INSTRUCTION ANUAL

ODEL: 8225NL

2-1/2” X 16 GA. BRAD NAILER KIT

04/2017

I PORTANT INFOR ATION

2-YEAR

LI ITED WARRANTY

FOR THIS 2-1/2” X 16 GA. BRAD NAILER KIT

KING CANADA TOOLS

OFFERS A 2-YEAR LI ITED WARRANTY

FOR NON-CO ERCIAL USE.

PROOF OF PURCHASE

Please keep your dated proof of purchase for warranty and servicing purposes.

REPLACE ENT PARTS

Replacement parts for this product are available at our authorized King Canada service centers across Canada.

LI ITED TOOL WARRANTY

King Canada makes every effort to ensure that this product meets high quality and durability standards. King Canada warrants to the

original retail consumer a 2-year limited warranty as of the date the product was purchased at retail and that each product is free from

defects in materials. Warranty does not apply to defects due directly or indirectly to misuse, abuse, normal wear and tear, negligence or

accidents, repairs done by an unauthorized service center, alterations and lack of maintenance. King Canada shall in no event be liable

for death, injuries to persons or property or for incidental, special or consequential damages arising from the use of our products.

To take advantage of this limited warranty, return the product at your expense together with your dated proof of purshase to an authorized

King Canada service center. Contact your retailer or visit our web site at www.kingcanada.com for an updated listing of our authorized

service centers. In cooperation with our authorized serviced center, King Canada will either repair or replace the product if any part or

parts covered under this warranty which examination proves to be defective in workmanship or material during the warranty period.

NOTE TO USER

This instruction manual is meant to serve as a guide only. Specifications and references are subject to change without prior notice.

PARTS DIAGRA & PARTS LISTS

Refer to the Parts section of the King Canada web site for the most updated parts diagram and parts list.

KING CANADA INC. DORVAL, QUÉBEC, CANADA H9P 2Y4

www.kingcanada.com

SPECIFICATIONS

odel..........................................................................................................................................................................................8225NL

Air inlet ......................................................................................................................................................................................1/4” NPT

Compressed air:

aximum permissible operating pressure....................................................................................................................120 PSI (8.3 bar)

Recommended operating pressure range ............................................................................................................................70-120 PSI

Nail range ............................................................................................................................3/4” to 2-1/2” 16 Ga. brad head finish nails

Nail capacity ..........................................................................................................................................................100 16 Ga. brad nails

Features:

•Powerful nailer drives standard 16 Ga. brad nails from 3/4” to 2-1/2”

•Special one piece hardened driver for long, trouble-free performance

•Quick release latch for clearing jams

•Adjustable air deflector controls the direction of air exhaust

•Sequential and bump firing modes

•70-120 PSI operating pressure

•Comes with 1/4” air inlet, oiler, safety glasses, hex. keys and

sturdy carrying case

GETTING TO KNOW YOUR NAILER

Nail loading area

Air inlet

Trigger

Quick clear latch

agazine

Nail discharge area

Air deflector

agazine latch

Safety release

AVAILABLE

KING INDUSTRIAL

16 GA. - BRAD NAILS

FN-1625 1’’ (25 APPROX.)

FN-1632 1-1/4’’ (32 APPROX.)

FN-1638 1-1/2’’ (38 APPROX.)

FN-1645 1-3/4’’ (45 APPROX.)

FN-1650 2’’ (50 APPROX.)

FN-1663 2-1/2’’ (63 APPROX.)

SAFETY INSTRUCTIONS

• Read and understand this manual and all the safety instructions before operating this nailer. If

you have any questions, please contact our authorized service centres or retailers for help.

• Never allow the use of flammable gases as a power source for the nailer. Use filtered, lubricated

and regulated compressed air only. The use of compressed gas may cause the nailer to explode

and may cause serious or fatal injury.

• Never use gasoline or other flammable liquids to clean this nailer. Vapors in the nailer will ignite

by a spark and cause the nailer to explode. This can result in serious or fatal injuries.

• Do not exceed the maximum permissible operating pressure of this nailer (120 PSI).

• Disconnect the nailer from its air supply before clearing jams, servicing, adjusting and while

the nailer is not in use. ALWAYS unplug the air lines before loading the tool with nails. Otherwise,

there is a risk of serious injury or loss of life.

• Do not keep the trigger pulled on contact safety trip mechanism when carrying or holding the

nailer. Never carry the nailer by the air hose or pull on the air hose to move the nailer.

• At the workplace, always wear protective equipment such as Z87 safety glasses, hearing and

head protection. The employer and the user must ensure that any person in the vicinity of the

nailer wear the safety equipment otherwise there is a risk of serious injury or permanent damage

to the hearing.

• Do not use a check valve or any other fitting which allows air to remain in the nailer.

• Do not place your hand or any part of your body in the nail discharge area of the nailer when

connecting or disconnecting from the air supply.

