KitchenAid 5KFCB519A Manual de usuario

5 Cup Cordless Food Chopper

5KFCB519A

W11419337C.indd 1W11419337C.indd 1 4/27/2022 6:27:43 PM4/27/2022 6:27:43 PM

PARTS AND FEATURES

1Lid

2Drive Adapter

3Multipurpose Blade

4Pour Spout

5Bowl (5 Cup/1.18 Litre)

6Base

7Battery Status Indicator

8Charging Port

9Speed Controller

10 Charger Adapter Pin

11 Charger Adapter

12 Handle

13 Whisking Accessory

14 Pulse/On Button

15 Drizzle Basin

W11419337C.indd 2W11419337C.indd 2 4/27/2022 6:27:43 PM4/27/2022 6:27:43 PM

ENGLISH

PRODUCT SAFETY

IMPORTANT SAFEGUARDS

When using electrical appliances, basic safety precautions should always be

followed, including the following:

1. Read all instructions. Misuse of appliance may result in personal injury.

2. To protect against risk of electrical shock, do not put the Base of Cordless Food

Chopper, Charger Adapter, cord, or electrical plug in water or other liquid.

3. This appliance is not intended for use by persons (including children) with

reduced physical, sensory, or mental capabilities, or lack of experience or

knowledge, unless they are closely supervised and instructed concerning use of

the appliance by a person responsible for their safety.

4. Close supervision is necessary when any appliance is used by or near children.

5. Children should be supervised to ensure that they do not play with the appliance.

6. Turn the appliance OFF when not in use, before assembling or disassembling

parts and before cleaning. To unplug the charger, grasp the plug and pull from

the outlet. Never pull from the power cord.

7. If the supply cord is damaged, it must be replaced by a special cord or assembly

available from the manufacturer or its service agent.

8. Avoid contacting moving parts.

9. Do not operate any appliance with a damaged cord or plug, or after the

appliance malfunctions, or is dropped or damaged in any manner. Return

appliance to the nearest Authorised Service Facility for examination, repair, or

electrical or mechanical adjustment.

10. The use of attachments not recommended or sold by the manufacturer

may cause re, electric shock, or injury.

11. Do not use the appliance outdoors.

12. Do not let cord hang over edge of table or counter.

13. The appliance contains batteries that are non-replaceable.

W11419337C.indd 3W11419337C.indd 3 4/27/2022 6:27:43 PM4/27/2022 6:27:43 PM

14. Keep hands and utensils away from the cutting blade while chopping food

to reduce the risk of severe injury to person, or damage to the Cordless Food

Chopper. A scraper may be used, but only when the Cordless Food Chopper is

not running.

15. Blades are sharp. Care should be taken when handling the sharp cutting blades,

emptying the jar and during cleaning.

16. To reduce the risk of injury, never place cutting blade on Base without rst

putting bowl properly in place.

17. Be certain cover is securely locked in place before operating the Cordless Food

Chopper.

18. Do not attempt to defeat the cover interlock mechanism.

19. Do not use an extension cord. Plug charger directly into an electric outlet.

20. WARNING: For the purposes of recharging the battery, only use the detachable

supply unit provided with this appliance. Do not attempt to use this charger with

any other product. Likewise, do not attempt to charge this appliance with any

other charger.

21. Allow the appliance to cool completely before putting on or taking off parts, and

before cleaning the appliance.

22. Do not incinerate this appliance even if it is severely damaged. The batteries can

explode in a re.

23. Refer to the “Care and Cleaning” section for instructions on cleaning the

surfaces in contact with food.

24. This appliance is intended to be used in household and similar applications such

as:

- staff kitchen areas in shops, ofces, or other working environments;

- farmhouses;

- by clients in hotels, motels and other residential type environments;

- bed and breakfast type environments.

25. Be careful if hot liquid is poured into the Cordless Food Chopper as it can be

ejected out of the appliance due to a sudden steaming.

