Klipsch Audiorock Instrucciones de funcionamiento

Tech Support: 1-800-KLIPSCH

OWNER’S MANUAL

and installation instructions

State-of-the-Art Wireless Portable AudioRock

Installs in 5 minutes or less!

Note: The AudioRock is an add on unit to an existing LightSpeaker®System. You need

a LightSpeaker®Transmitter to supply audio and control the music on this unit. The

Transmitter and Remote discussed in the manual are sold separately.

AudioRock Manual v2.indd 1 5/31/2010 10:46:20 PM

Tech Support: 1-800-KLIPSCH

The lightning flash with arrowhead symbol, within an equilateral

triangle, is intended to alert the user to the presence of

uninsulated “dangerous voltage” within the product’s enclosure

that may be of sufficient magnitude to constitute a risk of electric

shock to persons.

The exclamation point within an equilateral triangle is intended

to alert the user to the presence of important operating and

maintenance (servicing) instructions in the literature

accompanying the appliance.

CAUTION: Risk of Electrical Shock - Do not submerge the product in water

CAUTION: To reduce the risk of electric shock, do not remove cover (or back). No

user servicable parts – refer servicing to qualified service personnel only.

WARNING: To reduce the risk of fire or electric shock, do not submerge this

product in water

The AudioRock speaker uses a 12 volt Lithium Ion Battery for

operation. Please review the following safety instructions before use:

Li Ion Battery Safety Instructions:

Misuse can result in the batteries short-circuiting, the insulator melting and

damage to the safety valves or safety mechanisms, leading to leakage, heat

generation, or rupturing. Please observe the following precautions when using

batteries.

• Do not dispose in fire or expose to high temperature (140oF/60oC)

• Do not under any circumstances insert the batteries with the positive and

negative poles reversed.

• If the connection with the charger does not operate correctly, do not force the

battery in, but instead check the direction of the positive and negative poles.

• Do not charge with chargers not specified for this product

• Do not short the positive terminal and the negative terminal with metals

such as wire, coins, etc. Also, do not store or carry the batteries with metal

necklaces, etc.

• Do not disassemble or modify the battery.

• Do not puncture the battery

• Do not directly solder the battery.

• Do not use the battery if it shows signs of leakage, a change of color or shape

or any other changes in appearance.

• Do not wet the battery or place it in water or sea water. This may lead to the

battery generating heat or rusting.

• Store the battery out of reach of small children.

• When not using the battery, or not using the device for a prolonged period,

remove the battery from the device and store it in a dry place between

the temperatures of -20oC and +35oC. This prevents decreased battery

performance and service life

• The battery (battery or batteries or battery pack) shall not be exposed to

excessive heat such as sunshine, fire or the like.

CAUTION/MISE EN GARDE

Risk of Electric Shock, Do Not Open

AudioRock Manual v2.indd 2 5/31/2010 10:46:20 PM

Tech Support: 1-800-KLIPSCH

IMPORTANT SAFETY INSTRUCTIONS

1. Read these instructions. Keep these instructions. Heed all Warnings. Follow

all instructions.

2. Do not use this apparatus in water. The apparatus can be exposed to

rain, snow or any weather element without risk of injury or damage. Do not

submerge in water or other liquids. The product is water resistant not water

proof.

3. Clean only with a wet rag or light spray of water from garden hose. Do not

use high pressure hoses or washers to clean the product.

4. Do not block any ventilation openings. Install in accordance with the

manufacturer’s instructions.

5. Do not install near any heat sources such as radiators, heat registers, stoves,

or other apparatus (including amplifiers) that produce heat.

6. Only use approved batteries in this product in accordance with the

manufacturers instructions

7. Only use attachments/accessories specified by the manufacturer.

8. Refer all servicing to qualified service personnel. Servicing is required when

the apparatus has been damaged in any way, such as power-supply cord

or plug is damaged, liquid has been spilled or objects have fallen into the

apparatus, the apparatus has been exposed to rain or moisture, does not

operate normally, or has been dropped.

9. The weight of this device may cause instability of a

free-standing table or stand near a pool, pond or other

standing water. Insure that the surface or object that

the product is placed on is stable and cannot be tipped

over causing the product to be immearsed in water.

