Electric and

Gas Dryers

A Note to You........................2

Understanding

Dryer Safety ......................3-4

Parts and Features ..............5

Checking Your Vent ............6

Operating Your Dryer ..........8

Starting your dryer ..........8

Selecting the right cycle

and temperature setting..9

Loading ..........................10

Automatic cycle ............10

Timed Dry cycle ............11

Air Tumble cycle............12

Using the drying rack....13

Caring for Your Dryer ........14

Troubleshooting..................17

Requesting Assistance

or Service ............................19

Warranty..............................20

1•800•461•5681

Call with questions

or comments

www.kitchenaid.com/canada

Use&CareGuide

Thank you for buying a KITCHENAID* appliance!

KitchenAid designs the best tools for the most important room in your house. To ensure that you enjoy many

years of trouble-free operation, we developed this Use and Care Guide. It contains valuable information

concerning how to operate and maintain your new appliance properly and safely. Please read it carefully.

Also, please complete and mail the enclosed Product Registration Card.

For assistance and service

Call the Consumer Assistance Centre toll free ................................................1-800-461-5681

8:30 a.m. – 6 p.m. (EST)

If you need assistance or service, first see the “Troubleshooting” section of this book. After checking

“Troubleshooting,” additional help can be found by checking the “Requesting Assistance or Service” section,

or by calling one of the telephone numbers above. When calling, you will need to know your appliance’s

complete model number and serial number. You can find this information on the model and serial number

label/plate (see diagram in the “Parts and Features” section.)

Keep this book and the sales slip together in a safe place for future reference. You must provide proof of pur-

chase or installation date for in-warranty service.

Model Number ______________________

Serial Number________________________

Date Installed ________________________

Builder/Dealer Name __________________

Address ____________________________

Phone ______________________________

ANoteToYou

–Do not store or use gasoline or other flammable vapours and liquids in the vicinity

of this or any other appliance.

–WHAT TO DO IF YOU SMELL GAS

•Do not try to light any appliance.

•Do not touch any electrical switch; do not use any phone in your building.

•Clear the room, building or area of all occupants.

•Immediately call your gas supplier from a neighbor’s phone. Follow the gas

supplier’s instructions.

•If you cannot reach your gas supplier, call the fire department.

–Installation and service must be performed by a qualified installer, service agency

or the gas supplier.

continued on next page

WARNING: For your safety the information in this manual must be followed to

minimize the risk of fire or explosion or to prevent property damage, personal

injury or death.

You will be killed or seriously injured if you don’t

follow instructions.

You can be killed or seriously injured if you don’t

follow instructions.

Your safety and the safety of others is very important.

We have provided many important safety messages in this manual and on your appliance. Always read and

obey all safety messages.

This is the safety alert symbol.

This symbol alerts you to hazards that can kill or hurt you and others.

All safety messages will be preceded by the safety alert symbol and the word “DANGER” or

“WARNING.” These words mean:

All safety messages will identify the hazard, tell you how to reduce the chance of injury, and tell you what can

happen if the instructions are not followed.

wWARNING

wDANGER

UnderstandingDryerSafety

WARNING –To reduce the risk of fire, electric shock, or injury to persons when using the

dryer, follow basic precautions, including the following:

•Read all instructions before using

the dryer.

•Do not dry articles that have been previ-

ously cleaned in, washed in, soaked in,

or spotted with gasoline, dry-cleaning sol-

vents, other flammable, or explosive sub-

stances as they give off vapours that

could ignite or explode.

•Do not allow children to play on or in

the dryer. Close supervision of children

is necessary when the dryer is used

near children.

•Before the dryer is removed from service

or discarded, remove the door to the dry-

ing compartment.

•Do not reach into the dryer if the drum

is moving.

•Do not install or store the dryer where

it will be exposed to the weather.

•Do not tamper with controls.

•Do not repair or replace any part of the

dryer or attempt any servicing unless

specifically recommended in this Use and

Care Guide or in published user-repair in-

structions that you understand and have

the skills to carry out.

•Do not use fabric softeners or products to

eliminate static unless recommended by

the manufacturer of the fabric softener or

product.

•Do not use heat to dry articles containing

foam rubber or similarly textured rubber-

like materials.

•Clean lint screen before or after each load.

•Keep area around the exhaust opening

and adjacent surrounding areas free from

the accumulation of lint, dust, and dirt.

