CABINET LINER AND DOOR PARTS
1
For Models: KUIS18NNTW0, KUIS18NNTT0, KUIS18NNTB0, KUIS18NNTS0
(White) (Biscuit) (Black) (Stainless Steel)
5−09 Litho In U.S.A. (rrm) (psw) Part No. W10128530 Rev.A
ICE CUBE
MAKER
CABINET LINER AND DOOR PARTS
2
For Models: KUIS18NNTW0, KUIS18NNTT0, KUIS18NNTB0, KUIS18NNTS0
(White) (Biscuit) (Black) (Stainless Steel)
W10128530
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 Literature Parts
2313820 Use & Care Guide
2324311 Service &
Wiring Sheet
2 3400886 Screw 8−18 x 1 1/4
3 2208354 Bin, Door
4 2185678 Spacer
5 2217394 Cover, Wiring
6 489442 Screw
7 Panel, Exterior
2208352W White
2208352T Biscuit
2208352B Black
2208352S Stainless Steel
8 2217298 Panel, Interior
9 2208136 Clamp−Tube
10 2208377 Insulation
11 2217227 Ballast−Back, I.M.
12 941839 Hole Plug
13 Bracket, Door
2217466 (Left Side)
2217465 (Right Side)
14 489503 Clamp
15 2217295 Gasket, Door
16 2208535 Clip
17 Nameplate
W10046670
White
W10046700
Biscuit
W10046640
Black
W10046610
Grey
18 Hinge
2208425 (Left Side)
2208426 (Right Side)
19 2208401 Shim, Hinge
20 Handle, Icemaker
2208440W White
2208440T Biscuit
2208440B Black
22 2208399 Assembly,
Unit Cover
23 Screw, Handle
8281188 White
8281187 Biscuit
8281186 Black
25 2217225 Pad, Foam
26 2185691 Channel, Wiring
27 Endcap, Door
2208350W White
2208350T Biscuit
2208350B Black
28 2208453 Tube, Drain
29 2208386 Scoop
30 3400884 Screw 8−18 x 5/8
31 692400 Nut, Push−In
32 Panel, Wrap Lower
2208382W White
2208382T Biscuit
2208382B Black
2208382S Stainless Steel
33 2208487 Bracket, Spring
34 2208417 Pin, Hinge
35 489048 Screw, Ground
36 2208480 Spring, Hinge
37 Endcap, Panel
2208383W White
2208383T Biscuit
2208383B Black
38 2208529 Dampener, Spring
39 489423 Screw
40 2208449 Holder, Scoop
42 3374849 Leg, Leveler (4)
43 2208384 Insulation
44 Top
2929701W White
2929701T Biscuit
2929701B Black
45 2185690 Shield, Electrical
46 2217296 Gasket, Top Panel
47 Grill, Front
2217206W White
2217206T Biscuit
2217206B Black
48 489474 Screw 8−18 x 1
49 Cabinet & Liner
(NOT SERVICED)
52 3400240 Nut,
Leg Leveler
53 2208434 Strike, Magnet
54 3400916 Washer
55 8281191 Screw
58 488208 Screw
3
EVAPORATOR, ICE CUTTER GRID AND WATER PARTS
For Models: KUIS18NNTW0, KUIS18NNTT0, KUIS18NNTB0, KUIS18NNTS0
(White) (Biscuit) (Black) (Stainless Steel)
W10128530
EVAPORATOR, ICE CUTTER GRID AND WATER PARTS
4
For Models: KUIS18NNTW0, KUIS18NNTT0, KUIS18NNTB0, KUIS18NNTS0
(White) (Biscuit) (Black) (Stainless Steel)
W10128530
Illus. Part
No. No. DESCRIPTION
1 2313741 Valve, Complete
Water
2 2217286 Tube, Plastic
3 488208 Screw
4 2185523 Dispenser, Water
5 W10218037 Evaporator
6 2313705 Pump, Drain
7 2313851 Tube, Reservoir
Pump
8 2172593 Tube, Water Fill
9 488660 Nut, Speed
10 836667 Spacer
11 2208539 Fastener, Pushnut
12 489443 Screw
13 2185625 Reservoir,
Water Slide
14 2185626 Tube
15 2313890 Hose, Overflow
16 2217378 Bracket−Reservoir
17 2313603 Bracket, Front
and Rear
18 2313602 Bracket, Side
Left and Right
19 2185681 Harness, Grid
20 2208427 Support, Bracket
Evaporator/Grid
21 2313604 Guide, Ice Grid
22 2324305 Tube
