WS-6002U

Atomic Clock

Instruction Manual

              

TABLE OF CONTENTS

Topic Page

Inventory of Contents/ Additional Equipment 3

About WWVB 3

Quick Set-Up Guide 4

Detailed Set-Up Guide

Battery Installation 5

Program Mode

Function Buttons 6

Time Zone Setting 7

DST (Daylight Saving Time) Setting 7-8

Language Selection 8

Time Setting 8

Calendar Setting 9

12/24-Hour Setting 9

Selecting °F or °C 10

Features & Operations

Displaying the Seconds 10

Indoor Temperature 10

Mounting 11-12

Maintenance & Care 12

Troubleshooting 12-13

Specifications 13

Warranty Information 14-15

INVENTORY OF CONTENTS

1) WS-6002U

2) Instruction manual and warranty card.

ADDITIONAL EQUIPMENT (not included)

1) Two fresh 1.5V AA batteries.

2) Three wall-hanging screws.

3) Appropriate screwdriver for screws.

ABOUT WWVB (Radio Controlled Time)

The NIST (National Institute of Standards and Technology—Time

and Frequency Division) WWVB radio station is located in Ft.

Collins, Colorado, and transmits the exact time signal continuously

throughout the United States at 60 kHz. The signal can be

received up to 2, 000 miles away through the internal antenna in

the Atomic Clock. However, due to the nature of the Earth’s

Ionosphere, reception is very limited during daylight hours. The

Atomic Clock will search for a signal every night when reception

is best. The WWVB radio station derives its signal from the NIST

Atomic clock in Boulder, Colorado. A team of atomic physicists is

continually measuring every second, of every day, to an accuracy

of ten billionths of a second per day. These physicists have created

an international standard, measuring a second as 9,192,631,770

vibrations of a Cesium-133 atom in a vacuum. This Atomic Clock

regulates the WWVB transmitter.

QUICK SET-UP GUIDE

1) Insert two AA batteries into the Atomic Clock.

2) Wait 15 minutes for WWVB reception.

3) If there is no WWVB reception, manually set the time and date

(instructions in the Program Mode).

4) Program the settings.

5) Mount the WS-6002U in a suitable location, where WWVB

signals can be received.

DETAILED SET-UP GUIDE

SET

I) BATTERY INSTALLATION

Note: To avoid start-up problems make sure that the batteries

do not spring free.

Battery Compartment

Battery Cover

A) ATOMIC CLOCK

1) Remove the battery cover, located on the backside of the

function buttons.

2) Observe the correct polarity, and install 2 AA batteries.

3) Replace the battery cover.

Note: After the batteries have been installed all the LCD’s

(Liquid Crystal Display) will briefly light up. Then the indoor

temperature, the date as “1/ 1” and the weekday as “MON”

will be displayed. Also, the time will appear as “-:--” for

approximately 1 minute. Then the WWVB search is

automatically initiated, and a tower icon appears and flashes

with the time colon (no tower icon will appear if the WWVB is

too weak to be detected). While the WWVB search is being

conducted various numbers will appear in the time display.

The numbers “0”, “1”, or “8” will appear in the hour position

and the seconds will appear in the minute display. The Atomic

Clock will either display the WWVB time, or discontinue the

search after 10 minutes if the time is not found. When the

search is cancelled “-:--”will appear in the time LCD. The

Atomic Clock will conduct a WWVB search every hour until the

first signal is found. Once the WWVB time is found, a search is

automatically conducted nightly at midnight. If the signal is

found at midnight, the tower icon will remain, if not, another

search will take place every hour (up to 6:00 am) until the

signal is found successfully. If no signal is found during this

period, the tower icon will not appear and the clock will search

again at 12:00 am the next night.

WWVB Tower Icon

Indoor

Temperature

Weekday

Month/Date

PROGRAM MODE

To enter the Program Mode hold down the “SET” button for 2

seconds, until “-5EST” flashes in the Date LCD. The Program

Mode is laid out in a manner that allows you to program each

function separately, or you can follow the instructions entirely to

program the Atomic Clock. Complete programming is usually

done for the initial set-up, and will require you to skip step 1 of

programming sections III through VIII. Wait approximately 15

seconds for the Atomic Clock to automatically return to normal

operation.