•The interior of the dryer and exhaust vent

should be cleaned periodically by qualified

service personnel.

•See Installation Instructions for grounding

requirements.

– SAVE THESE INSTRUCTIONS –

IMPORTANT SAFETY INSTRUCTIONS

UnderstandingDryerSafety

This manual covers several different models. The dryer you have purchased may have some or all of

the parts and features listed below.

Start button

(p. 9)

Lint screen

(p. 14)

Exhaust grille

Electronic

dryness

sensor

(p. 10)

Wide-opening

hamper door†

Cycle control

knob

(pp. 8-13)

Model and

serial number

label

(p. 2)

Drum light

(p. 16)

Dryer drum

(p. 15)

Additional features your dryer may have:

Ultra Low temperature setting (p. 9)

Extra Low temperature setting (p. 9)

Drying Rack (p. 13)

Temperature

selector

(p. 8)

Extra care

selector†

(p. 8)

End of cycle

signal selector

(p. 8)

Other Doors:

Super wide-opening door†

(Reversible door-see Installation

Instructions)

† On some models

PartsandFeatures

If the dryer is not properly installed and vented, it

will not be covered under the warranty.

NOTE: Service calls caused by improper venting

will be paid for by the customer, whether it was a

paid installation or self-installed. For paid installation,

call the company that installed the vent for

adjustment.

Do not use plastic vent or flexible metal foil vent.

Use 10.16 cm (4 in)

heavy metal or flexible

metal vent. Do not kink

or crush flexible metal

vent. It must be com-

pletely extended to

allow adequate exhaust

air to flow. Check vent

after installation. Refer

to your Installation

Instructions for proper

length requirements of vent.

2. Use a 10.16 cm (4 in) exhaust hood. Smaller

hoods increase drying

times.

wWARNING

Your dryer must be properly installed and vented to achieve maximum drying efficiency and shorten

drying times. Use the minimum recommended installation clearances (found in your Installation

Instructions) to avoid blocking the flow of combustion and ventilation air. Install your dryer in a well-

ventilated room where the temperature is always above 7°C (45°F). Also make sure that your dryer

is leveled. Refer to your Installation Instructions for more information.

Venting

Fire Hazard

Use a heavy metal vent.

Do not use a plastic vent.

Do not use a metal foil vent.

Failure to follow these instructions can

result in death or fire.

3. The exhaust vent can be routed up, down, left,

right, or straight out the

back of the dryer. Space

requirements are listed

in your Installation

Instructions.

CheckingYourVent

10.16 cm (4 in)

Venting (cont.)

5. Use duct tape to seal all joints. Do not use screws

to secure vent. Lint may

catch on screws.

4. Use the straightest path possible when routing the

exhaust vent. Use the

fewest number of elbows

and turns. Allow room

when using elbows or

making turns. Bend vent

gradually to avoid kinking.

6. Clean exhaust vent periodically, depending on use,

but at least every 2 years,

or when installing your

dryer in a new location.

•Disconnect vent from

the dryer and clean one

section at a time until

you reach the exhaust

hood.

•Use the hose attach-

ment on your vacuum,

or a pole or wire with a

feather duster or rag attached, to clean out lint.

•Be sure the flapper on the outside end of vent

moves freely.

•When cleaning is complete, be sure to follow the

Installation Instructions supplied with your dryer

for final product check.

CheckingYourVent

The kit contains:

2 - 1.22 m (4 ft) vent sections with attached close

elbows

1 - Wall plate for close clearance installations

2 - 10.16 cm (4 in) clamps

For safe and easy installation of your dryer, a com-

plete exhaust vent kit

is available. SURE

CONNECT Vent Kit

(No. 4396028) con-

tains everything you

need to install your

dryer.

To install vent:

1. Clamp one elbow/vent section

to the wall and one to the dryer.

2. Extend the vent upward, almost

to the top of the dryer, then

push the dryer to the wall.

3. From over the top, snap the

vent together.

SURE CONNECT*Vent Kit (optional)

Wall

Dryer

Wall

Dryer

The SURE CONNECT Vent Kit (No.

4396028) can be ordered by calling

1-800-807-6777.

wWARNING wWARNING

Starting your dryer

Before using your dryer, wipe the dryer drum with a

damp cloth to remove dust from storing and shipping.

