Koden CVS-FX2 Manual de usuario

CVS-FX2/FX2BB Revision History

0092602002-12 i

CVS-FX2/FX2BB Installation Manual

Doc No. 0092602002

Document Revision History

No.

Doc. –Rev. No.

Date Revised

(Y/M/D)

Revised content

0092602002-00

2012/02/20

First edition

0092602002-01

2012/10/10

Dimensions, Chapter 1, Cover

0092602002-02

2014/03/10

System Configuration, Configuration of

Equipment, Dimensions, Chapter 1,

Chapter 2

0092602002-03

2014/11/10

Dimensions, Chapter 1

0092602002-04

2015/08/17

Chapter 1

0092602002-05

2015/11/02

System Configuration, Configuration of

Equipment

0092602002-06

2016/09/05

Configuration of Equipment, Chapter 3

0092602002-07

2017/01/31

Configuration of Equipment, Specifications

0092602002-08

2017/06/26

Chapter 1

0092602002-09

2018/03/30

TDM-091 Addition

0092602002-10

2020/04/01

System Configuration, Configuration of

Equipment, Chapter 2

0092602002-11

2020/11/09

Cover

0092602002-12

2021/03/10

Chapter 1

Document No. Revised Version Norm

When part of the document needs to be revised, the document has advanced revised number.

The document No. is indicated at the lower right side on the cover and at the left or right side

of the footer region of each page.

No part of this publication may be reproduced, transmitted, translated in any form by any means without

the written permission of Koden Electronics Coo., Ltd. The technical descriptions contained in this

publication are subject to change without notice. Koden assumes no responsibility for any errors,

incidentals or consequential damages caused by misinterpretation of the descriptions contained in this

publication.

Important Notice CVS-FX2/FX2BB

ii 0092602002-12

Important Notice

For copy and transcription of this Installation Manual (hereinafter referred to as this manual),

permission from Koden is needed. Koden prohibits the un-authorized copy and transcription of this

manual.

If this manual is lost or damaged, consult a dealer of Koden or Koden.

The specification of the products and the contents in this manual are subject to change without

notice.

The contents displayed on the menu of product may be different from the expression of this

manual. The fonts and shapes of the keys and menus in the illustration may differ from the actual

ones, and some parts may be omitted.

Koden is not liable for damages and troubles arisen from misunderstanding of the contents in this

manual.

Koden is not liable for any damages caused by earthquake, lightning, wind and flood damage and

fire for which Koden is not responsible, and actions by third parties, other accidents, customer’s

unintended error/abuse and the use under other abnormal conditions.

Koden is not liable for damages of accompaniment (change/loss of memorized content, loss of

business profit, stop of business) arisen from use or failure of our products.

If the stored data are changed or lost, irrespective of causes of troubles and damages, Koden is

not liable for them.

Koden is not liable for any damages arisen from malfunction caused by combination of software

and connected equipment in which Koden is not engaged.

CVS-FX2/FX2BB For Your Safe Operation

0092602002-12 iii

For Your Safe Operation

Symbol used in this Installation Manual

The following graphical symbols are used in this manual. The meaning of each symbols shall

be well understood and apply at maintenance and inspection works.

Symbol

Meaning

Mark for warning

This symbol denotes that there is a risk of death or serious injury when

not dealing with it correctly.

Mark for danger high voltage

This symbol denotes that there is a risk of death or serious injury caused

by electric shock when not dealing with it correctly.

Mark for caution

This symbol denotes that there is a risk of slight injury or damage of

device when not dealing with it correctly.

Mark for prohibition

This symbol denotes prohibition of the specified conduct. Description of

the prohibition is displayed near the mark.

Caution items on equipment

Be careful of a high voltage inside.

A high voltage, which may risk your life, is used. This high voltage

remains in the circuit after you have powered off switch. To prevent

touching the high voltage circuit inadvertently, the hard cover is provided

to the high voltage circuit and the high voltage caution label is affixed.

Ensure to power off switch for your safety and discharge the electricity

remaining in the capacity before starting to check. An engineer

authorized by our company should inspect and maintain

Be sure to power off in the boat.

If the power switch is inadvertently powered on during work, you will be

electrified. To prevent such accident from occurring, ensure to power off

in the boat and the power of equipment. Furthermore, it is safer to hang

the caution tag described as [Under Work] near the power switch of

equipment.