I) FUNCTION BUTTONS

There are 2 function buttons located on the backside of the

Atomic Clock. The function buttons are labeled: SET and +.

II) TIME ZONE SETTING

1) Hold down the “SET” button for 2 seconds, the default setting

“-5EST” will flash in the Date LCD.

2) Press and release the “+” button to select the appropriate time

zone. There are 13 time zones to choose from:

-5EST Eastern Time (default setting)

-6CST Central Time

-7MST Mountain Time

-8PST Pacific Time

-9ALA Alaskan Time

-10HAW Hawaiian Time

-11

-12

GMT Greenwich Mean Time

-1

-2

-3

-4ATL Atlantic Time

3) Press and release the “SET” button to confirm the time zone

setting, and to advance to DST (Daylight saving time) setting.

III) DST (DAYLIGHT SAVING TIME) SETTING

Note: The DST default is “On”, meaning that the WWVB will

automatically change the time according to Daylight Saving

Time in the spring and fall. For areas that do not recognize

DST changes (Arizona and parts of Indiana) turn the DST

“OFF”.

1) Hold down the “SET” button for 2 seconds (the selected time

zone will flash), press the “SET” button once more until “On”

flashes in the time LCD and “DST” flashes where the Weekday

normally appears.

2) Press and release the “+” button to turn the DST off, as will be

indicated by the display of “OFF” in the time LCD.

3) Press and release the “SET” button to confirm the DST setting,

and to advance to select the language for the weekday.

IV)LANGUAGE SELECTION FOR THE WEEKDAY

1) Hold down the “SET” button for 2 seconds (the selected time

zone will flash), press the “SET” button 2 more times, until the

default language “US” flashes in the time LCD.

2) Press and release the “+” button to toggle through and to select

the desired language. There are 3 languages to select from:

US English

F French

E Spanish

3) Press and release the “SET” button to confirm the language

setting, and to advance to manually set the time.

V) TIME SETTING

Note: When the WWVB signal is found, that time will over-ride

the manually set time.

1) Hold down the “SET” button for 2 seconds (the selected time

zone will flash), press the “SET” button 3 more times, until the

hour “12:00” flashes in the time LCD.

2) Press and release the “+” button to select the hour.

Note: when setting the hour, “PM” will appear to the left of

the hour display, if it is AM nothing will be displayed.

3) Press and release the “SET” button to confirm the hour setting,

and to shift to select the minutes.

4) Press and release the “+” button to select the minutes.

5) Press and release the “SET” button to confirm the time setting,

and to advance to manually set the calendar.

VI)CALENDAR SETTING

Note: When the WWVB signal is found, that date will over-ride

the manually set date.

1) Hold down the “SET” button for 2 seconds (the selected time

zone will flash), press the “SET” button 5 more times, until the

default year “00” flashes in the date LCD.

2) Press and release the “+” button to select the year.

3) Press and release the “SET” button to confirm the year, and to

set the month.

4) The default month “1” will flash. Press and release the “+”

button to select the appropriate month.

5) Press and release the “SET” button to confirm the month, and

to set the date.

6) The default date “1” will flash. Press and release the “+”

button to select the appropriate date.

7) Press and release the “SET” button to confirm the date, and to

set the weekday.

8) The default weekday “MON” (depends on selected language)

will flash. Press and release the “+” button to select the

appropriate weekday.

9) Press and release the “SET” button to confirm the calendar

settings, and to advance to select either 12 or 24-hour time

display.

VII) 12/24-HOUR SETTING

1) Hold down the “SET” button for 2 seconds (the selected time

zone will flash), press the “SET” button 9 more times, until the

“12” hour time display flashes in the time LCD.

2) Press and release the “+” button to toggle between 12 and 24

hour time.

3) Press and release the “SET” button to confirm the 12/24-hour

time display, and to advance to select either °F or °C.

Note: The “24 hour time” option is not recommended. The

LCD display will not show the first digit “2”.

VIII) SELECTING °F OR °C

1) Hold down the “SET” button for 2 seconds (the selected time

zone will flash), press the “SET” button 10 more times, until

the default “°F” flashes in the time LCD.

