Kodak PULSE DIGITAL FRAME Manual de usuario
KODAK PULSE Digital Frame
User guide
www.kodak.com
For help, go to www.kodak.com/go/pulseframesupport
Eastman Kodak Company
Rochester, New York 14650
© Eastman Kodak Company, 2010
All screen images are simulated.
Kodak and Pulse are trademarks of Eastman Kodak Company.
P/N 4H6784_en
Product features
www.kodak.com/go/support i
Back panel buttons and connectors
1See Attaching the power cable, page 1.
2See Viewing pictures from a memory card or USB device, page 12.
Power
button
USB connector2
Memory card slots2
DC-in1
Health Check
button
ii www.kodak.com/go/support
Product features
Touch screen icons/buttons
1 Play—start a slide show.
2 Collage—start a revolving five-picture slide show.
3 Information—view picture information.
4 Delete—remove pictures from the frame.
5 Copy—copy pictures from a memory card or USB device to your frame’s internal memory
(only appears if a memory card or USB device is inserted).
6 Transition Time—change how long each picture stays on the screen and the type of
transition between pictures.
7 Friends—view pictures grouped according to the friends who sent them (you can also view
pictures on an inserted memory card or USB device).
8 Previous/Next—view the previous/next picture on the frame.
9 Health Check—check/fix your network connection (only appears if there is a network
connection problem).
1 72 653 4
8 8
9
www.kodak.com/go/support iii
Table of contents 1
1 Getting started ......................................................................................1
Attaching the power cable ............................................................................1
Turning your frame on and off.......................................................................2
Setting your language ...................................................................................3
Connecting to your wireless network .............................................................3
Activating your frame....................................................................................9
Adding pictures to your frame .....................................................................10
2 Viewing pictures ..................................................................................11
Viewing pictures from internal memory........................................................11
Viewing pictures from a memory card or USB device ....................................12
Navigating through your pictures.................................................................14
Changing play speed and transition type .....................................................15
Viewing pictures as a collage.......................................................................16
3 Doing more with your frame ...............................................................17
Using your online account ...........................................................................17
Receiving and viewing pictures from friends.................................................18
Deleting pictures .........................................................................................20
Copying pictures to internal memory............................................................21
Maintaining your frame...............................................................................22
4 Troubleshooting and support ..............................................................24
Getting help on your digital frame ...............................................................24
Picture frame problems ...............................................................................25
Learning more about your frame..................................................................26
iv www.kodak.com/go/support
Table of contents
5 Appendix .............................................................................................27
Digital frame specifications..........................................................................27
Important safety instructions .......................................................................28
Additional care and maintenance ................................................................30
Limited warranty .........................................................................................30
Regulatory compliance and advisory ............................................................32
www.kodak.com/go/support 1
1Getting started
Attaching the power cable
NOTE: The frame automatically turns on when you plug it in for the first time.
CAUTION:
Do not use this power cable with other devices, including digital
cameras.
Your power cable may look
different from the one pictured.
If more than one plug is
included, use the plug for
your type of power outlet.
2www.kodak.com/go/support
Getting started
Turning your frame on and off
NOTE: The frame automatically turns on when you plug it in for the first time.
Press the power button to turn the frame on or off.
NOTE: Your frame is configured to save energy by automatically turning off at night and turning on in the
morning. You can change on/off times or to disable this feature: after you create your free online
account and activate your frame (see page 9), sign in to your account at
www.kodakpulse.com
, then click the Frame Settings tab.
Power button
Getting started
www.kodak.com/go/support 3
Setting your language
The language screen appears the first time you turn on your frame. Touch your
language.
NOTE: If someone else set up your frame, your language may already be selected, and the language screen
may not appear.
Once your language is set, you can only change it
through the KODAK PULSE Web site. After you
create your free online account and activate your
frame (see page 9), sign in to your account at
www.kodakpulse.com, then click the Frame Settings
tab.
Connecting to your wireless network
When you connect your frame to the Internet over your wireless network, you can
perform a host of activities including adding pictures from your computer to your
frame, receiving pictures from friends, changing frame settings, and more.
NOTE: If you are not sure you have a wireless network, ask the person who set up your network.
Using the network setup wizard
When you first set up of your frame, the network setup wizard appears.
NOTE: If someone else set up your frame, your screen may show fewer steps.
1Touch Start.
Touch Back to go to the language screen or touch
Exit to dismiss wireless setup and go to the slide
show view (see Chapter 2, Viewing pictures).
Available wireless networks are listed.
If your wireless network is not shown, see page 5.
4www.kodak.com/go/support
Getting started
2Touch your network.
If your router supports Wi-Fi Protected Setup (WPS),
see page 6.
If your network is secure, when prompted,
choose your Wi-Fi security type, then enter the
security code for your network using the on-screen
keyboard:
NOTE: Security codes are case-sensitive.
■Touch to switch between upper and lower
case characters.
■Touch to enter numbers and special
characters.
■When finished, touch OK.
If you do not know your security type or security
code, ask the person who set up your network.
The frame scans for your wireless network. A message
appears when it has successfully connected.