Be careful of dust

Inhaling dust may cause A respiratory disease. When cleaning the

inside of equipment, be careful not to inhale dust. Wearing a safety

mask is recommended.

Warning

Caution

Warning

For Your Safe Operation CVS-FX2/FX2BB

iv 0092602002-12

Caution on location of equipment

Do not install the equipment where it is excessively damp and suffers

from excessive water drops.

Measures against static electricity

The static electricity may be generated from the carpet on the floor in

the cabin or clothes made of synthetic fiber. The static electricity may

destroy the electronic parts on the circuit board. Handle the circuit

board, taking the measure of static electricity free.

Caution at installation of a transducers

Install the transducer at the location where it is not affected by bubble

and noise The bubble and noise seriously degrade the performance of

this unit.

Caution Items on handling

Do not disassemble or modify. It may leads to trouble, fire, smoking or

electric shock. In case of trouble, contact our dealer or our company.

In case of smoke or fire, boat power off and the power of this unit. It may

cause fire, electric shock or damage.

Be cautious of remaining high voltage.

A high voltage may remain in the capacitor for several minutes after you

have powered off. Before inspecting inside, wait at least 5 minutes after

powering off or discharge the remaining electricity in an appropriate

manner. Then, start the work.

The information displayed in this unit is not provided directly for your

navigation. For your navigation, be sure to see the specified material.

Use the specified fuse. If un-specified fuse is used, it may cause a fire,

smoke or damage.

Whenever transmitting, be sure to submerge the transducer in water

first. If transmitted without submerging the transducer, it may be

damaged.

Caution

Warning

ing

Warning

Caution

CVS-FX2/FX2BB Contents

0092602002-12 v

Contents

Document Revision History.......................................................................................................................i

Important Notice.......................................................................................................................................ii

For Your Safe Operation.........................................................................................................................iii

Contents...................................................................................................................................................v

System Configuration.............................................................................................................................vii

Configuration of Equipment.....................................................................................................................ix

Dimensions............................................................................................................................................xiv

Specifications .......................................................................................................................................xvii

Chapter 1 Installation..............................................................................................1-1

1.1 Installation precautions..............................................................................................................1-1

1.1.1 Unpacking of components......................................................................................................... 1-1

1.1.2 Appearance verification of each unit and accessories..............................................................1-1

1.1.3 Selection of location for installation........................................................................................... 1-1

1.1.4 Laying and connection of cables...............................................................................................1-2

1.1.5 Coordination after installation.................................................................................................... 1-2

1.2 Installation of CVS-FX2 Display unit ......................................................................................... 1-3

1.2.1 Desk-top installation.................................................................................................................. 1-3

1.2.2 Flush-mount installation............................................................................................................. 1-5

1.3 Installation of CVS-FX2BB Processor unit................................................................................ 1-6

1.4 Installation of Operation unit......................................................................................................1-7

1.4.1 Desk-top installation.................................................................................................................. 1-7

1.4.2 Flush-mount installation............................................................................................................. 1-9

1.5 Installation of transducer .........................................................................................................1-10

1.5.1 In the case of inner hull installation.........................................................................................1-10

1.6Wiring.......................................................................................................................................1-18

1.6.1 Connection of cables to Display and Processor unit...............................................................1-18

1.7 Connection of Hemisphere V102 GPS Compass /

ComNav Vector G1 GPS Satellite Compass........................................................................... 1-30

1.7.1 Connection of Hemisphere V102 GPS Compass /

ComNav Vector G1 GPS Satellite Compass........................................................................... 1-30

1.7.2 Setting of Hemisphere V102 GPS Compass /

ComNav Vector G1 GPS Satellite Compass........................................................................... 1-35

1.8List of input/output sentences..................................................................................................1-41

1.8.1 Input sentence......................................................................................................................... 1-41

1.8.2 Output sentence......................................................................................................................1-41

Chapter 2 Adjustment.............................................................................................2-1

2.1 Setup of transducer...................................................................................................................2-1

2.1.1 Setup of type of high frequency transducer...............................................................................2-1

2.1.2 Setup of type of low frequency transducer................................................................................2-1

2.2 Setup of frequency of transducer..............................................................................................2-2

2.2.1 Setup of frequency for high frequency transducer.................................................................... 2-2