PRODUCT SAFETY

SAVE THESE INSTRUCTIONS

W11419337C.indd 4W11419337C.indd 4 4/27/2022 6:27:43 PM4/27/2022 6:27:43 PM

ENGLISH

ELECTRICAL REQUIREMENTS

Charger Adapter:

Input: 220-240 V~ 50-60 Hz

Cordless Food Chopper:

Voltage: 12 V

NOTE:

If the plug does not fit in the outlet, contact a qualified electrician. Do not modify the

plug in any way.

Do not use an extension cord. If the power supply cord is too short, have a qualied electrician or

service technician install an outlet near the appliance

A short power supply cord (or detachable power supply cord) should be used to reduce the risk

resulting from becoming entangled in or tripping over a longer cord.

PRODUCT SAFETY

LITHIUM-ION BATTERY OPERATED PRODUCT DISPOSAL

Always dispose the battery operated products according to federal, state, and local

regulations. Contact a recycling agency in your area for recycling locations.

W11419337C.indd 5W11419337C.indd 5 4/27/2022 6:27:43 PM4/27/2022 6:27:43 PM

1. Charge the battery until the Battery Status Indicator turns solid green.

2. Clean all the parts (see "Care and Cleaning" section).

3. Remove all packaging materials, if present.

Battery status % Battery status Full charge* Quick charge**

Green 30% to 100%

40 Onions 11 OnionsYellow 15% to 30% (Consider charging)

Red Lower than 15% (Need to charge soon)

BEFORE FIRST USE

BATTERY STATUS

GETTING STARTED

*Full Charge:

The Cordless Food Chopper will be fully charged in 2 hours and 40 minutes. The Battery Status

Indicator pulses when it charges and turns to solid green with a full charge. The Cordless Food

Chopper will chop approximately 40 onions (weighing around 90 - 110 grams each) when

following the recommended battery maintenance.

**Quick Charge:

In 10 minutes, the Cordless Food Chopper will quick charge. The Cordless Food Chopper will

chop approximately 11 onions (weighing around 90 - 110 grams each) with one quick charge

when following the recommended battery maintenance.

Food Quantity Preparation Speed Pulse*

Beef 0.7 lb (317 gm) Cut into 2.5 cm (1 inch) cubes High Quick pulse

10 to 15 times

Bread,

Cookies, or

Crackers

up to 4 cups

Break bread, crackers, or

cookies into pieces that fit into

Bowl before processing.

High Quick pulse

20 to 30 times

Cooked fruits

and vegetables up to 2.5 cups Cut into 2.5 cm (1 inch) cubes High Quick pulse

10 to 15 times

Herbs and

Spices up to 4 cups Add herbs and spices as they

are; no preparation needed. High Quick pulse

20 to 30 times

Nuts up to 2.5 cups Place in whole nuts High Quick pulse

15 to 20 times

Raw fruits and

vegetables up to 3 cups Cut into 2.5 cm (1 inch) cubes High Quick pulse

6 to 10 times

SUGGESTED FOOD ITEMS – MULTIPURPOSE BLADE

*Processing settings are approximate.

Actual settings may vary depending on quality of food and desired chop size.

TIP: A Quick Pulse is one second On and one second Off operation.

General Battery Tips & Maintenance:

- Consider charging the appliance when the Battery Status Indicator is yellow.

- Remove the appliance from charger when finished charging.

- It is best to store the appliance at room temperature (60-80 ºF / 15-25 ºC) and away from

moisture.

- Avoid exposing to temperatures above 120 ºF / 50 ºC.

NOTE: Battery life is impacted by factors such as battery age and use.

W11419337C.indd 6W11419337C.indd 6 4/27/2022 6:27:43 PM4/27/2022 6:27:43 PM

ENGLISH

BATTERY STATUS

The Battery Status Indicator pulses when it

charges. It will be fully charged in 2 hours

and 40 minutes and the Battery Status

Indicator turns solid green.

Solid

Green

Pulsing

First, slide the Speed Controller to "O".

