La Crosse Technology, Ltd Page 1

515-1912 FAQS

The links below will work in most PDF viewers and link to the topic area by clicking the

link. We recommend Adobe Reader version 10 or greater available at:

http://get.adobe.com/reader

CONTENTS

515-1912 FAQS........................................................................................................................... 1

Batteries ..................................................................................................................................... 2

Digital Clock Factory Restart........................................................................................................ 2

Compatible Outdoor sensors................................................................................................... 2

Power Requirements ............................................................................................................... 2

Quick Connect ........................................................................................................................ 3

Dashes show for Outdoor Temperature ................................................................................... 3

Inaccurate Outdoor Temperature Reading ............................................................................... 3

Intermittent Outdoor Temperature ........................................................................................... 3

Outdoor Temperature is stuck or HH.H, LL.L ............................................................................ 4

Outdoor sensor drains batteries quickly ................................................................................... 4

Outdoor sensor fell. The sensor no longer works ..................................................................... 4

Mounting/Positioning Outdoor sensor ...................................................................................... 5

Fahrenheit/Celsius ...................................................................................................................... 5

Supported Time Zones............................................................................................................ 5

Dashes, HHH, LLL or Stuck Indoor Temperature....................................................................... 6

Does the clock have a backlight?............................................................................................. 6

Time is off by hours ................................................................................................................. 6

Daylight Saving Time............................................................................................................... 6

Manually Set Time/Date: Program Menu................................................................................... 7

No WWVB Tower Icon ............................................................................................................. 8

Timer ...................................................................................................................................... 8

Custom Date Display ............................................................................................................... 9

Position Clock ......................................................................................................................... 9

Digital clock has distorted or frozen display

.............................................................................. 9

Digital clock is blank: No letters, numbers or dashed lines ........................................................ 9

Day of the week is incorrect..................................................................................................... 9

Digital clock drains batteries quickly........................................................................................10

Digital clock has missing segments .........................................................................................10

La Crosse Technology, Ltd Page 2

Batteries

Explanation: Many problems are resolved with fresh batteries of the appropriate voltage.

Many items sent in under warranty work, when tested with fresh batteries. Batteries

manufactured this year will have an expiration date 10 years (or more) in the future. Battery

technology has improved, and batteries will maintain voltage longer in storage. However,

the environment the batteries reside in for the 10 years can deplete the power.

•We suggest name brand Alkaline batteries for indoor displays.

•A minimum voltage of 1.48V for each battery is necessary for proper performance.

•Use batteries dated at least six years in advance of the current year. Batteries dated

earlier than six years from now may still work but may be unstable in performance.

•Good name brand batteries make less noise, which reduces the chance of RF (radio

frequency) interference from the battery compartment.

Digital Clock Factory Restart

Explanation: The factory restart returns the clock and outdoor sensor to an “out-of-the-

box” default state and often resolves an issue.

Factory Restart:

1. Remove all power from outdoor sensor and clock.

2. Press one of the buttons on the clock at least 20 times to clear all memory.

3. Verify that the clock is blank before proceeding (there may be lines painted on the

screen that will show when there is no power).

4. Leave both units without power for 15 minutes (very important).

5. Insert fresh batteries into the outdoor sensor, then into the clock.

6. Keep the outdoor sensor 5-10 feet from the clock.

7. When RF connection is established, the temperature/humidity will appear on the

station. Allow the outdoor sensor and clock to sit together for 15 minutes to establish a

strong connection.

8. Do not press buttons for 15 minutes.

•For optimum 433MHz transmission, place the outdoor sensor no more than 330 feet

(100 meters, open air) from the clock.

•See the section on mounting and distance/resistance/interference for details on

mounting the outdoor sensor.

Compatible Outdoor sensors

•The TX191TH Outdoor sensor comes packaged with this atomic clock.

•The TX191TH (433MHz) Outdoor sensor is compatible with this atomic clock.

Power Requirements

•2-AA batteries power the Outdoor sensor.

•2-AA batteries power the clock.

•We recommend Alkaline batteries for the Outdoor sensor.

La Crosse Technology, Ltd Page 3

Quick Connect

Explanation: If sensor loses connection to the clock for any reason, the clock will show

NO in the outdoor temperature area after 30 minutes. The clock will search for 3 minutes

every hour to reconnect with sensor.

•Hold the PLUS (+) button 2 seconds to search for the outdoor sensor.

Dashes show for Outdoor Temperature

Explanation: Dashes mean the connection is lost between the atomic clock and the

Outdoor sensor.

