KitchenAid 5KCO211B Manual de usuario

Countertop Oven

5KCO211

W11407659A_EN.indd 1W11407659A_EN.indd 1 12/24/2019 5:11:51 PM12/24/2019 5:11:51 PM

Start

Pizza

Roast

Bagel

Toast

Bake

Broil

Reheat

Preheating

Shade Slices

Frozen

Hrs

Min

Start

Cancel

Frozen

Pizza

Roast

Bagel

Toast

Bake

Broil

Reheat

Keep Warm

Preheating

Shade Slices

Frozen

Hrs

Min

20 19

1Cool down surface for removable

Oven Rack

12 Temperature / Timer Knob*

2Chrome-plated Steel Broiling Rack 13 Mode Knob: Cooking mode selector

3Enamel-coated Pan 14 Frozen Icon

4Chrome-plated Steel Oven Rack 15 Fahrenheit Icon

5Door Handle 16 Celsius Icon

6Toughened Glass Window 17 Hours Icon

7Removable Crumb Tray 18 Minutes Icon

8High-contrast LCD Display 19 Slices Icon

9 Start: Start selected cooking mode 20 Shade Number Graphic

10 Cancel: Stops selected cooking mode 21 Shade Icon

11 Frozen: Push for frozen food items 22 Preheating Icon

PARTS AND FEATURES

*Adjust the time by 1 minute for the rst hour and then by 5 minutes for the next hour. Adjust

by 5 °F or 1 °C temperature, depending on the unit selected. Rotate and press to select

desired shade and number of slices while using the Toast or Bagel mode.

NOTE: Press and hold the Frozen button for 3 seconds to switch between the temperature

units Fahrenheit (°F) and Celsius (°C).

W11407659A_EN.indd 2W11407659A_EN.indd 2 12/24/2019 5:11:52 PM12/24/2019 5:11:52 PM

ENGLISH

PRODUCT SAFETY

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always

be followed, including the following:

1. Read all instructions. Misuse of appliance may result in personal injury.

2. Do not touch hot surfaces. Use handles or knobs.

3. To protect against risk of electrical shock, do not put cord, plugs, or any parts of

the Countertop Oven in water or other liquid.

4. This appliance is not intended for use by persons (including children) with

reduced physical, sensory or mental capabilities, or lack of experience and

knowledge, unless they have been given supervision or instruction concerning

use of the appliance by a person responsible for their safety.

5. Children should be supervised to ensure that they do not play with the appliance.

6. Unplug from outlet when not in use and before cleaning. Allow to cool before

putting on or taking off parts.

7. Do not operate any appliance with a damaged cord or plug or after the

appliance malfunctions, or is dropped or damaged in any manner. Contact the

manufacturer at their customer service telephone number for information on

examination, repair, or adjustment.

8. The use of accessory attachments not recommended by the appliance

manufacturer may cause injuries.

9. If the supply cord is damaged, it must be replaced by the manufacturer, its

service agent or similarly qualied persons in order to avoid a hazard.

10. Do not let cord hang over edge of table or counter, or touch hot surfaces.

11. This appliance is not intended to be operated by means of an external timer or a

separate remote-control system.

12. The temperature of accessible surfaces may be high when the appliance is

operating.

13. Do not place on or near a hot gas or electric burner, or in a heated oven.

W11407659A_EN.indd 3W11407659A_EN.indd 3 12/24/2019 5:11:53 PM12/24/2019 5:11:53 PM

14. Extreme caution must be used when moving an appliance containing hot oil or

other hot liquids.

15. Bread may burn. Therefore toasters must not be used near or below curtains and

other combustible materials.

16. Use extreme caution when removing Broiling Rack, Multipurpose Pan, Oven

Rack, or disposing of hot grease.

17. Oversize foods or metal utensils must not be inserted in a Countertop Oven as

they may create a re or risk of electric shock.

