OVEN PARTS

For Model: KDRP407HSS12

(Stainless Steel)

5−07 Litho in U.S.A. (cre) Part No. 8186300

30" KITCHENAID

FREE STANDING RANGE

DUAL FUEL

OVEN PARTS

For Model: KDRP407HSS12

(Stainless Steel)

8186300

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 Literature Parts

9759536 Installation

Instructions

8301284 Use & Care Guide

9759534 Tech Sheet

9759441 Conversion

Instructions

3191638 Safer Cooking Tips

2 4449809 Screw, 8−18 x 3/8

7 4455866 Top, Chassis

8 4448520 Bumper, Door

9 4452158 Tube, Vent

10 4452163 Lens, Light

11 4448972 Oven Light Assy

4449748 Screw

12 4452164 Bulb, Light

13 Hinge Receiver

4455605 Left Hand

4455606 Right Hand

14 9759060 Frame, Front

15 4455382 Gasket, Door

16 4452152 Bracket, Mounting

4449809 Screw

17 4452260 Spacer, Foam

19 4451478 Support, Insulation

21 4455510 Bracket, Support

24 9759525 Latch Assy

25 4455641 Side, Chassis

26 4452234 Back, Chassis

27 Liner, Oven

(Not serviceable)

29 4455636 Sensor

30 4449154 Screw, 8−32 x .440

31 4449040 Screw, 8−18 x 3/8

32 3196176 Screw, 8−18 x 1/2

37 9759243 Thermostat (TOD)

(Temp.) SPST

43 4455649 Base, Chassis

49 4448933 Retainer, Gasket

50 4451747 Cover, Back

56 4448982 Button, Plug

FOLLOWING PARTS

NOT ILLUSTRATED

INSULATION

4449316 Insulation, Wrap

4450365 Insulation, Back

4452337 Insulation,

Bottom Vent

OVEN DOOR PARTS

For Model: KDRP407HSS12

(Stainless Steel)

8186300

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 4457127 Door Liner

2 Hinge, Door

9760577 R.Side

9760578 L.Side

3 4449259 Glass, Inner

4 4451722 Insulation, Door

5 9759743 Retainer, Glass

7 4449263 Glass, Inner

8 4449743 Screw, 8−32 x 3/8

9 4451668 Retainer, Glass

12 4452316 Assy, Door Glass

13 9760544 Door Handle

14 Bracket, Handle

4455803 Right Hand

4455804 Left Hand

3400832 Screw

19 9757707 Shield, Heat

20 4449809 Screw, 8−18 x 3/8

21 4452326 Seal, Door Top

23 4451432 Retainer, Clip

3400832 Screw

24 3196184 Screw, 8−32 x .548

INTERNAL OVEN PARTS

For Model: KDRP407HSS12

(Stainless Steel)

8186300

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

2 4456103 Element, Broil

4449154 Screw

3 4457277 Grill, Broiler

4 4457276 Pan, Broiler

5 3181534 Rack, Roasting

6 4452807 Rack, Oven

7 4452155 Element, Hidden

Bake

9 4451583 Motor, Convection

10 4452226 Blade, Fan

11 4448418 Cover, Fan

12 4452227 Nut

13 4452157 Element,

Convection

14 4455037 Tray, Hidden

Bake

15 4450039 Cover, Access

16 4449154 Screw, 8−32 x .440

17 4449809 Screw, 8−18 x 3/8

CONTROL PANEL PARTS

For Model: KDRP407HSS12

(Stainless Steel)

8186300

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 4457268 Panel, Control

2 4453000 Bracket, Display

3 8300805 Bracket, Display

Mounting

4 3196537 Screw, 8−18 x 3/8

5 4452443 Control, Zodiac

6 4449746 Screw, 6−19 x 1

7 4455806 Glass,

Control Panel

8 4452999 Module, Display

9 2004333 Palnut

10 2005292 Nameplate

11 4457269 Face, Control

Panel

12 4455192 Bezel, Knob

13 4454970 Knob, Control

14 4455115 Knob, Temp/Time

15 4455141 Knob, Selector

16 4457218 Button, Cancel

4457278 Wire, Jumper

17 4452997 Button, Enter

18 4457152 Bezel, T−Stat

19 4452842 Switch, Rocker

TOP VENTING PARTS

For Model: KDRP407HSS12

(Stainless Steel)

8186300

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 4451759 Vent, Exhaust

2 4455178 Elbow, Vent−Top

3 4452811 Blower 60MM

4449809 Screw (4)

3400015 Screw (1)

4 4455177 Elbow, Vent−Bottom

5 6610122 Transformer, Light

6 8300642 Transformer,

Control

7 4449809 Screw, 8−18 x 3/8

8 4455352 Bracket, Blower

20 4457216 Standoff,

Zodiac Control

21 4451758 Seal, Foam

22 4452489 Deflector, Vent

Box

23 4452441 Bracket, Control

Mounting

24 9759149 Control, Zodiac

25 4451985 Suppressor

3400080 Screw (4)

26 4453207 Insulator,

Control Board

COOKTOP PARTS

For Model: KDRP407HSS12

(Stainless Steel)

