.9℃)

Slope correction

Correction of errors caused by sensor high

temperature values.

(-999～999) 0

INDICATOR

NAME

FUNCTION DESCRIPTION

FACTORY VALUE

Password

The password to modify the parameters in this

table is Lc = 9

Pon

Power down

memory function

0: OFF –if the power goes off, the controller

will stop working.

1: ON –if the power goes off, when the device

is turned on again it will continue running the

functions it was running when the power went

off.

(0～1)

ruT

RUN/STOP

key delay

Time after which the function of the RUN/STOP

button will be effective

(0～10s)

Maximum power

output

The maximum power percentage of the heating

output.

(0～100%)

100

Turn off the

heating output

deviation

THEN the heating output is turned OFF.

(0.0～20.0℃)

5.0

SPH

Upper

temperature limit

Upper limit of temperature set point

(0.0～200.0℃)

100.0

Adr

mailing address

The local communication address.

(1～32)

INDICATOR

NAME

FUNCTION DESCRIPTION

FACTORY VALUE

Password

The password to modify the parameters in this

table is Lc = 576

rST

Factory reset

0: Do not restore the factory value

1: Restore the factory value. Including:

·internal parameters table 1, 2 and 6

·parameters Fr, DB and dF from

internal parameters table 5

(0～1)

actual

temperature

value

temperature

measured

value

1000

actual temperature

value

temperature

measured value

temperature measured value

temperature

measurement

temperature

set value

≥

4. Speed internal parameter settings

4.1. How to use

In order to enter the temperature internal parameter setting mode, the user must introduce the

password. To do that, follow these steps:

4. Press for 3 seconds.

-The screen will display Lc

-The speed area of the screen will display the password value

5. Use to choose the required password value. See password values below.

6. Press to enter the value.

If the password is incorrect, the display will return to the home screen.

If the password is correct, the display will show the temperature internal parameter settings mode.

Then:

4. Press to modify each parameter.

5. Use to choose desired value.

6. Press for 3 seconds to return to the home screen.

If no key is pressed for 1 minute, the display will return to the home screen.

4.2. Internal parameter tables

INDICATOR

NAME

FUNCTION DESCRIPTION

FACTORY VALUE

Password

The password to modify the parameters in this

table is Lc = 3

Proportional

gain

Speed proportional gain.

(1～100)

Integral

coefficient

Speed integral coefficient.

(1～100)

InT

Acceleration

time

Time it takes for the motor to accelerate to the

new set speed.

(1～60)

dET

Deceleration

time

Time it takes for the motor to decelerate to the

new set speed.

(1～60)

SdL

Speed lower

limit

Minimum speed setting

(20～500)

SdH

Speed upper

limit

Maximum speed setting

(20～500)

300

INDICATOR

NAME

FUNCTION DESCRIPTION

FACTORY VALUE

Password

The password to modify the parameters in this

table is Lc = 9

EAr

Gear ratio

(1.0～10.0)

1.0

PoL

Pole logarithm

of motor

The DC brushless motor is extremely

logarithmic.

(1～32)

dIF

Motor rotation

reference

direction

0: clockwise rotation is the positive direction

1: counterclockwise rotation is the positive

direction

(0～1)

FdS

Speed

feedback

value

Speed feedback system value

(0.1～10.0)

1.0

FdC

Current

feedback

value

Current feedback system value

(0.1～10.0)

1.0

FrE

Carrier

frequency

Brushless motor carrier frequency

Note: when this parameter is changed, the

controller needs to be restarted.

(5～15)

Motor power

Brushless motor power.

Note: this parameter must be adjusted

according to the actual power of the motor.

(1～100)

Overflow

multiple

Allowable current multiplier for overcurrent

protection of the motor.

(1.0～10.0)

5.0

Rotation

direction

selection of

motor

0: The motor only runs in forward rotation.

1: The motor only runs in reverse.

2: The motor can run in both directions.

(0～2)

Insensitive

display

area

Speed display insensitive area

(0～100)

False display

Reservation is invalid

big gear diameter

pinion diameter

EAr

Tabla de contenidos

Idiomas:

Otros manuales de Equipo de laboratorio de lbx

lbx

lbx MCEN-15K-001 Manual de usuario

lbx

lbx H03D Manual de usuario

lbx

lbx H20D Series Manual de usuario

lbx

lbx MC7000 Manual de usuario

lbx

lbx S850 Manual de usuario

lbx

lbx CODB150 Manual de usuario

lbx

lbx EVA 180-B Series Manual de usuario

lbx

lbx WB01 Series Manual de usuario

lbx

lbx H20SQC Manual de usuario

lbx

lbx V05 Manual de usuario

lbx

lbx HDB120 Series Manual de usuario

Manuales populares de Equipo de laboratorio de otras marcas

Qiagen

Qiagen DML 3000 Manual de usuario

Queensgate

Queensgate NANOSCAN OP400 Manual de programación

Conviron

Conviron GEN1000-GE Manual de usuario

Parr Instrument

Parr Instrument 4560 Manual de instrucciones

IKA

IKA IC control Manual de usuario

Integra

Integra DOSE IT Manual de usuario

Agilent Technologies

Agilent Technologies 5800 ICP-OES Manual de usuario

Endress+Hauser

Endress+Hauser Cleanfit CPA875 Manual de usuario

NI PXI-5422 Manual

Collomix

Collomix Aqix Manual de usuario

SPEX SamplePrep

SPEX SamplePrep 6875 Freezer/Mill Series Manual de usuario

Ocean Insight

Ocean Insight FLAME-NIR+ Manual de usuario

Parker

Parker ALIGN-MG-NA Manual de usuario

BD 644787 Manual de usuario

DENTAURUM

DENTAURUM Compact Megaplus Manual de usuario

Biuged Laboratory Instruments

Biuged Laboratory Instruments BGD 626 Manual de usuario

VWR

VWR SAS Super IAQ Manual de usuario

illumina

illumina MiSeqDx Manual de usuario

lbx WB-S Manual de usuario

Manuales populares de Equipo de laboratorio de otras marcas