18. A re may occur if Countertop Oven is covered or touching ammable material,

including curtains, draperies, walls and the like, when in operation. Do not store

any item on top of the appliance when in operation.

19. Do not clean with metal scouring pads. Pieces can break off the pad and touch

electrical parts, creating a risk of electric shock.

20. Extreme caution should be exercised when using containers constructed of

materials other than metal or glass.

21. Do not store any materials, other than manufacturer’s recommended

accessories, in this Countertop Oven when not in use.

22. Do not place any of the following materials in the Countertop Oven: paper,

cardboard, plastic, or anything similar.

23. Do not cover crumb drawer or any part of the Countertop Oven with metal foil.

This will cause overheating of the oven.

24. To disconnect, turn the Countertop Oven “off” by pressing Cancel button, then

remove plug from wall outlet.

25. Do not use the appliance outdoors.

26. Do not use appliance for other than intended use.

27. Refer to the “Care and Cleaning” section for instructions on cleaning the

surfaces in contact with food.

28. This appliance is intended to be used in household and similar application such

as:

- staff kitchen areas in shops, ofces and others working environments;

- farm houses;

- by clients in hotels, motels and other residential type environments;

- bed and breakfast type environments.

CAUTION: Surface may get hot during use.

SAVE THESE INSTRUCTIONS

PRODUCT SAFETY

W11407659A_EN.indd 4W11407659A_EN.indd 4 12/24/2019 5:11:53 PM12/24/2019 5:11:53 PM

ENGLISH

ELECTRICAL REQUIREMENTS

5KCO211B

5KCO211E

Voltage: 220-240 VAC

Frequency: 50-60 Hz

Wattage: 1647-1960 W

5KCO211P

Voltage: 230 VAC

Frequency: 60 Hz

Wattage: 1800 W

NOTE: If the plug does not fit in the outlet,

contact a qualified electrician or service

technician. Do not modify the plug in any

way. Do not use an adapter.

Do not use an extension cord. If the power

supply cord is too short, have a qualified

electrician or service technician to install an

outlet near the appliance.

The cord should be arranged so that it will

not drape over the countertop or tabletop

where it can be pulled on by children or

tripped over unintentionally.

PRODUCT SAFETY

Electrical Shock Hazard

Plug into an earthed outlet.

Do not remove earth prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these

instructions can result in

death, fire, or electrical shock.

GETTING STARTED

Before rst use, clean all parts and accessories (see “Care and Cleaning” section). Remove all

packaging materials, if present. Place the Countertop Oven on a dry and at level surface.

10 cm (4")

Make sure all sides are positioned with 10

cm (4”) distance.

Start

Follow below guidelines to position the

Oven Rack:

1. Top: Use for broiling most meats,

toast and cookies.

2. Bottom: Optimal for most baking and

cooking operations. This position is

suitable for cooking taller food items.

1 2

W11407659A_EN.indd 5W11407659A_EN.indd 5 12/24/2019 5:11:53 PM12/24/2019 5:11:53 PM

PRODUCT FUNCTIONS

The product features 9 cooking functions for a variety of cooking tasks. Memory settings

allows customisations. All your settings will be remembered for next use (until unplugged).

FROZEN OPTION

Allows proper thawing of frozen food items and thawing time varies depending on the

selected functions.

PREHEATING

Allows your oven to saturate the walls and cooking racks based on oven’s set temperature

to remove cold spots that draw heat away from food. During preheating, a light ring around

the start button will glow with “Preheating” displayed in the LCD. A chime will sound after

reaching preheat set temperature. Now insert the food and begin cooking. To skip the

Preheating and start the timer directly, push the START button again. Refer to recipes for

specic Preheating details.

Pizza

Roast

Bagel

Toast

Bake

Broil

Reheat

Keep Warm

Toast mode: The oven distributes power

between the top and bottom heating

elements to deliver fast and even toasting.

