La Crosse BBB86088 Manual de usuario
Model: BBB86088
Instruction Manual
DC: 103017
Atomic Digital Wall Clock with
Indoor/Outdoor Temperature
Table of Contents
Page | 1 www.lacrossetechnology.com/support BBB86088
Let’s Get Started
Basic Settings
Fahrenheit | Celsius
LCD Features
Daylight Saving Time Indicator
Atomic Time - WWVB Signal
Time Alarm
Activate | Deactivate Alarm
Snooze
Sensor Reception and Search
Temperature Trend Arrows
Position TX141-Bv2 Sensor
Low Battery
Let’s Get Social
Care and Maintenance
Warranty and Support
Specifications
FCC Statement
2
3
4
5
5
6
6
7
7
7
8
8
8
9
9
9
10
11
Welcome to the La Crosse Technology® family!
We hope you enjoy your new Atomic Clock.
Lets Get Started
BBB86088 www.lacrossetechnology.com/support Page | 2
AA
AA
AA
AA
1. Insert 2 AA batteries into
your sensor.
∙The red LED light will flash
when your sensor transmits.
∙The TX button lets you
manually transmit a signal.
LED
TX Button
2. Insert 2 AA batteries into
your clock.
3. Configure basic settings.
4. After 5 minutes, place
your sensor outside in a
shaded location.
Wall Hang
Pullout Stand
∙ Mount your clock on the wall with the 3 holes on the back, or
use the pullout stand to place your clock on a desk or
counter.
Time Zones
Zone AST - Atlantic
Zone EST - Eastern
Zone CST - Central
Zone MST - Mountain
Zone PST - Pacific
Zone AKT - Alaska
Zone HAT - Hawaii
Page | 3 www.lacrossetechnology.com/support BBB86088
Basic Settings
1. Hold the °F/°C button 3 seconds to enter settings mode.
2. Press the + or - button to adjust the flashing values, hold to
adjust quickly.
3. Press the °F/°C button to confirm adjustments and move to
the next item.
4. Press the SNOOZE button at any time to exit.
Settings menu order:
• Language (English, Español, Francais)
• Beep ON/OFF
• Atomic ON/OFF
• DST ON/OFF
• Time Zone
• 12/24 Hour Format
• Hour
• Minutes
• Year
• Month
• Date
Note: When Español or Francais
are selected, the settings
menu will continue in the
language selected.
LCD Features
AM | PM
Alarm Bell
DST Indicator
Atomic Time
Sensor Reception
Low Battery
Fahrenheit | Celsius
Temperature Trend
Daylight Saving Time (DST) Indicator
The letters DST will show when your clock has received the
atomic time signal and Daylight Saving Time is being
observed.
Page | 5 www.lacrossetechnology.com/support BBB86088
Atomic Time -WWVB Signal
• Your clock will search for the atomic signal at UTC 7:00, 8:00,
9:00, 10:00, and 11:00.
• If there is no WWVB signal reception, your clock will search
every 2 hours until the WWVB time is received.
• The atomic time signal icon (tower) will flash while searching,
and be solid when connected.
• Hold the MINUS button for 3 seconds to manually search for
the WWVB atomic time signal.
• For information about WWVB visit: http://bit.ly/AtomicTime
Time Alarm
1. Hold the ALARM button 3 seconds to enter alarm mode.
2. Press the + or - button to adjust the flashing values, hold to
adjust quickly.
3. Press the ALARM button to confirm adjustments and move
to the next item.
4. Press the SNOOZE button at any time to exit.
AM
BBB86088 www.lacrossetechnology.com/support Page | 6
• The alarm is active when set. From normal time display,
press and release the ALARM button to deactivate or
activate the alarm.
• Alarm icon (bell) will show then active.
Activate | Deactivate Alarm
• When your alarm sounds, press the SNOOZE button to
silence alarm for 10 minutes. The alarm bell will flash.
• Press any button except SNOOZE to silence the alarm
for 24 hours.
Snooze
Sensor Reception & Search
• If the signal is lost, your clock will display the LAST DATA
recorded from the sensor for 10 minutes.
• After that 10 minutes if the signal does not come back
dashes will show for outdoor temperature.
• After 30 minutes, your clock will automatically search
for the sensor.
• Hold the PLUS button for 3 seconds to manually search for
your outdoor sensor.
• The sensor reception icon will flash while searching.
• The icon will be solid when the sensor is connected.
Page | 7 www.lacrossetechnology.com/support BBB86088
Position TX141-Bv2 Sensor
• Mount your sensor with the hole at the top:
Either hang it from the back using a nail, or
insert one mounting screw through the front.
• Mount your sensor on a north-facing wall or
in any shaded area. Under an eave or deck
rail is preferred.
• The maximum wireless transmission range
to your clock is over 330 feet (100 meters)
in open air, not including walls or floors.
• Be sure the sensor is mounted vertically, to
allow moisture to drain out properly.
• Watch sensor mounting video:
http://bit.ly/TH_SensorMounting
• The trend arrows indicate changes in your
temperature (2°F, 1°C) over the past hour.
• They update every 15 minutes and compare
data from exactly one hour prior.
Temperature Trend Arrows
Low Battery
• When the low battery icon appears by the time, replace
the batteries in your clock.
• When the low battery icon appears by the outdoor
temperature, replace the batteries in your sensor.
BBB86088 www.lacrossetechnology.com/support Page | 8
Page | 9 www.lacrossetechnology.com/support BBB86088
Let’s Get Social
JOIN THE CONVERSATION
Ask questions, watch detailed setup videos, and provide
feedback on our social media channels!
• Do not mix old and new batteries
• Do not mix Alkaline, Standard, Lithium or Rechargeable Batteries
• Always purchase the correct size and grade of battery most suitable
for intended use.
• Replace all batteries of a set at the same time.
• Clean the battery contacts and also those of the device prior to
battery installation.
• Ensure the batteries are installed with correct polarity ( + and - ).
• Remove batteries from equipment when it is not to be used for an
extended period of time.
• Promptly remove expired batteries.
Care and Maintenance
La Crosse Technology, Ltd. provides a 1-year limited time warranty
(from date of purchase) on this product relating to manufacturing
defects in materials & workmanship.
Before returning a product, please contact our friendly customer
support or visit our online help:
Phone: 1-608-782-1610
Online: www.lacrossetechnology.com/support
Warranty and Support
