KitchenAid SUPERBA KEBS277BAL3 Manual de usuario

CONTROL PANEL PARTS

For Models: KEBS277BBL3, KEBS277BAL3, KEBS277BWH3

(Black) (Almond) (White)

1−96 Litho in U.S.A.(rmb) Part No. 885791

SUPERBA

27" BUILT−IN ELECTRIC

DOUBLE OVEN

Convection Upper

Self Clean Lower

CONTROL PANEL PARTS

OPTIONAL PARTS (NOT INCLUDED)

For Models: KEBS277BBL3, KEBS277BAL3, KEBS277BWH3

(Black) (Almond) (White)

885791

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

NOTE: The screws and nuts

required to attach a part are

listed immediately following

that part.

1 Membrane, Switch

4454365 Black

4454366 White

4454367 Almond

2 3181889 Bracket, Mounting

Membrane Switch

3 3181705 Microcomputer

3185648 Screw (2)

4 3183705 Retainer, Bracket

98520 Screw

5 3182985 Clip, (3)

Retainer

6 3182162 Hinge, Vent Door

7 Door, Latch Handle

3182151 Black

3182157 Almond

3182154 White

3178001 Screw

8 3183702 Trim, Panel

3185647 Screw

309133 Screw (2)

9 3184321 Bracket (2)

98520 Screw (2)

10 Frame, Control

Panel

3187954 Black Model

3187955 White Model

3187956 Almond Model

11 3184567 Clip, Control

Frame

LITERATURE PARTS

LIT3185962

Tech Sheet

LIT3183659

Installation

Instructions

LIT3188199

Use & Care Guide

LIT4449066

Cookbook

LIT3183987

Guide, Auto Set

LIT3183790

Video

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

FOLLOWING PARTS

NOT ILLUSTRATED

SPLICING WIRES−−25FT.

LENGTH

18 Ga. 80 c Rating

350806 Yellow

16 Ga. 80 c Rating

242829 Blue

14 Ga. 150 c Rating

242820 Black

242821 Blue

242822 Brown

242823 Green

242824 Orange

242825 Red

242826 White

242827 Yellow

14 Ga. 200 c Rating

242830 Brown

242831 Red

242832 Yellow

12 Ga. 150 c Rating

242828 Black

242829 Red

PAINT, TOUCH−UP (1/2oz.)

72017 White

72107 Almond

72110 Harvest Gold

72112 Toast

72113 Platinum

72032 Black

261869 Citrine White

PAINT, PRESSURIZED SPRAY

(13 oz.)

350930 White

350956 Almond

261890 Harvest Gold

285365 Toast

285366 Platinum

830864 Black

350942 Primer

PAINT, BULK (1 qt.)

799344 White

978883 Almond

261891 Harvest Gold

285367 Toast

285368 Platinum

ADHESIVE

482338 Sealer, Silastic

(3 Oz.)

591014 Adhesive, Loctite

(1/3 Oz.)

UPPER OVEN PARTS

For Models: KEBS277BBL3, KEBS277BAL3, KEBS277BWH3

(Black) (Almond) (White)

885791

UPPER OVEN PARTS

For Models: KEBS277BBL3, KEBS277BAL3, KEBS277BWH3

(Black) (Almond) (White)

885791

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

NOTE: The screws and nuts

required to attach a part are

listed immediately following

that part.

2 3177545 Bracket, Conduit

3 3177739 Cabinet, Back

3185647 Screw

6 3178143 Cabinet, Top

3185647 Screw

7 3183748 Top, Module

3185647 Screw

8 Side, Cabinet

3177440 Right Hand

3177438 Left Hand

3185647 Screw

9 3186684 Tube, Vent

3185648 Screw (3)

10 3150505 Oven Light Assy.

11 3184533 Gasket, Light

12 311255 Bulb, Oven

Light

13 3185085 Plug, Button

Bulb

14 4454458 Frame, Front

15 3179813 Seal, Door

16 3179848 Clip, Oven Seal

17 3177681 Bracket, Switch

18 3177923 Insulator, Switch

19 3177621 Module, Bottom

20 3179220 Rail, Support (4)

3185647 Screw

22 3177434 Support, Oven

3185647 Screw

23 3178612 Shield, Radiation

3179795 Screw (6)

3185647 Screw

24 3177433 Bracket, Hinge

3185647 Screw

25 Side Trim,

Door (2)

3187875 Black Model

3187878 White Model

3187881 Almond Model

26 3177561 Back, Module

3185647 Screw

27 3185563 Liner, Oven

28 3178298 Hinge, Door (2)

