Kyocera ECOSYS FS-1370DN Manual de usuario

ADVANCED OPERATION GUIDE

FS-1370DN

Contents

1 Paper Handling ........................................................................... 1-1

General Guidelines ..................................................................... 1-2

Selecting the Right Paper .......................................................... 1-4

Paper Type ................................................................................ 1-11

2 Using the Operation Panel ......................................................... 2-1

General Information ................................................................... 2-2

Understanding the Operation Panel ......................................... 2-3

Using the Menu Selection System ............................................ 2-8

Report Print ............................................................................... 2-11

USB Memory (USB flash memory selection) ......................... 2-16

Counter (Viewing the counter value) ...................................... 2-18

Paper Settings .......................................................................... 2-19

Print Settings ............................................................................ 2-28

Network (Network settings) ..................................................... 2-40

Device Common (Selecting/Setting the common device) .... 2-45

Security ..................................................................................... 2-57

Admin (Administrator settings) ............................................... 2-65

Adjust/Maintenance (Adjust/Maintenance selection/setting) 2-67

3 Option .......................................................................................... 3-1

General Information ................................................................... 3-2

Expansion Memory Modules ..................................................... 3-3

Paper Feeder (PF-100) ................................................................ 3-5

CompactFlash (CF) Card ........................................................... 3-6

USB Flash Memory ..................................................................... 3-6

4 Computer Interface ..................................................................... 4-1

General Information ................................................................... 4-2

USB Interface .............................................................................. 4-2

Network Interface ....................................................................... 4-3

Glossary ..................................................................................... 5-1

Index .................................................................................... Index-1

iii

Introduction

Regarding Tradenames

PRESCRIBE is a registered trademark of Kyocera Corporation. KPDL is

trademark of Kyocera Corporation.Hewlett-Packard, PCL, and PJL are

registered trademarks of Hewlett-Packard Company. Centronics is a

trade name of Centronics Data Computer Inc. Adobe, Acrobat, Flash,

and PostScript are registered trademarks of Adobe Systems

Incorporated. Macintosh and Bonjour are registered trademarks of Apple

Computer, Inc. Microsoft and Windows are registered trademarks of

Microsoft Corporation in the U.S.A. and/or other countries. Microsoft

Windows Server, Windows XP and Windows Vista are trademarks of

Microsoft Corporation. PowerPC is a trademark of International Business

Machines Corporation. CompactFlash is a trademark of SanDisk

Corporation. ENERGY STAR is a U.S. registered mark. All other brand

and product names are registered trademarks or trademarks of their

respective companies.

This product was developed using the Tornado™Real Time Operating

System and Tools from Wind River Systems.

This product contains UFST™and MicroType®from Monotype Imaging

Inc.

About the Advanced Operation Guide

This guide has the following chapters:

1Paper Handling

This chapter explains how choose, handle and load paper.

2 Using the Operation Panel

This chapter explains how to use the operation panel to configure the

printer.

3Option

This chapter explains the options for this printer.

4 Computer Interface

This chapter explains the possible connections between the printer and

your computer.

Glossary

A Glossary of terms used is provided here.

Conventions in This Guide

This manual uses the following conventions.

Convention Description Example

Italic

Typeface

Used to emphasize a key word,

phrase or reference to additional

information.

Refer to Configuration Tool on page 3-9.

Bold Used to denote buttons on the

software.

To start printing, click OK.

Bracket Bold Used to denote operation panel

keys.

Printing resumes when [GO] is

pressed.

Note Used to provide additional or

useful information about a

function or feature.

Note Do not remove the toner

container from the carton until you

are ready to install it in the printer.

Important Used to provide important

information. IMPORTANT Take care not to touch

the transfer roller (black) during

cleaning.

Caution Cautions are statements that

suggest mechanical damage as

a result of an action.

CAUTION When pulling the paper, pull

it gently so as not to tear it. Torn pieces

of paper are difficult to remove and may

be easily overlooked, deterring the

paper jam recovery.

Warning Used to alert users to the

possibility of personal injury. WARNING If you ship the printer,

remove and pack the developer unit

and drum unit in a plastic bag and ship

them separately from the printer.