•Batteries often resolve the connection.

•Distance/Resistance can cause loss of connection between the Outdoor sensor and

the atomic clock.

•Turn the atomic clock 90 degrees towards the Outdoor sensor to provide better

reception. This allows more antenna surface to face the Outdoor sensor signal.

•Try the quick connect or factory restart.

Inaccurate Outdoor Temperature Reading

Explanation: High Outdoor temperature readings are generally a location issue. Low

Outdoor temperature readings are power related or a sensor going bad.

•The Outdoor sensor reads the environment where it is mounted. When mounted inside

the home, it will read inside temperature.

•When the Outdoor sensor reads high during the day, but not at night, it is a positioning

problem.

•Look for heat sources such as sunlight, door or window frames or reflected heat.

Side-by-side test: Place the Outdoor sensor right next to the atomic clock for 2 hours.

•Compare indoor and Outdoor temperature. The temperatures should be within 4

degrees to be within tolerance.

•If the Outdoor sensor reads correctly when next to the atomic clock, try a different

location outside.

Intermittent Outdoor Temperature

Explanation: Intermittent problems are the hardest to resolve. RF (radio frequency)

communication may come and go occasionally. This can be normal in some environments

(e.g. moister climates). If Outdoor sensor signal is lost, please wait 2-4 hours for the signal

to reconnect on its own.

•Move the Outdoor sensor to a closer location.

•Distance/Resistance can cause loss of Outdoor sensor signal.

•Check Batteries.

La Crosse Technology, Ltd Page 4

Freezer test: Confirm the atomic clock is reading the correct Outdoor sensor (not a

neighbor’s sensor). Place the Outdoor sensor in the freezer for an hour and watch the

temperature drop on the atomic clock.

Indoor distance test: Please complete the Restart with Outdoor sensor and atomic clock

5-10 feet apart and inside to establish a strong connection.

•After 15 minutes, if there is a reading in the Outdoor temperature area, move the

Outdoor sensor to another room with one wall between the Outdoor sensor and the

atomic clock.

•Observe to see if the temperature remains on consistently for 1 hour.

•If the temperature remains on while in the house, then it is likely a distance/resistance

issue.

•Move the Outdoor sensor to different locations outside to find a location where the

temperature reading will hold.

Outdoor Temperature is stuck or HH.H, LL.L

Explanation: These symbols are error messages indicating the Outdoor sensor is outside

of its readable range.

•Check Batteries.Overpowered or underpowered batteries can cause this reading.

•Replace Outdoor sensor.

Outdoor sensor drains batteries quickly

•Test a new set of alkaline batteries. Write down the date of installation and the voltage

of the batteries.

•When the batteries fail, please note the date and voltage again.

•Check the distance and resistance between the Outdoor sensor and atomic clock.

Outdoor sensors at the end of the range may work while batteries are fresh but not

after they drain a bit.

•Check for leaking batteries, which may damage the Outdoor sensor.

•Battery life is over 18 months when using reputable battery brands.

Outdoor sensor fell. The sensor no longer works

Explanation: If there is no physical damage to the Outdoor sensor, the fall may not have

caused internal damage. A fall can shock the Outdoor sensor or the batteries in the

Outdoor sensor. Batteries that have fallen on a hard surface may be damaged and unable

to function properly.

•Complete a Restart with fresh batteries.

•Use Batteries dated at least six years in advance of the current year. Batteries dated

earlier than six years from now may still work but may be unstable in performance.

Note: A Outdoor sensor that has fallen into puddle, snow, or other standing water, will

likely have water damage and need to be replaced. Outdoor sensors are water resistant,

not waterproof.

La Crosse Technology, Ltd Page 5

Mounting/Positioning Outdoor sensor

First: Place the Outdoor sensor in the desired shaded location and the atomic clock in the

home. Wait approximately 1 hour before permanently mounting the Outdoor sensor to

ensure that there is proper reception.

POSITION

Outdoor:

•Protect the Outdoor sensor from standing rain or snow and from the overhead sun,

which can cause it to read incorrectly.

•Mounting under an eave or deck rail works well.

•If you choose, you can construct a small roof or box for the Outdoor sensor. Be sure a

box has vents.

•Mount the Outdoor sensor on the North side where to prevent sun from causing

incorrect readings.

•Mount at least 6 feet in the air for a strong RF (radio frequency) signal.

•Do not mount the Outdoor sensor on a metal fence. This significantly reduces the

effective range.

