Full Color LED Video processor KS600 User Manual
Full Color LED Video Processor
KS600
User Manual
Beijing KYSTAR Technology Co.,LTD
Full Color LED Video processor KS600 User Manual
Cautions
Dangerous
There is high voltage in the device .Non professionals please
do not dismantle the device in case of danger.
Warning
●Pay attention to water proof and moisture proof work
●Keep away from fire or hot environment
●Strange noise,smoking or odd smell appears,unplug the power plug
and contact dealer
●Forbid to plug/unplug VGA and DVI signal cables
Attention
1Read the user manual carefully and keep it for further use.
2Unplug the power plug when there is thunder and lightning or long
time disuse;
3. The device is not suitable for nonprofessionals,please use under
professionals instructions;
3Do not slip anything into the blowhole of the device in case of any
damage or incident;
4Keep the device away from water or moisture environment.
5Keep the device away from cooling fin or other hot environment
6Tidy up and place the power cable properly in case of damage
7Unplug the power plug of the device and contact us for repair when
blow situation happens
●Liquid splashed into the device
●Device falling or case damage
●Obvious dysfunction or performance difference
Full Color LED Video processor KS600 User Manual
Catalogue
I.Product Overview......................................................................5
II.Product Features......................................................................6
III.Technical Parameters..............................................................3
IV.Work diagram ..........................................................................5
V. Panel ........................................................................................6
Front...........................................................................................6
Back...........................................................................................7
VI.Connection and installation...................................................8
Connection diagram ...................................................................8
Installation procedure .................................................................8
VII.Device debug .........................................................................9
Wizard mode--4 steps to achieve setup......................................9
VIII.Control Menu.......................................................................17
1Language ........................................................................18
Full Color LED Video processor KS600 User Manual
2Factory settings...............................................................19
3Technical support.............................................................19
4Scheduled task................................................................19
5Transition effect...............................................................19
6VGA setting .........................................
7Contast setting.................................................................19
8Image statics ...................................................................19
9Sound setting ..................................................................19
10)Expert setting...................................................................19
IX .FAQ ...........................................................
Technical support and Contact Info .............................................20
Full Color LED Video processor KS600 User Manual
I.
Product overview
With the rapid development of LED industry and the continuous expansion of
application needs, a variety of control requirements intended for large-screen control
system come into being. Ho ever, due to the limitations of large-screen control
system in image processing, screen control and signal format conversion, the control
system of LED large screen has some eaknesses in the follo ing aspects:
1. The signal source access format of LED large screen control system is limited.
Currently, only digital DVI signal is used, and many signal sources (e.g. VGA) can’t be
displayed on the LED large screen directly through the control system;
2. The traditional signal acquisition card is poor in image processing, and the image
resolution ill be reduced significantly hen the signal format is converted;
3. The control system of LED large screen can only capture and display the images of
corresponding points on the LED large screen; ho ever, in some sites, the customer
may need to display any size or the full computer desktop;
4. With the shrinking of LED screen pitch and increasing of screen points, the era that
single picture displays on single screen no longer exists. More application
requirements and display requirements are prominent, and the control system of LED
big screen can better meet customer needs in coordination ith other peripherals.
To solve these problems, the company has developed a variety of video processing
products. With advanced control and image processing technology, the products can
not only s itch bet een signals fast and stably, but also process the images in
multiple levels. In addition, the product can be controlled by the equipment
keyboard and PC, hich are easy to operate.
Full Color LED Video processor KS600 User Manual
II定
Product features
1.Operate by f
ront panel independently,knob and numbering key bring
more convenience for the operation.
2.PC software control,achieve prompt operation visually.
3.Fade in/out,perfect switch
4.Brightness and contrast control,enhance image display effect.
5.Picture zoom in/out freely( adjust picture pixel by pixel ,the minimum size can be 1
pixel)
6.Motion compensation,avoid trailing of pictures
7.Noise reduction(reduce noise stain)
8.6-channel HD video signal inputs,2-channel video outputs
9.Max input resolution is 1920*1080, max output user-defined resolution is
1920*1200
10.Key lock function,prevent misoperation after debug
11.5 modes save and call
12.Wizard setting
13.Standard 1.5U,convenient for carry and installation
Full Color LED Video processor KS600 User Manual
III.Technical parameters
Video processor adapts latest patent video processing technology and
has AIAO (any format input ,corresponding format output )video conversion
ability.CVBS,HDMI,VGARGBand DVI-D can be processed and enhanced
to meet practical applications.Below is the detailed specification:
CVBS(BNC input)
Number of Inputs 2
Supported Standards PAL/NTSC
Signal Level 1Vpp±3db (0.7V Video+0.3v Sync )
75Ω
HDMI Input
Number of Inputs 1
Supported Standards
EDID/DDC2B
Signal Level 1Vpp±3dB (0.7V Video+0.3v Sync )
75Ω
VGA(DB15 Input)
Number of Inputs 1
Interface type Standard DB15 socket
Supported Standards VGA-UXGA
Signal Level RGBHsyncVsync:0 to1Vpp±3dB (0.7V
Video+0.3v Sync )
75Ω
black level: 300mV Sync-tip: 0V
Full Color LED Video processor KS600 User Manual
DVI Input
Number of Inputs 1
Interface type Standard DVI-D socket
Resolution supported
SMPTE: 625/25 PAL, 525/29.97
NTSC, 625/50p PAL, 525/59.94p
NTSC, 1080P60,1080i50, 1080i59.94/60, 720p50
and 720p59.94/60
VESA: 800×600@60Hz1024×768@60Hz
1280×768@60Hz1280×1024@60Hz
1600×1200@60Hz
Signal level TMDS signal level165MHz bandwidth
Standard DVI 1.1
DVI Output
Number 2
Interface type Standard DVI-D
Resolution supported
1024×768@60Hz,1280×1024@60Hz
1366×768@60Hz,1440×900@60Hz
1600×1200@60Hz1680×1050@60Hz
1920×1080@60Hz,1920x1200@60Hz
Signal level TMDS electrical level165MHz bandwidth
Others
CE standard
BS EN 55013:2001+A1:2003+A2:2006
BS EN 61000-3-2:2006+A2:2009
BS EN 6100-3-3:2008
BS EN 55020:2007
BS EN 6006:2002+A1:2006+A11:2008
PC or central control system
control RS232
Power 85-264V 2A IEC-3 power interface
Work environment 0°C~45°C
Humidity 10% to 90%
Product guarantee period 3 years
Full Color LED Video processor KS600 User Manual
IV.Work diagram
LED screen
Sending card
Video processor
PC Laptop Camera DVD
Full Color LED Video processor KS600 User Manual
V.Panel
Front Panel
POWER:device switch,OFF—power offON—power on
LCD:text display screen,display menu,parameters etc.
DVI:digital signal key
HDMI:HD multi-media key
VGA:analog signal key
BRI:Brightness setting
MODE:User mode call
MENU:Menu key
OK:Confirm keypress it and enter next profile under navigation mode
ADJUST:Increase or decrease key,press down to confirm
/
CV1~2:CVBS key
Reserved key:Number 8
OUT:make switch between blank and normal screen output(For blue
screen ,please use know)
PART:part and full switch
Wizard key:user navigation mode,work as step key when set data
Arrow:return key