Then, insert the Charger Adapter Pin into

the Charging Port.

Plug the Charger Adapter into electrical

outlet.

BATTERY CHARGING

GETTING STARTED

WHISKING ACCESSORY RECOMMENDATIONS CHART

The whisking accessory can be used to incorporate air into foods such as eggs, egg

whites, heavy cream, mayonnaise, etc. Use the drizzle basin and pour spout to easily make

mayonnaise or dressings.

Suggested

Food Food Preparation Amount Processing

Time Setting

Eggs and Egg

whites

Remove eggs from shells; separate

yolks from whites as needed; use

1/8 tsp cream of tartar per egg.

Up to

420 ml

(1.5 cups)

60 seconds Speed 1

Heavy Cream Add cream and desired flavours to

work bowl.

Up to

240 ml

(1 cup)

30 seconds Speed 2

Emulsions

(Mayonnaise,

Aioli, Salad

dressing)

Add ingredients to work bowl; use

the drizzle basin while mixing to add

oils.

Up to

350 ml

(1.5 cups)

60 seconds Speed 2

TIP: Do not operate Whisk Accessory continuously for more than 60 seconds.

W11419337C.indd 7W11419337C.indd 7 4/27/2022 6:27:44 PM4/27/2022 6:27:44 PM

Rotate and lower the Drive Adapter and

then Multipurpose Blade or optional

Whisking Accessory in the centre of the

Bowl until it rests at the bottom.

NOTE: The Cordless Food Chopper will operate with either the Multipurpose Blade or the

Whisking Accessory in place, not both. Do not try to use both at the same time.

Add ingredients to the Bowl.

Place the Lid on the Bowl. Twist and lock it

into place. The Lid will click when properly

locked into place.

IMPORTANT: The Bowl and Lid must be locked into place for the Cordless Food

Chopper to operate.

Slide the Speed Controller to your desired

setting (1or 2).

Press down the Pulse/On Button to start.

For a coarse chop, use a pulsing

motion to rapidly press and release the

Pulse/On Button until your desired results

are achieved.

PRODUCT USAGE

IMPORTANT: Make sure the Cordless Food Chopper is charged before using.

Make sure that the Speed Controller is

at "O" position before attaching or

removing any parts.

Hold the Handle facing front on the Base.

Twist and lock the Bowl in the slots of the

Base.

W11419337C.indd 8W11419337C.indd 8 4/27/2022 6:27:44 PM4/27/2022 6:27:44 PM

ENGLISH

Use the Drizzle Basin to conveniently add liquid ingredients while processing dressings,

mayonnaises, sauces, and more. Use the Pour Spout for easier serving.

Slowly pour liquids, such as oil, in the

Drizzle Basin. The liquid will be efciently

and thoroughly mixed into the ingredients

as they spin inside the Bowl.

Once processing is complete, remove the

Lid, Drive Adapter, and Multipurpose Blade

to use the Pour Spout.

Pour

Spout

PRODUCT USAGE

NOTE: For convenient storage, always

reassemble the Cordless Food Chopper

after cleaning.

Remove the Lid, Multipurpose Blade, and

Drive Adapter. Hold the Base steady. Twist

and lift the Bowl to unlock from the Base.

Wipe the Base with a damp cloth.

Do not immerse the Base in water.

For detailed information on the Cordless Food Chopper:

Visit www.KitchenAid.com.au for additional instructions with videos, inspiring recipes,

and tips on how to use and clean your Cordless Food Chopper.

Dishwasher-safe, top rack only: Bowl, Lid,

Whisking Accessory, Drive Adapter, and

Multipurpose Blade.

CARE AND CLEANING

NOTE: Mild dish soap may be used, but

do not use abrasive cleaners.

IMPORTANT: Allow the appliance to cool completely before putting on or taking off

parts, and before cleaning the appliance. Also make sure that the Speed Controller is at

"O" position. Unplug before removing, attaching parts, or before cleaning.