Paper Handling 1-1

1 Paper Handling

This chapter explains paper specifications for this printer.

General Guidelines 1-2

Selecting the Right Paper 1-4

Paper Type 1-11

1-2 Paper Handling

General Guidelines

The machine is designed to print on standard copier paper, but it can

also accept a variety of other types of paper within the limits specified

below.

Selection of the right paper is important. Using the wrong paper can

result in paper jams, curling, poor print quality, and paper waste, and in

extreme cases can damage the machine. The guidelines given below

will increase the productivity of your office by ensuring efficient, trouble-

free printing and reducing wear and tear on the machine.

Paper Availability

Most types of paper are compatible with a variety of machines. Paper

intended for xerographic copiers can also be used with the machine.

There are three general grades of paper: economy, standard, and

premium. The most significant difference between grades is the ease

with which they pass through the machine. This is affected by the

smoothness, size, and moisture content of the paper, and the way in

which the paper is cut. The higher the grade of paper you use, the less

risk there will be of paper jams and other problems, and the higher the

level of quality your printed output will reflect.

Differences between paper from different suppliers can also affect the

machine's performance. A high-quality printer cannot produce high-

quality results when the wrong paper is used. Low-priced paper is not

economical in the long run if it causes printing problems.

Paper in each grade is available in a range of basis weights (defined

later). The traditional standard weights are 60 to 120 g/m2(16 to 31.9b).

Paper Specifications

The following table summarizes the basic paper specifications. Details

are given on the following pages:

Note The manufacturer assumes no liability for problems that

occur when paper not satisfying these requirements is used.

Item Specifications

Weight Cassette: 60 to 120 g/m² (16 to 31.9 lb/ream)

MP tray: 60 to 220 g/m² (16 to 58.5 lb/ream)

Thickness 0.086 to 0.110mm (3.4 to 4.3 mils)

Dimensional

Accuracy

±0.7 mm (±0.0276 inches)

Squareness of

Corners

90±0.2°

Moisture Content 4 to 6%

Direction of Grain Long grain

Pulp Content 80% or more

Paper Handling 1-3

Minimum and Maximum Paper Sizes

The minimum and maximum paper sizes are as follows. For the paper

smaller than JIS B6, postcards, and envelopes, the MP tray must be

used.

105mm

(4-1/8 inches)

216mm (8-1/2 inches)

356mm (14 inches)

Minimum

Paper Size

Maximum

Paper Size

Paper cassette

70mm

(2-3/4 inches)

148mm (5-13/16 inches)

Minimum

Paper Size

Maximum

Paper Size

MP tray

216mm (8-1/2 inches)

148mm (5-13/16 inches)

356mm (14 inches)

Note The minimum paper size of the optional paper feeder (PF-

100) is 148 x 210 mm (5-13/16 x 8-5/16 inches).

1-4 Paper Handling

Selecting the Right Paper

This section describes the guidelines for selecting paper.

Condition

Avoid using paper that is bent at the edges, curled, dirty, torn,

embossed, or contaminated with lint, clay, or paper shreds.

Use of paper in these conditions can lead to illegible printing and paper

jams, and can shorten the life of the machine. In particular, avoid using

paper with a surface coating or other surface treatment. Paper should

have as smooth and even a surface as possible.

Composition

Do not use paper that has been surface-treated and contains plastic or

carbon. The heat of fusing can cause such paper to give off harmful

fumes.

Bond paper should contain at least 80% pulp. Not more than 20% of the

total paper content should consist of cotton or other fibers.

Paper Sizes

Cassettes and the MP Tray are available for the paper sizes shown

below. The dimensional tolerances are ±0.7mm for the length and width.

The angle at the corners must be 90° ±0.2°.

