Owner's Manual
IMPORTANT:
Read all safety precautions and instructions carefully before operating
equipment. Refer to operating instruction of equipment that this engine powers.
Ensure engine is stopped and level before performing any maintenance or
service.
Warranty coverage as outlined in the warranty card and on KohlerEngines.
com. Please review carefully as it provides your specifi c rights and obligations.
To maintain compliance with applicable emission regulations, exhaust system
backpressure may not exceed limits which can be found on KohlerEngines.
com. Search by Model No., then select Specs tab.
Kohler Engines has published CO2 values on KohlerEngines.com website.
Record engine information to reference when ordering parts or obtaining warranty coverage.
Engine Model
Specifi cation
Serial Number
Purchase Date
CH640, CH730, CH740
Liquefi ed Petroleum Gas (LPG) or LPG/Natural Gas (NG) Fueled
2 24 590 48 Rev. --KohlerEngines.com
Safety Precautions
WARNING: A hazard that could result in death, serious injury, or substantial property damage.
CAUTION: A hazard that could result in minor personal injury or property damage.
NOTE: is used to notify people of important installation, operation, or maintenance information.
WARNING
Explosive Fuel
can cause fi res
and severe
burns.
If a gaseous
odor is detected,
ventilate area
and contact
an authorized
service
technician.
LPG is extremely fl ammable
and is heavier than air and
tends to settle in low areas
where a spark or fl ame
could ignite gas. Do not
start or operate this engine
in a poorly ventilated area
where leaking gas could
accumulate and endanger
safety of persons in area.
NG is extremely fl ammable,
is lighter than air, and rises.
Do not start or operate this
engine in a poorly ventilated
area where leaking gas
could accumulate and
endanger safety of persons
in area.
To ensure personal
safety, installation and
repair of LPG/NG fuel
supply systems must
be performed only by
qualifi ed LPG/NG system
technicians. Improperly
installed and maintained
LPG/NG equipment could
cause fuel supply system
or other components to
malfunction, causing gas
leaks.
Observe federal, state
and local laws governing
LPG/NG fuel, storage, and
systems.
WARNING
Hot Parts can
cause severe
burns.
Do not touch
engine while
operating or just
after stopping.
Never operate engine with
heat shields or guards
removed.
WARNING
Accidental
Starts can cause
severe injury or
death.
Disconnect and
ground spark
plug lead(s)
before servicing.
Before working on engine or
equipment, disable engine
as follows: 1) Disconnect
spark plug lead(s). 2)
Disconnect negative (–)
battery cable from battery.
Before disconnecting
negative (-) ground cable,
make sure all switches
are OFF. If ON, a spark
will occur at ground cable
terminal which could cause
an explosion if hydrogen
gas or LPG/NG fuel vapors
are present.
WARNING
Carbon
Monoxide can
cause severe
nausea, fainting
or death.
Avoid inhaling
exhaust fumes.
Never run
engine indoors
or in enclosed
spaces.
Engine exhaust gases
contain poisonous carbon
monoxide. Carbon
monoxide is odorless,
colorless, and can cause
death if inhaled.
CAUTION
Electrical Shock
can cause injury.
Do not touch
wires while
engine is
running.
WARNING
Rotating Parts
can cause
severe injury.
Stay away while
engine is in
operation.
Keep hands, feet, hair,
and clothing away from all
moving parts to prevent
injury. Never operate engine
with covers, shrouds, or
guards removed.
WARNING: This product can expose you to chemicals
including carbon monoxide and benzene, which are known
to the State of California to cause cancer and birth defects
or other reproductive harm. For more information go to
www.P65Warnings.ca.gov.
3
24 590 48 Rev. -- KohlerEngines.com
Pre-Start Checklist
1. Check oil level. Add oil if low. Do not overfi ll.
2. Check fuel gauge (if equipped). If LPG tank is low, have it refi lled. Check fuel system
components and lines for leaks.
3. Check and clean cooling areas, air intake areas and external surfaces of engine (particularly
after storage).
4. Check that air cleaner components and all shrouds, equipment covers, and guards are in place
and securely fastened.