•Outdoor sensors are water resistant, not waterproof.

Indoor or Outdoor:

•Mount Outdoor temperature sensor vertically.

•Avoid more than one wall between the Outdoor sensor and the atomic clock.

•The maximum transmitting range in open air is over 200 feet (60 meters).

•Obstacles such as walls, windows, stucco, concrete and large metal objects can

reduce the range.

•Do not mount near electrical wires, transmitting antennas or other items that will

interfere with the signal.

•RF (radio frequency) signals do not travel well through moisture or dirt.

MOUNT

Option 1:

•Install one mounting screw (not included) into a wall.

•Place the Outdoor sensor onto the screw (hanging hole on the backside).

•Gently pull down to lock the screw in place.

Option 2:

•Insert the mounting screw through the front of the Outdoor sensor and into the wall.

•Tighten the screw to snug (do not over tighten).

Fahrenheit/Celsius

•Use the program menu to switch from Fahrenheit to Celsius.

Supported Time Zones

•This clock has 7 Time Zones: AST=Atlantic, EST= Eastern, CST= Central,

La Crosse Technology, Ltd Page 6

MST= Mountain, PST= Pacific, AKT= Alaska, HAT=Hawaiian The digital clock works in

North America.

•Outside of North America, the digital clock will not receive a WWVB signal, but will

keep time like a quartz clock.

Dashes, HHH, LLL or Stuck Indoor Temperature

Explanation: These symbols are error messages indication the indoor sensor is outside of

its readable range. For indoor readings, this is generally a power related issue.

•This is generally a power related issue.

•Batteries may be overpowered or underpowered. Remove batteries from atomic digital

clock.

•Press any button 20 times. Leave the digital clock unpowered for 1-2 hours.

•Insert fresh alkaline batteries with correct polarity.

•If the indoor temperature is still dashes or HHH, LLL, the digital clock may need

replacement.

Does the clock have a backlight?

•No, as this clock is battery operated there is no backlight.

Time is off by hours

•Check to see if the WWVB Tower icon appears on the atomic digital clock. If not, the

digital clock has not received a WWVB time signal in the past 24 hours.

•Reposition the digital clock with the front or back facing Colorado.

•Check that the Time Zone selected correctly reflects your location. Adjust the time

zone in the Program Menu.

•Check that the DST indicator is correct for your location (most areas observe DST so

this should be ON). Adjust the DST indicator in the Program Menu.

•Large buildings, metal roofed buildings and buildings or rooms full of electrical and/or

radio equipment make it difficult to receive the WWVB time signal.

Daylight Saving Time

Some states are considering going to year around Daylight Saving Time. We have built in

options to accommodate this feature into the program menu.

DST ON: (Automatically gain 1 hour in spring, lose 1 hour in fall)

DST OFF: (Remain in Standard Time all year long)

DST ALWAYS ON: (Remain in Daylight Saving Time all year long)

•Dependent on your location, position of the clock in your home, and atmospheric

interference, it may take up to 5 nights for the change from Daylight Savings Time to

Standard Time and vice-versa to occur.

•Check for a WWVB Tower Icon showing on the atomic digital clock. The tower icon

indicates you have received the WWVB signal from Ft Collins CO in the past 24 hours.

•Check that the clock is in the correct Time Zone.

La Crosse Technology, Ltd Page 7

•Check whether the DST indicator is ON, OFF or ALWAYS ON. If the indicator is OFF or

ON the clock will not change seasonally.

•Check for fresh batteries. Without proper batteries, the antenna will have a harder

time picking up the signal.

•Position the digital clock in a window (with the front or back) facing Ft. Collins, Colorado

and leave for up to five nights. If you do not have a window facing this direction,

position the clock near an outside wall and point the unit in this general direction.

Manually Set Time/Date: Program Menu

1. Hold the SET button 2 seconds to enter settings mode.

2. Press the + or - button to adjust the flashing values.

3. Hold the + or - buttons to adjust quickly.

4. Press the SET button to confirm adjustments and move to the next item.

5. Press the TIMER button at any time to exit.

IMPORTANT: Some states in the USA are considering keeping Daylight Saving Time all

year long. We are including an additional DST setting of DST ALWAYS ON.

