KitchenAid KCO124 Manual de usuario

Countertop Oven

Four grille-pain

Horno para mostrador

KCO124

W11407666E.indb 1W11407666E.indb 1 9/12/2023 11:39:47 AM9/12/2023 11:39:47 AM

2 |

PARTS AND FEATURES

1Toughened Glass Window

2Removable Crumb Tray

3Cool Down Surface for Removable

Oven Rack

4Chrome-plated Steel Broiling Rack

5Enamel-coated Pan

6Chrome-plated Steel Oven Rack

7Door Handle

Air Fry Basket

9Start: Start Selected Cooking Mode

10 Cancel: Stops Selected Cooking

Mode

11 Convection: Temperature Switch

Mode

12 Temperature/ Timer Knob

13 Mode Knob: Cooking Mode Selector

14 Preheating Icon

15 Shade Icon

16 Shade Number Graphic

17 Convection Icon

18 Fahrenheit Icon

19 Celsius Icon

Hours Icon

Minutes Icon

Slices Icon

NOTE: Press and hold the Convection button for 3 seconds to switch between the

temperature units Fahrenheit (°F) and Celsius (°C).

W11407666E.indb 2W11407666E.indb 2 9/12/2023 11:39:49 AM9/12/2023 11:39:49 AM

ENGLISH

| 3

PRODUCT SAFETY

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always

be followed, including the following:

1. Read all instructions.

2. Do not touch hot surfaces. Use handles or knobs.

3. To protect against risk of electrical shock, do not put cord, plugs, or any parts of

the Air Fryer in water or other liquid.

4. Close supervision is necessary when any appliance is used by or near children.

5. Unplug from outlet when not in use and before cleaning. Allow to cool before

putting on or taking off parts.

6. Do not operate any appliance with a damaged cord or plug, or after the

appliance malfunctions, or is dropped or damaged in any manner. Return

appliance to the nearest Authorized Service Facility for examination, repair, or

adjustment.

7. The use of accessories/attachments not recommended or sold by KitchenAid

may cause fire, electrical shock, or injury to persons.

8. Do not let cord hang over edge of table or counter, or touch hot surfaces.

9. Do not place on or near a hot gas or electric burner, or in a heated oven.

10. Extreme caution must be used when moving an appliance containing hot oil or

other hot liquids.

11. Use extreme caution when removing Broiling Rack, Multipurpose Pan, Oven

Rack, or disposing of hot grease.

12. Oversize foods or metal utensils must not be inserted in a Air Fryer as they may

create a fire or risk of electric shock.

13. A fire may occur if Air Fryer is covered or touching flammable material, including

curtains, draperies, walls and the like, when in operation. Do not store any item

on top of the appliance when in operation.

W11407666E.indb 3W11407666E.indb 3 9/12/2023 11:39:49 AM9/12/2023 11:39:49 AM

4 |

14. Do not clean with metal scouring pads. Pieces can break off the pad and touch

electrical parts, creating a risk of electric shock.

15. Extreme caution should be exercised when using containers constructed of

materials other than metal or glass.

16. Do not store any materials, other than manufacturer’s recommended

accessories, in this Air Fry when not in use.

17. Do not place any of the following materials in the Air Fry: paper, cardboard,

plastic, or anything similar.

18. Do not cover crumb drawer or any part of the Air Fry with metal foil. This will

cause overheating of the oven.

19. To disconnect, turn the Air Fry “off” by pressing Cancel button, then remove plug

from wall outlet.

20. Do not use the appliance outdoors.

21. Do not use the appliance for other than intended use.

SAVE THESE INSTRUCTIONS

This product is designed for household use only.

PRODUCT SAFETY

ELECTRICAL REQUIREMENTS

Voltage: 120 V~

Frequency: 60 Hz

Power: 1800 W

NOTE: If the plug does not fit in the outlet,

contact a qualified electrician.

Do not modify the plug in any way.

Do not use an adapter.

