Lanix Ilium W250 Manual de usuario
1
Ilium W250
User Manual
2
Content
Get Started .......................................................................3
Insert SIM card ...........................................................3
Insert Memory card ....................................................3
Charge the Battery or Connect to a Computer ...............4
Keys and Parts...................................................................5
Lock and Unlock the Screen...............................................6
Make it yours ....................................................................7
Add more icons to Home Screen........................................8
Adding icons to home screen .......................................8
Rearranging or removing icons on your Home screen.....8
Enter Application screen....................................................9
Open and Switch Applications......................................9
Switch to Recently Used Application...........................10
Make a Call ..................................................................... 11
Call Log ........................................................................... 12
Reject a Call by Sending a Busy Message.......................... 13
Add a Contact ................................................................. 14
Send and Receive Message(s) .......................................... 15
Browse the Web.............................................................. 18
Download Applications From Store.................................. 20
Maintenance & Safety..................................................... 21
bluetooth........................................................................ 22
3
Get Started
Insert SIM card
To insert SIM card:
1. Switch off the mobile phone and remove the rear cover and
battery.
2. Insert the SIM card correctly in the card slot (See figure below)
3. Finally insert the battery and replace the rear cover of the mobile
phone.
Insert Memory card
1. Power off the mobile phone and remove the rear cover and
battery.
2. Insert the Micro SD card into the slot.
3. Finally insert the battery and the rear cover of the mobile phone.
Note: After user inserts the Micro SD card into the slot, you must
reboot the mobile phone; otherwise the mobile phone will not
SIM Card
4
identify the Micro SD card.
Use only compatible memory cards for use with this device.
Incompatible memory cards may damage the card or the device and
corrupt the data stored in the card.
Charge the Battery or Connect to a Computer
You can charge your battery using the charger or connect the USB
cable (supplied with this phone) to the computer.
Note: Please use the specific battery, otherwise it may cause
explosion.
Micro SD card
5
Keys and Parts
The smart phone supports 3G Card and gives you marvelous feelings
to experience on Camera, Video recorder, FM radio, Music and Sound
recorder. Let you install various APPs, games, and more (supports APK
format) by downloading from Store.
Front camera
Headset port
USB jack
Back
Windows key
Search
Volume
Up/down
Camera Lens
Speaker
LCD
Receiver
Power
6
Lock and Unlock the Screen
Press power button to enter Sleep mode and meanwhile the screen
will be locked; press power button again to wake up and then from
down to up sliding screen.
7
Make it yours
1) Home screen: It is your starting point to access all the features on
your phone. It displays application icons.
2) Notification Bar: At the top of the screen, the Status bar displays
the time, status, and notifications. If there is a new message, missed
call or something in the notification bar, you can drag it down to open
notification panel and click the desired one to have a view. When you
finished, you can close it by dragging the panel up or pressing “Back”.
3) Application screen: Slide left the main screen, enter the application
interface, shows all of the application.
Notification Bar
Home screen
Application screen
8
Add more icons to Home Screen
Adding icons to home screen
Enter Application interface and long press and hold an application till
appear the options menu, and then select pin to start, application
will appear in the main screen at the bottom.
Rearranging or removing icons on your Home screen
a). Long press and hold the icon you want to move. Until the icon
bigger. Drag the icon to a new location on the screen. b）. Press and
hold on an icon till the icon bigger, then click on the upper right
corner of the icon, the application will removed.
9
Enter Application screen
Open and Switch Applications
The Launcher holds icons for all of the applications on your phone,
including any application that you downloaded from Store or other
sources. On the Home screen, scroll left the home screen, enter the
application interface.
Press Windows icon or Back icon to close the Application screen.
Touch an application to
open it.
Slide the screen up or
down to bring more icons
into view.
10
Switch to Recently Used Application
Press and hold the Back icon for a few seconds.
Touch to open the
application