•DST ON- Clock gains 1 hour in spring and loses 1 hour in the fall

•DST OFF- Clock remains in Standard Time all year long

•DST ALWAYS ON- Clock remains in Daylight Saving Time all year long

Settings Menu Order:

•Beep ON/OFF

•Atomic ON/OFF

•DST (Daylight Saving Time)

oDST ON

oDST OFF

oDST ALWAYS ON

•Time Zone

•Hour

•Minutes

•Year

•Month

•Date

•Fahrenheit/Celsius

To begin:

1. Hold the SET button for 2 seconds to enter setting mode. BEEP ON will show. ON

flashes. Press the + or - button to turn the button beep sound off.

2. Press SET to confirm and move to the atomic time ON/OFF. The tower icon and ON

will show. ON flashes. Press the + or - button if you do not want Atomic Time signal

(OFF).

3. Press SET to confirm and move to the Daylight Saving Indicator. DST ON will show. ON

flashes. Press the + or - button to turn DST OFF if you do not observe Daylight Saving

Time changes, or to DST ALWAYS ON if your state has selected year around DST.

La Crosse Technology, Ltd Page 8

4. Press SET to confirm and move to the Time Zone. EST will flash. Press the + or - button

to select your time zone.

5. Press SET to confirm and move to the hour. The HOUR will flash. Press the + or -

button to choose the hour.

6. Press SET to confirm and move to the minutes. The MINUTES will flash. Press the + or -

button to choose the minutes.

7. Press SET to confirm and move to the year. The Year number will flash. Press the + or

- button to change the year.

8. Press SET to confirm and move to the month. Month number will flash. Press the + or -

button to change the month.

9. Press SET to confirm and move to the date. Date number will flash. Press the + or -

button to change the date.

10. Press SET to confirm and move to the temperature unit. °F will flash. Press the + or -

button if you prefer °C (Celsius).

11. Press SET to confirm and exit.

•No button press for 10 seconds-clock will resume normal time display.

•Weekday will set automatically as year, month and date are set.

No WWVB Tower Icon

•The digital clock has not received a WWVB time signal in the past 24 hours.

•Position the digital clock for better reception.

•Press and release the SET button to send the digital clock on a WWVB signal search at

night.

•Allow up to 5 nights to receive the time signal.

Timer

A timer can be set from 1 minute (minimum) to 99 Minutes (maximum).

1. Hold the TIMER button for 2 seconds. The Minutes will flash. Press and release the + or

– button to adjust the minutes.

2. Press and release the TIMER button to confirm and exit.

Start/Pause/Restart Timer:

•Timer will start automatically once it is set.

•Press the TIMER button at any time to pause the timer. Stopwatch icon will flash.

•Press the TIMER button again to resume the timer countdown.

Stop Timer:

•While timer is showing, press any button except Timer button, to stop timer.

•The Timer will automatically return to the last countdown time set. This value will show

for 3 seconds then clock will default to normal clock display with Temp/Humidity.

Example: If Timer was set for 15 minutes and stopped before it reached zero, the Timer

will automatically reset to 15 minutes. Remaining time for the Timer will no longer be saved.

•User will need to enter TIMER SETTINGS to change the Timer duration.

•Press TIMER at any time to start or stop the timer countdown.

La Crosse Technology, Ltd Page 9

Timer Sounds

•When count down reaches 0, the timer will sound 5 beeps every 15 seconds for up to 1

minute.

•The timer to be at 72db heard from 1 foot away from the front of the clock.

•The timer icon.

Custom Date Display

Indoor Temperature & Seconds or Outdoor Temperature/Humidity Display:

•Press the MINUS (-) button to toggle between Indoor Temperature & Seconds

Counting and Outdoor Temperature/Humidity Display.

Position Clock

•Use the slot on the battery cover to mount your clock with a screw, or insert the suction

cup attachment into the slot and mount on a clean, smooth surface.

•When using suction cup, occasionally press and hold the clock to be sure it is secure.

•Position the digital clock for better Atomic Time Signal reception. The front or back

should face toward Colorado.

Digital clock has distorted or frozen display

Explanation: On a brand new digital clock, check for thin plastic film of printed scratch

guard that may be on the screen of the digital clock. This thin piece of plastic has printed

numbers for store displays. When the batteries are installed, the “real” numbers show

behind the printed scratch guard and create distortion.

•With all power removed, the digital clock should be blank.

•If numbers still appear, please check for scratch guard.

Power:

•Check that the batteries are installed correctly.

•This is generally a power related issue.

•Batteries may be overpowered or underpowered.

•Remove batteries from digital clock.

•Press any button 20 times. Leave the batteries out of the display for 2 hours.

•Insert batteries into the digital clock.

