CABINET PARTS

For Models: KSRK25FVWH01, KSRK25FVBL01, KSRK25FVBT01, KSRK25FVMK01, KSRK25FVSS01, KSRK25FVMS01

(White) (Black) (Biscuit) (Mono Stainless) (Stainless Steel) (Mono Stainless)

10−08 Printed In U.S.A. (jdc) (eeb) Part No. W10233042 Rev. A

REFRIGERATOR

CABINET PARTS

For Models: KSRK25FVWH01, KSRK25FVBL01, KSRK25FVBT01, KSRK25FVMK01, KSRK25FVSS01, KSRK25FVMS01

(White) (Black) (Biscuit) (Mono Stainless) (Stainless Steel) (Mono Stainless)

W10233042

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Literature Parts

W10162452

Use & Care Guide

W10181781

Service & Wiring

Sheet

W10194135

Energy Guide

2220407 Modular Icemaker

Service Sheet

W10206334

Instr Sheet,

Door Removal

2 2174748 Front Roller (2)

3 3400517 Screw

4 2196236 Roller (Rear) (2)

5 489427 Screw

6 2155013 Clip, Grille

7 488500 Screw

8 2203771 Hinge Top, RC

9 3400858 Screw

10 Hinge Cover, FC

W10138581

White

W10138582

Black

W10138583

Biscuit

W10138584

Apollo Gray

W10138965

Hinge Bottom

12 Filler, Wrapper

2304846 White

2304848 Black

2304849 Biscuit

W10143043

Apollo Gray

13 Grille

W10184886

White

W10184888

Black

W10184889

Biscuit

W10184890

Apollo Gray

14 489497 Screw

15 2203770 Hinge, Top FC

16 489464 Screw

17 2304888 Drain Fitting

W10153550

Tube, Extension

19 2188735 Cover, Unit

20 Hinge Cover, RC

W10138576

White

W10138577

Black

W10138578

Biscuit

W10138579

Apollo Gray

21 549193 Clamp, Service

Cord

22 489084 Screw

23 2155311 Door Closer,

Lower Cam (2)

24 489483 Screw

25 2260507 Housing, Water

Filter

26 4396841 Water Filter

27 489500 Screw

28 Cap, Water

Filter

2260502W White

2260502B Black

2260502T Biscuit

2260502MG

Apollo Gray

29 Cabinet (Not A

Serviceable Part)

30 8281227 Screw

31 3400113 Screw

32 2255012 Tube, Filter

Outlet

33 2319867 Tube, Filter

Inlet

34 2260519 Block, Housing

Support

35 Button, Water

Filter

2260503W White

2260503B Black

2260503T Biscuit

2260503MG

Apollo Gray

REFRIGERATOR LINER PARTS

For Models: KSRK25FVWH01, KSRK25FVBL01, KSRK25FVBT01, KSRK25FVMK01, KSRK25FVSS01, KSRK25FVMS01

(White) (Black) (Biscuit) (Mono Stainless) (Stainless Steel) (Mono Stainless)

W10233042

Illus. Part

No. No. DESCRIPTION

1 Liner (Not A

Serviceable Part)

W10175967

Escutcheon, Meat

Pan Control

3 2182757 Slide Meat

Pan Control

4 2257741 Louver

5 2256035 Bracket, Dual

Crisper Lights

6 2311637 Wire Harness,

Dual Crisper

Lights

8 2319866 Ladder, Shelf (2)

W10004810

Screw (2)

11 489478 Screw

W10128734

Air Diffuser

Assembly

W10128735

Air Diffuser

Cover

15 2162085 Socket

16 2307107 Reservoir

17 2326255 Light Bulb

18 2209769 Light Lens

19 488280 Screw

REFRIGERATOR SHELF PARTS

For Models: KSRK25FVWH01, KSRK25FVBL01, KSRK25FVBT01, KSRK25FVMK01, KSRK25FVSS01, KSRK25FVMS01

(White) (Black) (Biscuit) (Mono Stainless) (Stainless Steel) (Mono Stainless)

W10233042

Illus. Part

No. No. DESCRIPTION

1 2195975 Shelf Assembly,

Cantilever (3)

2 2301025 Button, Humidity

3 2301026 Slide, Humidity

4 2301117 Gasket, Side (2)

5 2301568 Cover, Meat Pan

(Includes Items

13, 14, 15 & 20)

W10142717

Snack Pan

(Includes 30)

7 Glide Assy

2301549 Left Side

2301548 Right Side

8 2301010 Glass, Cover

9 2301567 Cover, Crisper

(Includes 2,

3, 4, 11, 12,

13, 14 & 19)

10 2301009 Glass, Cover

11 2301116 Gasket (Front)

12 2301115 Gasket (Rear)

W10165598

Crisper Pan

(Includes 13,

14, 18, 19 & 21)

W10165656

Meat Pan

(Includes 13,

14, 19 & 22)

18 2301001 Window, Crisper

20 2301126 Deflector

21 Cap, Crisper Pan

2301016 Right Side

2301017 Left Side

22 2301227 Window, Meat Pan

24 2216102 Shelf & Roller

Assembly

25 2196485 Stud Assembly

W10141750

Shelf, Snack Pan

27 3400894 Screw

28 2196483 Stud Assembly

29 8281158 Screw

30 2179243 Trim, Snack Pan

FREEZER LINER PARTS

For Models: KSRK25FVWH01, KSRK25FVBL01, KSRK25FVBT01, KSRK25FVMK01, KSRK25FVSS01, KSRK25FVMS01

(White) (Black) (Biscuit) (Mono Stainless) (Stainless Steel) (Mono Stainless)