5. Check spark arrestor (if equipped).
AP
O
AOil Fill B Vaporizer CLPG Regulator DDebris Screen
EDipstick FOil Filter GOil Drain Plug HAir Cleaner
Base
IPaper Element JPrecleaner KRubber Seal LElement Cover
MWing Nut NAir Cleaner
Cover OAir Cleaner
Knob PLow-Profi le Air
Cleaner
Visit KohlerEngines.com for service parts information and purchasing options.
M
K
L
J
I
H
N
B
C
B
C
G
E
D
F
4 24 590 48 Rev. --KohlerEngines.com
Starting
WARNING
Carbon Monoxide can cause
severe nausea, fainting or death.
Avoid inhaling exhaust fumes.
Never run engine indoors or in
enclosed spaces.
Engine exhaust gases contain poisonous
carbon monoxide. Carbon monoxide is
odorless, colorless, and can cause death if
inhaled.
WARNING
Rotating Parts can cause severe
injury.
Stay away while engine is in
operation.
Keep hands, feet, hair, and clothing away
from all moving parts to prevent injury. Never
operate engine with covers, shrouds, or
guards removed.
NOTE: Do not crank engine continuously for
more than 10 seconds. Allow a 60
second cool down period between
starting attempts. Failure to follow
these guidelines can burn out starter
motor.
NOTE: Upon start-up, a metallic ticking may
occur. Run engine for 5 minutes. If
noise continues, run engine at mid
throttle for 20 minutes. If noise persists,
take engine to your local Kohler
authorized dealer.
NOTE: If starter is engaged while fl ywheel is
rotating, starter pinion and fl ywheel ring
gear may clash resulting in damage to
starter.
1. Place throttle control (if equipped) into idle
position. Place choke control (if equipped)
into ON position.
2. Slowly turn fuel valve on LPG (propane) tank
or NG line (if equipped) to full open position.
3. Turn key switch to START position. Release
switch as soon as engine starts. If starter
does not turn engine over, shut off key switch
immediately. Do not make further attempts to
start engine until condition is corrected. Do
not jump start. See your Kohler authorized
dealer for trouble analysis.
Cold Weather Starting Hints
1. Use proper oil for temperature expected.
2. Disengage all possible external loads.
Stopping
1. If possible, remove load by disengaging all
PTO driven attachments.
2. Turn fuel valve to full closed position and
allow engine to continue running until it runs
out of fuel. Turn key switch to OFF position.
Switching off key switch prior to allowing
engine to run out of fuel may create a
backfi re.
Angle of Operation
Refer to operating instructions of equipment
this engine powers. Do not operate this engine
exceeding maximum angle of operation; see
specifi cation table. Engine damage could result
from insuffi cient lubrication.
Engine Speed
NOTE: Do not tamper with governor setting to
increase maximum engine speed.
Overspeed is hazardous and will void
warranty.
5
24 590 48 Rev. -- KohlerEngines.com
Maintenance Instructions
WARNING Before working on engine or equipment, disable
engine as follows: 1) Disconnect spark plug
lead(s). 2) Disconnect negative (–) battery cable
from battery.
Accidental Starts can cause
severe injury or death.
Disconnect and ground spark
plug lead(s) before servicing.
Normal maintenance, replacement or repair of emission control devices and systems may be
performed by any repair establishment or individual; however, warranty repairs must be performed
by a Kohler authorized dealer found at KohlerEngines.com or 1-800-544-2444 (U.S. and Canada).
For safety and health reasons, many states require special licensing or certifi cation for servicing
LPG fuel systems. Check local and state regulations before choosing a repair establishment to
perform fuel system repairs.
Maintenance Schedule
Every 25 Hours1
● Service precleaner element.
Every 100 Hours1
● Check oil cooler fi ns, clean as necessary (if equipped).
● Change oil.
● Replace air cleaner element.
● Remove cooling shrouds and clean cooling areas.
Every 200 Hours1
● Change oil fi lter.
Every 500 Hours or Annually1 (whichever comes first)
● Check all lines (high pressure/vacuum) including fi ttings for leaks.
● Drain regulator of accumulated fuel deposits.
● Replace spark plugs and set gap.
Every 500 Hours or Annually1,2 (whichever comes first)
● Have lock-off /fi lter serviced.
● Have combustion deposits removed if using non-synthetic oil.
Every 1500 Hours1,2
● Have regulator disassembled, cleaned, and reset.
