Technical Guide

KONICA MINOLTA and the KONICA MINOLTA logo are trademarks or registered trademarks of KONICA MINOLTA

HOLDINGS, INC. magicolor is a trademark or registered trademark of KONICA MINOLTA PRINTING SOLUTIONS

U.S.A., INC. PageScope is a trademark or registered trademark of KONICA MINOLTA BUSINESS TECHNOLOGIES,

INC. All other trademarks or registered trademarks are the property of their respective owners.

January 2005

Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1

Specs at a Glance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2

Engine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Duty Cycle . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Print Speeds by Page Size . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

First-Page-Out Times . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3

Weights and Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4

Operating Environment Conditions . . . . . . . . . . . . . . . . . . . . . . . . 4

Controller . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Type . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Processor . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Connectivity . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Printer Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6

Resolution. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7

Compatibility and Minimum System Requirements . . . . . . . . . . . . 7

Media Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Standard Media Handling . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Print Media . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Imageable Area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8

Supported Media Sizes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9

Advanced Document Processing. . . . . . . . . . . . . . . . . . . . . . . . . 10

Media Path . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11

Consumables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Toner Cartridges . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Drum Cartridge . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12

Consumable Yields . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

In-box Consumables . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Replacement Consumables. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13

Consumables Monitoring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14

Contents

Printer Management . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Convenient Printer Management Tools . . . . . . . . . . . . . . . . . . . . 15

Printer Drivers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15

Status Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18

PageScope Web Connection. . . . . . . . . . . . . . . . . . . . . . . . . . . . 19

Printer Control Panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Cancel Button . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Menu/Select Button. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Left and Right Buttons. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Up and Down Buttons . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20

Electronic User Documentation . . . . . . . . . . . . . . . . . . . . . . . . . . 21

Camera Direct Photo Print . . . . . . . . . . . . . . . . . . . . . . 22

USB Host Port with PictBridge Compatibility . . . . . . . . . . . . . . . . 22

Camera Direct Photo Print Functions. . . . . . . . . . . . . . . . . . . . . . 22

Color Control . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

Professional Color Tools for Both Novices and Professionals . . . . 23

Automatic ICC-Based Color Matching . . . . . . . . . . . . . . . . . . . . . 23

ICC Device Profiles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24

Enhanced Automatic Image Density Control (eAIDC). . . . . . . . . . 24

Options & Requirements . . . . . . . . . . . . . . . . . . . . . . . 25

Duplex Option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Lower Feeder Unit. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25

Introduction

The magicolor®2430 DL is a network-ready color laser printer for small

businesses, workgroups, and home offices. Its small price, small size,

and speeds up to 20 monochrome pages or 5 full-color pages per

minute make it a perfect replacement for your old inkjet printer. It’s also

the first color laser printer to come equipped with camera-direct photo

printing. You can print clear, crisp, durable pictures at up to 2400 x 600

dpi resolution directly from any PictBridge-enabled digital camera—with

no computer required!

KONICA MINOLTA designed the magicolor 2430 DL to be ready for

printing right out of the box. The CD-ROM that ships with the printer

includes all drivers, utilities, and documentation necessary for installing

and operating the printer in any home or small business. It’s extremely

easy to use, and it functions seamlessly with computers running

Windows®Server 2003, XP, 2000, Me, 98SE, and NT 4.0 as well as

Macintosh®OS 10.2+ and Linux®Red Hat 8.0+ and SuSE 8.1+.

Maintaining the magicolor 2430 DL is also simple and straightforward.

The toner cartridge and drum cartridge are separately replaceable for

more economical use, and the printer comes with a one-year exchange

warranty.

This Technical Guide is intended for use by KONICA MINOLTA

sales personnel and reseller partners. It includes complete

information about the magicolor 2430 DL and provides

data that can help you explain the features of the

printer to customers. For the most complete and

up-to-date information on the printer, be sure to

check our password-protected Reseller Partner

Program web site at

printer.konicaminolta.com/reseller

Specs at a Glance

An overview of the magicolor 2430 DL’s features.

