KUDOS HYNC Series Manual
KuDos Mechanical Co., Ltd.
Safe Operation & Maintenance Instructions
Hydraulic Nut Splitter
HYNC Double Chisel Series
Version: 07/2014
Hydraulic Compression Heads are carefully inspected for quality
and tested for safety. We follow ISO 9001: 2008/ ISO 14001: 2004/ IECQ QC
080001/ OHSAS 18001: 2007 & CE Standards
ATTENTION!
Safe Operation & Maintenance Instructions must be followed.
Table of Contents
Table of Contents………………………………….……………….1
Safety Instructions…………………………………………………2
Table of Components…………….………………………………3
Diagram of Components ……………………………………….4
Product Description………………………………………………..5
Limited Lifetime Warranty……………………………………6
Trouble–Shooting………………………………………………...7
Maintenance……………………………………………………….8
Model Specifications.……………………………… ………9
Accessories……………………………………………………… 10
Operating Instructions……………………………………………11
Chisel Replacement……………………………………………13
Manufacture & Quality Certificate
1 KuDos Mechanical Co., Ltd.
Safety Instructions
■ Follow ALL instructions to ensure safety.
WARNING
ATTENTION
Read all information regarding your
hydraulic power source and be
familiar with its operation.
To avoid injury keep hands and feet
away from the tool and workpiece
during operation.
Do not use this tool on glass, plastic,
wood or any other materials which
could shatter. Do not exceed
equipment ratings.
Always wear safety goggles when
operating this product. Projectiles or
hydraulic fluid can cause serious
injuries.
Thank you for using KuDos® products. This manual must be read
carefully prior to operating this product. Special attention should be paid
to the section “Safety Instructions”. Damages and injuries caused by
improper use of this product are NOT included in our warranty. We
would like to remind you to work safely and to keep this manual on hand.
2 KuDos Mechanical Co., Ltd.
Table of Components
Part No.
Qty.
Part Name
1
1
Cylinder Cup
2
1
Oil Seal
3
1
Screw
4
1
Piston
5
1
Spring
6
1
Key
7
1
Chisel
8
1
Screw
9
1
Main Body
10
1
Chisel
11
1
Screw
3 KuDos Mechanical Co., Ltd.
Diagram of Components
4 KuDos Mechanical Co., Ltd.
Product Description
■ Subassembly
■ C
haracteristics and Functions
FEATURES:
1. Easy to Use and Unique angle head design with double blades for a variety of applications
2. Single Action Cylinder with hydraulic advance with spring return.
3. Two blades design for easy to use and time saving.
4. Closed type head design to avoid any slip caused when splitting the nuts.
5. Operated by any hydraulic pump with related oil pressure of 700bar/10,000psi.
Main Body
Coupler
Chisel
Cylinder
Spring
Piston
Chisel
5 KuDos Mechanical Co., Ltd.
Limited Lifetime Warranty
■Kudos hydraulic products are warrantied against defects in materials and
workmanship for the life of the product. This is defined as that point in time
when the product no longer functions due to normal wear.
■This warranty is subject to the following exclusions and limitations:
1. This warranty does not cover damages to products which are not
installed, operated, used and maintained in accordance with written
instructions.
2. This warranty does not cover products that have been worn out,
damaged by improper storage, damaged or otherwise altered, or from
disassembly or attempted disassembly by parties other than KuDos® or
its authorized service representatives.
3. This warranty does not cover damages caused by the use of components
not manufactured or authorized by KuDos® , acts of God, accidents, or
use in a manner for which they are not intended.
■KuDos® 's liability in all cases is limited to, and shall not exceed, the
purchase price paid. Kudos shall not be liable to any buyer for
consequential or incidental damages of any kind.
■Batteries, chargers, electric motors, gas engines and cutting blades sold
with Kudos products are not covered by this warranty.All electric motors
and gas engines are seperately warrantied by the manufacturer.
■Receipt and warranty card are required for warranty services.
■If the tool is found to be defective, in our sole judgement, Kudos will either
repair or replace the defective product or part.
■All revisions in warranty policy and product informations will be
included in future versions of our manuals. Copies of this warranty are
available from the factory upon request.
6 KuDos Mechanical Co., Ltd.
Trouble-Shooting
■Failure to split nuts:
4. The hardness or size of applied nuts might exceed equipment ratings.
4. The chisel is worn or damaged and must be replaced. Splitting nuts with
a worn or damaged chisel might cause property damage or even personal
injury.
4. The pump output might be insufficient.
4. Internal leakages of hydraulic fluid: Contact your KuDos® service
representatives.
■Insufficient operating pressure: (less than 700bar or 10,000psi)
1. Secure the couplers properly to prevent restricted oil flow.
2. Inspect the pump output for possible pressure losses. Do not use your
fingers when looking for fluid leaks.
3. Test the pump to ensure it reaches 700 bar pressure. Never adjust the
pump relief valve over 700 bar.
■Replace any worn or damaged parts immediately, especially the
chisels. Do not use parts not supplied by Kudos.
■Contact KuDos® service representatives to request parts or for
problems not shown above.
■Do NOT attempt to disassemble or repair the product.
■ Kudos hydraulic tools must be serviced by a qualified technician.
Contact your Kudos® representative for more information.
7 KuDos Mechanical Co., Ltd.
Maintenance
■Keep the tool head free of dirt and metal chips. Use a lubricant to clean the
tool when necessary.
■Routine application of rust preventive oil to the product is needed. Avoid
bringing the tool into contact with water or solvents.
■Routine renewal of pump oil is required. Particles mixed in the pump oil is
the most common cause of product failure.
■Do NOT lift the tool by the hydraulic hose or couplers, or let the tool drop to
the ground or into the carrying case.
■Do NOT keep this product in places with high temperatures, high humidity,
or direct sunlight.
■Suggested working temperatures：-10°C ~ 40°C. Check hydraulic fluid
specifications.
■Hydraulic fluid temperatures over 65°C might soften packings and seals and
cause fluid leaks.
■The hydraulic fluid pressure should only be adjusted by KuDos® service
representatives.
■Inform KuDos® authorized distributors in case of any abnormalities or
malfunctions of the product.
■DO NOT DISASSEMBLE OR ATTEMPT TO REPAIR THIS TOOL.
ATTENTION
• Release pressure from the system before
servicing.
• Kudos hydraulic tools must be serviced by a
qualified technician.
KuDos Mechanical Co., Ltd 8
Model Specifications
9 KuDos Mechanical Co., Ltd.
