KitchenAid 5KHMB732A Manual de usuario

7 Speed Cordless Hand Mixer

5KHMB732A

W11419335C.indd 1W11419335C.indd 1 4/28/2022 10:55:15 AM4/28/2022 10:55:15 AM

PARTS AND FEATURES

1Upright Stance

2Motor Body

3Beaters

4Eject Button

5Battery Status Indicator

6Charging Port

7Speed Controller

Handle

9Charger Adapter

10 Charger Adapter Pin

W11419335C.indd 2W11419335C.indd 2 4/28/2022 10:55:15 AM4/28/2022 10:55:15 AM

ENGLISH

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be

followed, including the following:

1. Read all instructions. Misuse of appliance may result in personal injury.

2. To protect against risk of electrical shock, do not put the Motor Body of Cordless

Hand Mixer, Charger Adapter, cord, or electrical plug in water or other liquid.

3. This appliance is not intended for use by persons (including children) with reduced

physical, sensory, or mental capabilities, or lack of experience and knowledge,

unless they are closely supervised and instructed concerning use of the appliance

by a person responsible for their safety.

4. Close supervision is necessary when any appliance is used by or near children.

5. Children should be supervised to ensure that they do not play with the appliance.

6. Turn the appliance to “O” Position when not in use, before assembling or

disassembling parts and before cleaning. To unplug the charger, grasp the plug

and pull from the outlet. Never pull from the power cord.

7. If the supply cord is damaged, it must be replaced by a special cord or assembly

available from the manufacturer or its service agent.

8. Do not use an extension cord. Plug charger directly into an electric outlet.

9. WARNING: For the purposes of recharging the battery, only use the detachable

supply unit provided with this appliance. Do not attempt to use this charger with

any other product. Likewise, do not attempt to charge this appliance with any

other charger.

10.The appliance contains batteries that are non-replaceable.

11. Do not incinerate this appliance even if it is severely damaged. The batteries can

explode in a fire.

PRODUCT SAFETY

W11419335C.indd 3W11419335C.indd 3 4/28/2022 10:55:16 AM4/28/2022 10:55:16 AM

12. Avoid contacting moving parts. Keep hands, hair clothing, as well as spatulas

and other utensils away from Beaters and accessories during operation to

reduce the risk of injury to persons or damage to the Cordless Hand Mixer.

13. Do not operate any appliance with a damaged cord or plug, or after the

appliance malfunctions, or is dropped or damaged in any manner. Return

appliance to the nearest Authorised Service Facility for examination, repair, or

electrical or mechanical adjustment.

14. The use of attachments not recommended or sold by KitchenAid may cause fire,

electric shock, or injury.

15. Do not use the appliance outdoors.

16. Do not let cord hang over edge of table or counter.

17. Never leave the appliance unattended while it is in operation.

18. Do not let cord contact hot surface, including the stove.

19. Remove Beaters or accessories from the Cordless Hand Mixer before washing.

20. Allow the appliance to cool completely before putting on or taking off parts, and

before cleaning the appliance.

21. Refer to the “Care and Cleaning” section for instructions on cleaning the surfaces

in contact with food.

22. This appliance is intended to be used in household and similar applications such

as:

- staff kitchen areas in shops, offices and other working environments;

- farm houses;

- by clients in hotels, motels and other residential type environments;

- bed and breakfast type environments.

SAVE THESE INSTRUCTIONS

PRODUCT SAFETY

LITHIUM-ION BATTERY OPERATED PRODUCT DISPOSAL

Always dispose the battery operated products according to federal, state, and local

regulations. Contact a recycling agency in your area for recycling locations.

ELECTRICAL REQUIREMENTS

Charger Adapter:

Input: 220-240 V~ 50-60 Hz

Cordless Hand Mixer:

Voltage: 12 V

NOTE: If the plug does not fit fully in the outlet, contact a qualified electrician. Do not

modify the plug in any way.

W11419335C.indd 4W11419335C.indd 4 4/28/2022 10:55:16 AM4/28/2022 10:55:16 AM

ENGLISH

GETTING STARTED

1. Charge the battery until the Battery Status Indicator turns solid green.

2. Clean all the parts. (see "Care and Cleaning" section).

3. Remove all packaging materials, if present.

BATTERY

STATUS % BATTERY STATUS FULL

CHARGE*

QUICK

CHARGE**

Green 30% to 100%

200 cookies 1 cake batter

Yellow 15% - 30% (Consider Charging)

Red Lower than 15% (Need to charge soon)

BEFORE FIRST USE

General Battery Tips & Maintenance

- Consider charging the appliance when the Battery Status Indicator is yellow.

- Remove the appliance from charger when finished charging.

- It is best to store the appliance at room temperature (60-80 degrees F/15-25 degrees C)

and away from moisture.

- Avoid exposing to temperatures above 120 F/50 C.