W11419337C.indd 9W11419337C.indd 9 4/27/2022 6:27:45 PM4/27/2022 6:27:45 PM

TROUBLESHOOTING GUIDE

Problem Solution

If the Cordless Food Chopper

fails to start:

Check if the Cordless Food Chopper is charged.

Charge the battery when the Battery Status Indicator is

red or when the battery is completely drained.

Make sure that the Bowl and Lid are properly aligned and

locked into place.

If the Cordless Food Chopper is

not getting charged:

If you have a circuit breaker box, check to make sure that

the circuit is closed.

If the problem cannot be

corrected:

See the “Customer Service” sections.

Do not return the Cordless Food Chopper to the retailer –

retailers do not provide service.

W11419337C.indd 10W11419337C.indd 10 4/27/2022 6:27:45 PM4/27/2022 6:27:45 PM

Tabla de contenidos

Otros manuales de Procesador de alimentos de KitchenAid

KitchenAid

KitchenAid 5KFP1335 Manual de usuario

KitchenAid

KitchenAid KSM12FPA Manual de usuario

KitchenAid

KitchenAid KFP0719 Manual de usuario

KitchenAid

KitchenAid 5KFP0925 Manual de usuario

KitchenAid

KitchenAid KFP740 Guía rápida

KitchenAid

KitchenAid 5KFP0922 Instrucciones de montaje

KitchenAid

KitchenAid PRO LINE KPFP850 series Manual de usuario

KitchenAid

KitchenAid PROFESSIONAL 670 Guía rápida

KitchenAid

KitchenAid KFP1642CA0 Manual de usuario

KitchenAid

KitchenAid 12 CUP KFP750 Manual de usuario

KitchenAid

KitchenAid KFC3100BU1 Manual de usuario

KitchenAid

KitchenAid 4KFC3100BU2 Manual de usuario

KitchenAid

KitchenAid KFC0516 Manual de usuario

KitchenAid

KitchenAid KFP0722 Manual de usuario

KitchenAid

KitchenAid 5KFP0925 Manual de usuario

KitchenAid

KitchenAid KFP0718L Manual de usuario

KitchenAid

KitchenAid KFP1133 Manual de usuario

KitchenAid

KitchenAid 5KFC3516 Manual de usuario

KitchenAid

KitchenAid KFP0719L Manual de usuario

KitchenAid

KitchenAid KFP1317 Manual de usuario

KitchenAid

KitchenAid 5KFC3516 Manual de usuario

KitchenAid

KitchenAid 4KFP740CR0 Manual de usuario

KitchenAid

KitchenAid KFP1642CA Manual de usuario

KitchenAid

KitchenAid KFP1333 Instrucciones de funcionamiento

Manuales populares de Procesador de alimentos de otras marcas

INNOLIVING

INNOLIVING INN-727 Manual de usuario

Berkel

Berkel C32 Manual de usuario

Beko

Beko CHP5554W Manual de usuario

QUIGG

QUIGG KM 2017Wi.20 Manual de usuario

Lakeland

Lakeland PRESS AND CHOP 31557 Manual de usuario

Bosch

Bosch MMR08 GB Series Manual de usuario

HOFFEN

HOFFEN Chef Express T9532 Manual de usuario

Garland

Garland 852 ZG Manual de usuario

Robot Coupe

Robot Coupe CL50 Gourmet Manual de usuario

SAPIRHOME

SAPIRHOME SP-1111-K Manual de usuario

Moulinex

Moulinex DJ3051 Manual de usuario

Bosch

Bosch MUM5 Manual de usuario

cecotec

cecotec Mambo Touch Manual de usuario

Black & Decker

Black & Decker hc 300 Instrucciones de instalación

Gorenje

Gorenje SBR 1000 DV Manual de usuario

Arzum

Arzum AR 1128 Manual de usuario

Saturn

Saturn ST-FP0069 Manual de usuario

Vitek

Vitek VT-1641 W Manual de usuario
