Kwikset 62541/01 Manual de usuario

23/8" (60 mm)

23/4" (70 mm)

Backset •

Centerline

13/8" (35 mm)

13/4" (44 mm)

21/4" (57 mm)

Face of the doorEdge of the door

Fold

Additional tools

(if needed)

wood block

Installation Guide

If drilling a new door, use

the supplied template and

the complete door drilling

instructions

Parts in the boxRequired tools

*Call Kwikset to order

a service kit for 21/4"

(57 mm) thick doors.

Latch Strike

Screws

Keys Knobs

SmartKey® tool

(SmartKey locks only)

Not required for all applications

23/8" (60 mm)

23/4" (70 mm)

13/8"–21/4"*

35 mm–57 mm*

21/8"

54 mm

25 mm

Do not remove

screws!

Hold the latch in front of the door hole, with

the latch face lush against the door edge.

If the latch holes are centered in the door hole,

no adjustment is required. Proceed to step 4.

If the latch holes are NOT centered, adjust

latch. See “Latch Adjustment” (step 3C).

Latch Adjustment (only if needed)

Drilling Template

Move the pin to

extend the latch.

Template is only needed if a new hole must be drilled in the door.

62541 / 01

notcentered

centered

Instructions continue on reverse

A E

Twist the side

with the holes.

counter-clockwise

Pull to

separate

knobs.

Set knobs aside until step 5.

Prepare door and check dimensions

Disconnect knobs (if pre-assembled)

Adjust the backset of the latch (if needed)

Do not use harsh chemicals or

solvents to clean your lock.

Mechanical lock

Use a damp cloth to wipe away

any excess dirt or debris.

Electronic lock

Use a damp cloth on the lock’s exterior to wipe

away any excess dirt or debris. Use a dry cloth to

clean interior components.

Door edge NOT

chiseled

Door edge chiseled

WARNING: This Manufacturer advises that no lock can provide complete security by itself. This lock may be

defeated by forcible or technical means, or evaded by entry elsewhere on the property. No lock can substitute

for caution, awareness of your environment, and common sense. Builder’s hardware is available in multiple

performance grades to suit the application. In order to enhance security and reduce risk, you should consult a

qualiied locksmith or other security professional.

If small bolt of latch enters strike hole, reposition strike.

small bolt in

strike hole

small bolt NOT

in strike hole

wood block

slant of latch bolt faces door frame

door frame

Remove plates

Install drive-in collar

C (2x)

If latch is loose in the strike, adjust

the strike tab so it grips the latch bolt

better when the door is closed.

tab

Close door, test latch operation and make adjustments as needed:

exterior

Press latch bolt to

install exterior knob.

1. Twist counter-clockwise2. Push while twisting 3. Twist clockwise

Push up on knob while

tightening screws to keep latch

horizontal and centered.

Align round

edges.

To catch screws:

interior

OK if lipped

D (2x)

B C

Install latch

Install knobs

Install strike on door frame