● Have vaporizer disassembled, cleaned, and serviced.
1 Perform these procedures more frequently under severe, dusty, dirty conditions.
2 Must be performed by a Kohler authorized dealer or qualifi ed LPG personnel only.
6 24 590 48 Rev. --KohlerEngines.com
Oil Recommendations
Synthetic oil is recommended for use in
LPG/NG fueled engines. Non-synthetic oil must
be low ash* rated oil. Oils (including synthetic)
must meet API (American Petroleum Institute)
service class SG, SH, SJ, or SL. Select
viscosity based on air temperature at time of
operation as shown in table below.
*Low ash is defi ned as less than 1% sulfated
ash.
°F -20 020324060
50 80 100
°C -30 -20 -10 0 10 20 30 40
5W-30
10W-30
SAE 30
Check Oil Level
NOTE: To prevent extensive engine wear or
damage, never run engine with oil level
below or above operating range
indicator on dipstick.
Ensure engine is cool. Clean oil fi ll/dipstick
areas of any debris.
1. Remove dipstick; wipe oil off .
a. Press-in cap: reinsert dipstick into tube;
press completely down.
or
b. Thread-on cap: reinsert dipstick into
tube; rest cap on tube, do not thread cap
onto tube.
2. Remove dipstick; check oil level. Level
should be at top of indicator on dipstick.
3. If oil is low on indicator, add oil up to top of
indicator mark.
4. Reinstall dipstick and tighten securely.
Change Oil and Filter
Change oil while engine is warm.
1. Clean area around oil fi ll cap/dipstick, drain
plug/oil drain valve.
a. Remove drain plug and oil fi ll cap/
dipstick. Allow oil to drain completely.
or
b. Open oil drain valve cap; if needed,
attach a length of 1/2 in. I.D. hose to
direct oil into appropriate container; twist
valve drain body counterclockwise and
pull. Remove dipstick. Allow oil to drain
completely.
2. Clean area around oil fi lter. Place a container
under fi lter to catch any oil and remove fi lter.
Wipe off mounting surface.
a. Reinstall drain plug. Torque to 10 ft. lb.
(13.6 N·m).
or
b. Close oil drain valve body, remove hose
(if used), and replace cap.
3. Place new fi lter in shallow pan with open end
up. Fill with new oil until oil reaches bottom of
threads. Allow 2 minutes for oil to be
absorbed by fi lter material.
4. Apply a thin fi lm of clean oil to rubber gasket
on new fi lter.
5. Refer to instructions on oil fi lter for proper
installation.
6. Fill crankcase with new oil. Level should be
at top of indicator on dipstick.
7. Reinstall oil fi ll cap/dipstick and tighten
securely.
8. Start engine; check for oil leaks. Stop engine;
correct leaks. Recheck oil level.
9. Dispose of used oil and fi lter in accordance
with local ordinances.
7
24 590 48 Rev. -- KohlerEngines.com
Oil Sentry™ (if equipped)
This switch is designed to prevent engine
from starting in a low oil or no oil condition. Oil
Sentry™ may not shut down a running engine
before damage occurs. In some applications
this switch may activate a warning signal. Read
your equipment manuals for more information.
Fuel Recommendations
WARNING
Explosive Fuel can cause fi res
and severe burns.
If a gaseous odor is detected,
ventilate area and contact an
authorized service technician.
LPG is extremely fl ammable and is heavier
than air and tends to settle in low areas
where a spark or fl ame could ignite gas. Do
not start or operate this engine in a poorly
ventilated area where leaking gas could
accumulate and endanger safety of persons
in area.
NG is extremely fl ammable, is lighter than air,
and rises. Do not start or operate this engine
in a poorly ventilated area where leaking gas
could accumulate and endanger safety of
persons in area.
To ensure personal safety, installation and
repair of LPG/NG fuel supply systems must
be performed only by qualifi ed LPG/NG
system technicians. Improperly installed and
maintained LPG/NG equipment could cause
fuel supply system or other components to
malfunction, causing gas leaks.
Observe federal, state and local laws
governing LPG/NG fuel, storage, and
systems.
This engine is certifi ed to operate on LPG or
LPG/NG.
LPG Engines
LPG from an appropriate LPG fuel tank
(supplied separately) is required to operate this
engine.