W10233042

FREEZER LINER PARTS

For Models: KSRK25FVWH01, KSRK25FVBL01, KSRK25FVBT01, KSRK25FVMK01, KSRK25FVSS01, KSRK25FVMS01

(White) (Black) (Biscuit) (Mono Stainless) (Stainless Steel) (Mono Stainless)

W10233042

Illus. Part

No. No. DESCRIPTION

1 Liner (Not A

Seviceable Part)

2 3400893 Screw

4 2198697 Gasket

5 2301139 Basket, Tall

6 Track, Basket−Dual

2301293 Right Side

2301294 Left Side

7 2211746K Shelf, Slide Out

Upper

8 2301134K Basket, Front

9 Shelf Track

2301289 Right Side

2301290 Left Side

10 2205837K Shelf (2)

11 2301140 Basket, Sloped

W10004810

Screw

13 842534 Clip, Air Duct (2)

14 2198587 Cover, Emitter

15 2198635 Spring

16 2198634 Pin

17 1115373 Switch, Rocker Arm

W10193840

P.C. Board

Emitter

19 2255720 Cover, Ice Maker

20 2212321 Slide, Ice Maker

Mounting

21 489478 Screw

22 489214 Screw

23 2162085 Light Socket

24 2326255 Light Bulb

25 8281185 Screw

26 2198633 Flipper

W10173569

Cover, Receiver

28 2315398 Slide, Ice Maker

Shut Off

W10193666

P.C. Board,

Receiver

30 2198643 Lens

31 2198589 Light Shield

32 2212340 Light Lens

33 2198641 Bracket, Ice Maker

Cover

34 2155597 Socket, Light

35 Ladder

2198609 Left Side

2198610 Right Side

36 2303234 Shield, Wiring

MOTOR AND ICE CONTAINER PARTS

For Models: KSRK25FVWH01, KSRK25FVBL01, KSRK25FVBT01, KSRK25FVMK01, KSRK25FVSS01, KSRK25FVMS01

(White) (Black) (Biscuit) (Mono Stainless) (Stainless Steel) (Mono Stainless)

W10233042

MOTOR AND ICE CONTAINER PARTS

For Models: KSRK25FVWH01, KSRK25FVBL01, KSRK25FVBT01, KSRK25FVMK01, KSRK25FVSS01, KSRK25FVMS01

(White) (Black) (Biscuit) (Mono Stainless) (Stainless Steel) (Mono Stainless)

W10233042

Illus. Part

No. No. DESCRIPTION

1 2198573 Ice Bin

2 2317256 Crusher Bin

3 2317240 Auger

4 2258220 Washer

5 1119007 Spacer, Flat (4)

6 2317248 Cover, Crusher

7 2257024 Blade, Rotary

8 1119005 Spacer, Step (2)

9 2257020 Blade, Fixed

10 2257023 Blade, Rotary

11 2317239 Block, Blade

12 489229 Roll Pin

13 2257022 Blade, Rotary

14 489235 Washer, Plain

15 2198661 Washer, Coupling

16 2188918 Coupling

17 8281164 Screw

18 3400065 Screw

19 2317277 Latch, Bin

20 2198608 Spring, Latch

21 8281163 Screw

22 2188919 Holder

23 2317243 Wiper

24 2198628 Seal

25 2317250 Divider−Chamber

26 2188916 Drive Shaft

27 2322488 Enclosure, Motor

28 2322580 Dispenser, Motor

29 2212305 Cover

W10209450

Wire Harness,

IDI Motor

31 2315559 Sleeve, Coupling

100 2317273 Ice Container

(Complete)

REFRIGERATOR DOOR PARTS

For Models: KSRK25FVWH01, KSRK25FVBL01, KSRK25FVBT01, KSRK25FVMK01, KSRK25FVSS01, KSRK25FVMS01

(White) (Black) (Biscuit) (Mono Stainless) (Stainless Steel) (Mono Stainless)

W10233042

REFRIGERATOR DOOR PARTS

For Models: KSRK25FVWH01, KSRK25FVBL01, KSRK25FVBT01, KSRK25FVMK01, KSRK25FVSS01, KSRK25FVMS01

(White) (Black) (Biscuit) (Mono Stainless) (Stainless Steel) (Mono Stainless)

W10233042

Illus. Part

No. No. DESCRIPTION

1 Refrigerator Door

(Includes #7)

2313299W White

2313299B Black

2313299T Biscuit

2301184S Stainless Steel

2301184SAP

Monochromatic

Satina

2 2301486 Door, Compartment

3 2193409K Beverage Holder(2)

4 Handle

2319727W White

2319727B Black

2319727T Biscuit

2319727S Stainless Steel

5 Door Gasket,

Magnetic

2221302 Mist Beige

2221313 Black

6 2219698 Stud

7 Set Screw

W10010140

Chrome

W10010150

Black

8 Nameplate

W10046670

White

W10046640

Black

W10046700

Biscuit

W10046610

Gray

9 488208 Screw

10 2182178 Door Closer,

Upper Cam

11 2159124 Gasket

12 489420 Screw

13 Bracket, Door Stop

2206629 Chrome

2206629B Black

14 2223434K Door Bin (4)

15 3400012 Screw

16 Thimble−Top

2308091 For White,Biscuit,

& Black Models

2308050 For Stainless

Steel and

Monochromatic

Satina Models