8186300

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 4456868 Cooktop

2 4455849 Burner Head

3 3368921 Screw, 7−18 x 3/4

4 4455243 Cap, Burner

5 4456622 Orifice Holder

(Includes Orific &

Ignitor)

3400843 Screw

6 3177991 Screw, 8−18 x 1/4

7 4457331 Grate, Burner

8 4457150 Grate, Filler

9 4454961 Trim, Island

10 4455031 Support,

Backsplash

11 4454959 Trim, Backsplash

12 3400837 Screw, 8−18 x 3/8

15 4455109 Plate, Simmer

BURNER BOX AND MANIFOLD PARTS

For Model: KDRP407HSS12

(Stainless Steel)

8186300

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 4457272 Tubing, Gas

Burner − RF

2 4457273 Tubing, Gas

Burner − RR

3 4457274 Tubing, Gas

Burner − LF

4 4457275 Tubing, Gas

Burner − LR

7 4457267 Manifold

8 4456818 Valve, Burner

9 3186217 Bolt, Gas Valve

10 4457173 Burner Switch &

Harness Assembly

3191387 Seal, Switch

11 9759091 Pressure Regulator

12 4457265 Box, Burner

13 3192439 Seal, Switch

14 Support, Cooktop

4452442 R.Side

4457220 L.Side

4449809 Screw

15 Side, Burner Box

8285607 Right Side

8285606 Left Side

16 4457315 Support, Rear

17 9760557 Support, Cooktop

18 3192811 Bracket, Burner

19 3177991 Screw, 8−18 x 1/4

21 4455645 Tube, Manifold

22 4457271 Cover, Manifold

23 Adapter

4453116 1/2" Female

4453115 1/2" Male

4450118 Nut, 6−32 U Type

24 4453036 Cover, Burner

Box

25 8522426 Module, Spark

CHASSIS PARTS

For Model: KDRP407HSS12

(Stainless Steel)

8186300

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

1 4452802 Vent, Bottom

Lower

2 4449809 Screw, 8−18 x 3/8

3 4452798 Backer, Trim Lower

4 3400837 Screw, 8−18 x 3/8

5 4452800 Deflector, Center

6 4452420 Vent, Bottom Upper

7 4452425 Vent, Center

4453323 Gasket

3400805 Screw (4)

8 3196537 Screw, 8−18 x 3/8

9 9759092 Bracket, Mounting

Regulator

10 9759117 Foot

11 3400518 Screw,

5/16−12 x 5/8

12 4455644 Gusset

13 4455643 Support, Channel

3400080 Screw (8)

14 9760672 Brace, Rear

15 Trim, Front

4452804 Right Side

4453205 Left Side

16 3196537 Screw, 8−18 x 3/8

17 Side Chassis

4457251 Right Side

4457252 Left Side

18 9760476 Box, Terminal

19 9760482 Cover, Terminal

Box

20 9757403 Block, Terminal

21 9759118 Plate, Mounting

OPTIONAL PARTS

For Model: KDRP407HSS12

(Stainless Steel)

8186300

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

SPLICING WIRES−−25FT.

LENGTH

242828 Wire (12 Ga.

150 c Black)

242820 Wire (14 Ga.

150 c Black)

242821 Wire (14 Ga.

150 c Blue)

242822 Wire (14 Ga.

150 c Brown)

242830 Wire (14 Ga.

200 c Brown)

242823 Wire (14 Ga.

150 c Green)

242824 Wire (14 Ga.

150 c Orange)

242829 Wire (12 Ga.

150 c Red)

242825 Wire (14 Ga.

150 c Red)

242831 Wire (14 Ga.

200 c Red)

242826 Wire (14 Ga.

150 c White)

242827 Wire (14 Ga.

150 c Yellow)

242832 Wire (14 Ga.

200 c Yellow)

WIRING HARNESS PARTS

4448444 Grommet, Rail

9759256 Harness, Wire

(Main)

4456549 Harness, Wire

(Spark Module)

4456628 Harness, Wire

(Ignitor 39")

4456627 Harness, Wire

(Ignitor 28")

4456626 Harness, Wire

(Ignitor 15")

3191506 Bushing, Conduit

1129449 Bushing

9760506 Conduit

4449809 Screw

112432 Nut

4450800 Screw, Ground

4454835 Tie, Cable

4452222 Spacer, Harness

Miscellaneous

814381 Pin Hinge Kit

8301282 Conv. Kit (LP)

4453141 Bracket, Anti−Tip

4453202 Bracket, Anti−Tip

ADHESIVE

591014 Adhesive

Loctite (1/3 oz.)

482338 Sealer, Silastic

(3 oz.)

4453192 Seal, Ribbon

Cable

4453191 Seal, Access

Panel
