KYMCO PEOPLE S 125 Manual de usuario

KWANG YANG MOTOR CO., LTD.

OWNER’S MANUAL – PEOPLE S 50 / 125 / 200

Dear KYMCO Scooter Users:

Thank you for purchasing this KYMCO scooter and welcome to the

family of KYMCO scooter riders. To enjoy safer and more pleasant

riding, become thoroughly familiar with this owner's manual before you

ride the scooter. Your safety depends not only on your own alertness

and familiarity with the scooter but also the scooter’s mechanical

condition. A pre-ride inspection before every outing and regular

maintenance are essential. The quality of each KYMCO scooter is

guaranteed.

NOTE: 1. The information and specifications stated in this manual are for

reference only and subject to change without notice.

2. When starting the engine, the battery must be installed to

facilitate starting and increase the engine performance.

1. ENSURING A SAFE RIDE 01

RIDING GEAR 01

RIDINGMETHOD 02

CARRYING GOODS 02

2.PARTSLOCATION 03

VIN 06

ENGINE & KEY NUMBERS 07

3. OPERATING INSTRUCTIONS 08

IGNITION SWITCH & HANDLEBAR LOCK 08

ELECTRIC STARTER BUTTON 09

HEADLIGHT SWITCH 09

HEADLIGHT DIMMER SWITCH 10

PASSING SIGNAL SWITCH 10

HORN BUTTON & TURN SIGNAL SWITCH 11

SEAT LOCK / MET-IN BOX 12

HELMET BUCKLE 12

INSTRUMENTS & INDICATORS 13

OPERATION INSTRUCTIONS FOR

MULTI-METER 15

CELLPHONESOCKET 17

REAR SHOCKS 17

4. PRE RIDE INSPECTION 18

ADVANCE INSPECTION 18

ENGINE OIL LEVEL INSPECTION / REFILL 18

FRONT LUGGAGE BOX 19

TIRE INSPECTION 20

FUEL LEVEL INSPECTION / REFILLING 22

STEERING HANDLEBAR 23

INSTRUMENT LIGHTS INSPECTION 23

BRAKE FLUID LEVEL INSPECTION 24

BRAKE PAD WEAR 25

BRAKE SHOE WEAR 25

BRAKE LEVER FREE PLAY INSPECTION

ANDADJUSTMENT 26

HORN / LIGHTS INPECTION 28

FRONT / REAR SHOCK ABSORBER

INSPECTION 29

BRAKE PERFORMANCE INSPECTION 29

REAR VIEW MIRROR ANGLE CHECK 29

LICENSE PLATE CHECK 29

REFLECTOR CHECK 29

PREVIOUS DAMAGE INSPECTION 29

LUBRICATION POINT CHECK 29

5. ENGINE STARTING METHOD 30

TURN THE IGNITION SWITCH “ON” 30

LOCK THE REAR WHEEL 30

USING THE ELECTRIC STARTER BUTTON 31

STARTING WITH THE KICK PEDAL 32

6. NORMAL RIDING METHOD 33

STARTING THE ENGINE 33

REBOUNDING THE MAIN STAND 33

CORRECT SITTING POSITION 34

ROTATE THE THROTTLE GRIP 34

7. PRECAUTIONS FOR RIDING 35

CORRECT RIDING 35

SPEEDCONTROL 35

PROPER RIDING & ENGINE LIFE 36

BRAKING WITH FRONT & REAR LEVERS 36

DO NOT MAKE SUDDEN STOPS/TURNS 37

RIDING IN RAIN – USE EXTRA CAUTION 38

8. HOW TO STOP RIDING 39

WHEN APPROACHING A PARKING SPOT 39

WHEN THE SCOOTER HAS STOPPED 39

PARKING 40

TABLE OF CONTENTS

HANDLEBAR 40

9. EASY MAINTENANCE 41

AIR FILTER CLEANING/REPLACEMENT 41

CLEANING EXTERIOR SURFACES 43

BATTERY 44

FUSE REPLACEMENT 46

ENGINE OIL CHANGE 48

TRANSMISSION GEAR OIL 49

SPARK PLUG INSPECTION 50

BRAKE FLUID LEVEL INSPECTION 51

RUBBER COVER INSPECTION 51

10. IMPORTANT NOTICES 52

ENGINE FAILS TO START/STOPS RUNNING 52

IN CASE OF BREAKDOWN 52

PERIODIC INSPECTION & MAINTENANCE

SCHEDULE 53

SPECIFICATIONS (50cc) 54

SPECIFICATIONS (125cc) 55

SPECIFICATIONS (200cc) 56

11. KYMCO CLEAN AIR 57

- 1 -

1. ENSURING A SAFE RIDE

RIDING GEAR

•In order to ensure a safe ride be sure to relax and wear

comfortable clothing.

•Observe all traffic laws and be careful.

1) Always wear a helmet and make sure it is fastened.

2) Arrange your clothing – fasten shirt cuffs to prevent

them from hooking the brake lever.

3) Wear low healed shoes.

4) When riding, use both hands to grasp the handlebar.

It is very dangerous to hold the handlebar with just

one hand.

•A scooter rider should NEVER wear loose clothing

•To avoid the risk of being burned, DO NOT touch the

exhaust muffler during or up to 10 minutes after riding.

•When parking the scooter, keep it away from dry grass or

any other flammable objects or materials.

- 2 -

RIDING METHOD

•Safety on a two-wheeled vehicle is influence by seating

position. The rider should sit on the central part of the

seat cushion. Should the rider sit on the rear part of the seat,

the load of the front wheel will decrease, the handlebars

could swing therefore putting the rider in danger.

•When making a turn, it will be easier for the rider to steer

the scooter by leaning the body inward slightly. Failure

to do this could result in a loss of balance.

•When riding on a damaged or gravel road be sure to slow

down your speed and hold the handlebars tightly.

CARRYING GOODS

•Maintain proper posture at all times while operating the scooter.

•The handlebars will feel different when carrying goods on

the scooter. Overloading may cause the handlebars to swing.

Do not exceed maximum loading capacity.

1) Maximum loading capacity of the met-in box is 10 kg.

2) Maximum loading capacity of the rear carrier is 5 kg.

3) Maximum loading capacity of the front tool box is 1.5kg.

- 3 -

2. PARTS LOCATION

(1) Headlight Switch & Electric Starter Button– pg 9

(2) Speedometer – pg 13

(3) Main Stand

(4) Ignition Switch – pg 8

(5) Helmet Holder – pg 12

(6) Battery / Fuse – pg 45 & 46

(7) Muffler

(8) Front Luggage Box – pg 19

- 4 -

(1) Seat Lock – pg 12

(2) Fuel Fill Cap – pg 22

(3) Met-in Box – pg 12

(4) Helmet Holder – pg 12

(5) Centre Hook – pg 19

(6) Side Stand

(7) Headlight Dimmer Switch – pg 10

Passing Signal Switch – pg 10

Turn Signal Switch – pg 11

Horn Button – pg 11

(8) Kick Starter Pedal – pg 31

(9) Air Filter Housing – pg 41

- 5 -

(1) Headlight

(2) Left Side View Mirror

(3) Rear Brake Lever

(4) Front Left Turn Signal Light

(5) Front Left Shocks

(6) Right Side View Mirror

(7) Front Brake Lever

(8) Front Right Turn Signal Light

(9) Front Right Shocks
