KYOCERA d.Blue Modules

KYOCERA has also gone from two bus bars per cell to three.

By adopting three-bus electrode circuitry in combination with its

“d.Blue” solar cell technology, K YOCERA has increased the power

output of its solar modules by as much as seven percent without

affecting the physical size of the modules. This gives the KYOCERA

OFF-GRID Modules line a broad power range – from 40 watts to

135 watts–providing a solution for nearly every application.

OFF-GRID MODULES | d.Blue Modules

40 -135 WATT POWER RANGE

MODULES FEATURE CONDUIT-READY JUNCTION BOX

HEAVY-DUTY ANODIZED ALUMINUM FRAME

20-YEAR POWER OUTPUT WARRANTY

KYOCERA’S d.Blue technology is a

process of texturing the surface of

the solar cells to reduce reflection.

This keeps more of the light energy

within the cell, creating a gain in

output power. The cell texturing and

the new three-bus-bar electrodes

combine to raise module performance

to a new level.

Kyocera Empowers Your Future

OFF-GRID MODULES SPECIFICATIONS

KD135SX KC85T KC65T KC50T KC40T

Maximum Power 135W 87W 65W 54W 43W

Tolerance +5%/-5% +10%/-5% +10%/-5% +10%/-5% +10%/-5%

Maximum System

Voltage 600V 600V 600V 600V 600V

Maximum Power

Voltage 17.7V 17.4V 17.4V 17.4V 17.4V

Maximum Power

Current 7.63A 5.02A 3.75A 3.11A 2.48A

Open Circuit Voltage 22.1V 21.7V 21.7V 21.7V 21.7V

Short Circuit Current 8.37A 5.34A 3.99A 3.31A 2.65A

Length 59.1” 39.6” 29.6” 25.2” 20.7”

Width 26.3” 25.7” 25.7” 25.7” 25.7”

Depth 1.8” 2.3” 2.1” 2.1” 2.1”

Weight 27.5 lbs 18.3 lbs 13.2 lbs 11.0 lbs 9.9 lbs

Warranty 20 Years 20 Years 20 Years 20 Years 20 Years

Frame Color Black Anodized Clear Anodized Clear Anodized Clear Anodized Clear Anodized

Termination Method Conduit Ready

Junction Box

Conduit Ready

Junction Box

Conduit Ready

Junction Box

Conduit Ready

Junction Box

Conduit Ready

Junction Box

© 2010 Kyocera Solar, Inc. All rights reserved.

KYOCERA SOLAR, INC.

800-223-9580 toll-free

800-523-2329 fax

www.kyocerasolar.com

Kyocera reserves the right to modify these specifications without notice.

All specification at 25°C. cell temperature, 1.5 AM and 1000W/m2.

Modules have a conduit ready junction box.