Note: Battery life is impacted by factors such as battery age and use.

*Full Charge:

The Cordless Hand Mixer will be fully charged in 2 hours 40 minutes. The Battery Status

Indicator pulses when it charges and turns to solid green with a full charge.

The Cordless Hand Mixer will prepare approximately 200 cookies, based on 4 batches of

chocolate chip cookies when following the recommended battery maintenance.

**Quick Charge:

In 10 minutes the Cordless Hand Mixer will quick charge. The Cordless Hand Mixer will stir

up a cake batter recipe with one quick charge when following the recommended battery

maintenance.

BATTERY STATUS

BATTERY CHARGING

First, slide the Speed Controller to “O”

position and insert the Charger Adapter

Pin into the Charging Port.

Plug the Charger Adapter into an earthed

electrical outlet.

W11419335C.indd 5W11419335C.indd 5 4/28/2022 10:55:16 AM4/28/2022 10:55:16 AM

BATTERY CHARGING

IMPORTANT: Make sure that the Speed

Controller is at “O” position before

attaching and removing Beaters.

The Battery Status Indicator pulses when it

charges. It will be fully charged in 2 hours

and 40 Minutes and the Battery Status

Indicator turns solid green.

Insert the Beater without a collar (A) into

the smaller opening (C) and Beater with a

collar (B) into the larger opening (D). Align

and push to lock into place. Both the

Beaters will click in.

PRODUCT ASSEMBLY

There are two Beaters. One is without a

collar (A) and another with a collar (B).

W11419335C.indd 6W11419335C.indd 6 4/28/2022 10:55:16 AM4/28/2022 10:55:16 AM

ENGLISH

Always start mixing at the lowest speed,

and by sliding the Speed Controller,

increase the speed according to the

recipes.

When finished, slide the Speed controller

to "O" position.

PRODUCT USAGE

To increase the speed, slide the Speed

Controller forward ( ). To decrease

the speed, slide the Speed Controller

backward ( ).

NOTE: Make sure the Cordless Hand Mixer is charged before use. Do not operate

continuously for more than 1 minute.

CARE AND CLEANING

IMPORTANT: Allow the appliance to cool completely before putting on or taking off

parts, and before cleaning the appliance. Make sure the Speed Controller is at “O” before

attaching or removing Beaters.

Press the Eject Button to release the

Beaters from the Cordless Hand Mixer.

Always remove the Beaters from the

Cordless Hand Mixer before cleaning.

Wash in dishwasher, or by hand in warm,

soapy water. Rinse and wipe dry.

When finished, slide the Speed Controller

to “O” position.

W11419335C.indd 7W11419335C.indd 7 4/28/2022 10:55:16 AM4/28/2022 10:55:16 AM

Wipe the Cordless Hand Mixer with a

damp cloth. Dry with a soft cloth.

3NOTE: To avoid damage to the Cordless

Hand Mixer, do not immerse in water.

TROUBLESHOOTING GUIDE

PROBLEM SOLUTION

If the Cordless Hand Mixer fails

to start:

Check if the product is charged.

Charge the battery when the Battery Status Indicator is

red or when the battery is completely drained.

If the Cordless Hand Mixer is not

getting charged:

If you have a circuit breaker box, make sure that the circuit

is closed.

If the problem cannot be

corrected:

See the “Customer Service” section.

Do not return the Cordless Hand Mixer to the retailer.

Retailers do not provide service.

CARE AND CLEANING

For detailed information about the

Cordless Hand Mixer:

Visit www.KitchenAid.com.au for

additional instructions with videos,

inspiring recipes, and tips on how to use

and clean your Cordless Hand Mixer.

W11419335C.indd 8W11419335C.indd 8 4/28/2022 10:55:16 AM4/28/2022 10:55:16 AM

ENGLISH

CUSTOMER SERVICE

In Australia:

For any questions, or to find the nearest Authorised KitchenAid Service Centre,

please find our contact details below.

NOTE: All service should be handled locally by an Authorised KitchenAid Service

Centre.

Toll free number: 1-800-990-990

Phone number: 02 49026500

Address Australia:

KitchenAid Australia Pty Ltd

6-8 Billbrooke Close

Cameron Park NSW 2285, Australia

Phone: 1-800-990-990

Mobile: 0249026500

Email: [email protected]

In New Zealand:

Website: www.kitchenaid.co.nz

Email: [email protected]

Phone: 0800 881 200

In other countries:

For all product related questions and after-sales matters, please contact your dealer

to obtain the name of the nearest Authorised KitchenAid Service/Customer Centre.

For more information, visit our website at:

www.KitchenAid.com.au

W11419335C.indd 9W11419335C.indd 9 4/28/2022 10:55:16 AM4/28/2022 10:55:16 AM

NOTES

W11419335C.indd 10W11419335C.indd 10 4/28/2022 10:55:16 AM4/28/2022 10:55:16 AM