31 4173553 Switch, Door

4159117 Nut (2)

313489 Screw (2)

33 3179587 Retainer, Seal

4159450 Screw (2)

3179776 Screw (2)

34 Vent, Middle Trim

3187883 Black Model

3187885 White Model

3187887 Almond Model

3188644 Screw, Black (4)

3188645 Screw (4)

3188646 Screw, Almond (4)

4168863 Screw (2)

35 3183791 Vent, Tube

4173231 Screw

39 4168203 Cover, Cap Tube

4159445 Screw

41 3183752 Bracket, Control

3177991 Screw

44 4173179 Retainer,

Insulation

3185647 Screw

FOLLOWING PARTS

NOT ILLUSTRATED

INSULATION

4454418 Insulation, Wrap

LOWER OVEN PARTS

For Models: KEBS277BBL3, KEBS277BAL3, KEBS277BWH3

(Black) (Almond) (White)

885791

LOWER OVEN PARTS

For Models: KEBS277BBL3, KEBS277BAL3, KEBS277BWH3

(Black) (Almond) (White)

885791

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

NOTE: The screws and nuts

required to attach a part are

listed immediately following

that part.

3 3183748 Top, Module

3185647 Screw

4 3186684 Tube, Vent

3185648 Screw (3)

5 3185562 Liner, Oven

7 311255 Bulb, Oven Light

9 3150505 Oven Light Assy.

11 3184533 Gasket, Light

12 4454457 Frame, Front

13 3179813 Seal, Door

3179848 Clip, Oven Seal

14 3177681 Bracket, Switch

3177991 Screw (2)

15 3177923 Insulator, Switch

16 3177551 Bottom, Oven

17 3179220 Rail, Support (2)

3185647 Screw

18 3177433 Bracket, Hinge (2)

3179795 Screw (6)

3185647 Screw

19 3177621 Bottom, Module

20 3178612 Shield, Radiation

3179795 Screw (6)

3185647 Screw

21 3177434 Support, Oven

3185647 Screw

22 3177560 Back, Module

3185647 Screw

24 3179848 Clip, Seal (3)

25 3178298 Hinge, Door (2)

26 3185085 Button, Plug

27 3182814 Button, Plug

28 3179945 Vent Tube, Lower

3185647 Screw

29 3187388 Vent Tube, Upper

30 4173553 Switch, Door

4159117 Nut (2)

313489 Screw (2)

32 3179587 Retainer, Seal

4159450 Screw (2)

33 4168203 Cover, Cap Tube

4159445 Screw

34 Trim, Lower Vent

3177783 Black Model

3187957 White Model

3187959 Almond Model

35 4163883 Cover, Probe

36 3149653 SPST Thermostat

FOLLOWING PARTS

NOT ILLUSTRATED

INSULATION

4454418 Insulation, Wrap

UPPER AND LOWER OVEN DOOR PARTS

For Models: KEBS277BBL3, KEBS277BAL3, KEBS277BWH3

(Black) (Almond) (White)

885791

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

NOTE: The screws and nuts

required to attach a part are

listed immediately following

that part.

1 3185497 Liner, Door

2 3185462 Gasket, Window

3 3185457 Glass, Clear

4 3185460 Insulation, Door

5 3188815 Insulation

Retainer

4173601 Screw (4)

6 3185458 Glass, Reflective

7 Glass, Door

3187863 Black Model

3187867 Almond Model

3187865 White Model

8 3185439 Retainer, Glass

9 3185459 Glass, Clear

10 Handle, Door

3185986 Black Model

3185988 Almond Model

3185987 White Model

11 3185438 Plate, Latch

12 Frame, Door

3187850 Black Model

3187852 White Model

3187854 Almond model

13 3182138 Spacer, Handle

14 3188599 Bushing, Handle

3181637 Screw

15 3188633 Foil, Adhesive

16 3188635 Foil, Adhesive

INTERNAL OVEN PARTS

For Models: KEBS277BBL3, KEBS277BAL3, KEBS277BWH3

(Black) (Almond) (White)

885791

Illus. Part

No. No. DESCRIPTION Illus. Part

No. No. DESCRIPTION

NOTE: The screws and nuts

required to attach a part are

listed immediately following

that part.

1 Liner, Oven

3185562 Self Clean (Lower)

3185563 Convection (Upper)

2 661415 Element, Broil

3 3147563 Grill, Broiler

4 3147845 Pan, Broiler

5 3185367 Rack, Offset

6 3185368 Rack, Oven

7 661416 Element, Bake

3185648 Screw (2)

8 4167277 Nut, Meat Probe

9 4163975 Gasket, Meat Probe

10 4167266 Probe Cover

11 4159557 Washer

12 3179672 Spacer − Tubing

13 3150107 Meat Probe Jack

14 3150144 Meat Probe

19 3180815 Cover, Fan

3185648 Screw (4)

20 3178517 Element, Convect.

