CABINET PARTS

For Model: KDDO24RVX00

(Custom Panel Overlay)

5−09 Litho In U.S.A. (wam) (psw) Part No. W10233586 Rev. B

DOUBLE DRAWER

CABINET PARTS

For Model: KDDO24RVX00

(Custom Panel Overlay)

W10233586

Illus. Part

No. No. DESCRIPTION

1 Literature Parts

W10130022

Installation

Instructions

W10130023

Use & Care Guide

W10233837

Service &

Wiring Sheet

W10233839

Energy Guide

2 4344793 Screw

W10233777

Rail Assy.

W10233778

Support Shelf, LH

W10233779

Support Shelf, RH

W10233780

Support Rubber A

7 4344748 Ladder, LH

8 4344749 Ladder, RH

9 4344794 Screw

10 4344795 Washer

W10162986

Screw & Washer

W10204610

Defrost Heater

13 4344747 Heat Shield

W10204621

Thermal Fuse Assy.

W10204630

Lead Wire Support

W10204632

Liner Bushing

17 Cabinet (Not a

Servicable Part)

LINER PARTS

For Model: KDDO24RVX00

(Custom Panel Overlay)

W10233586

LINER PARTS

For Model: KDDO24RVX00

(Custom Panel Overlay)

W10233586

Illus. Part

No. No. DESCRIPTION

W10204635

Kick Plate

2 4344762 Plate, Bottom

3 4344763 Leveling Leg

W10204638

Auxiliary Plate

5 4344823 Seal, Brace

6 4344789 Side Frame, LH

7 4344790 Side Frame, RH

8 4344771 Bracket, Grille

9 4344820 Side Support, LH

10 4344821 Side Support, RH

W10204640

Kick Plate Mount

12 4344797 Screw, Lower Hinge

13 4344826 Screw, Grille

W10204644

Screw

15 4344824 Cable Clamp

16 4344825 Screw

W10204645

Main PCB Box

W10204646

PCB Box Film

W10204648

Main PCB

W10204647

PCB Box Cover

W10204659

PCB Standoff

W10204663

Power Harness

W10205076

Acoustic Foam B

W10205077

Acoustic Foam C

W10205078

Acoustic Foam A

W10204929

Lamp Cover

W10204931

Lamp Holder

W10204930

LED Lamp

W10205067

Mullion Cover

W10205069

Screw

W10205071

Mullion Insulation

W10205072

Mullion Insulation

UPPER DRAWER PARTS

For Model: KDDO24RVX00

(Custom Panel Overlay)

W10233586

UPPER DRAWER PARTS

For Model: KDDO24RVX00

(Custom Panel Overlay)

W10233586

Illus. Part

No. No. DESCRIPTION

W10204697

Drawer Box Assy.

W10204698

Top Mat

W10204699

Drawer Partition

W10233777

Rail Assy.

W10204700

Gasket

W10204702

Top Door Assy.

W10204808

Screw

W10204809

Screw

W10204810

Screw

W10204861

Top Wrap

W10204865

Screw

12 4344809 Plate, Door Handle

W10204866

Screw

W10204867

Wrap Spacer

W10204868

Wrap Gap Spacer

W10204884

Indicator Harness

W10204885

Lead Wire Support

W10204887

Control Panel Assy

W10204888

Door Handle

W10204920

Nut

W10204889

Door Gasket, Long

W10204897

Door Gasket, Short

W10205081

Wire Support Tape

W10204927

Control Panel

W10204928

Label, Panel

W10204929

Lamp Cover

W10204930

LED Lamp

W10204931

Lamp Holder

W10204932

Display PCB Assy.

W10204933

PCB Harness

W10204934

Lamp Harness

W10204935

Screw

W10204936

Panel Insulation

W10204937

Panel Insulation B

Following Parts Not Illustrated

W10204926

Overlay Parts Kit

LOWER DRAWER PARTS

For Model: KDDO24RVX00

(Custom Panel Overlay)

W10233586

LOWER DRAWER PARTS

For Model: KDDO24RVX00

(Custom Panel Overlay)

W10233586

Illus. Part

No. No. DESCRIPTION

W10204921

Drawer Box Assy.

W10204922

Bottom Mat

W10204923

Drawer Partition

W10233777

Rail Assy.

W10204700

Gasket

W10204925

Formed Door Assy.

W10204808

Screw

W10204809

Screw

W10204810

Screw

W10204861

Top Wrap

W10204865

Screw

12 4344809 Plate, Door Handle

W10204866

Screw

W10204867

Wrap Spacer

W10204868

Wrap Gap Spacer

16 4344813 Name Plate

W10204888

Door Handle

W10204920

Nut

W10204889

Door Gasket, Long

W10204897

Door Gasket, Short

UNIT PARTS

For Model: KDDO24RVX00

(Custom Panel Overlay)

W10233586

UNIT PARTS

For Model: KDDO24RVX00

(Custom Panel Overlay)

W10233586

Illus. Part

No. No. DESCRIPTION

1 4344775 Compressor

2 4344780 Bolt

3 4344779 Grommet

W10204672

Rear Insulation

5 4344786 Rear Cover

W10204673

Cabinet Base Plate

W10204674

Air Baffle

8 4344763 Leg

W10163273

Dryer

10 4344829 Cable Tie

W10163193

Drain Tray

W10163276

Drain Trap

W10163274

Vibration Rubber

W10204676

Power Cord

W10204677

Condenser Motor

16 4344776 Motor Starter

17 4344837 Capacitor

18 4344836 5SP Clip

19 4344831 Bushing Clip

20 4344907 Edge Trim

21 4344825 Screw

22 4344832 Screw

W10204686

Bolt

24 4344826 Screw

25 4344797 Bolt

26 4344913 Warning Label

W10204687

Fan Cover

W10204688

Fan Bushing

W10204689

Vibration Rubber A

W10204690

Vibration Rubber B

31 4344829 Cable Tie

32 4344773 Bracket, Timer

W10205063

Defrost Sensor

W10205062

Terminal Protector

W10204941

Fan Cover

W10204942

Motor & Fan

W10204943

Door Switch

W10204945

Sensor Case

W10204946

Temp Sensor

W10204947

Wire Harness

W10204948

Sensor Case Seal

W10204952

Insulation

W10205060

Plate Cover

W10205061

Screw

W10270493

Nut

Following Parts Not Illustrated

4344912 Warning Label

REFRIGERANT CHARGE

3.25 oz.
