SET UP GUIDE

MODEL: BBB86118v3

Curved Digital Atomic Wall Clock

with Moon Phase

1. Insert 2-AA batteries into your Outdoor Sensor.

2. Insert 3-AA batteries Into your Atomic Clock.

3. Enter the Settings Menu to adjust yoour time and date.

4. Once the sensor is reading to your clock, place the senor outside in a

shaded location. View our sensor mounting video here:

bit.ly/th_sensor_mounting

• The clock will search for the Atomic Time Signal at power up and at UTC

7:00, 8:00, 9:00, 10:00, and 11:00.

• The Atomic Time Signal Icon will ﬂash while searching and be solid

when it has connected.

• From the normal time display, press the SEARCH button to manually start

or stop a search for the WWVB time signal. For information about WWVB

visit: bit.ly/AtomicTime

Power Up

Atomic Time

Atomic Clock

BBB86111v3

Outdoor Sensor

TX141-Bv3

Settings Menu

1. Hold the SET button to enter the Settings Menu.

2. Use the +/- buttons to adjust values.

3. Press SET to conﬁrm values.

4. Press the SNOOZE button at any time to save and exit.

Settings Menu Order:

• Beep ON/OFF

• Atomic ON/OFF

• DST AUTOMATIC/ DST ALWAYS OFF / DST ALWAYS ON

(Change Spring/Fall) (Standard Time all year) (DST all year)

• Time Zone

• Hour

• Minutes

• Year

• Month

• Date

• Temperature Fahrenheit/Celsius

Notes:

• If Atomic OFF is selected, menu will skip DST and Time Zone settings and

move straight to the Hour setting.

• Weekday sets automatically when Year, Month and Date are set.

TIME ZONE

ATLANTIC

EASTERN

CENTRAL

MOUNTAIN

PACIFIC

ALASKA

HAWAII

Press the MOON button to switch between Calendar or Moon Phase.

Your clock will stay on the selection.

Custom Display

• The moon phase is based on

the Lunar Calendar and the year,

month, and date settings.

• Due to character limitations on

the clock; Large and Small Waxing

and Waning Phases will not state

Large or Small.

Moon Phase

New Moon

NEW MOON

Small Waxing

Crescent

WAXING CRES

First Quarter

FIRST QTR

Small Waxing

Gibbous

WAXING GIBB

Large Waxing

Gibbous

WAXING GIBB

Full Moon

FULL MOON

Large Waning

Gibbous

WANING GIBB

Small Waning

Gibbous

WANING GIBB

Last Quarter

LAST QTR

Large Waning

Crescent

WANING CRES

Small Waning

Crescent

WANING CRES

Large Waxing

Crescent

WAXING CRES

Phase / Clock Reads Phase / Clock Reads Phase / Clock Reads

Time Alarm

Set Alarm:

1. Hold the ALARM button to enter Alarm Settings.

2. Use the +/- buttons to adjust values.

3. Press the ALARM button to confirm and move to next item.

Silence a sounding alarm: Press any button except SNOOZE to silence the

alarm for 24 hours.

Activate/Deactivate Alarm:

• Press the ALARM button to activate or deactivate the alarm.

• The Alarm Icon will show when alarm is active.

Snooze:

• When the alarm sounds, press the SNOOZE button to silence

the alarm for 10 minutes. Zz will show.

Note: The alarm will sound with increasing frequency for two minutes,

then shut off automatically if not silenced.

HI/LO Temperature Records

View: Press the + button to view Outdoor, then Indoor Temperature HI and

LO Records with time and date stamps.

Reset: While viewing individual records, hold the - button to reset to current

temperatures.

Temperature Trend Arrows

Both the Indoor and Outdoor temperature have Trend Arrows to indicate

temperature changes (2°F / 1°C) over the past one hour period.

Temperature has risen over the past hour.

Temperature has been steady over the past hour.

Temperature has fallen over the past hour.

Search for Outdoor Temperature

If you are seeing NO or dashes for your outdoor readings, please try the

following steps:

1. Hold the +button to search for your outdoor sensor. The Reception

Indicator will begin to animate.