23 8281193 Screw
24 2310169 Wire Assembly
(Valve)
26 3400886 Screw 8−18 x 1 1/4
28 2313637 Grid Assembly
(Complete)
29 2174754 Wire, Grid Cutter
30 8281192 Screw
31 2208365 Cover, Grid
32 8281228 Thumbscrew
33 2324334 Reservoir, Water
34 3400884 Screw 8−18 x 5/8
35 2185696 Cap, Drain
36 3400909 Nut, Push−In
PUMP PARTS
5
For Models: KUIS18NNTW0, KUIS18NNTT0, KUIS18NNTB0, KUIS18NNTS0
(White) (Biscuit) (Black) (Stainless Steel)
W10128530
Illus. Part
No. No. DESCRIPTION
1 2313628 Pump−Recirculating
2 3400884 Screw 8−18 x 5/8
3 2185677 Cover, Pump
4 2313844 Bracket, Connector
Assembly
5 2313627 Bracket−Pump
6 2313643 Sensor−Motor
7 2324307 Clip−Retainer (3)
8 2310092 Wiring Harness
Main To Pump
9 2313702 Pump Assembly
6
CONTROL PANEL PARTS
For Models: KUIS18NNTW0, KUIS18NNTT0, KUIS18NNTB0, KUIS18NNTS0
(White) (Biscuit) (Black) (Stainless Steel)
W10128530
Illus. Part
No. No. DESCRIPTION
1 2185738 Box, Control
2 2310139 Transformer
3 2304122 Assembly, Switch
(ALSO ORDER #4)
4 2313693 Overlay
5 2321774 Control Board
6 2149705 Switch, Plunger
Grid/ Light
9 745362 Bulb
12 2313633 Thermostat, Bin
13 2185825 Clamp
15 3400884 Screw 8−18 x 5/8
18 3400850 Screw 8−16 x 3/8
20 2313635 Thermister,
Ice Control
UNIT PARTS
7
For Models: KUIS18NNTW0, KUIS18NNTT0, KUIS18NNTB0, KUIS18NNTS0
(White) (Biscuit) (Black) (Stainless Steel)
W10128530
UNIT PARTS
8
For Models: KUIS18NNTW0, KUIS18NNTT0, KUIS18NNTB0, KUIS18NNTS0
(White) (Biscuit) (Black) (Stainless Steel)
W10128530
Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION Illus. Part
No. No. DESCRIPTION
1 2185532 Bracket, Fan Mtg.
2 2185675 Pad, Foam
3 2188935 Blade, Fan
4 2315558 Motor & Mounting
Plate Assembly
5 2310125 Wiring Harness,
Complete Unit
(Includes
Power Cord)
6 304392 Screw
7 2313858 Compressor
(Includes
Illus. 11,18,
20,21 & 23)
8 A201435 Clip, Mounting
9 A201441 Shim (4)
10 1115375 Clip−Wiring
11 Grommet (4)
2217318 Production
4387558 Service
12 2208415 Tube, Process
13 489423 Screw
14 489472 Screw
15 759112 Coil, Solenoid
16 2313806 Hot Gas Valve
17 2187629 Wiring Harness,
Condenser Fan
18 Overload
2217223 Production
4387938 Service
(Includes Relay)
19 2155774 Strap
20 Relay, Start
2217224 Production
4387938 Service
(Includes
Overload)
21 Cover, Terminal
2208371 Production
4387731 Service
22 2185788 Clamp
23 Drier
2319826 Production
4387019 Service
24 2313624 Condenser
25 3400884 Screw
26 488500 Screw
27 2217397 Pad, Foam (2)
28 2185960 Clamp−Service Cord
29 8281197 Screw
30 2217423 Base, Unit
31 8281196 Screw
32 304392 Screw
34 2319835 Grommet−Cond.(1)
REFRIGERANT CHARGE
6.5 OZ. (R134A)
OPTIONAL PARTS
9
For Models: KUIS18NNTW0, KUIS18NNTT0, KUIS18NNTB0, KUIS18NNTS0
(White) (Biscuit) (Black) (Stainless Steel)
W10128530
Illus. Part
No. No. DESCRIPTION
Parts Not Illustrated and
Optional Parts (Not Included)
503695 Sealer, Cork
(1/4 Pound)
797403 Cement, Insulation
(1 Oz.)
505587 Sealer, Mastic
(1 Qt.)
212643 Sealer, Gum
(22 Pcs. 3/16" x 7")
479976 Kit, Insulation
(5 Pcs. 3" x 24"
x 48")
8537055 Cleaner,
Stainless Steel
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