2) Press and release the “+” button to toggle between °F and °C.

3) Press and release the “SET” button to confirm the °F or °C

selection, and exit the Program Mode.

FEATURES & OPERATIONS

I) CHANGING DISPLAY MODE (DAY, SECONDS, AND

TEMPERATURE)

There are three possible display modes to view the day,

seconds, and temperature. The month & date/ weekday/ indoor

temperature is the default.

To change the display:

1) Press and release the “+” button. The display should now

show the month & date/ weekday/ seconds.

2) Press and release the “+” button a second time and the

display will now show the month & date/ seconds/ indoor

temperature.

3) Press and release the “+” button a third time and the display

will return to the normal display.

II) INDOOR TEMPERATURE

The Indoor Temperature appears on the right side of the Date

LCD. The temperature is checked every 10 seconds, and

updated whenever there is a change.

Otros manuales para WS-6002U

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Reloj de La Crosse Technology

La Crosse Technology

La Crosse Technology BBB85395 Manual de usuario

La Crosse Technology

La Crosse Technology 404-3942 Manual de usuario

La Crosse Technology

La Crosse Technology WS-6118AL-IT Manual de usuario

La Crosse Technology

La Crosse Technology T84220 Manual de usuario

La Crosse Technology

La Crosse Technology WS-7038U Manual de usuario

La Crosse Technology

La Crosse Technology WS-9412 Manual de usuario

La Crosse Technology

La Crosse Technology C86279V3 Manual de usuario

La Crosse Technology

La Crosse Technology 513-1429BL Dimensiones

La Crosse Technology

La Crosse Technology 404-3051B Manual de usuario

La Crosse Technology

La Crosse Technology 513-1918S Manual de usuario

La Crosse Technology

La Crosse Technology 404-1225 Manual de usuario

La Crosse Technology

La Crosse Technology WT-8002U Manual de usuario

La Crosse Technology

La Crosse Technology 404-1246 Manual de usuario

La Crosse Technology

La Crosse Technology BBB87740 Manual de usuario

La Crosse Technology

La Crosse Technology 513-1918B Dimensiones

La Crosse Technology

La Crosse Technology Radio Controlled Projection Alarm WT-5110 Manual de usuario

La Crosse Technology

La Crosse Technology WT-5350 Manual de usuario

La Crosse Technology

La Crosse Technology 404-3624BL Manual de usuario

La Crosse Technology

La Crosse Technology 404-50447 Manual de usuario

La Crosse Technology

La Crosse Technology BBB87733 Manual de operación y mantenimiento

La Crosse Technology

La Crosse Technology WS-8120U Manual de usuario

La Crosse Technology

La Crosse Technology 404-1946 Manual de usuario

La Crosse Technology

La Crosse Technology Payton 404-3015CC Manual de usuario

La Crosse Technology

La Crosse Technology 513-1918S Guía de instalación

Manuales populares de Reloj de otras marcas

Silicon Laboratories

Silicon Laboratories SI5324 Manual de usuario

Heathkit

Heathkit GC-1005 Manual de usuario

Oregon Scientific

Oregon Scientific PRYSMA RMR221P Manual de usuario

Andrew O'Malley

Andrew O'Malley DOTKLOK Manual de usuario

ALGE-Timing

ALGE-Timing ASC3 Manual de usuario

Bodet

Bodet Profil 960 Manual de usuario

Nixie Clock

Nixie Clock Divergence Meter Manual de usuario

Mini Gadgets

Mini Gadgets MCPro Manual de usuario

Casio

Casio TMR-200 Manual de usuario

Progetti

Progetti ILTEMPOSTRINGE Manual

BVItech

BVItech BV-101 Manual de usuario

Progetti

Progetti KALIMERO Manual

Sharp

Sharp SPC900 Manual de usuario

Datexx

Datexx DF0063 Manual de usuario

LG LEC-005 Manual de usuario

IKEA

IKEA ROTBLÖTA Manual de usuario

U-Line

U-Line Н-2811 Manual de usuario

Digiview

Digiview RC305EL Manual de usuario