10. FOR USE WHERE EXPOSED TO THE WEATHER

PAS EXPOSER AUX INTEMPÉRIES

Declaration of Conformity

Trade Name: LightSpeaker

Model: R 5.2.0

Responsible Party: Kadence Designs LLC

Address: PO Box 2359, Thompson Falls, MT 59873

Telephone Number: 877-81AUDIO

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions: (1) This device may not cause

harmful interference, and (2) this device must accept any interference

received, including interference that may cause undesired operation.

Correct Disposal of this product. This marking indicates that this

product should not be disposed with other household wastes

throughout the EU. To prevent possible harm to the environment

or human health from uncontrolled waste disposal, recycle it

responsibly to promote the sustainable reuse of material resources.

To return your used device, please use the return and collection

systems or contact the retailer where the product was purchased.

They can take this product for environmental safe recycling.

AudioRock Manual v2.indd 3 5/31/2010 10:46:20 PM

Tech Support: 1-800-KLIPSCH

Congratulations

Thank you for choosing the wireless, portable

AudioRockTM from Klipsch® Speakers. With proper

installation and operation, you will enjoy years of

trouble-free use. Klipsch Speakers offers numerous

loudspeakers for use inside or outside your home. To see

the complete Klipsch Speakers product assortment, visit

us on the Internet at: www. Klipsch.com.

AudioRock Manual v2.indd 4 5/31/2010 10:46:20 PM

Tech Support: 1-800-KLIPSCH

Table of Contents

AudioRock Overview.............................................................................6

What is in this box................................................................................8

Installation Considerations................................................................9

Selecting Locations...............................................................................9

Setting up Zones.................................................................................10

Preparing AudioRock for Installation.......................................11

Installation Instructions...................................................................12

Pairing the AudioRock to the Transmitter..............................13

Operating and Controlling Your AudioRock..........................15

Specifications......................................................................16

Accessories........................................................................16

Warranty...............................................................................................18

FCC Declaration...................................................................................19

Technical Support Information...................................Back Cover

AudioRock Manual v2.indd 5 5/31/2010 10:46:20 PM

Tech Support: 1-800-KLIPSCH

AudioRockTM Overview

This wireless portable AudioRock is intended to install in

a few minutes and since it runs on batteries it increases

the flexibility of where these speakers can be used. The

system can use up to 8 wireless AudioRocks (when used

with a Klipsch Speakers LightSpeaker® transmitter) to

provide audio to your entire outdoor area. You can even

divide your outdoor spaces into unique areas where

different sources, and sound control allow you the

flexibility to easily configure and install an outdoor system

to be enjoyed by all.

Additionally, the system can be expanded by adding our

patented LightSpeakers®. These LightSpeakers install

in minutes and fit into 5” and 6” recessed ceiling cans

as well as table lamps, hanging lamps or anywhere you

AudioRock Manual v2.indd 6 5/31/2010 10:46:21 PM

Tech Support: 1-800-KLIPSCH

find a standard Edison socket. They can provide “green”

lighting and outstanding sound throughout your home.

The LightSpeakers are available from your retailer or at

www.Klipsch.com.

The entire system provides even greater flexibility to you

as the owner; because you can take it with you if you

move. If you do need to remove it, it leaves no trace that

the system was ever installed or used.

What’s in the box

AudioRock Manual v2.indd 7 5/31/2010 10:46:21 PM

Tech Support: 1-800-KLIPSCH

NOTE: The AudioRock can only be used with the Klipsch

Speakers wireless LightSpeaker transmitter. It cannot be

used or operated without the LightSpeaker transmitter.

What’s in this Box

Wireless AudioRock

Owner’s Manual

One Charger

One Rechargeable Lithium-ion Battery

Remote and transmitter sold separately.

AudioRock Manual v2.indd 8 5/31/2010 10:46:21 PM

Tech Support: 1-800-KLIPSCH

Installation Considerations

Remember the outdoor line-of-sight range of the system

is up to 125 feet, so as long as the distance from the

transmitter to the farthest AudioRock, in any direction, is

less than 125 feet, the placement of the transmitter is up

to you.