3185648 Screw (3)

23 3180694 Bracket, Element

3185648 Screw (2)

24 3181534 Rack, Roasting T/C

25 3148440 Sensor

LATCH AND VENT PARTS

For Models: KEBS277BBL3, KEBS277BAL3, KEBS277BWH3

(Black) (Almond) (White)

885791

LATCH AND VENT PARTS

For Models: KEBS277BBL3, KEBS277BAL3, KEBS277BWH3

(Black) (Almond) (White)

885791

Illus. Part

No. No. DESCRIPTION

NOTE: The screws and nuts

required to attach a part are

listed immediately following

that part.

1 3183748 Module, Top

2 258076 Block, Terminal

308043 Screw

4 Switch, Latch

3178668 Upper Oven

3183784 Lower Oven

98106 Screw

5 3178185 Insulator, Switch

98106 Screw

254225 Screw

6 3177662 Guard, Latch

3177991 Screw

7 Handle, Latch

3177969 Upper Oven

3184037 Screw (2)

3179116 Screw

3181963 Lower Over

3185414 Screw (2)

8 3184039 Knob, Handle

3183294 Screw

10 3178410 Latch Mechanism

11 3177496 Plate, Mounting

3177991 Screw

12 3185455 Baffle, Blower

311773 Screw

13 3183954 Nozzle, Vent

Bottom (2)

14 3183955 Nozzle, Vent

Top (2)

15 3183999 Box, Vent

16 3183964 End, Vent Box

3185647 Screw

17 3183533 Bracket, Mounting

Fan

3177991 Screw

18 3183720 Blower, Fan

19 3183791 Vent, Tube

4173231 Screw

20 3149650 SPST Thermostat

3185647 Screw

21 3183785 Shield, Heat

3177991 Screw

26 313755 Seal, Foam

27 4159035 Bushing

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Horno de KitchenAid

KitchenAid

KitchenAid KERS807SBL - 30 Inch Electric Range Manual de usuario

KitchenAid

KitchenAid KEBS107SBL04 Manual de usuario

KitchenAid

KitchenAid Superba KEBS277 Manual de usuario

KitchenAid

KitchenAid KEBK276SBL04 Manual de usuario

KitchenAid

KitchenAid KEBS207SBL04 Manual de usuario

KitchenAid

KitchenAid KEMI301B Manual de usuario

KitchenAid

KitchenAid KESS908SPB04 Manual de usuario

KitchenAid

KitchenAid SUPERBA KEBS277BAL0 Manual de usuario

KitchenAid

KitchenAid ULTIMA COOK KHHS179L Manual de usuario

KitchenAid

KitchenAid KCO253CU Manual de usuario

KitchenAid

KitchenAid Architect Series II KEBU208SSS Manual de usuario

KitchenAid

KitchenAid Oven Manual de usuario

KitchenAid

KitchenAid Superba KEBS277WBL2 Manual de usuario

KitchenAid

KitchenAid KFGD500ESS Manual de usuario

KitchenAid

KitchenAid KEBS177SWH - 27 Inch Single Electric Wall... Manual de usuario

KitchenAid

KitchenAid KOHSPB 60603 Manual de usuario

KitchenAid

KitchenAid KEBC147VWH - 24" Single Wall Oven Manual de usuario

KitchenAid

KitchenAid KEBS208B Manual de usuario

KitchenAid

KitchenAid KEBS277SBL2 Manual de usuario

KitchenAid

KitchenAid KCO224 Manual de usuario

KitchenAid

KitchenAid KEBK101SBL04 Manual de usuario

KitchenAid

KitchenAid KEMS308SBL04 Manual de usuario

KitchenAid

KitchenAid KEBS107SSS04 Manual de usuario

KitchenAid

KitchenAid KGSS907SBL02 Manual de usuario

Manuales populares de Horno de otras marcas

Bosch

Bosch HVA531NS0 Manual de usuario

Electrolux

Electrolux EOF6P46X Manual de usuario

NEFF

NEFF B44S32 5GB Series Manual de usuario

Combi

Combi BLODGETT BC142GDS Manual de usuario

AEG

AEG COMPETENCE 311704300 Manual de usuario

Falcon

Falcon DOMINATOR PLUS G3106 Series Guía del usuario

Rational

Rational SCC WE 61G Manual de usuario

Smeg

Smeg DOSPA38X Manual de instalación y operación

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manual de usuario

Miele

Miele HR 1954-2 Manual de usuario

KHIND

KHIND OT50 Manual de usuario

Henny Penny

Henny Penny Smoker Box Manual de usuario

Lang

Lang ECOD-AP Manual de usuario

AEG

AEG BEK455310M Manual de usuario

Frigidaire

Frigidaire FNGE90JGR Manual de usuario

Hotpoint

Hotpoint FE9 S831 JSH IX Manual de usuario

GE Advantium SCB2000 Manual de usuario

AEG

AEG DE401301DM Manual de usuario
