Laser SPK-S20 Manual de usuario
WARNING:
Do not expose speakers to direct sunlight for
extended periods.
Do not use speakers in extremely hot, dusty,
humid or damp conditions.
Do not attempt to disassemble these speakers.
There are no user serviceable parts inside.
Opening these speakers may void your warranty.
For technical support please visit
http://www.laserco.com.au
SPECIFICATION
Total Output Power: RMS 1W
> RMS 0.5W Per Channel
> 2” Full Range Speaker Driver
> Frequency Response: 150Hz~18KHz
> Magnetically Shielded
> Power Indicator
> Dimension: 60(W) x 85(D) x 133(H)mm
OPERATING METHOD
USB connecting cable
LED
NOTE:
The power LED will light when connected to an active USB port.
The LED will flicker when the speakers are recieving an audio signal.
TROUBLE SHOOTING:
Device not recognised:
Confirm that the operating system has native drivers for USB Audio
devices.
Audio will stop at full volume:
Ensure that the USB port used to connect the speakers is not
overloaded. Move connection to other ports or connect using a
powered USB hub.
OPERATING METHOD
NOTE:
In some cases Win98SE or ME can
not detect USB audio devices
and switch to them.
If the operating system does not
detect the USB speakers,
please open the “Control Panel”,
select “Sound and Audio Devices”.
Choose the “Audio” page and then
change the “Default Device” to
“USB Device” or “C-Media USB
Device”
1: Plug the USB cable in a spare USB socket on your computer.
2: In the first instance the operating system should detect the
speaker and automatically load the correct drivers.
3: Adjust the volume to the desired level.
SYSTEM CONNECTION
CONNECTING METHOD
User Manual
SPK-S20
Please read carefully before use
