KitchenAid KTRC22KV Instrucciones de uso

Top Mount Refrigerator

PRODUCT MODEL NUMBERS PRODUCT DIMENSIONS

LOCATION REQUIREMENTS

KTRC22KV

Electrical: A 115-volt, 60-Hz., AC-only, 15- or

20-amp fused, grounded electrical supply is

required. It is recommended that a separate

circuit serving only your refrigerator be

provided. Use an outlet that cannot be turned

off by a switch. Do not use an extension cord.

NOTE: Before performing any type of

installation, cleaning, or removing a light

bulb, turn the control (Thermostat,

Refrigerator or Freezer Control depending on

the model) to OFF and then disconnect the

refrigerator from the electrical source. When

you are finished, reconnect the refrigerator to

the electrical source and reset the control

(Thermostat, Refrigerator or Freezer Control

depending on the model) to the desired

setting.

Water: A cold water supply with water

pressure of between 30 and 120 psi (207

and 827 kPa) is required to operate the water

dispenser and ice maker. If you have

questions about your water pressure, call

a licensed, qualified plumber.

IMPORTANT: The pressure of the water

supply coming out of a reverse osmosis

system going to the water inlet valve of the

refrigerator needs to be between 30 and

120 psi (207 and 827 kPa).

If a reverse osmosis water filtration system

is connected to your cold water supply, the

water pressure to the reverse osmosis

system needs to be a minimum of 40 to

60 psi (276 to 414 kPa).

Because Whirlpool Corporation policy includes a continuous commitment to improve

our products, we reserve the right to change materials and specifications without notice.

Dimensions are for planning purposes only. For complete details, see Installation

Instructions packed with product. Specifications subject to change without notice.

Ref. W10208837

09-03-08

To ensure proper ventilation for your refrigerator, allow for a 1/2" (1.25 cm) space

on each side and at the top. When installing your refrigerator next to a fixed wall,

leave 2" (5.1 cm) minimum on the hinge side (some models require more) to allow

for the door to swing open. If your refrigerator has an ice maker, allow extra space

at the back for the water line connections.

NOTE: It is recommended that you do not install the refrigerator near an oven,

radiator, or other heat source. Do not install the refrigerator in a location where the

temperature will fall below 55°F (13°C).

Depth Cab. Width Door Width Cab. Height Overall Height

Model size "A" "B" "C" "D" "E"

22 cu. ft. 31-1/2" 32-1/2" 33-1/8" 65-1/2" 66-1/2"

(80 cm) (82.6 cm) (84.1 cm) (166.4 cm) (168.9 cm)

all

top of

cabinet

overall

2" (1.25 cm)

2" (5.1 cm)