Do not use an extension cord. If the power

supply cord is too short, have a qualified

electrician or service technician to install an

outlet near the appliance.

The cord should be arranged so that it will

not drape over the countertop or tabletop

where it can be pulled on by children or

tripped over unintentionally.

W11407666E.indb 4W11407666E.indb 4 9/12/2023 11:39:49 AM9/12/2023 11:39:49 AM

ENGLISH

| 5

GETTING STARTED

Make sure all sides are positioned with at

least 4” (10 cm) distance.

Toast

Bagel

Proof

Air Fry

Bake

Broil

Reheat

Dehydrate

Start

Cancel

Convection

Preheating

Shade Slices

Convection

Hrs

Min

Keep Warm

Toast

Bagel

Proof

Air Fry

Bake

Broil

Reheat

Start

Cancel

Convection

Preheating

Shade

Slices

Convection

Hrs

Min

Open the door and align the rack with the

grooves for desired positions

(see”Air Fryer rack position” section).

Before fi rst use, clean all parts and accessories (see “Care and Cleaning” section). Place the

Air Fryer on a dry and fl at level surface. Remove all packaging materials and labels, if present.

Plug into a grounded 3 prong outlet.

Your Air Fryer is now ready to use.

NOTE: Upon fi rst use, the Air Fryer may

produce light smoke. This is normal.

W11407666E.indb 5W11407666E.indb 5 9/12/2023 11:39:50 AM9/12/2023 11:39:50 AM

6 |

Food Portion Temperature Time

Chicken Nuggets 1 Layer 425°F (218°C) 8-10 minutes

Chicken Tenders 1 Layer 425°F (218°C) 13-15 minutes

Chicken Wings 1 Layer 425°F (218°C) 18-20 minutes

Fish Fillets 1 Layer 450°F (232°C) 12-14 minutes

Fish Sticks 1 Layer 450°F (232°C) 10-12 minutes

French Fries 1 Layer 425°F (218°C) 22-24 minutes

Mozarella Sticks 1 Layer 450°F (232°C) 5-7 minutes

Taquitos 1 Layer 400°F (204°C) 5-7 minutes

TIME RECOMMENDATION - AIR FRY FUNCTION

GETTING STARTED

PREHEATING

Preheating your Air Fryer is important for consistent and even results. Once you select your

desired cooking mode or any other settings, and press Start.

The light ring around the Start button will be on, and the Preheat indicator will show on the

LCD. Once the oven has reached the set temperature, a tone will sound to let you know that

you can insert food and begin cooking. Preheating is NOT necessary in all cooking modes.

To skip the Preheat and start the timer directly, push the Start button a second time.

The convection fan is controlled by the Convection button. Pushing the Convection button will

toggle the fan on or off for Bake, Broil, Keep Warm, and Reheat functions. A “Convection”

label and fan icon will appear on the display when the convection fan is on. The Air Fry

function uses a high speed convection fan that cannot be turned off. The Dehydrate function

uses the high speed convection fan as preset, but it may be turned off by pushing the

Convection button.

NOTE: Automatic Preheat is not programmed for Dehydrate, Keep Warm, Reheat, Toast and

Bagel functions.

CONVECTION

NOTE: Gently spray the basket with oil before each batch of food. No more oil is needed.

Results may vary with different food brands and sizes. Follow Toaster Oven instructions from

the back of the food package and reduce time.

TIP: When cooking fatty foods, such as non breaded poultry with skin, use the baking pan

instead of the Air Fry Basket to catch excess oil that may drip from the food.

COOKING FUNCTIONS

W11407666E.indb 6W11407666E.indb 6 9/12/2023 11:39:51 AM9/12/2023 11:39:51 AM

ENGLISH

| 7

Cooking

function Rack

No.

Preset

Temp.

°C (°F)

Temperature

Range °C (°F)

Preset

Time

(Mins.)