1. Load clothes loosely into the dryer and close the

door. Do not pack the

dryer; allow space for

clothes to tumble freely.

2. Turn the Cycle Control knob to the recommended

cycle for the type of

load being dried.

Use the Energy

Preferred Automatic

Setting (*) in the Sensor

Dry cycle to dry most

heavyweight and

mediumweight loads.

3. Set the Temperature selector to the recommended

setting for the type of fabric being dried. The cycle

descriptions later in this section include tempera-

ture setting suggestions.

4. (OPTIONAL STEP) Set the End of Cycle Signal

selector to On or to the volume level you prefer

(on some models) if you want the dryer to sound a

signal when a cycle is finished. The signal is

helpful when you are drying permanent press,

synthetics, and other items that should be

removed from the dryer as soon as it stops.

5. (OPTIONAL STEP) Your dryer may have an

On/Off Extra Care selector. The Extra Care fea-

ture protects your clothes from wrinkling when you

do not remove them from the dryer as soon as it

stops.

• Set the Extra Care selector to On to tumble the

load without heat every few minutes up to 45

minutes after the drying cycle ends.

• A signal will sound every few minutes while

Extra Care is running if the End of Cycle Signal

feature is set On.

• Set the Extra Care selector to Off if you do not

want to run this feature.

Fire Hazard

No washer can completely remove oil.

Do not dry anything that has ever had any

type of oil on it (including cooking oils).

Items containing foam, rubber, or plastic

must be dried on a clothesline or by using

an Air Cycle.

Failure to follow these instructions can result

in death or fire.

Explosion Hazard

Keep flammable materials and vapours, such

as gasoline, away from dryer.

Do not dry anything that has ever had

anything flammable on it (even after

washing).

Failure to follow these instructions can

result in death, explosion, or fire.

OperatingYourDryer

Starting your dryer (cont.)

6. Push the Start button. Stopping and restarting your dryer

You can stop your dryer anytime during a cycle.

To stop your dryer:

Open the dryer door or turn the Cycle Control knob

to Off.

NOTE: The Cycle Control knob should point to an

Off area when the dryer is not in use.

To restart your dryer:

Close the door, select a new cycle and temperature

(if desired), and push the Start button.

NOTE: Your dryer stops automatically when a

cycle ends.

Cycle and temperature tips

•In the Automatic cycle (Sensor Dry), the FLO-

THRU™Drying System automatically reduces

the heat near the end of the cycle to prevent

overdrying.

•If your dryer has a special Ultra Low or Extra Low

temperature setting, this reduces drying tempera-

tures and provides enhanced fabric care for

delicates and other fine fabrics.

•If some types of loads in the cycle descriptions

have more than one suggested temperature

setting, choose the lowest setting available on

your dryer.

•The last few minutes of all cycles are without heat

to make the load cooler to handle.

Selecting the right cycle and temperature setting

Drying tips

•Make sure you have selected the correct cycle

and temperature for your load. For example,

select a High temperature setting for best drying

results with extra heavy items.

•Always follow care label directions when they

are available.

•If you use fabric softener sheets, always use

fabric softener sheets labeled as dryer safe and

follow package instructions carefully.

•Remove the load from the dryer as soon as tum-

bling stops to reduce wrinkling. This is especially

important for permanent press, knits, and syn-

thetic fabrics.

OperatingYourDryer

Use the Sensor Dry Automatic cycle for

heavyweight and

mediumweight cotton

items, such as towels,

linens, bedspreads,

work clothes, blue

jeans, and corduroys.

Set your dryer to a heat

setting that matches the

care label directions.

Delicates

3 camisoles

1 quilted robe

4 slips

4 panties

2 bras

2 nighties

1 baby’s dress

Automatic cycle

Your dryer has an Automatic cycle, Sensor Dry.

Sensor Dry uses an electronic dryness sensor con-

trol that senses the amount of moisture in the load

and shuts off the dryer when the selected dryness is

reached. The Cycle Control knob does not move

until the load is almost dry. After the cool-down, the

knob automatically turns to an Off area and tumbling

stops.

•Dry most loads using the Energy Preferred Auto-

matic Setting (*) in the Sensor Dry cycle.

•For any Automatic setting, you can choose any

temperature setting you want.

•If the load is drier than you like, select a setting

closer to Less Dry the next time you dry a

similar load.

•If the load is not as dry as you like, complete dry-

ing using the Timed Dry cycle (see next page).