MP Tray:

Envelope Monarch, Envelope #10, Envelope #9, Envelope #6, Envelope

C5, Envelope DL, Legal, Letter, Statement, Oficio II, Executive, ISO A4,

ISO A5, ISO A6, Folio, ISO B5, JIS B5, JIS B6, Hagaki, Ofuku-Hagaki,

Youkei 2, Youkei 4, 16 kai, Custom (70 × 148 to 216 × 356mm (2-13/16 ×

5-13/16 to 8-1/2 × 14 inches))

Cassette:

Legal, Letter, Statement (only for machine’s paper cassette), Oficio II,

Executive, ISO A4, ISO A5, A6 (only for machine’s paper cassette),

Folio, ISO B5, JIS B5, Envelope C5, 16 kai, Custom (Paper Cassette:

105 × 148 to 216 × 356mm (4-1/8 × 5-13/16 to 8-1/2 × 14 inches), Paper

Feeder: 148 × 210 to 216 × 356mm (5-13/16 × 8-5/16 to 8-1/2 × 14

inches))

Smoothness

The paper should have a smooth, uncoated surface. Paper with a rough

or sandy surface can cause blank spaces in the printed output. Paper

that is too smooth can cause multiple feeding and fogging problems.

(Fogging is a gray background effect.)

Note If the length of custom paper is larger than 297mm (11-11/16

inches), the printer can be specified ISO A4, Oficio II, Folio, and

Legal as the standard paper size.

Note If the length of custom paper is larger than 297mm (11-11/16

inches), the printer can be specified ISO A4, Oficio II, Folio, and

Legal as the standard paper size.

Otros manuales para ECOSYS FS-1370DN

Tabla de contenidos

Otros manuales de Impresora de Kyocera

Kyocera

Kyocera ECOSYS FS-3920DN Manual de usuario

Kyocera

Kyocera ECOSYS FS-6525MFP Manual de instalación y funcionamiento

Kyocera

Kyocera ECOSYS FS-C5150DN Manual de usuario

Kyocera

Kyocera ECOSYS FS-6525MFP Manual de usuario

Kyocera

Kyocera FS-1300D Manual de usuario

Kyocera

Kyocera ECOSYS P5021cdn Manual de usuario

Kyocera

Kyocera FS-3040MFP Manual de usuario

Kyocera

Kyocera FS-5800C Manual de usuario

Kyocera

Kyocera ECOSYS FS-C5150DN Manual de usuario

Kyocera

Kyocera FS-2000DN Manual de usuario

Kyocera

Kyocera ECOSYS M6530cdn Manual de usuario

Kyocera

Kyocera FS-C5015N Guía de referencia rápida

Kyocera

Kyocera Mita FS-1900 Manual de usuario

Kyocera

Kyocera FS-1920 Ecosys Manual de usuario

Kyocera

Kyocera ECOSYS P4035dn Manual de usuario

Kyocera

Kyocera ECOSYS FS-3140MFP Manual de instalación y operación

Kyocera

Kyocera ECOSYS FS-C5150DN Manual de instalación y funcionamiento

Kyocera

Kyocera ECOSYS FS-1035MFP/DP Guía de referencia

Kyocera

Kyocera ECOSYS FS-3040MFP+ Manual de usuario

Kyocera

Kyocera Ecosys FS-6700 Manual de usuario

Kyocera

Kyocera ECOSYS P3060dn Manual de referencia

Kyocera

Kyocera ECOSYS FS-6525MFP Manual de usuario

Kyocera

Kyocera ECOSYS P4040dn Manual de usuario

Kyocera

Kyocera KM-1815 Manual de usuario

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Canon

Canon i70 Series Manual de usuario

Evolis

Evolis Elypso Manual de usuario

Canon

Canon LASER SHOT LBP-1210 Manual de usuario

Samsung

Samsung BIXOLON SRP-350plusF Manual de usuario

Canon

Canon PIXMA PRO-1 Series Manual de usuario

Canon

Canon PIXMA G3560 Guía de configuración

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Epson

Epson ET-7750 Instrucciones de funcionamiento

Canon

Canon CLBR 460ps Manual de usuario

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Epson

Epson SC-F7100 series Manual de usuario

Epson

Epson Stylus C40UX Manual de usuario

Canon

Canon imagePASS-A2 Manual de usuario

Canon

Canon S820D Manual de usuario

IRA3D

IRA3D POETRY4 Manual de usuario
