SICOM3005A Switching Serial Port Server
Hardware Installation Manual
Publication Date: May. 2014
Version: V0.1
SICOM3005A Switching Serial Port Server
Hardware Installation Manual
Disclaimer: Kyland Technology Co., Ltd. tries to keep the content of this manual as
accurate and as updated as possible. This document is not guaranteed to be error-free, and
we reserve the right to amend it without notice to users.
All rights reserved.
No part of this documentation may be excerpted, reproduced, translated, annotated or
duplicated, in any form or by any means without the prior written permission of KYLAND
Corporation.
Copyright © 2014 Kyland Technology Co., Ltd.
Notice for Safety Operation
The product performs reliably as long as it is used according to the guidance. Artificial
damage or destruction of the device should be avoided. Before using the device, read this
notice carefully for personal and equipment safety. Please keep the manual for further
reference. Kyland is not liable to any personal or equipment damage caused by violation of
this notice.
Do not place the device near water sources or damp areas. Keep the ambient relative
humidity within the range from 5% to 95% (non-condensing).
Do not place the device in an environment with high magnetic field, strong shock, or high
temperature. Keep the working and storage temperatures within the allowed range.
Install and place the device securely and firmly.
Please keep the device clean; if necessary, wipe it with a soft cotton cloth.
Do not place any irrelevant materials on the device or cables. Ensure adequate heat
dissipation and tidy cable layout without knots.
Wear antistatic gloves or take other protective measures when operating the device.
Avoid any exposed metal wires because they may be oxidized or electrified.
Install the device in accordance with related national and local regulations.
Before power-on, make sure the power supply is within the allowed range of the device.
High voltage may damage the device.
Power connectors and other connectors should be firmly interconnected.
Do not plug in or out the power supply with wet hands. When the device is powered on,
do not touch the device or any parts with wet hands.
Before operating a device connected to a power cable, remove all jewelry (such as rings,
bracelets, watches, and necklaces) or any other metal objects, because they may cause
electric shock or burns.
Do not operate the device or connect or disconnect cables during an electrical storm.
Use compatible connectors and cables. If you are not sure, contact our sales or
technical support personnel for confirmation.
Do not disassemble the device by yourself. When an anomaly occurs, contact our sales
or technical support personnel.
If any part is lost, contact our sales or technical support personnel to purchase the
substitute. Do not purchase parts from other channels.
Dispose of the device in accordance with relevant national provisions, preventing
environmental pollution.
In the following cases, please immediately shut down your power supply and contact your
Kyland representative:
Water gets into the equipment.
Equipment damage or shell damage.
Equipment operation or performance has abnormally changed.
The equipment emits odor, smoke or abnormal noise.
I
Contents
1Product Overview......................................................................................................1
2Structure and Interface .............................................................................................2
2.1 Front Panel...........................................................................................................2
2.2 Top Panel .............................................................................................................3
3Mounting...................................................................................................................4
3.1 Dimension Drawing (Unit: mm).............................................................................4
3.2 Mounting Modes and Steps..................................................................................5
3.2.1DIN-rail Mounting ...........................................................................................5
3.2.2Panel Mounting ..............................................................................................7
4Cable Connection .....................................................................................................9
4.1 10/100Base-T(X) Ethernet Port ............................................................................9
4.2 100Base-FX Ethernet Port..................................................................................10
4.3 RS232/485/422 Serial Port.................................................................................11
4.4 Console Port.......................................................................................................12
4.5 Grounding...........................................................................................................13
4.6 Power Terminal Block.........................................................................................13
4.7 Alarm Terminal Block..........................................................................................15
5Reset ......................................................................................................................17
6LEDs.......................................................................................................................18
7Access....................................................................................................................20
7.1 Access through Console Port .............................................................................21
7.2 Access through Telnet........................................................................................22
7.3Access through Web...........................................................................................23
8Basic Features and Specifications..........................................................................24
Product Overview
1
1 Product Overview
SICOM3005A includes a series of access and aggregation devices tailored specifically for
power. Equipped with dual systems, the series devices can serve as switches and serial port
server. The device is easy to install, and it occupies only a small space. A switch or serial
port server for network access does not need to be separately purchased, greatly reducing
the power consumption and cost. SICOM3005A supports mutual conversion between
RS232/485/422 and Ethernet data with the serial port server system. The device supports
data transmission over network cable.