2. If after 3 minutes the sensor still isn’t connected, bring the sensor inside

next to the display and remove power from both the sensor and clock.

3. Press any button on the clock 20 times and leave the parts sit for a few

moments with the power o.

4. Install a new set of alkaline batteries into the sensor, then into your clock.

For additional help visit: bit.ly/basic_restart

5. If your outdoor data is still not appearing after these steps, please

contact our support sta via the links below.

If you require additional support, get in touch with our friendly customer

support team based in La Crosse, WI.

Phone: 1.608.782.1610

Online: bit.ly/contact_techsupport

Our knowledgable customer support team is available:

Mon-Fri 8am-6pm CST

We’re Here to Help

Stay in Touch

Follow La Crosse Technology on YouTube,

Twitter, Facebook and Instgram.

Ask questions, watch setup videos, and

provide feedback on our social media outlets.

Low Battery Indicator

By the Time, replace clock batteries.

By the Outdoor Temperature, replace

sensor batteries.

Care + Maintanence

Do not mix old and new batteries.

Do not mix Alkaline, Lithium, standard, or

rechargeable batteries.

Always purchase the correct size and grade

of battery most suitable for intended use.

Clean the battery contacts and also those of

the device prior to battery installation.

Ensure the batteries have been installed

with correct polarity (+/-).

Remove batteries from equipment that will

not to be used for an extended period.

Promptly remove expired batteries.

Speciﬁcations

Atomic Clock (BBB86118v3)

Temperature Range:

32°F to 122°F (0°C to 50°C)

Power Requirements:

3-AA, IEC, LR6 batteries (not included)

Dimensions:

12.19” W x 1.59” D x 11.80” H

(30.96 W x 4.04 D x 29.98 H cm)

Outdoor Sensor (TX141-Bv3)

Temperature Range:

-40°F to 140°F (-40°C to 60°C)

Transmission Range: Over 330 ft. open air

(100 meters) RF 433MHz

Update Interval: About every 51 seconds

Power: 2-AA, IEC, LR6 batteries (not included)

Battery Life: Over 12 months

Dimensions:

1.57” L x 0.79” W x 5.12” H

(4.0cm L x 2.0cm W x 13.0 H cm)

Designed in La Crosse, Wisconsin •Made in China •Printed in China •DC 071321

Warranty Info

La Crosse Technology, Ltd. provides a 1-year

limited time warranty (from date of purchase) on

this product relating to manufacturing defects in

materials & workmanship.

La Crosse Technology, Ltd,

2830 S. 26th St.

La Crosse, WI 54601

For Full Warranty Details, Visit:

www.lacrossetechnology.com/pages/warranty

This product can expose you to chemicals including

styrene, which is known in the State of California to

cause cancer.

For more information, go to:

www.P65Warnings.ca.gov

WARNING:

This equipment has been tested and found to comply with

the limits for a Class B digital device, pursuant to part 15

of the FCC Rules. These limits are designed to provide

reasonable protection against harmful interference in a

residential installation. This equipment generates, uses and

can radiate radio frequency energy and, if not installed and

used in accordance with the instructions, may cause harmful

interference to radio communications. However, there is

no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference

to radio or television reception, which can be determined by

turning the equipment o and on, the user is encouraged to

try to correct the interference by one or more of the following

measures:

Reorient or relocate the receiving antenna.

Increase the separation between the equipment and

receiver.

Connect the equipment into an outlet on a circuit dierent

from that to which the receiver is connected.

Consult the dealer or an experienced radio/TV technician

for help.

This device complies with Part 15 of the FCC Rules. Operation

is subject to the following two conditions:

(1) This device may not cause harmful interference, and

(2) This device must accept any interference received,

including interference that may cause undesired operation.

Caution!

Any changes or modiﬁcations not expressly approved by

the party responsible for compliance could void the user’s

authority to operate the equipment.

in any form, even in part, or duplicated or processed using

electronic, mechanical or chemical process without the

written permission of the publisher.

This booklet may contain errors or misprints. The information

it contains is regularly checked and corrections are included

in subsequent editions. We disclaim any responsibility for

any technical error or printing error, or their consequences.