Time

Range Elements Run

Dehydrate 1 - 2 150°F

(66°C) 80–180°F

(27–82 °C) 6 hours 1 min–12

hours

2 bottom;

high speed

convect

Proof 1 90°F

(32°C) 75–90°F

(24–32°C) 30 1 min–1

hours 2 bottom

Air Fry 2 400°F

(205°C) 150–450°F

(66–232°C) 17 1 min–1

hours

2 top, 2 bottom,

high speed

convect

Bake 2 350°F

(176°C) 150–450°F

(66–232°C) 30 1 min–2

hours 2 top, 2 bottom,

convect available

Broil 2 450°F

(232°C) 350°F (176°C)

450°F (232°C) 81 min–30

mins 2 top,

convect available

Reheat 2 300°F

(149°C) 150–450°F

(66–232°C) 15 1 min–2

hours 2 top, 2 bottom,

convect available

Keep Warm 2 170°F

(77 °C) 150–450°F

(66–232°C) 1 hour 1 min–2

hours 2 bottom,

convect available

COOKING FUNCTIONS

Cook all foods to minimum safe internal temperatures. Consuming raw or undercooked meats,

poultry, seafood, shellfish, or eggs may increase your risk of food borne illness.

Toasting

functions Rack

No. Preset

Shade Shade Range

(Light to Dark) Preset

Slices Range

(# of slices) Elements Run

Toast 2 4 1-8 2 1-6 Runs 4

elements

Bagel 2 4 1-8 2 1-6 Runs 4

elements

W11407666E.indb 7W11407666E.indb 7 9/12/2023 11:39:51 AM9/12/2023 11:39:51 AM

8 |

AIR FRY RACK POSITION

Rack position for Air Fry

Rack position for Bake, Reheat,

Dehydrate, Proof, Bagel, Toast,

Keep Warm, Broil

Rack position for Baking large

items or items that are sensitive

to over browning on top

W11407666E.indb 8W11407666E.indb 8 9/12/2023 11:39:54 AM9/12/2023 11:39:54 AM

ENGLISH

| 9

USING THE DEHYDRATE FUNCTION

Dehydrate option is to remove moisture content from veggies or fruits to dry and preserve

them.

Set the function knob to Dehydrate.

The preset temperature 150°F will be

shown. If desired, rotate knob to adjust.

Press the knob to show preset time. The

preset time is 6 hours. If desired, rotate

knob to adjust.

Open the door and place the food on the

center of the rack. Close the door.

Press Start to start the cycle.

When the time has elapsed, the end

signal will sound and the Air Fryer will

shut off automatically.

3IMPORTANT: Always use oven mitts when

removing pans or racks.

USING THE PROOF FUNCTION

Dehydrate

Bagel

Proof

Toast

Air Fry

Bake

Broil

Reheat

Keep Warm

Set the function knob to Proof.

The preset temperature 90 °F will be

shown. If desired, rotate knob to adjust.

Press the knob to show preset time. The

preset time is 30 minutes. If desired,

rotate knob to adjust.

The Proof function maintains a warm

environment useful for rising yeast.

Use for dough. To speed up bread proofi ng.

With a range of 75–90°F temperature and

lower heating elements, this setting can be

used to accelerate bread proofi ng (rising).

W11407666E.indb 9W11407666E.indb 9 9/12/2023 11:39:56 AM9/12/2023 11:39:56 AM

10 |

USING THE PROOF FUNCTION

Open the door and place the food on the

center of the rack. Close the door.

Press Start to start the cycle.

When the time has elapsed, the end

signal will sound and the Air Fryer will

shut off automatically.

USING THE BAGEL FUNCTION

Set the function knob to Bagel. Shade and

slices will be shown.

In Bagel mode, the oven distributes power between the top and bottom heating elements to

nicely brown the top of cut bagels while gently warming the outside.

Open the door and place the food on the

center of the rack. Close the door.

Toast

Bagel

Proof

Air Fry

Bake

Broil

Reheat

Dehydrate

Start

Cancel

Convection

Preheating

Shade Slices

Convection

Hrs

Min

Keep Warm

When the time has elapsed, the end

signal will sound and the Air Fryer will

shut off automatically.