SICOM3005A provides powerful network management functions. The device can be
managed through CLI, Telnet, Web, SNMP-based network management software.
SICOM3005A supports DIN rail mounting and panel mounting. It provides up to two
100Base-FX Ethernet ports, four 10/100Base-T(X) Ethernet ports, and four RS232/485/422
serial ports. For details, see the following table.
Table 1 SICOM3005A Models
Model
Port
Power Supply
100Base-FX
Ethernet port
10/100Base-T(X)
Ethernet port
RS232/485/
422 serial
port
SICOM3005A-2S4T-4D
2
4
4
L5 (12DCW, redundant)
L2 (24DCW, redundant)
HV (220AC/DCW:
DC: redundant
AC: single-PWR1)
SICOM3005A-2M4T-4D
2
4
4
SICOM3005A-2S4T
2
4
--
SICOM3005A-2M4T
2
4
--
SICOM3005A-6T-4D
--
6
4
SICOM3005A-6T
--
6
--
NOTE:
We reserve the right to amend the product information listed in the table above without notice.
To obtain the latest information, contact our sales or technical support personnel.
Structure and Interface
2
2 Structure and Interface
CAUTION:
It is recommended to purchase the port dustproof shield (optional) to keep ports clean and ensure
device performance.
2.1 Front Panel
Figure 1 Front Panel
Table 2 Description of Front Panel
No.
Identifier
Description
(1)
PWR1
Power 1 LED
PWR2
Power 2 LED
Run1
Switch Running LED
Run2
Serial port server Running LED
Ring
Ring LED
Alarm
Alarm LED
Structure and Interface
3
5-6
100Base-FX Ethernet port LEDs
(2)
5-6 , TX / RX
two 100Base-FX Ethernet ports
(3)
1-4
four 10/100Base-T(X) Ethernet ports
(4)
--
10/100Base-T(X) Ethernet port speed LED (yellow)
(5)
--
10/100Base-T(X) Ethernet port connection status LED (green)
(6)
Reset
Reset button
(7)
D1-D4
four serial ports and serial port LEDS (upper LED indicates the
status of receiving, while lower LED indicates the status of
transmitting)
2.2 Top Panel
Figure 2 Top Panel
Table 3 Description of the Top Panel
No.
Identifier
Description
(1)
--
Grounding screw
(2)
PWR1 / PWR2
Power terminal block
(3)
FAULT
Alarm terminal block
(4)
Console
Console port
Mounting
4
3 Mounting
3.1 Dimension Drawing (Unit: mm)
Figure 3 Dimensions for DIN-rail Mounting
Figure 4 Dimensions for Panel Mounting
Mounting
5
CAUTION:
As part of the heat dissipation system, the device housing becomes hot during operation.
Please use caution when coming in contact and avoid covering the device housing when the
device is running.
The figures in this chapter are only for reference.
3.2 Mounting Modes and Steps
The device supports both DIN-rail mounting and panel mounting. Before installation, make
sure that the following requirements are met.
1) Environment: temperature (-40℃to 75℃), ambient relative humidity (5% to 95%,
non-condensing)
2) Power requirement: The power input is within the voltage range of the device.
3) Grounding resistance: <5
4) No direct sunlight, distant from heat source and areas with strong electromagnetic
interference.
3.2.1 DIN-rail Mounting
Mounting
Step 1: Select the mounting position for the device and guarantee adequate space and heat
dissipation for it (dimensions: 66mm×135mm×107.5mm).
Step 2: Insert the connecting seat onto the top of the DIN rail, and push the bottom of the
device inward and upward to ensure the DIN rail fits in the connecting seat. Make
sure the device is firmly installed on the DIN rail, as shown in the following figure.