Select a setting closer to More Dry the next time

you dry a similar load.

•The Extra Care feature (on some models) protects

your clothing from wrinkles if you are unable to

unload the dryer within 5 minutes after tumbling

stops. The Extra Care feature tumbles the load

without heat every few minutes up to 45 minutes

after the cycle ends.

NOTE: If the Extra Care selector is set to Off,

the Sensor Dry cycle ends after cool-down.

A signal will sound every few minutes when Extra

Care is running if the End of Cycle Signal feature

is set On. The signal and cycle stop when you

open the dryer door.

Dry

Less

Dry

Cool

Down

Extra

Care

Heavy

OFF

(Option)

Loading suggestions

The chart below provides some guidelines on various types of drying loads. Load clothes loosely into the

dryer. Do not pack the dryer; allow space for clothes to tumble freely.

Heavy Work Clothes

3 pair pants

3 shirts

4 pair jeans

1 coverall

1 overall

Towels

10 bath towels

10 hand towels

14 wash cloths

1 bath mat

Mixed Load

3 double sheets

4 pillowcases

8 T-shirts

6 pair shorts

2 shirts

2 blouses

8 handkerchiefs

OperatingYourDryer

Tabla de contenidos

Idiomas:

Otros manuales de Secadora de KitchenAid

KitchenAid

KitchenAid KEYE664W Manual de usuario

KitchenAid

KitchenAid PRO LINE KHEV01RSS0 Manual de usuario

KitchenAid

KitchenAid KEYS677E Manual de usuario

KitchenAid

KitchenAid PRO LINE KHGV01RSS0 Manual de usuario

KitchenAid

KitchenAid KGHS02RWH0 Manual de usuario

KitchenAid

KitchenAid KEYS700J Manual de usuario

KitchenAid

KitchenAid KEYW870B Manual de usuario

KitchenAid

KitchenAid KEYE770B Manual de usuario

KitchenAid

KitchenAid KEYE850V Manual de usuario

KitchenAid

KitchenAid KEHS02RWH1 Manual de usuario

KitchenAid

KitchenAid KEYE665B Manual de usuario

KitchenAid

KitchenAid KEYE800T Manual de usuario

KitchenAid

KitchenAid KEYE750V Manual de usuario

KitchenAid

KitchenAid KEYL410B Manual de usuario

KitchenAid

KitchenAid KEYE800S Manual de usuario

KitchenAid

KitchenAid KHEV01RSS - Pro Line Plus Electric Dryer Manual de usuario

KitchenAid

KitchenAid KHEV01RSS - Pro Line Plus Electric Dryer Manual de usuario

KitchenAid

KitchenAid KEYW770B Manual de usuario

KitchenAid

KitchenAid KEYE550V Manual de usuario

KitchenAid

KitchenAid KEYE900S Manual de usuario

KitchenAid

KitchenAid KEYS977E Manual de usuario

KitchenAid

KitchenAid KGHS02RWH1 Manual de usuario

KitchenAid

KitchenAid KEYW977B Manual de usuario

KitchenAid

KitchenAid KGYS700LT0 Manual de usuario

Manuales populares de Secadora de otras marcas

Bosch

Bosch WTA79200GB Manual de usuario

Amana

Amana W10233410A Manual de usuario

Miele

Miele TWH 780 WP Manual de usuario

Asko

Asko T760 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems 25 Series Manual de usuario

Bosch

Bosch Logixx 10 WTB76556GB Hoja de especificaciones

STIEBEL ELTRON

STIEBEL ELTRON Ultronic S Manual de instrucciones

Electrolux

Electrolux EW2H328R2 Manual de usuario

Beko

Beko DS8433RX1M Manual de usuario

Dawlance

Dawlance Spinner DS 6000 C Manual de usuario

Electrolux

Electrolux TP5080TW Manual de usuario

AEG

AEG TR838P4OB Manual de usuario

Indesit

Indesit IDV 75 Manual de usuario

Infiniton

Infiniton SD-DG85C Manual de usuario

BOMANN

BOMANN WT 5019 Manual de usuario

Alliance Laundry Systems

Alliance Laundry Systems TMB795C Manual de usuario

Asko

Asko T793C Manual de usuario

Kenmore

Kenmore 8041 - 5.8 cu. Ft. Capacity Electric Dryer Manual de usuario
