USER MANUAL

MODEL:

KT‑107S

Touch Panel

Kramer Electronics Ltd.

KT‑107S –Contents

Contents

Introduction 1

Getting Started 1

Overview 2

Typical Applications 3

Defining the KT‑107S 4

KT‑107S Touch Panel 4

KT‑107S Tabletop Mount 5

KT‑107S On-Wall Mount 7

Mounting the KT‑107S 8

Mounting the KT‑107S on a Table 8

Mounting the KT‑107S on a Wall 12

Connecting Options 16

Setting up the KT‑107S 17

Initial Setup 17

Additional KT‑107S Important Functions 27

Upgrading the Firmware 28

Setup your PC for Firmware Upgrade 28

Install the RockChip Driver Assistant 29

Prepare the KT‑107S for Firmware Upgrade 30

Upgrade the Firmware via PC 30

Technical Specifications 34

Kramer Electronics Ltd.

KT‑107S –Introduction

Introduction

Welcome to Kramer Electronics! Since 1981, Kramer Electronics has been providing a world

of unique, creative, and affordable solutions to the vast range of problems that confront the

video, audio, presentation, and broadcasting professional on a daily basis. In recent years, we

have redesigned and upgraded most of our line, making the best even better!

Getting Started

We recommend that you:

•Unpack the equipment carefully and save the original box and packaging materials for

possible future shipment.

•Review the contents of this user manual.

Go to www.kramerav.com/downloads/KT‑107S to check for up-to-date user manuals,

application programs, and to check if firmware upgrades are available (where appropriate).

Achieving the Best Performance

•Use only good quality connection cables (we recommend Kramer high-performance,

high-resolution cables) to avoid interference, deterioration in signal quality due to poor

matching, and elevated noise levels (often associated with low quality cables).

•Do not secure the cables in tight bundles or roll the slack into tight coils.

•Avoid interference from neighboring electrical appliances that may adversely influence

signal quality.

•Position your Kramer KT‑107S away from moisture, excessive sunlight and dust.

This equipment is to be used only inside a building.

Safety Instructions

Caution: There are no operator serviceable parts inside the unit

Warning: Use only the Kramer Electronics power supply that is provided with the unit

Warning: Disconnect the power and unplug the unit from the wall before installing

Recycling Kramer Products

The Waste Electrical and Electronic Equipment (WEEE) Directive 2002/96/EC aims to reduce

the amount of WEEE sent for disposal to landfill or incineration by requiring it to be collected

and recycled. To comply with the WEEE Directive, Kramer Electronics has made

arrangements with the European Advanced Recycling Network (EARN) and will cover any

costs of treatment, recycling and recovery of waste Kramer Electronics branded equipment on

Kramer Electronics Ltd.

KT‑107S –Introduction

arrival at the EARN facility. For details of Kramer’s recycling arrangements in your particular

country go to our recycling pages at www.kramerav.com/support/recycling.

Overview

Congratulations on purchasing your Kramer KT‑107S Touch Panel.

KT‑107S is a 7-inch IPS multi-touch, powerful Touch Panel with 1280x800 resolution. The

elegantly designed portable Touch Panel can be deployed either on a table or on the wall.

The KT‑107S supports wired Power over Ethernet (PoE).

To ensure easy installation with elegant wiring and secured mounting, the Touch Panel

comes with table and wall mounts, a USB cable and a power supply unit.

The KT‑107S is an Android-based Touch Panel that is ideal for any 24/7 Kramer-supported

commercial AV or control application and features a user-friendly, fully customizable graphical

user interface configured by Kramer software.

The KT‑107S provides exceptional quality, advanced and user-friendly operation, and

high-level security options.

Exceptional Quality

•Elegant Design –Smooth integration with room furniture, either on tables or walls, with

flexible panel cabling and locking design options.

•Superior User Experience –IPS 1280x800 high-resolution screen with ±85° horizontal

and vertical wide viewing angles, built-in lighting sensor for auto-adaptable brightness,

advanced 10 multi-touch points, and 2-finger gesture capabilities.

•Powerful Processing –Quad-core CPU, GPU, 2GB RAM, 16GB ROM processing

performance for smoothly running complicated media- and graphics-rich applications,

encoding and decoding H.265 video and audio streams.

•Flexible Services –Advanced Android 6.0 Operating System with rich Kramer and

market-available software applications offered via cloud/store, such as K-Touch Control.

Advanced and User-friendly Operation

•Easy Installation –Powering and connectivity via a single Ethernet cable.

•Flexible Mounting –Including table and wall mounts that fit into standard market-

available 2-Gang in-wall junction boxes.

