Kogan KASMRWTCBLB Manual de usuario

KIDS' SMART WATCH

KASMRWTCBLB, KASMRWTCPKB

Safety & Warnings 3

Components List 3

Overview 4

Before First Use 5

Operation 6

Cleaning & Care 17

Troubleshooting 17

Specifications 19

Ensure to read all instructions and warnings in this user guide prior to first use. Retain this

user guide for future reference.

•Misuse of batteries can lead to them bursting, causing a fire, or chemical burns.

•Do not disassemble this watch.

•Do not crush or expose the battery to shock or force (for example, dropping or

stepping on it).

•Do not short circuit the watch.

•Do not expose the watch to high temperatures or place it near heat sources (fires,

stoves, heaters).

•Do not expose the watch to direct sunlight.

•Do not expose the watch to high moisture areas, and do not allow it to touch or

submerge in water or any other liquid.

•If the battery within the watch is damaged or leaking, stop use immediately and

contact help.Kogan.com for assistance.

•Keep the battery dry and out of the reach from children.

•If the watch is damaged, stop use immediately and contact help.Kogan.com for

assistance.

•Charging should only be performing by an adult.

•The battery within cannot be disposed in normal waste. If disposing, follow local

regulations.

•Smart watch with detachable watch strap

•Micro-USB cable

•User guide

SAFETY & WARNINGS

COMPONENTS LIST

Side view

Back view

OVERVIEW

Microphone

Micro-USB port

Top camera

Front camera

Torch

Reset button

Home button

Power switch

Display

Charging

It is highly recommended to fully charge the watch before first use.

1. Lift the rubber cover of the Micro-USB port on the watch. Insert the smaller end of the

Micro-USB cable into the Micro-USB port on the watch.

2.Turn on your computer and insert the larger end of the Micro-USB cable into a spare

USB port on the computer.

3.Once connected, you will see the battery charging symbol shown on the display for

one second and then the data transfer symbol. Select ‘USB Charging’ and ‘OK’. The

battery will continuously charge whilst connected.

4.Monitor the watch regularly throughout the charging process. When the battery is

fully charged, a full battery symbol will show on the display. Disconnect the watch

from the computer.

Notes:

•A full charge takes approximately three hours. The actual time will depend on

the power supply, the remaining charge, and the ambient temperature of the

charging environment.

•The optimal ambient temperature is 0–40°C.

•5V adapters may also be used to charge the watch.

•If the watch takes longer than three hours to fully charge, try charging from a

different USB power source.

•

Do not use any quick charging adapters.

BEFORE FIRST USE

Powering

1. Ensure the battery has been fully charged. Slide the power switch to the ON position.

2.Press and hold the home button for three seconds to turn the watch on. The watch

will then show a clock/time display. From here, you can either swipe up or down on

the display to show different options and shortcuts.

Icon Step/Description

Swipe up and tap/hold on the mouth icon. The watch will then state the current

time.

Swipe up and tap/hold on the Gubi icon. Click the star icon on Gubi clock

face, then Gubi will come onto the screen. From here, you can have various

interactions with Gubi for example by swiping and holding on the display, and

shaking the watch.

Swipe up and tap/hold the music icon. Music will then begin playing from the

watch.

Swipe down and tap/hold the speaker icon to mute/unmute the watch.

Swipe down and tap/hold the alarm clock icon to turn the alarm function

on/off.

OPERATION

Notes:

•When touching the display, ensure your whole finger is pressing the display for

one second.

•Do not use fingernails.

Lock screen

This watch features various analogue and digital clock/time displays as lock screens. To

change the clock/time display, swipe the display left or right.

Tap the centre of the display to change to show analogue or digital clock/time displays.

Home menu

When the watch is showing the lock screen, press the home button to display the home

menu. From here, most of the watch’s functions can be accessed.

Swipe left and right to view the available functions. Tap the desired icon to open the

function.

Camera

•Tap the camera icon on the display to take a photo.

•Tap the switch camera icon to switch between the front and top camera.

•Tap the wand icon to cycle through different photo frames.

•Tap the photo gallery icon to view photos.

•Tap the arrows or swipe on the display to browse through the photo gallery.

•Tap the bin icon on the display and follow to prompts to delete photos.

Video

•Tap the video camera icon on the display to take a video.

•Tap the switch camera icon to switch between the front and top camera.

•Tap the video gallery icon to view videos.

•Tap the arrows or swipe on the display to browse through the video gallery.

•Tap the bin icon on the display and follow the prompts to delete videos.

Voice recorder

•Tap the record icon to start voice recording.

•Tap the stop icon to save the recording.

•Tap the play icon to play the last recording.

•Use the arrows to select and browse through the recordings.

Music player

Music can be uploaded from a computer to the watch and be played. To upload:

1. Use the Micro-USB cable to connect your watch to a computer/laptop.

2.On the watch, select ‘Mass storage’ and ‘OK’. Folders for the watch will then appear

on the computer.

3.Copy any MP3 music files into the ‘My Music’ folder. After the transfer is complete,

safely eject the watch from your computer and unplug the Micro-USB cable.

To play music you have transferred to the watch, select the music player icon from the

home menu, then press the play icon to begin playing a file. Other controls are listed as

below.

Icon Description

Pause track

Volume increase

Volume decrease

Play previous track

Play next track

Games

There are 13 built-in games on this watch. Swipe the display to browse through the games,

then tap on the desired game to play.

Icon Game name How to play

Memory Test Test your memory by matching the card sets

Foodie War Tap on the desserts with the same colour on the bottom

of the display that match those in the window.

Turntable

•Spin the wheel and see where it lands. It will land on a

colour and number. Tap the required number of times

on the colour.

•For example, ‘Not Yellow 5’ means to tap any colour but

yellow five times.

Princess Dress Up Tap on the small icon on the top left. Choose the outfit,

hair and accessories for the princess.

Guess the Fingers Tap the number of fingers shown on the display quickly

within a 60 second period.

Jelly Flow Swap the jellies so there are three in a row to clear.

Sweet Together Tap on the coloured test tubes and place candy of the

same colour into the test tubes.

ShakeFun Shake the watch to roll the dice.

2048

•Swipe in all directions of the display to move the tiles.

•A new tile will appear after every swipe.

•Tiles with the same number will merge and the goal is

to add tiles to 2048.

Basketball Shoot

Master

The backboard will be moving. When it is moving towards

the middle, tap on the basketball to shoot.

Bee War

•Tap the display left and right to move the fighter and

shoot.

•Purple enemies must be hit twice.

•You have three lives.

Pinball Hit Bricks

•Destroy all bricks to progress to the next level.

•Blue bricks must be hit twice.

•White bricks give a three-ball bonus.

Ultimate Racing

•Press and hold on the car to move it left and right to

switch lanes.

•The car in front may drop coins, collect as many coins

as possible.

Musical instruments simulation

This watch features nine simulated instruments. Tap on the desired instrument to play. The

instruments include:

•Piano

•Violin

•Triangle

•Rattle

•Snare drum

•Taiko

•Bass

•Guitar

•Ukulele

Pedometer

Use the pedometer to count your steps.

Follow the onscreen prompts to start or reset the pedometer. When started, the count will

be updated every 30 seconds.

Sound simulation

This watch features eight simulated sounds. Tap on the desired sound icon to play. These

sounds will keep playing on every tap.

•Light saber

•Hammer

•Basketball

•Tennis

•Ka Me Ha

•Clap

•Magic

•Wand