Digital clock is blank: No letters, numbers or dashed lines

•Check that the batteries are installed correctly.

•Batteries may be overpowered or underpowered.

•Remove batteries from digital clock.

•Press any button 20 times. Leave the batteries out of the display for 2 hours.

•Insert batteries into the digital clock.

Day of the week is incorrect.

La Crosse Technology, Ltd Page 10

•Check the year setting in the program menu. The day of the week sets automatically

based on the setting of the year, month and date.

Digital clock drains batteries quickly

•Test a new set of alkaline batteries. Write down the date of installation and the voltage

of the batteries.

•When the batteries fail, please note the date and voltage again. This is helpful in

determining the problem.

•Check for leaking batteries, which may damage the digital clock.

Digital clock has missing segments

Explanation: When parts of numbers, letters, or pictures are missing on the display, it is

often power related.

•With all power removed, the digital clock should be blank.

•If numbers still appear, please check for scratch guard.

Power:

•Check that the batteries are installed correctly.

•This is generally a power related issue.

•Batteries may be overpowered or underpowered.

•Remove batteries from digital clock.

•Press any button 20 times. Leave the batteries out of the display for 2 hours.

•Insert batteries into the digital clock.

Otros manuales para 515-1912

Tabla de contenidos

Otros manuales de Reloj de La Crosse Technology

La Crosse Technology

La Crosse Technology 513-1918S Manual de usuario

La Crosse Technology

La Crosse Technology 513-1429THV2 Dimensiones

La Crosse Technology

La Crosse Technology WS-8001U Manual de usuario

La Crosse Technology

La Crosse Technology WS6158-IT Manual de usuario

La Crosse Technology

La Crosse Technology WT-3161BKx1 Manual de usuario

La Crosse Technology

La Crosse Technology 616-1410B Manual de usuario

La Crosse Technology

La Crosse Technology WS-8236U-AL Manual de usuario

La Crosse Technology

La Crosse Technology WT-3181PLQ Dimensiones

La Crosse Technology

La Crosse Technology 404-1946 Manual de usuario

La Crosse Technology

La Crosse Technology W86111V2 Manual de usuario

La Crosse Technology

La Crosse Technology 515-1419 Dimensiones

La Crosse Technology

La Crosse Technology WS-8418AL-IT Manual de usuario

La Crosse Technology

La Crosse Technology WT-3161WH Manual de usuario

La Crosse Technology

La Crosse Technology 403-3246BR Manual de usuario

La Crosse Technology

La Crosse Technology 83193-BHG Manual de usuario

La Crosse Technology

La Crosse Technology WS-8119U Manual de usuario

La Crosse Technology

La Crosse Technology 513-148 Manual de usuario

La Crosse Technology

La Crosse Technology KWS-8140U-IT Manual de usuario

La Crosse Technology

La Crosse Technology 513-63867v2 Manual de usuario

La Crosse Technology

La Crosse Technology 513-1311 Manual de usuario

La Crosse Technology

La Crosse Technology BBB84022 Manual de usuario

La Crosse Technology

La Crosse Technology Radio Controlled Projection Alarm WT-5110 Manual de usuario

La Crosse Technology

La Crosse Technology WS-8157U-IT Manual de usuario

La Crosse Technology

La Crosse Technology WS-8256-AL Manual de usuario

Manuales populares de Reloj de otras marcas

Silicon Laboratories

Silicon Laboratories SI5324 Manual de usuario

Heathkit

Heathkit GC-1005 Manual de usuario

Oregon Scientific

Oregon Scientific PRYSMA RMR221P Manual de usuario

Andrew O'Malley

Andrew O'Malley DOTKLOK Manual de usuario

ALGE-Timing

ALGE-Timing ASC3 Manual de usuario

Bodet

Bodet Profil 960 Manual de usuario

Nixie Clock

Nixie Clock Divergence Meter Manual de usuario

Mini Gadgets

Mini Gadgets MCPro Manual de usuario

Casio

Casio TMR-200 Manual de usuario

Progetti

Progetti ILTEMPOSTRINGE Manual

BVItech

BVItech BV-101 Manual de usuario

Progetti

Progetti KALIMERO Manual

Sharp

Sharp SPC900 Manual de usuario

Datexx

Datexx DF0063 Manual de usuario

LG LEC-005 Manual de usuario

IKEA

IKEA ROTBLÖTA Manual de usuario

U-Line

U-Line Н-2811 Manual de usuario

Digiview

Digiview RC305EL Manual de usuario