Selecting AudioRockTM Locations

Your wireless AudioRock can be placed anywhere it is

convenient in your outdoor listening areas. You can

even space multiple AudioRocks so that no one speaker

is further than 35 feet from the other speaker. This will

provide for the best and most even coverage for you to

enjoy outstanding sound quality.

AudioRock Manual v2.indd 9 5/31/2010 10:46:21 PM

Tech Support: 1-800-KLIPSCH

Setting Up Zones

If you have more than one AudioRock and you want to

set up separate listening zones in your outdoor area, you

have the option of setting up a second zone. An audio

zone is any area or group of areas where you want the

same audio source playing and want the volume of the

speakers to be about the same. If you want an area to

have different volume level or play a different set of music

then use the two zone option. Please note that there is no

right or wrong way to do this, it is simply how you think you

want to use your AudioRock system. If you try an option

and don’t like it, it is easy to change and try another one.

NOTE: You have some control over an area being on or

off by using the power switch that is on the rear of the

AudioRock. Simply turn it off and there will not be any

sound in that area.

AudioRock Manual v2.indd 10 5/31/2010 10:46:21 PM

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Sistema de altavoces de Klipsch

Klipsch

Klipsch Comm Sat Manual de usuario

Klipsch

Klipsch iFi Manual de usuario

Klipsch

Klipsch RSB-11 Manual de usuario

Klipsch

Klipsch ProMedia ProMedia 5.1 Manual de usuario

Klipsch

Klipsch ROOMGROOVE Manual de usuario

Klipsch

Klipsch ProMedia ProMedia 4.1 Manual de usuario

Klipsch

Klipsch Professional Cinema Professional Cinema Loudspeaker... Manual de usuario

Klipsch

Klipsch Cornwall II Manual de usuario

Klipsch

Klipsch R-20B Manual de usuario

Klipsch

Klipsch RSB-14 Manual de usuario

Klipsch

Klipsch BAR 48 Manual de usuario

Klipsch

Klipsch RSB-11 Manual de uso y cuidado

Klipsch

Klipsch CINEMA 400 Manual de usuario

Klipsch

Klipsch ProMedia Ultra 2.0 Manual de usuario

Klipsch

Klipsch PROMEDIA Guía

Klipsch

Klipsch Palladium 5.1 Manual de usuario

Klipsch

Klipsch Cinema 6 Manual de usuario

Klipsch

Klipsch CA 8-T Manual de usuario

Klipsch

Klipsch Flexus CORE 200 Manual de usuario

Klipsch

Klipsch RSB-8 Manual de usuario

Klipsch

Klipsch iFi Manual de usuario

Klipsch

Klipsch Quintet Quintet SL Manual de usuario

Klipsch

Klipsch CA-650-T Manual de usuario

Klipsch

Klipsch Synergy SC.5 Suplemento

Manuales populares de Sistema de altavoces de otras marcas

JVC

JVC CA-MXK5R Manual de usuario

LG NB4532B Manual de usuario

JVC

JVC CA-FSH100 Manual de usuario

5Core

5Core Pro Series Manual de usuario

EAW

EAW MQV1394e Manual de usuario

Lynx

Lynx GXR-LA10A Manual de usuario

iLive

iLive ITB066B Manual de usuario

RDX

RDX QuickStation 4 Manual de usuario

Electro-Voice

Electro-Voice S-122 Manual de usuario

Sven

Sven SPS-619 GOLD Manual de usuario

Pioneer

Pioneer CS-7070 Manual de usuario

EAW

EAW UB82e Manual de usuario

Sondpex

Sondpex Active Speaker System and Digital Music... Manual de usuario

JVC

JVC NX-PN7 Manual de usuario

Marshall Amplification

Marshall Amplification AR-DM61-BT Manual de usuario

Yamaha

Yamaha NX-A01 - Speaker Sys Manual de usuario

SE Audiotechnik

SE Audiotechnik I-LINE Manual de usuario

Gemini

Gemini WRX-843 Series Manual de usuario