Start

Cancel

Convection

Preheating

Shade Slices

Convection

Hrs

Min

Toast

Bagel

Proof

Air Fry

Bake

Broil

Reheat

Dehydrate

Start

Cancel

Convection

Preheating

Shade Slices

Convection

Hrs

Min

Keep Warm

The Shade Icon starts flashing. Rotate the

knob to adjust shade. Press knob to select

slices. The Slices Icon will starts flashing.

If desired, rotate knob to adjust number

of slices.

Press Start to start the cycle.

W11407666E.indb 10W11407666E.indb 10 9/12/2023 11:40:00 AM9/12/2023 11:40:00 AM

Otros manuales para KCO124

Tabla de contenidos

Otros manuales de Horno de KitchenAid

KitchenAid

KitchenAid Architect Series II KEBS107SSS Manual de usuario

KitchenAid

KitchenAid SUPERBA KEBS277XBL0 Manual de usuario

KitchenAid

KitchenAid KEBC147KBL - Architect Series: 24'' Single Electric Wall... Manual de usuario

KitchenAid

KitchenAid KODC304ESS Manual de usuario

KitchenAid

KitchenAid KEBS107SBL04 Manual de usuario

KitchenAid

KitchenAid KESS907SWW - on 30 Inch Slide-In Electric... Manual de usuario

KitchenAid

KitchenAid W10162200A Manual de uso y mantenimiento

KitchenAid

KitchenAid KEMI300W Manual de usuario

KitchenAid

KitchenAid SUPERBA KEMS308 Manual de usuario

KitchenAid

KitchenAid KOSE500ESS Manual de uso y mantenimiento

KitchenAid

KitchenAid KEBS107S Manual de usuario

KitchenAid

KitchenAid KEBK101BSS Manual de usuario

KitchenAid

KitchenAid KEBC107 Manual de usuario

KitchenAid

KitchenAid SUPERBA KEBS277XBL2 Manual de usuario

KitchenAid

KitchenAid KMCE 3610 Manual de usuario

KitchenAid

KitchenAid KEBS278DBL9 Manual de usuario

KitchenAid

KitchenAid KEBS277DBL9 Manual de usuario

KitchenAid

KitchenAid KEHU309SSS03 Manual de usuario

KitchenAid

KitchenAid KOASP60600 Manual de usuario

KitchenAid

KitchenAid KEBS246X Manual de usuario

KitchenAid

KitchenAid KEBS276WBL3 Manual de usuario

KitchenAid

KitchenAid KEBS177SBL04 Manual de usuario

KitchenAid

KitchenAid KEBS208DBL11 Manual de usuario

KitchenAid

KitchenAid KEBC167 Manual de usuario

Manuales populares de Horno de otras marcas

Bosch

Bosch HVA531NS0 Manual de usuario

Electrolux

Electrolux EOF6P46X Manual de usuario

NEFF

NEFF B44S32 5GB Series Manual de usuario

Combi

Combi BLODGETT BC142GDS Manual de usuario

AEG

AEG COMPETENCE 311704300 Manual de usuario

Falcon

Falcon DOMINATOR PLUS G3106 Series Guía del usuario

Rational

Rational SCC WE 61G Manual de usuario

Smeg

Smeg DOSPA38X Manual de instalación y operación

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manual de usuario

Miele

Miele HR 1954-2 Manual de usuario

KHIND

KHIND OT50 Manual de usuario

Henny Penny

Henny Penny Smoker Box Manual de usuario

Lang

Lang ECOD-AP Manual de usuario

AEG

AEG BEK455310M Manual de usuario

Frigidaire

Frigidaire FNGE90JGR Manual de usuario

Hotpoint

Hotpoint FE9 S831 JSH IX Manual de usuario

GE Advantium SCB2000 Manual de usuario

AEG

AEG DE401301DM Manual de usuario