All trademarks and patents are recognized.

FCC Statment

Canada Statment

This device contains licence-exempt transmitter(s)/receiver(s)

that comply with Innovation, Science and Economic

Development Canada’s licence-exempt RSS(s). Operation is

subject to the following two conditions:

(1) This device may not cause interference.

(2) This device must accept any interference, including

interference that may cause undesired operation of the

device.

L’émetteur/récepteur exempt de licence contenu dans

le présent appareil est conforme aux CNR d’Innovation,

Sciences et Développement économique Canada

applicables aux appareils radio exempts de licence.

L’exploitation est autorisée aux deux conditions suivantes :

1) L’appareil ne doit pas produire de brouillage;

2) L’appareil doit accepter tout brouillage radioélectrique

subi, même si le brouillage est susceptible d’en

compromettre le fonctionnement.

Tabla de contenidos

Otros manuales de Reloj de La Crosse Technology

La Crosse Technology

La Crosse Technology BBB86088v2 Manual de usuario

La Crosse Technology

La Crosse Technology T84220 Manual de usuario

La Crosse Technology

La Crosse Technology C86279V3 Manual de usuario

La Crosse Technology

La Crosse Technology 519-1416 Dimensiones

La Crosse Technology

La Crosse Technology 513-1417ALv4 Dimensiones

La Crosse Technology

La Crosse Technology 404-1246 Manual de usuario

La Crosse Technology

La Crosse Technology 513-1918S Manual de usuario

La Crosse Technology

La Crosse Technology Sagebrook 404-3015CC Manual de usuario

La Crosse Technology

La Crosse Technology WT-3181PLX1 Dimensiones

La Crosse Technology

La Crosse Technology 513-1419BL-WA Manual de usuario

La Crosse Technology

La Crosse Technology WT-8005U Manual de operación y mantenimiento

La Crosse Technology

La Crosse Technology 513-1211 Manual de usuario

La Crosse Technology

La Crosse Technology WT-8005U Manual de usuario

La Crosse Technology

La Crosse Technology T82394 Manual de usuario

La Crosse Technology

La Crosse Technology WS-6003U Manual de usuario

La Crosse Technology

La Crosse Technology 513-1417CH Manual de usuario

La Crosse Technology

La Crosse Technology WS-8120U Manual de usuario

La Crosse Technology

La Crosse Technology 513-1417v5 Manual de usuario

La Crosse Technology

La Crosse Technology 404-3840MA Manual de usuario

La Crosse Technology

La Crosse Technology WS-8418U-IT Manual de usuario

La Crosse Technology

La Crosse Technology 616-1410B Manual de usuario

La Crosse Technology

La Crosse Technology K86302 Manual de usuario

La Crosse Technology

La Crosse Technology 404-1235UA-SS Manual de usuario

La Crosse Technology

La Crosse Technology 404-54667 Manual de usuario

Manuales populares de Reloj de otras marcas

Silicon Laboratories

Silicon Laboratories SI5324 Manual de usuario

Heathkit

Heathkit GC-1005 Manual de usuario

Oregon Scientific

Oregon Scientific PRYSMA RMR221P Manual de usuario

Andrew O'Malley

Andrew O'Malley DOTKLOK Manual de usuario

ALGE-Timing

ALGE-Timing ASC3 Manual de usuario

Bodet

Bodet Profil 960 Manual de usuario

Nixie Clock

Nixie Clock Divergence Meter Manual de usuario

Mini Gadgets

Mini Gadgets MCPro Manual de usuario

Casio

Casio TMR-200 Manual de usuario

Progetti

Progetti ILTEMPOSTRINGE Manual

BVItech

BVItech BV-101 Manual de usuario

Progetti

Progetti KALIMERO Manual

Sharp

Sharp SPC900 Manual de usuario

Datexx

Datexx DF0063 Manual de usuario

LG LEC-005 Manual de usuario

IKEA

IKEA ROTBLÖTA Manual de usuario

U-Line

U-Line Н-2811 Manual de usuario

Digiview

Digiview RC305EL Manual de usuario