2.2.2 Setup of frequency for low frequency transducer...................................................................... 2-2

2.3 Setup of BeamAngle of transducer...........................................................................................2-3

2.3.1 Setup of BeamAngle for high frequency transducer................................................................. 2-3

2.3.2 Setup of BeamAngle for low frequency transducer.................................................................. 2-3

2.4 Setup of Bottom Limit................................................................................................................ 2-4

2.4.1 Setup of Bottom Limit HF ..........................................................................................................2-4

2.4.2 Setup of Bottom Limit LF........................................................................................................... 2-4

2.5 Setup of Draft Set...................................................................................................................... 2-4

2.6 Setup of Gain (TD) for transducer.............................................................................................2-5

2.7Setup of Output Limit for transmitter .........................................................................................2-6

2.7.1 Display of Output Limit Menu .................................................................................................... 2-6

2.7.2 Setup of Output Limit HF...........................................................................................................2-6

Contents CVS-FX2/FX2BB

vi 0092602002-12

2.7.3 Setup of Output Limit LF............................................................................................................2-6

2.7.4 Relation of the set value between [Output Limit] and [MENU] - [EchoAdjust] - [TX Power].....2-7

Chapter 3 Maintenance...........................................................................................3-1

3.1 Inspection...................................................................................................................................3-1

3.2 Cleaning.....................................................................................................................................3-1

3.2.1 Display unit of CVS-FX2............................................................................................................3-1

3.2.2 Transducer.................................................................................................................................3-2

3.3 Fuse Replacement.....................................................................................................................3-2

3.4 Diagnostics of troubles ..............................................................................................................3-2

3.4.1 Necessary information for requesting repair..............................................................................3-2

3.4.2 Diagnostics ................................................................................................................................3-3

3.4.3 LCD Test....................................................................................................................................3-4

3.4.4 Initialize......................................................................................................................................3-4

3.4.5 Update of program.....................................................................................................................3-4

3.5 If you suspect a failure...............................................................................................................3-6

CVS-FX2/FX2BB System Configuration

0092602002-12 vii

System Configuration

Connection diagram of CVS-FX2

Owner supply

Option

Standard configuration

Legend

Display unit ESD-200

With mounting bracket and Knobs

J1 connector

J2 connector

J3 connector

External echo sounder

(Owner supply)

CW-372-5M

Speaker with amplifier

(Owner supply)

CW-264A-2M

NMEA2 circuit input output

(12 V power output)

(Owner supply)

CW-373-5M

CW-374-5M

CW-376-5M

GPS sensor

NMEA1 circuit input output

(Owner supply)

J8 connector

Junction

box

CW-836-3M

CW-270-2M

POWER connector

White +

Black -

21.6 to 31.2 VDC

connector

CCD camera

CW-405-0.3M

External monitor

CW-576-0.5M

Transducer TDM-052/062

TDM-091/041

connector

J7 connector

CW-373-5M

CW-374-5M

CW-376-5M

Fuse

10 A

CW-844-3M

Operation unit

CW-409A-5M

Connector of

Operation unit

System Configuration CVS-FX2/FX2BB

viii 0092602002-12

Connection diagram of CVS-FX2BB

Owner supply

Option

Standard configuration

Legend

Processor unit ESM-200

J1 connector

J2 connector

J3 connector

External echo sounder

(Owner supply)

CW-372-5M

Speaker with amplifier

(Owner supply)

CW-264A-2M

NMEA2 circuit input output

(12 V power output)

(Owner supply)

CW-373-5M

CW-374-5M

CW-376-5M

GPS sensor

NMEA1 circuit input output

(Owner supply)

J8 connector

Junction

box

CW-836-3M

CW-270-2M

POWER connector

White +

Black -

21.6 to 31.2 VDC

connector

CCD camera

CW-405-0.3M

External monitor

CW-576-0.5M

connector

J7 connector

CW-373-5M

CW-374-5M

CW-376-5M

Fuse

10 A

CW-844-3M

Operation unit

Connector of

Operation unit

CW-409A-5M

External Monitor

(Owners supply)

Cable for External

monitor

CW-560-2M

Transducer TDM-052/062

TDM-091/041

Otros manuales para CVS-FX2

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Ecosonda de Koden

Koden

Koden CVS-FX1 Manual de usuario
