KitchenAid KECC568MBB01 Manual de usuario

COOKTOP PARTS

For Models: KECC568MBL01, KECC568MWW01, KECC568MSS01, KECC568MBB01

(Black) (Designer White) (S.Steel) (Pure Biscuit)

10−04 Litho in U.S.A. (cre) Part No. 8186151

36" ELECTRIC

BUILT−IN

COOKTOP

COOKTOP PARTS

For Models: KECC568MBL01, KECC568MWW01, KECC568MSS01, KECC568MBB01

(Black) (Designer White) (S.Steel) (Pure Biscuit)

8186151

Illus. Part

No. No. DESCRIPTION

1 Literature Parts

LIT8285316

Installation

Instructions

LIT8285628

Tech Sheet

LIT8285368

Use & Care Guide

LIT3191638

Safe Cooking Tips

2 Cooktop, Glass

8285315 Black

8285390 Designer White

8285392 Stainless Steel

8285391 Pure Biscuit

3 246119 Screw

4 8285573 Wall, Inside

3196160 Screw

6 3191791 Spring Locator(10)

8 3192439 Seal, Switch

9 8285242 Seal, Heat Shield

11 8285184 Box, Burner

12 3192737 Seal, Burner Box

13 8285347 Board, Power

4449745 Screw

14 3196537 Screw

15 8285622 Board, Control

16 8284628 Frame, Cooktop

(S.Steel Only)

17 8285534 Bracket, Bottom

3196160 Screw

18 8285323 Cable Ass’y

20 8285104 Rail, Element (2)

21 3192269 Rail, Element (1)

23 4456924 Box, Touch Control

3196160 Screw

24 Element, Surface

8285233 1000/2400W LF

8285230 1200W RF−RR

8285468 1800W CR

8285231 1500W LR

25 4449868 Block, Terminal

26 3196163 Screw, 10−16 x 7/8

27 8285568 Cover, Harness

3196160 Screw

28 4456922 Support, Module

29 4455917 Bracket, Mounting

3400093 Screw

MISCELLANEOUS PARTS

For Models: KECC568MBL01, KECC568MWW01, KECC568MSS01, KECC568MBB01

(Black) (Designer White) (S.Steel) (Pure Biscuit)

8186151

Illus. Part

No. No. DESCRIPTION

FOLLOWING PARTS

NOT ILLUSTRATED

Miscellaneous

3192408 Bracket,

Support (2)

SPLICING WIRES−−25FT.

LENGTH

242828 Wire, Black

12 Ga. 150 C

242820 Wire, Black

14 Ga. 150 C

242822 Wire, Blue

14 Ga. 150 C

242830 Wire, Brown

14 Ga. 200 C

242823 Wire, Green

14 Ga. 150 C

242824 Wire, Orange

14 Ga. 150 C

242829 Wire, Red

12 Ga. 150 C

242825 Wire, Red

14 Ga. 150 C

242831 Wire, Red

14 Ga. 200 C

242826 Wire, White

14 Ga. 150 C

242827 Wire, Yellow

14 Ga. 150 C

242832 Wire, Yellow

14 Ga. 200 C

FE02313 Bushing

ACCESSORY PARTS

4456147 Cleaner, Glass

WIRING HARNESS PARTS

8285471 Harness, Main

3400015 Screw, Ground

8285599 Conduit