Use the Toast mode for bread, toaster

pastries, frozen waffles.

If reheating pastries, use the Reheat mode.

Pizza

Roast

Bagel

Toast

Bake

Broil

Reheat

Keep Warm

Bagel mode: The oven distributes power

between the top and bottom heating

elements to nicely brown the top of cut

bagels while gently warming the outside.

NOTE: NOT available on Broil, Roast, Reheat, or Keep Warm cooking mode.

Refer to the below charts for toasting and cooking functions, or see detailed explanations and

tips provided further for all functions.

TOASTING MODES CHART

Mode Rack

Position

Preset

Shade

Shade Range

(Light to Dark) Preset Slices Range (# of slices)

Toast 1 5 1 - 8 2 1 - 6

Bagel 1 5 1 - 8 2 1 - 6

TOASTING FUNCTIONS

TOASTING MODE

NOTE: Preheating is NOT available on Keep Warm, Reheat, Toast, or Bagel modes.

W11407659A_EN.indd 6W11407659A_EN.indd 6 12/24/2019 5:11:54 PM12/24/2019 5:11:54 PM

ENGLISH

Mode Rack

No.

Preset Temp.

°C (°F )

Temp. Range

°C (°F )

Preset

Time (Mins)

Recommended

Foods

Pizza* 1 - 2 205°C (400°F) 65 °C - 232 °C

(150–450°F) 17 Fresh and frozen

Pizza

Cookies* 1 190°C (375°F) 65 °C - 232 °C

(150–450°F) 10 Cookie Dough

Bake* 1 - 2 175°C (350°F) 65 °C - 232 °C

(150–450°F) 30 Cakes, breads,

casseroles, mufns

Broil* 1 - 2 230°C (445°F) 175°C (350°F)

232°C (450°F) 8Chops, sh,

seafood, browning

Roast* 2 180°C (355°F) 65 °C - 232 °C

(150–450°F) 60 Chicken, meat and

vegetables

Keep

Warm 1 - 2 75°C (170°F) 65 °C - 93 °C

(150–200°F) 60 Keeps food warm

Reheat 1 - 2 150°C (305°F) 65 °C - 232 °C

(150–450°F) 15 Leftovers

COOKING MODES CHART

* The Countertop Oven will automatically preheat when these modes are selected.

COOKING FUNCTIONS

Pizza

Roast

Bagel

Toast

Bake

Broil

Reheat

Keep Warm

Pizza Mode: The oven distributes power

to the top and bottom heating elements to

maintain the desired oven temperature.

Frozen mode:

Pizza setting will default to Frozen mode.

You may use the Frozen button to provide

extra time for frozen pizzas to cook, or

deselect it when cooking freshly prepared

pizzas.

Pizza

Roast

Bagel

Toast

Bake

Broil

Reheat

Keep Warm

Cookies mode: The oven distributes power

to the top and bottom heating elements to

maintain the desired oven temperature.

COOKING MODE

W11407659A_EN.indd 7W11407659A_EN.indd 7 12/24/2019 5:11:54 PM12/24/2019 5:11:54 PM

COOKING FUNCTIONS

Pizza

Roast

Bagel

Toast

Bake

Broil

Reheat

Keep Warm

Roast mode: The oven distributes power

to the top and bottom heating elements to

maintain the desired oven temperature.

Pizza

Roast

Bagel

Toast

Bake

Broil

Reheat

Keep Warm

Keep Warm mode: The oven distributes

power to the bottom elements to keep

food warm before serving.

Pizza

Roast

Bagel

Toast

Bake

Broil

Reheat

Keep Warm

Reheat mode: The oven distributes power

to the top and bottom elements to bring

food to serving temperature. Reheating

too long may overcook or dry out food.

Pizza

Roast

Bagel

Toast

Bake

Broil

Reheat

Keep Warm

Bake mode: The oven distributes power to

the top and bottom heating elements to

maintain the desired oven temperature.