Print Method Electrophotographic color laser

Processor ARM9, 130 MHz

Print Speed Up to 20 monochrome ppm (letter/A4)

Up to 5 color ppm (letter/A4)

Resolution Up to 2400 x 600 dpi

Duty Cycle Up to 35,000 letter/A4 prints/month

Camera-Direct Photo PictBridge 1.0

Print (Additional 256 MB RAM required for

full functionality and best quality)

Memory 32 MB on the controller board

Upgradable to 544 MB via 1 DIMM

connector

Standard Interfaces USB 2.0 (High-Speed)

USB 1.1 Host Port for Camera-Direct

Photo Print

Ethernet 10/100BaseTX

Media Sizes Up to legal (8.5"x14"/216x356 mm)

Media Input 200-sheet multipurpose tray

Optional 500-sheet Lower Feeder Unit

Duplex Option

Media Output 200-sheet face-down tray

Print Media Types Plain/recycled paper, glossy stock,

thick stock, OHP transparencies,

postcards, laser-quality labels,

envelopes

Software Utilities Printer drivers for Windows Server

2003, XP, 2000, Me, 98SE, and NT 4.0;

Macintosh OS X (v. 10.2+); Linux Red

Hat 8.0+, SuSE 8.1+

Status Display for Windows

Color Control Enhanced Automatic Image Density

Control (eAIDC) built-in calibration,

Automatic ICC-based color matching

Compatibility Windows Server 2003, XP, 2000, Me,

98SE, and NT 4.0

Macintosh OS X (v. 10.2+)

Linux Red Hat 8.0, and SuSE 8.1

Warranty One-year exchange

Engine

Excellent print quality and durability are hallmarks

of the magicolor 2430 DL print engine.

Type

The magicolor 2430 DL is based on the KONICA MINOLTA NC-L7001

laser printer engine. The engine features selectable resolutions of

600 x 600, 1200 x 600, and 2400 x 600 dpi.

Duty Cycle

35,000 prints (letter/A4 size) per month maximum.

Print Speeds by Page Size

Page Size* Monochrome (Black) Full Color Simplex/Duplex

Letter/A4 20 ppm 5 ppm Simplex

Letter/A4 11.4 ppm 5 ppm Duplex

Legal 10 ppm 2.5 ppm Simplex

A5 19 ppm 5 ppm Simplex

B5 20 ppm 5 ppm Simplex

* Normal paper

First-Page-Out Times*

Page Size** Monochrome (Black) Full Color Simplex/Duplex

Letter/A4 12 seconds 21 seconds Simplex

Letter/A4 26 seconds 32 seconds Duplex

Legal 13 seconds 31 seconds Simplex

A5 12 seconds 21 seconds Simplex

B5 12 seconds 21 seconds Simplex

* From an idle, ready state

** Normal paper

The magicolor 2430 DL produces high-

quality prints like the one above at full speed

in 600 x 600 dpi, 1200 x 600 dpi, and

2400 x 600 dpi resolutions.

Weights and Dimensions

Packaging

Width Depth Height

23.3" (591 mm) 19.5" (496 mm) 20.6" (522 mm)

Printer (with multipurpose tray extended)

Width Depth Height

16.9" (430 mm) 19.8" (502 mm) 13.4" (341 mm)

Printer (with optional lower feeder unit and duplex option)

Width Depth Height

16.9" (430 mm) 22.1" (561 mm) 18.0" (457 mm)

Weight

Shipping (printer) 54 lbs (24 kg)

Shipping (lower feeder unit) 15 lbs (6.8 kg)

Shipping (duplex option) 7.5 lbs (3.4 kg)

Printer only with consumables 44 lbs (20 kg)

Printer only without consumables 39.6 lbs (18 kg)

Operating Environment Conditions

Power supply 110–127 V, 50–60 Hz

Power consumption 1,100 W maximum

600 W or less (monochrome printing)

450 W or less (color printing)

250 W or less (standby)

28 W or less (Energy Saver)

Temperature (operating)

50°–95° F (10 –35° C)

Humidity (operating) 15–85% RH

Noise 53 dB or less (printing)

39 dB or less (standby)

Use the Status Display to change the time interval

before the printer goes into Energy Saver mode.

Choices range from Off to 60 minutes.

Clearance dimensions (front view)

Clearance dimensions (side view)

Controller

The magicolor 2430 DL uses the power of the

host computer’s operating system to deliver great

performance for less cost.

Type

The magicolor 2430 DL uses an easy-to-access controller with 32 MB

SDRAM on board.

Processor

The magicolor 2430 DL uses the power of the host computer’s

operating system for processing documents prior to printing. The

printer’s controller features a ARM9 130 MHz ASIC for imaging the

document.