NG Engines
NG from an approved system or source of
supply can be used to operate this engine.
Fuel Conversion
NOTE: When switching from NG to LPG fuel
or LPG to NG fuel, battery must be
temporarily disconnected for safety and
to reset system.
Some engines are equipped to convert between
LPG and NG. Models with fi tting and jet should
follow these instructions for conversion. Other
metering valves should be installed following
instructions given by equipment it powers.
Shut off fuel supply before any servicing is
performed.
LPG Operation
Installation of jet in regulator fi tting is required
for LPG operation.
Switching from NG to LPG
Remove fuel inlet hose. Inspect internal threads
of regulator fi tting to ensure they are clean and
dry. Install jet into fuel elbow orifi ce for LPG
operation. Reconnect and fully tighten fuel inlet
hose.
Outlet pressure should be checked and if
required, set at secondary regulator to 4.0 to
5.0 psi by qualifi ed personnel.
NG Operation
Removal of jet from regulator fi tting is required
for NG operation.
Switching from LPG to NG
Remove LPG fuel jet from regulator fi tting.
Disconnect hose, remove jet from orifi ce, and
reconnect hose.
Recommended fuel inlet pressure for NG
systems is 11 in. water (engine off ). Reduced
pressure could result in hard starting.
8 24 590 48 Rev. --KohlerEngines.com
LPG Regulator
In compliance with government emission
standards, regulator is preset at factory to
provide proper supply of fuel. No adjustment or
resetting of regulator is to be made. All service
relating to regulator must be performed by
a Kohler authorized dealer or qualifi ed LPG
personnel only.
Over time, fuel deposits can accumulate
inside regulator. Removing these deposits is
recommended (Nikki regulators only). Follow
steps below to drain Nikki Regulators.
1. Turn fuel supply valve off , run engine out of
fuel, and turn off ignition switch.
2. Disconnect and ground spark plug leads.
3. Remove 1/8" pipe plug from bottom of
regulator. Remove any accumulated
deposits.
4. Reinstall plug using Tefl on® pipe sealant (not
Tefl on® tape) on threads and tighten securely.
If required, a replacement plug can be found
at KohlerEngines.com.
Lock-Off /Filter Assembly
Lock-Off /Filter Assembly opens, closes, and
fi lters liquid fuel fl ow from supply tank before
reaching vaporizer.
Vaporizer
Vaporizer changes Liquefi ed Petroleum (LPG)
from supply tank to a gaseous/vapor state.
Spark Plugs
CAUTION
Electrical Shock can cause injury.
Do not touch wires while engine
is running.
Clean out spark plug recess. Remove plug and
replace.
1. Check gap using wire feeler gauge. Adjust
gap, see specifi cation table for adjustment.
2. Install plug into cylinder head.
3. Torque plug to 20 ft. lb. (27 N·m).
Air Cleaner
NOTE: Operating engine with loose or
damaged air cleaner components
could cause premature wear and
failure. Replace all bent or damaged
components.
NOTE: Paper element cannot be blown out
with compressed air.
Loosen knob and remove air cleaner cover.
Precleaner:
1. Remove precleaner from paper element.
2. Replace or wash precleaner in warm water
with detergent. Rinse and allow to air dry.
3. Saturate precleaner with new engine oil;
squeeze out excess oil.
4. Reinstall precleaner over paper element.
Paper Element:
1. Clean area around element. Remove wing
nut, element cover, and paper element with
precleaner.
2. Separate precleaner from element; service
precleaner and replace paper element.
3. Check condition of rubber seal and replace if
necessary.
4. Install new paper element on base; install
precleaner over paper element; reinstall
element cover and secure with wing nut.
Reinstall air cleaner cover and secure with
knob.
Breather Tube (if equipped)
Ensure end of breather tube is properly
connected.
9
24 590 48 Rev. -- KohlerEngines.com
Oil Cooler (if equipped)
1. Clean fi ns with a brush or compressed air.
2. Remove two screws securing oil cooler, and
tilt to clean back side.
3. Reinstall oil cooler.
Air Cooling
WARNING
Hot Parts can cause severe
burns.
Do not touch engine while
operating or just after stopping.
Never operate engine with heat shields or
guards removed.