•Connectivity –Connection to USB peripheral devices for either table or wall-mount

installations using the included USB cable.

•Versatile Powering Options –PoE, PSU and battery.

•Auto Sensing –Optimized performance and operation according to automatically

detected LAN speed.

•Firmware Upgrade –Via USB port.

Kramer Electronics Ltd.

KT‑107S –Introduction

Security

•Secured Deployment –Flexible locking options to prevent unwanted panel-mount

removal, elegantly designed to remain out of site.

•Secured Operation –Highly secured operation of applications such as auto boot start for

a selected application, password protected exit, hidden control buttons and so on.

Typical Applications

The KT‑107S is ideal for the following typical applications:

•Control user interface in meeting and conference rooms, boardrooms, and auditoriums.

•Presentation of room scheduling.

Kramer Electronics Ltd.

KT‑107S –Defining the KT‑107S

Defining the KT‑107S

This section defines the KT‑107S Touch Panel, the tabletop and the on-wall mounts.

KT‑107S Touch Panel

Figure 1: KT‑107S Touch Panel Front, Rear, and Lower Side view

Feature

Function

Hidden Reset

Button

Located on top-side. Insert a pin and hold for a few seconds to reset KT‑107S.

Light Sensor

Automatically adjusts the screen brightness according to the room lighting

conditions.

Activity RGB

LED

Flashes green when charging the battery and lights green when powered on.

Speakers

To output the sound.

Control Button

Press and hold (for 2 seconds) to open the pop-up menu which lets you power

down the unit, reboot it or return to the Home-page. The control button is

password protected (default: Kramer).

When connected to a power source, the unit reboots when Power off is

selected.

Tabletop Mount

Connector

For connecting to the tabletop mount.

Cover

Covers the wall mount connections and power button.

Power Button

Press to power on the KT‑107S.

When powered, press briefly to open the pop-up menu and power down the

device, reboot it or return to the Home-page.

This button can also be used for firmware upgrade.

Firmware-

Upgrade Button

Used for firmware upgrade (also can be used to increase KT‑107S speaker

volume).

Micro USB Port

For connecting to an adjacent on-wall USB device and for firmware upgrade.

Flat Cable

Connector

For connecting to the on-wall mount unit.

Connecting

Holes

For connecting to the tabletop mount or the panel mount plate.

To prevent potential damage to the Touch Panel, use only Kramer supplied

screws and mounts.

Kramer Electronics Ltd.

KT‑107S –Defining the KT‑107S

KT‑107S Tabletop Mount

This section defines the KT‑107S tabletop mount.

Figure 2: Tabletop Mount Front View

Feature

Function

Screw Openings (x2)

For attaching the Touch Panel to the tabletop mount using the supplied

M2x4 screws (see Mounting the KT‑107S on a Table on page 8).

M5x60 Secure Screw

Opening

For safely securing the tabletop mount to the table from underneath

(see Figure 7).

Kramer Electronics Ltd.

KT‑107S –Defining the KT‑107S

Figure 3: Tabletop Mount Rear View

Feature

Function

Micro USB Port

For connecting to an external USB device, such as a headset or a

memory disk.

Connect external devices only with the OTG type USB cable (supplied).

Regular USB cables (such as a smartphone data cable) can be used to

connect the device to a PC (for file transfer, and so on).

Power 2-pin Terminal

Block Connector

Connect to a power adapter and to the mains.

Cable Opening

Knock-out area

Cable pass-through area.

Screw Openings with

Rubber Covers (x2)

For covering the M2x4 screws that are used for attaching the KT‑107S

to the tabletop mount (see Mounting the KT‑107S on a Table on

page 8).

Kensington Locker Port

For securely connecting the tabletop mount to a table with a

Kensington-compatible locker.

PoE Ethernet RJ-45

Port

Connect to the PoE-enabled Ethernet cable.

Cable Cover with

Opening

Hides the ports and includes an opening for passing connected cables

over the table.

Solid Cable Cover

Hides the ports when passing connected cables under the table.

Kramer Electronics Ltd.

KT‑107S –Defining the KT‑107S

KT‑107S On-Wall Mount

This section defines the KT‑107S on-wall mount.

Figure 4: KT‑107S Touch Panel Front Panel

Feature

Function

Groove (x4)

For hanging the panel mount plate (attached to KT‑107S) on a wall.

Flat Cable Connector

Connect to the rear side of the KT‑107S using the supplied flat cable.

Passes the Ethernet signal and power to the KT‑107S.

Screw Opening (x8)

For attaching the on-wall mount unit to a standard in-wall junction box

(various holes fit different standard in-wall junction boxes), see

Mounting the KT‑107S on a Wall on page 12.

