●This product is designed for indoor installation.
Please be sure to install it indoors.
●This product requires a floor drain.
●The water and drain hoses are not supplied with the
product and will need to be purchased locally.
●The external appearance, design, color, and
components of this machine may be changed without
prior notice.
Model KCU-80-AB
ICE MAKER User's Manual
Toll Free: (888) 275-4538
international: (514) 737-9701
Fax: (514) 342-3854
Toll Free Fax: (877) 453-8832
CONTENTS
2
Features of the Product
Safety Warning
Safety Precautions
Major Components
Cautions for Installation
Installation
Correct Operation
Disassembling, Cleaning
How to Clean
Ice Making and Harvest
Checkpoints/
Maintenance Product
Specifications
Troubleshooting Chart
Product Warranty
3
4
10
12
13
15
16
17
18
20
21
22
23
24
- Keep this user manual within reach for your reference.
3
Features of the Product
New Technologies Developed by Professionals, Fast Freezing through
4 Seasons, Powerful Ice Making Capacity
1. MICOM Controller
The ice making system is optimized using an automatic ice formation control sensor.
2. Integrated ice formation control sensor
When the ice container is full, the automatic sensor stops the ice making system to reduce
power and water consumption.
3. Pure, crystal ice
Features a nozzle spray type to form transparent cubic crystals. Pure ice crystals are formed
by the freezing point depression principle.
4. Low noise, low vibration
High efficiency, low noise fan provides quiet operation and an economical ice making
system.
5. Ergonomic design
User convenience implemented by the sloped door designed with human-spatial engineering.
Thank you for purchasing this ice maker
Please read through this user manual as it aims to prevent injuries to users and
ensure complete customer satisfaction.
Safety Warning
Please read and save these instructions. Precautions are marked with
symbols to prevent accidents which could be caused by incorrect operation.
Failure to comply with instructions could result in personal injury and/or
property damage.
Danger
This symbol means that if the user fails to observe the instructions, the danger will cause serious
physical injury, death or major property damage.
Warning
This symbol means that if the user fails to observe the instructions, there can be serious physical
injury, death or major property damage.
Caution
This symbol means that if the user fails to observe the instructions, there is a possibility of physical
injury to the user, or damage to property.
Injury: A scratch, burn (hot, cold), or electric shock which does not require
hospitalization or long-term medical treatment.
Damage to property: The damages to a building, furniture,etc.
The meanings of the symbols are as follows;
4
Danger, Warning, Caution
Do not touch!
Prohibited
Keep fire source away
Very Important
The system must be grounded
(connected to the earth).
Do not disassemble
Electric shock hazard
Burn hazard
Warning
Make sure that the power supply conforms to the specifications.
- Check that the supply voltage is in accordance with the voltage
specified on the name plate.
- The name plate is attached on the left side of the product.
- Incorrect power supply voltage can cause product failure, fire
or an electric shock.
5
■Never disassemble, repair or remodel the product.
-Unauthorized disassembling, repairing, or modifying may
deteriorate the safety of the product.
-In case of any failure, please refer to this User’s Manual.
■Install the product on a level, even and strong floor.
-Operation of the product in an unstable condition may cause failure and/or
deformation.
-Operation on a moving surface, such as a vehicle or ship, may result in the
unit falling over.
■Keep away from any fire source or inflammable material
(spray cans, butane container, gas cylinder, oil, etc.).
-Otherwise, an explosion or fire may break out.
■Do not spray insecticide or other inflammable
sprays, perfume, etc., near the product.
-Otherwise, a fire may break out.
■Do not store anything other than ice inside the product.
-It may cause unsanitary conditions.
-It may cause product failure or electric shock.
■Do not place or store heavy items on the top of the
product.
-Excessive weight can cause the unit to overheat and/or a fire.
Warning
6
Warning
■
The Ice Machine must be plugged into a grounded outlet.
-Do not use an adapter , or an extension cord.
-Do not remove the grounding prong.
-The unit must be installed in accordance with the state and local electrical
and plumbing codes.
■GFCI/GFI circuit protection is not recommended unless it is
required.
-Rated sensitive current: 30mA.
-An ungrounded circuit may cause product failure or an electric shock.
■The power cord should be removed by holding the plug.
-Do not disconnect power by holding the cord , or electric shock may occur.
-Damage to the power cord could cause fire or electrical shock.
■Do not connect or touch the power cord with wet hands.
-Otherwise, the user may get an electric shock.
■Make sure power cord is clean and free from any foreign
matter.
-If the prongs of the power plug are dirty, wet or improperly connected
to the receptacle, electric shock or fire may occur.
■When reconnecting the power cord after disconnection,
wait for at least three minutes before reconnection.
-Reconnection within three minutes may cause product failure.
Wait at least 3 minutes!
7
■Do not bend the power cord excessively or place a
heavy object on top of the cord.
-Otherwise, there is a danger of current leak, or electric shock.
■Replace damaged power cord and the cord plug if the
metal components are worn or loose.
-A damaged cord or plug can cause an electric shock or fire.
■Do not unplug or move the product during operation.
-Otherwise, water leaks, product failure or fire may result.
■Troubleshooting
-In case of an earthquake, fire, abnormal sound or smell from the
product, stop operation and unplug the power cord from the
receptacle immediately.
■Do not install the product in a wet or humid place.
-Do not install the product near any hot water tanks.
-Do not install the product in a bathroom, shower room, or near a
swimming pool.
-If water penetrates into the product, it may cause failure and/or
electric shock
Warning
8
Warning
■Provide at least 8" of space between the product and
the wall.
-Being too close to the wall may cause product failure.
■For cleaning and maintenance, remove the power plug from
the outlet and close the water supply valve. Perform work
only after the ice making operation stops.
-It may cause an electric shock or injury
■Be sure to clean the condenser at least once a month.
-When dust accumulates, ventilation is restricted which may cause low
product performance, excess power consumption, product failure.
■The ambient temperature must be between 50oF ~ 100oF.
-If installing in a cold place 50℉ or below, freeze break may occur.
-If installing in a hot place 100℉ or over, product failure may occur.
■The pressure and temperature of the supply water must be
20~80 psi, and 50℉~90℉, respectively.
-If the pressure or temperature of the supply water exceeds the above specified
ranges, the ice quality may deteriorate and/or product failure
may occur.
■Make sure to connect the product to the cold water outlet.
-Connection to a hot water line may cause product failure.
■The supply water must be tap water.
-The use of a water filter is highly recommended
9
Warning
■Be sure to use the potable water supply.
■When moving the product, do not go over 45 degrees
on the incline.
-It may cause a product failure.
■Do not twist or kink the water supply or drain hose.
-It may cause a water leak, ice to melt in the bin or product failure.
■The ice maker must be on a dedicated circuit.
-When multiple plugs are connect using a power strip,
it may cause a fire.
■Do not let children climb or hang on the ice maker.
-The ice maker may fall and cause serious injury.
■Do not use the product outdoors.
-The product is for indoor use only at temperatures between
50-100oF.
-When product is used outdoors, it may cause deformation of the
unit, discoloration and product failure.
10
Safety Precautions
Caution
■Use this product as described in the user manual.
-If you do not follow the instructions, it may cause an electric shock
or property loss.
-When transferring the product to another person, transfer the user manual
with the product.
■When the product is not going to be used for a long period of
time, shut off the water supply, remove the ice and disconnect
the plug from the outlet.
■Do not use the product near the fireplace.
-It may cause a fire.
■Install the product in a sanitary area.
-Because ice is edible, install the product in a sanitary and clean area.
