Kogan KAMOPEL11VA Manual de usuario
CORDLESS ELECTRIC MOP
KAMOPEL11VA
•This appliance is only intended for use in domestic living environments. Do not use
it in a business or industrial environment.
•Remove large particles or substances before using. This product is not for
sweeping or vacuuming.
•Do not drench or submerge the unit in water, even during use.
•In the case of jamming by small substances, power off the appliance before
removing the obstruction.
•Do not let children use the mop as a toy.
•Use a clean cloth to wipe down the mop when it is powered off.
•Do not bend or apply stress to the metal handle of the product.
•Use caution when waxing wooden floors and always keep safe footing.
Battery and charging
•Only use the charger and batteries included with the product. Do not use third
party accessories.
•Do not attempt to disassemble or modify the battery and charger.
•Keep the charger away from heat sources such as radiators, ovens etc.
•Do not touch the charger or power adaptor with wet hands
•Ensure to dispose of batteries in an environmentally friendly manner, in
accordance with local governmental rules and regulations.
•If there is any damage to the cable, discontinue use and contact Kogan.com.
•Make sure the unit is powered off before transporting and use the original
packaging where possible.
•If the machine will not be used for an extended period, charge the battery to 100%,
place it in a dry and cool environment and charge it every 3 months to avoid
battery over-discharge.
SAFETY & WARNINGS
In the box
Measuring cup
Cleaning pads
Power adapter
User guide
Screws
Allen key
OVERVIEW
Handle
Charging port
Water filling hole
Pad attachments
Spray button
Spray nozzle
Power button/
battery indicator LED
Main unit
1. Connect the metal pipe to the pipe joint, then attach the handle with the fixing
screws through the corresponding holes.
2. Place the base on the ground and keep the joint part straight.
ASSEMBLY
Threaded Hole
Connecting
Pipe Joint
Note:
It may take some force to fold the movable handle.
3. Insert the connecting tube into the mop head and screw it in firmly.
4. Place the cleaning pads on the ground and lift the machine to place it onto the
cleaning pads. The cleaning pads will attach to the base of the mop head.
Cleaning pads
First time charging
Pull out the rubber stopper and turn it until the whole charging port is uncovered. Plug in the
charger into the charging port, and the battery indicator light will alternate between red and
blue while charging. When fully charged (after approx. 3 hours) the indicator will be solid
blue.
Turn off the machine before charging.
OPERATION
Note:
Always use the original power adaptor included with the unit.
Battery indicator
LED
Charging port
Fill the water tank
Open the cap of the water tank and fill it, using the measuring cup to add water. Do not
exceed the maximum water level line. Securely close the cap after filling.
•Maximum capacity of the water tank is 130ml.
•Matched cleaner or essential oils can be used in the water tank.
•Ensure clean water is used to avoid obstructing the spray nozzle or water pump.
•To avoid the nozzle becoming blocked, do not leave any detergent/cleaning liquid
or waxing oil in the water tank for more than 24 hours.
Power on/off
Press and hold the power button until a tone is heard; the indicator light will illuminate, and
the appliance will begin operating.
Repeat this process to turn the unit off.
“MAX” line
Spraying water
Press the spray button on the handle and water will be sprayed; releasing the button will
stop spraying accordingly.
•Do not operate the spray function while the unit is charging.
•The longest time of spraying will keep 5 seconds with one press.
•Avoid using the water spray more frequently than every 1s.
Battery indicator LED
Briefly pressing the power button will display the current charge level:
•Blue indicates sufficient battery.
•Solid red indicates lower battery and that charging will soon be required.
•Flashing red indicates that the battery has been depleted. Charge the unit as soon
as possible.
Spray Button
Battery indicator
LED
Replacing cleaning pads
Turn the machine upside down and hold the edge of the pad and then tear off it.
Replacing handle batteries
After extended use of the product, if pressing the spray button emits no water, the remote
batteries in the handle may need to be replaced.
•Remove the screw on the back of the handle and pull out the tail cap. Replace
both AAA batteries inside.
Operation Tips
Pad attachment area
The attachment area may collect fibres after multiple uses. Gently clean with a toothbrush.
Cleaning pads
Clean the pads under water and dry after using or use disposable cleaning pads.
AAA batteries
Tail cap