Pizza

Roast

Bagel

Toast

Bake

Broil

Reheat

Keep Warm

Broil mode: Broiling uses direct radiant

heat to cook food from above. Oven will

distribute power to the top two heating

elements. To deliver efcient broiling, the

bottom elements will run then shut off

after the oven preheats.

Tips:

Use the 23 cm x 33 cm (9” x 13”)

multipurpose pan and rack.

COOKING MODE

W11407659A_EN.indd 8W11407659A_EN.indd 8 12/24/2019 5:11:54 PM12/24/2019 5:11:54 PM

ENGLISH

ADJUSTING THE RACK POSITION

Bagel

Pizza

Roast

Toast

Bake

Broil

Reheat

Start

Cancel

Frozen

Preheating

Shade Slices

Frozen

Hrs

Min

Keep Warm

To adjust the Oven Rack position, Open

the door of oven and slide the Oven Rack

out completely.

Bagel

Pizza

Roast

Toast

Bake

Broil

Reheat

Start

Cancel

Frozen

Preheating

Shade Slices

Frozen

Hrs

Min

Keep Warm

Align the sides of the oven rack with the

grooves for the desired position (1 or 2)

and slide the Oven Rack straight in.

PRODUCT USAGE

IMPORTANT: Maintain enough clearance between the top of the food item and the top

elements. If necessary, adjust the Oven Rack position.

Start

Make sure there will be enough clearance

between the top of the food item and the

top elements. If necessary, adjust the Oven

Rack position between 1 or 2. Close the

door.

Pizza

Roast

Bagel

Toast

Bake

Broil

Reheat

Keep Warm

Plug into an earthed outlet. Turn the Mode

knob to select the desired cooking or

toasting mode. The preset temperature will

be shown for a selected cooking mode.

Shade and slices will be shown if selected

Bagel or Toast mode.

WARNING

Electrical Shock Hazard

Plug into an earthed outlet.

Do not remove an earth prong.

Do not use an adapter.

Do not use an extension cord.

Failure to follow these instructions can result in death, re,

or electrical shock.

SETTING A COOKING OR TOASTING MODE

W11407659A_EN.indd 9W11407659A_EN.indd 9 12/24/2019 5:11:55 PM12/24/2019 5:11:55 PM

10 |

Start

Cancel

Frozen

Preheating

Shade Slices

Frozen

Hrs

Min

Bagel

Pizza

Roast

Toast

Bake

Broil

Reheat

Start

Cancel

Frozen

Preheating

Shade Slices

Frozen

Hrs

Min

Keep Warm

For Cooking mode: Rotate Temperature/

Timer Knob to adjust preset temperature.

Press Knob to show preset time and if

needed, rotate Knob to adjust cooking

time.

(See “Cooking Modes”chart for

temperature ranges.)

Start

Cancel

Frozen

Preheating

Slices

Frozen

Hrs

Min

Shade

Bagel

Pizza

Roast

Toast

Bake

Broil

Reheat

Start

Cancel

Frozen

Preheating

Shade Slices

Frozen

Hrs

Min

Keep Warm

For Toast and Bagel modes: The shade

icon starts flashing. If desired, rotate

Temperature/Timer Knob to adjust shade.

Press Knob to select slices. The slices icon

will starts flashing. If desired, rotate knob

to adjust number of slices.

(See “Toasting Modes” chart for shade and

slices.)

Start

Cancel

Frozen

Preheating

Shade

Slices

Frozen

Hrs

Min

Push the FROZEN button, if desired to

add additional cycle time to the selected

cooking mode to allow for thawing and

proper cooking. The additional time varies

depending on the selected cooking mode.

NOTE: The Frozen option is NOT available

on Broil, Roast, Reheat, or Keep Warm

modes.