Unit Cable Opening

Pass the supplied right-angle OTG USB cable through the opening to

connect to the rear side of the KT‑107S.

Indication Arrows

Top side up; shows the correct direction for mounting the on-wall mount

unit and for hanging the Touch Panel.

Screw Opening (x2)

For attaching the on-wall mount unit to a standard in-wall junction box

(various holes fit different standard in-wall junction boxes.

Indication Arrows

Top side up; shows the correct direction for hanging the panel mount

plate.

Plate Cable Opening

Fits the opening on the on-wall mount unit. Pass the right-angle OTG

USB cable through the opening to connect to the rear side of the

KT‑107S.

Screw Opening (x4)

Attach the KT‑107S to the panel mount plate using the supplied screws.

Cable Opening

Pass the cables through the opening to connect to the rear side of the

KT‑107S.

Tab (x4)

For hanging the KT‑107S with the attached panel mount plate on the

on-wall mount unit.

Kramer Electronics Ltd.

KT‑107S –Mounting the KT‑107S

Mounting the KT‑107S

The KT‑107S can be placed on a table or mounted on a wall.

Always be careful when attaching or removing the Touch Panel from either mount.

Mounting the KT‑107S on a Table

•Mount on a table using one of the following options:

•Portable Mount: Place the tabletop mount on the table. Connected cables remain

visible and the table remains intact.

•Secure Mount: Bolt the tabletop mount into the table. Connected cables are hidden

through a hole in the table.

Preparing the Table for a Secure Mount

To install the KT‑107S on a secure mount, go to Installing KT‑107S on the Tabletop Mount

on page 11.

To mount KT‑107S securely on a table, prepare the table as follows:

•Drill a hole in the table to fit the M5x60 screw used for securing the tabletop mount to the

table.

•Cut an opening in the table if you need to pass the cables from underneath.

The thickness of the table should be 76.2mm (3”) or less.

Correctly measure the location of the M5x60 screw holes and the cable pass-through opening

using the cut-out template available on the Kramer website at

www.kramerav.com/downloads/KT‑107S.

Figure 5: Cut-Out Dimensions (image not to scale)

Otros manuales para KT-107S

Tabla de contenidos

Otros manuales de Panel táctil de Kramer

Kramer

Kramer KT-208 Manual de usuario

Kramer

Kramer KT-107S Manual de usuario

Kramer

Kramer KT-2010 Manual de usuario

Kramer

Kramer KT-107SC Manual de usuario

Kramer

Kramer KT-10 Manual de usuario

Kramer

Kramer KT-107 Manual de usuario

Kramer

Kramer KT-208 Manual de usuario

Kramer

Kramer KT-10 Manual de usuario

Kramer

Kramer KT-205WM Manual de usuario

Kramer

Kramer KronoMeet KT-1010SC Manual de usuario

Kramer

Kramer KT-7 Manual de usuario

Kramer

Kramer KT-1010 Manual de usuario

Kramer

Kramer KT-2010 Manual de usuario

Kramer

Kramer KT-1010 Manual de usuario

Kramer

Kramer KT-107 Manual de usuario

Kramer

Kramer KT-205WM Manual de usuario

Kramer

Kramer KT-205WM Manual de usuario

Kramer

Kramer KT-107 Manual de usuario

Manuales populares de Panel táctil de otras marcas

FlowLine

FlowLine Data loop Manual de usuario

ALPEX

ALPEX AEx-8 P Series Manual de usuario

Ltech

Ltech E5S Manual de usuario

Harman

Harman AMX MODERO S MSD-701-L2 Manual de usuario

Acnodes

Acnodes PC 1150 Manual de usuario

AIS

AIS IP10IA99 series Manual de usuario

IBASE Technology

IBASE Technology ASTUT-152-RE1S Manual de usuario

YASKAWA

YASKAWA TP 610C Manual de usuario

B&R

B&R Power Panel C Series Manual de usuario

Beijer Electronics

Beijer Electronics X2 control Manual de usuario

AXIOMTEK

AXIOMTEK GOT321W-521 Manual de usuario

TRIDONIC.ATCO

TRIDONIC.ATCO x-touchBOX Manual de usuario

Qomo

Qomo QIT1386 Manual de usuario

DFI

DFI KS104-CD Manual de usuario

AMX

AMX AXP-PPC Guía

Sartorius

Sartorius X3 PR 5410 Manual de usuario

AMX

AMX Modero X Series Manual de usuario

Advantech

Advantech TPC-30 Series Manual de usuario
