Kirisun PT6500 Manual de usuario
PT6500 User’s Manual
Page 1 of 30
PT6500 User’s Manual
CONTENTS
■Unpacking and checking
◆Supplied accessories
■Preparation
◆Charging the battery
◆Installing/Removing the battery pack
◆Installing the antenna
■Getting acquainted
■Basic Operation
■Programmable Button functions
■VOX
■Copy mode
■Whole setting
◆Time-out Timer（TOT）
◆Battery Saving
◆Low battery warning
◆Voice Annunciation of Channel Number
◆CTCSS/ DCS
■User’s resolution
◆Busy Channel Lockout（BCL）
◆Receiving squelch mode
◆DTMF signaling
◆2TONE signaling
◆Transmit start/over signaling (PTT ID)
■Problems and troubleshooting
■Major Specifications
■Status setting
PT6500 User’s Manual
Page 2 of 30
FCC Warning:
PT6500-02 is a a occupational equipment. And it operate with a duty factor not exceeding 50%.
The EUT cannot worn on the body.
The us version of this transmitter operates solely on us frequencies. The user is not able to
select on non-us frequencies.
PT6500 User’s Manual
Page 3 of 30
█Unpacking and checking
Unpack the transceiver carefully. We recommend that you identify the items listed in the following table
before discarding the packing material. If any items are missing or have been damaged during
shipment, please contact the dealer immediately.
Supplied accessories
Item Quantity
Antenna 1
Battery 1
Charger 1
Power adapter 1
Hand strap 1
User’s Manual 1
█Preparation
◆Charging the battery
Connect the power adapter with the battery charger. Plug the adapter into an AC wall outlet
and the indicator turns green.
P
ower a
d
a
p
te
r
B
atter
y
Ch
ar
g
e
r
PT6500 User’s Manual
Page 4 of 30
Place the battery or transceiver into the charger slot, and make sure the transceiver has
been turned off.
Make sure the battery is well connected with charger, then the indicator turns red or flashes,
then the charger gets in the state of charging automatically.
When battery is fully charged the indicator turns green.
The performance will be at the best condition if you remove the battery when the green
indicator is on. Then remove the power adaptor from the wall outlet.
The charger will enter the protection mode when the yellow indicator flashes, which means
the temperature or the circuit is abnormal. Do not charge the battery at this moment, just
remove the battery and turn off the power of the charger.
Notes:
* The battery is not fully charged in the factory. Before the initial use, please charge the new
battery.
* The KB-36A Ni-MH battery/KB-36C Li-ion battery of this company is adaptable with this
machine.
* When you charge the battery the first time or after long time storage (2 months), several
times of charging is needed. Make sure the battery is charged at least once every three
months.
* Do not charge the battery again if it is charged fully or not in the low-pressure warning
mode, otherwise, its life will be shortened or it will be damaged. Remove the battery from
the charger after charging.
* When you use the KB-36A battery, and the transceiver is in the low-pressure warning
PT6500 User’s Manual
Page 5 of 30
mode, recharge the battery before use. Do not power on by force, otherwise, its life will be
shortened or it will be damaged.
* There is a protection circuit in KB-36C battery, so the power will be cut off at too low
battery.
◆Installing/Removing the battery pack
To install the battery pack:
Match the 3 bulges of the battery pack with the corresponding holes at the rear Button of
the transceiver.
To install the battery pack:
Then firmly press the battery pack downwards to lock it in place until a click is heard.
To remove the battery pack:
Use your thumb to press the belt clip, and one side of your index finger to press the release
button; and then pull the battery away from the transceiver.
PT6500 User’s Manual
Page 6 of 30
Notes:
* Do not cause short-circuit or throw the battery to the fire.
* Do not disassemble the battery by your self.
◆Installing the antenna
Screw the antenna into the connector at the top of the transceiver by holding the Button of
the antenna and turn it clockwise until secure.
Getting acquainted
PT6500 User’s Manual
Page 7 of 30
The functions of the components are as follows:
A. LED Indicator
Lights red while transmitting;
Lights green while receiving a signal.
B. Power/Volume Switch
Turn clockwise till a click is heard to switch on the radio.
Turn counterclockwise till a click is heard to switch off the radio.
Rotate to adjust the volume after turning on the radio.
C. Channel Selector
Rotate to select the channel 1-128.
D. Antenna
E. Top Button (programmable button)
It is recommended to be set as the emergency warning Button.
F. Side button 1 (programmable button)
G. PTT（PUSH-TO-TALK）:
To make a call, press and hold the PTT button, then speak into the microphone with
normal voice.
H. Side button 2 (programmable button)
I. Button
Return and delete button in the menu.
J. Button
Select Button.
K. Button
Select Button.
L. Button
Enter and Confirm Button.
M. Numeric keypad
Explanation for the screen
PT6500 User’s Manual
Page 8 of 30
5Basic Operation
1. Switch On
Switch on the radio by turning the Power/Volume switch clockwise
till a click is heard, then the radio will be in the state of stand by
and you will hear a beep if the dealer has set it.
2. Adjust Volume
Press the button preset as canceling squelch to listen to the background noise and rotate
the Power/Volume switch to adjust volume.
Icon Description
Signal intensity
SVC
Compandor
Disturbance Frequency
Busy channel lockout
Scanning
Key lockout
Signal reminder is programmed
Battery volume, flashes when the
battery power goes too low
PT6500 User’s Manual
Page 9 of 30
3. Select a Channel
Rotate the channel selector to select channels. You will hear voice from the speaker while
receiving proper signals.
As shown in the above right figure:
Zone 1 is the zone of current channel (8 zones from 0 to 7).
H is the transmit power of the channel, H stands for high power, M for middle power while
L for low power.
CHANNEL 1 is the current channel (128 zones from 1 to 128).
4. Make a Call
To make a call, press PTT, and speak in normal voice and please keep your mouth 3~4
cm away from the microphone.
PT6500 User’s Manual
Page 10 of 30
5. Receive a Call
Release the PTT button to receive a call.
Your dealer can set CTCSS, DCS, 2 Tone signaling on you radio channels by PC software.
If you select a channel that has been preset with the tone signaling, you will not hear any
other calls except those from your own system.
6. Operation on menu: press “ ”button to enter the menu or confirm any contents;
press “ ” button to return to the previous menu or cancel the set. When entered the
menu, select the sub-menu with the “channel selector”, “ “or “ ”.
The
menu
is as
follows
:
菜单
Utilities
(应用选项)
Phone
(电话)
Rptr/Talkarnd
（脱网）
Speak mode
（喇叭模式）
Zone Edit
（区编辑）
Call
（联系列表）
Ch Edit
(信道编辑)
Scan
(扫描)Back Light
(背景灯)Squelch Levevl
(静噪等级)
Key tone
(按键音)Scrambler
(扰频)
Power Level
(功率水平)
Companding
(压缩扩展)
Save
(省电)
Rx FRQ
(接收频率)Tx FRQ
(传输频率)Rx Ctcss
(接收亚音)Tx Ctcss
(传输亚音)
开/关开/关0～9级 高、中、低
开/关开/关开/关关闭省电或
1:1、1:2、1:4
传输亚音频率
设置
接收亚音频率
设置
传输频率设置
接收频率设置
对讲机号码名单
选择区域
选择静噪模式
M
e
n
u