Bagel

Pizza

Roast

Toast

Bake

Broil

Reheat

Start

Cancel

Frozen

Preheating

Shade Slices

Frozen

Hrs

Min

Keep Warm

For Cooking modes: Press START to

preheat the oven. To skip preheat and

start the timer directly, press START button

again.

NOTE: In Broil mode, the bottom

elements will be on until oven reaches set

temperature.

For Toasting modes: Press START to begin

the toasting process and the timer will start

to countdown.

SETTING A COOKING OR TOASTING MODE

PRODUCT USAGE

W11407659A_EN.indd 10W11407659A_EN.indd 10 12/24/2019 5:11:56 PM12/24/2019 5:11:56 PM

Este manual sirve para los siguientes modelos

Tabla de contenidos

Otros manuales de Horno de KitchenAid

KitchenAid

KitchenAid SUPERBA KEBS277BAL0 Manual de usuario

KitchenAid

KitchenAid KEBC167MSS - Architect Series 36'' Single Electric Wall... Manual de usuario

KitchenAid

KitchenAid KEMS306X Manual de usuario

KitchenAid

KitchenAid KCO1005ER - Countertop Oven Manual de usuario

KitchenAid

KitchenAid KEBS207BAL1 Manual de usuario

KitchenAid

KitchenAid KOCE507ESS Manual de usuario

KitchenAid

KitchenAid Superba KEBS107 Manual de usuario

KitchenAid

KitchenAid KEMC377KBL05 Manual de usuario

KitchenAid

KitchenAid KEBS209BSS Guía

KitchenAid

KitchenAid KEBS207SBL00 Manual de usuario

KitchenAid

KitchenAid KEBS277W Manual de usuario

KitchenAid

KitchenAid KEMS308SBL02 Manual de usuario

KitchenAid

KitchenAid KEBU208SSS03 Manual de usuario

KitchenAid

KitchenAid Superba KEBS277WBL1 Manual de usuario

KitchenAid

KitchenAid KBMS1454 Manual de usuario

KitchenAid

KitchenAid KEHU309SSS00 Manual de usuario

KitchenAid

KitchenAid KOSC504PPS Manual de usuario

KitchenAid

KitchenAid KEBI100W Manual de usuario

KitchenAid

KitchenAid KEBC247VBL - 24 Inch Double Electric Wall... Manual de usuario

KitchenAid

KitchenAid KEBS276YBL3 Manual de usuario

KitchenAid

KitchenAid SUPERBA KEBS277XBL2 Manual de usuario

KitchenAid

KitchenAid KEBS208DBL10 Manual de usuario

KitchenAid

KitchenAid KEBC247KBL03 Manual de usuario

KitchenAid

KitchenAid KEBS278AAL0 Manual de usuario

Manuales populares de Horno de otras marcas

Bosch

Bosch HVA531NS0 Manual de usuario

Electrolux

Electrolux EOF6P46X Manual de usuario

NEFF

NEFF B44S32 5GB Series Manual de usuario

Combi

Combi BLODGETT BC142GDS Manual de usuario

AEG

AEG COMPETENCE 311704300 Manual de usuario

Falcon

Falcon DOMINATOR PLUS G3106 Series Guía del usuario

Rational

Rational SCC WE 61G Manual de usuario

Smeg

Smeg DOSPA38X Manual de instalación y operación

Electrolux

Electrolux air-o-convect 20 GN 2/1 Manual de usuario

Miele

Miele HR 1954-2 Manual de usuario

KHIND

KHIND OT50 Manual de usuario

Henny Penny

Henny Penny Smoker Box Manual de usuario

Lang

Lang ECOD-AP Manual de usuario

AEG

AEG BEK455310M Manual de usuario

Frigidaire

Frigidaire FNGE90JGR Manual de usuario

Hotpoint

Hotpoint FE9 S831 JSH IX Manual de usuario

GE Advantium SCB2000 Manual de usuario

AEG

AEG DE401301DM Manual de usuario