Connectivity

Three interfaces are integrated into the magicolor 2430 DL’s controller:

The USB 2.0 (High-Speed) compliant interface provides a 4-pin

Series B connector and runs at 480 Mbps. This “Plug and Play”

interface supports Windows Server 2003, XP, 2000, Me, and

98SE; Macintosh OS X 10.2+; and Linux Red Hat 8.0+ and SuSE

8.1+ operating systems.

The Ethernet 10/100BaseTX autosensing interface operates on

both the traditional 10 Mbps LAN and 100 Mbps Fast Ethernet

networks, and it supports TCP/IP, IPP, DHCP, BOOTP, HTTP,

SNMP, SLP, LPR, Rendezvous, and Raw Port protocols.

The USB 1.1 Host Port, conveniently located on the front of the

printer, features PictBridge 1.0 compatibility for quick photo prints.

Printer Memory

The magicolor 2430 DL’s 32 MB RAM is sufficient for printing all

supported page sizes (simplex and duplex) at all supported resolutions.

One DIMM slot is available for upgrading printer memory up to 544 MB.

Additional memory can improve the printer’s performance, especially in

a network environment. Increasing the host computer’s memory may

also improve transmission speed and overall performance of the printer.

For full functionality and best quality camera-direct photo printing

(PictBridge), an additional 256 MB RAM is required. Standard printer

memory does not support high-resolution or index prints from

PictBridge.

The magicolor 2430 DL’s USB 2.0

(High-Speed) and 10/100BaseTX Ethernet

(IEEE 802.3) interfaces allow it to serve one

or many users.

Otros manuales para magicolor 2430 DL

Tabla de contenidos

Otros manuales de Impresora de Konica Minolta

Konica Minolta

Konica Minolta bizhub C3320i Manual de usuario

Konica Minolta

Konica Minolta bizhub PRO 950 Series Manual de usuario

Konica Minolta

Konica Minolta bizhub PRESS C8000 Instrucciones originales

Konica Minolta

Konica Minolta magicolor 7450 II Manual de usuario

Konica Minolta

Konica Minolta accuriopress c6100 Manual de usuario

Konica Minolta

Konica Minolta PagePro 9100 Manual de usuario

Konica Minolta

Konica Minolta magicolor 2400W Manual de usuario

Konica Minolta

Konica Minolta PagePro 1400W Manual de usuario

Konica Minolta

Konica Minolta PAGEPRO 5650EN Manual de usuario

Konica Minolta

Konica Minolta BIZHUB PRO C6500 Manual de usuario

Konica Minolta

Konica Minolta Magicolor 7300 Manual

Konica Minolta

Konica Minolta bizhub C3100P Manual de usuario

Konica Minolta

Konica Minolta Magicolor 5440 dl Manual de usuario

Konica Minolta

Konica Minolta Magicolor 2450 Manual de usuario

Konica Minolta

Konica Minolta A0VD011 Instrucciones originales

Konica Minolta

Konica Minolta bizhub PRO 951 Manual de usuario

Konica Minolta

Konica Minolta Magicolor 2350 EN Manual de usuario

Konica Minolta

Konica Minolta bizhub C658 Manual de usuario

Konica Minolta

Konica Minolta BIZHUB 164 Manual de usuario

Konica Minolta

Konica Minolta bizhub 40P/40PX Manual de usuario

Konica Minolta

Konica Minolta Magicolor 2350 EN Manual de usuario

Konica Minolta

Konica Minolta magicolor 1690MF Instrucciones originales

Konica Minolta

Konica Minolta AccurioPress C3080 Manual de usuario

Konica Minolta

Konica Minolta bizhub 350 Manual de usuario

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Canon

Canon i70 Series Manual de usuario

Evolis

Evolis Elypso Manual de usuario

Kyocera

Kyocera FS-9530DN Manual de usuario

Canon

Canon LASER SHOT LBP-1210 Manual de usuario

Samsung

Samsung BIXOLON SRP-350plusF Manual de usuario

Canon

Canon PIXMA PRO-1 Series Manual de usuario

Canon

Canon PIXMA G3560 Guía de configuración

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Epson

Epson ET-7750 Instrucciones de funcionamiento

Canon

Canon CLBR 460ps Manual de usuario

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Epson

Epson SC-F7100 series Manual de usuario

Epson

Epson Stylus C40UX Manual de usuario

Canon

Canon imagePASS-A2 Manual de usuario

Canon

Canon S820D Manual de usuario

Konica Minolta magicolor 2430 DL Guía de inicio rápido

Manuales populares de Impresora de otras marcas