Proper cooling is essential. To prevent over
heating, clean screens, cooling fi ns, and other
external surfaces of engine. Avoid spraying
water at wiring harness or any electrical
components. See Maintenance Schedule.
Repairs/Service Parts
We recommend that you use a Kohler
authorized dealer for all maintenance,
service, and replacement parts for engine.
To fi nd a Kohler authorized dealer visit
KohlerEngines.com or call 1-800-544-2444
(U.S. and Canada).
Leakage Check/Testing
With fuel valve fully opened, engine not
running, turn key switch ON. Check all fuel
system connections and lines for leaks using
soapy water. Any leakage must be corrected
before restarting engine. Have service
performed by a Kohler authorized dealer or
qualifi ed LPG/NG personnel only.
Storage
If engine will be out of service for 2 months or
more follow procedure below.
1. Change oil while engine is still warm from
operation. Remove spark plug(s) and pour
about 1 oz. of engine oil into cylinder(s).
Replace spark plug(s) and crank engine
slowly to distribute oil.
2. Disconnect negative (-) battery cable.
3. Separate LPG tank from unit and store
separately in an area designated for safe
LPG tank storage.
4. Store engine in a clean, dry place.
10 24 590 48 Rev. --KohlerEngines.com
Troubleshooting
Do not attempt to service or replace major engine components, or any items that require special timing or adjustment procedures. This work
should be performed by a Kohler authorized dealer.
Possible Cause
Problem
No Fuel
Improper
Fuel
Dirt In
Fuel Line
Dirty/
Restricted
Lock-off
Fuel Filter
Dirty
Debris
Screen
Incorrect
Oil Level
Engine
Overloaded
Dirty Air
Cleaner
Faulty
Spark
Plug
Dirty/
Restricted
Regulator
Will Not Start ●●●●●●●●●
Hard Starting ●●● ● ● ● ● ●● ●
Stops Suddenly ●●●●●●● ●
Lacks Power ●● ● ● ● ● ●● ●
Operates Erratically ●● ● ● ● ●● ●
Knocks or Pings ●●● ●●●
Skips or Misfi res ●● ● ● ●● ●
Backfi res ●● ●● ●
Overheats ●● ● ● ● ● ● ●
High Fuel Consumption ●●
Otros manuales para Command PRO CH640
1
Este manual sirve para los siguientes modelos
2
Otros manuales de Motor de Kohler
Kohler
Kohler K582 Manual de usuario
Kohler
Kohler KT19 series II Manual de usuario
Kohler
Kohler KD425-2 Manual de usuario
Kohler
Kohler Command PRO CH270 Manual de usuario
Kohler
Kohler Command PRO CH260 Manual de usuario
Kohler
Kohler LOMBADINI 15 LD 500 Manual de lista de piezas
Kohler
Kohler KDI 3404TCR-SCR Manual de usuario
Kohler
Kohler Lombardini 3 LD 450 Manual de lista de piezas
Kohler
Kohler LOMBARDINI MARINE KDI 1903M-MP Manual de usuario
Kohler
Kohler COMMAND 20-25 HP Manual de usuario
Kohler
Kohler LOMBARDINI MARINE KDI 1903M-MP Manual de usuario
Kohler
Kohler KT610-KT620 Manual de usuario
Kohler
Kohler Lombardini 3 LD 450 Manual de usuario
Kohler
Kohler AEGIS LH630 Manual de usuario
Kohler
Kohler LAMBARDDINI LDW 1503 Manual de instrucciones
Kohler
Kohler COURAGE SV710-740 Manual de usuario
Kohler
Kohler Command Pro CH255 Manual de usuario
Kohler
Kohler Courage SH265 Manual de usuario
Kohler
Kohler Courage SH265 Manual de usuario
Kohler
Kohler KDI 3404TCR-SCR Manual de usuario
Manuales populares de Motor de otras marcas
KSB
KSB SuPreme Series Instrucciones de instalación
Hiwin
Hiwin EM1 Series Manual de usuario
Rotax
Rotax 912 i series Instrucciones de funcionamiento
Siemens
Siemens SIMOTICS XP 1MB1 Manual de usuario
Bosch
Bosch Rexroth 70 Series Manual de usuario
Wacker Neuson
Wacker Neuson WM 130 Instrucciones de funcionamiento
