Konica Minolta Magicolor 2480 MF Manual de usuario

magicolor®2480 MF

Quick Guide

1760562-001A 4556-9583-00

- 1 -

Item

Name

Function key

Error LED

Display key

Quality key

2in1 key

Collate key

Light/Dark key

Reduce/Enlarge key

Message Window

+/- keys

/ keys

Menu Select key

Cancel/C key

TC Change key

Numeric Keypad

Copy key/LED

Start (Color) key/LED

Start (B/W) key/LED

Stop/Reset key

Function

Specify the media tray setting for copying (when an optional

tray and/or optional duplex unit are installed)

Indicates an error condition

Shows information, like copy settings, remaining toner, and

error messages

Select type of document to be copied and the copy resolution

Specify that two originals be copied onto one page

Sort multiple copies into sets

Adjust the brightness of the copy

Set the size of the copy

Displays settings, menus, and messages

Move up and down through menus, options, or choices

Move left and right through menus, options, or choices

Enter configuration mode or select a setting

Cancel the current setting or clear specified number of copies

Prepare the printer for toner replacement

Enter the number of copies

Enter copy mode

Start a color copy

Start a monochrome copy

Stop the current process or exit a menu

231 4 9 15 16

567819

17 18

13 14

10 10 11

Copy

Chapter

- 2 -

User's Guide

Mix x1.00 01

1XX Status

Document

type Copies

Density Paper tray/

Paper Size

Status

messages

Zoom

ratio

(1) (7)

Mix x1.00 01

1XX Status

2 digits

max.

50 sheets

60-135 g/m2

(16-36 lb)

1 sheet

Metric

0.50

0.70

0.81

1.00

1.15

1.41

2.00

Inch

0.50

0.64

0.78

1.00

1.29

1.54

2.00

Mix x-.-- 01

1XX Status

mc 2480 MF, 230V: Zoom = 0.70

mc 2480 MF, 110V: Zoom = 0.64

For ADF only

...

X.Y1

X.Y2

X.Y3

...

Mix x1.00 01

1XX Status

Mix

Text


Mix x1.00 01

1XX Status

Scan

Chapter

- 3 -

User's Guide

Mix x1.00 01

1XX Status

Document

type Copies

Density Paper tray/

Paper Size

Status

messages

Zoom

ratio

Note : Refer to the Installation Guide for details on how to install the TWAIN plug-in driver in your

 software application. Refer to the User's Guide for details on how to use the TWAIN driver.

- 4 -

REPLACING

CONSUMABLES

Chapter

TONER

User's Guide

Mix x1.00 01

1XX Status

Document

type Copies

Density Paper tray/

Paper Size

Status

messages

Zoom

ratio

NEW TONER CARTRIDGE

4-5x

(CLOSE ADF)

(X = C, M, Y, K)

X TONER EMPTY

CHANGE X TONER

UNTIL EMPTY TONER

CARTRIDGE (X)

*CAUTION!*

X TONER EMPTY

*CAUTION!*

CHANGE X TONER

max.

50 sheets

60-135 g/m2

(16-36 lb)

1 sheet 2

Chapter

- 5 -

User's Guide

TONER (cont.)

REPLACING

CONSUMABLES

13 15

Mix x1.00 01

1XX Status

Document

type Copies

Density Paper tray/

Paper Size

Status

messages

Zoom

ratio

- 6-

REPLACING

CONSUMABLES

Chapter

DRUM CARTRIDGE

User's Guide

Mix x1.00 01

1XX Status

Document

type Copies

Density Paper tray/

Paper Size

Status

messages

Zoom

ratio

NEW DRUM CARTRIDGE

(CLOSE ADF)

*CAUTION!*

END OF LIFE

*CAUTION!*

CHANGE DRUM