• Never point any operational nail driving tool at yourself or at any other person. The nailer can be

loaded. The accidental release of the nailer can cause serious or fatal injuries.

LUBRICATION

AIR SUPPLY AND CONNECTIONS

LUBRICATION AND AINTENANCE

• Your nailer needs to be lubricated before and after the first time you use it.

• Disconnect the air supply from the nailer before lubricating.

• Turn the nailer so that the inlet is facing up and put ONE DROP of high speed spindle oil or oil without

detergent into the air inlet. Never use detergent oil or additives. Operate the nailer briefly after adding

oil.

• Wipe off excessive oil at the exhaust. Excessive oil will damage O-rings of the nailer. If a in-line oiler

is used, manual lubrication through the air inlet is not required on a daily basis.

AIR SUPPLY AND CONNECTIONS

WARNING!

THE FOLLOWING ILLUSTRATION SHOWS THE CORRECT ODE OF CONNECTION TO THE AIR SUPPLY

SYSTE WHICH WILL INCREASE THE EFFICIENCY AND USEFUL LIFE OF THE NAILER.

• any air tool users find it convenient to use an oiler to help provide oil circulation through the tool

and it increases the efficiency and useful life of the tool. Check oil level in the oiler daily.

• any air tool users find it convenient to use a filter to remove moisture and impurities which can rust

or wear internal parts of the tool. A filter also increases the efficiency and useful life of the tool. The

filter must be checked on a daily basis and, if necessary, drained.

• For better performance, install a 3/8” quick connector (1/4” NPT threads) with an inside diameter of

.315” on your tool and a 3/8” quick coupler on the air hose.

Quick couplers

Quick connector

Oiler

Air hose Quick

connector

Regulator

Filter

Compressor

OPERATIONAL ODES

(SEQUENTIAL AND BU P FIRE ODE)

OPERATIONAL ODES

This brad nailer may be operated in either “sequential” or “bump fire” mode. This brad nailer is shipped with a

black trigger installed, this black trigger allows “sequential” firing. A separate red trigger for “bump fire” mode is

included and needs to be installed to use.

Sequential ode

When the black trigger is installed, this framing nailer is in “sequential” mode. This method is recommended when

precise nail placement is required. In sequential mode, the trigger needs to be pulled and released each time a

nail is driven.

• The operator is required to have the finger off the trigger and the nose of the nailer to be placed on the

workpiece.

• The contact safety trip mechanism is then depressed against the workpiece and the trigger is pulled to drive

the nail.

• The trigger is released after each nail is driven.

• ove the nailer to the next location and repeat the above procedure.

VERIFICATION

• Disconnect the air supply from the air inlet.

• Empty all nails from the magazine.

• ake sure the trigger and the contact safety trip mechanism moves up and down without sticking.

• Connect the air supply to the nailer air inlet.

• Depress the contact safety trip mechanism against the workpiece without pulling the trigger. The nailer must

not cycle. Never use the tool if a cycle occurs.

• Hold the nailer clear of the workpiece. The contact safety trip mechanism should return to its original down

position. Pull the trigger. The tool must not cycle. Never use the nailer if a cycle occurs.

• Depress the contact safety trip mechanism against the workpiece and pull the trigger, the nailer must cycle.

Bump Fire ode

When the red trigger is installed, this brad nailer is in “bump fire” mode. This method is recommended when less

precise nail placement is required. In bump fire mode, the trigger must be depressed with the brad nailer nose

off the work surface. Then, the nose of the brad nailer is tapped against the work surface causing a nail to be

driven. In this mode, each time the brad nailer nose is depressed, a nail is driven.

Changing odes

To change the firing mode of your drad nailer, remove the o-ring (A) which secures the trigger pin (B). Remove

the trigger pin (B), trigger (C), and the trigger spring (D). Interchange the trigger only and reassemble the parts.

LOADING NAILER & CLEARING JA S

LOADING NAILER AGAZINE

• Disconnect the air hose from the nailer air inlet.

• Depress the magazine latch, pull back on the magazine cover.

• Insert a stick of nails into the magazine. ake sure the pointed ends of the nails are as close to the

bottom edge of the magazine as possible, ensuring the head of the nail is aligned with the

appropriate machined groove in the magazine.

• Push the magazine cover forward until the latch catches.

CLEARING JA S

Disconnect the nailer from the air compressor before adjusting, clearing jams, servicing relocating

and during non-operation.

• Disconnect the air hose from the nailer air inlet.

• Depress the magazine latch, pull back on the magazine cover and remove all nails.

• Release the front mounted quick clear latch and lift cover.

• Remove jammed nail, lower cover and latch securely.

OPERATING YOUR NAILER

WARNING! protect your eyes and ears. Wear Z87 safety glasses with side shields. Wear hearing

protection. Employers are responsible for ensuring the user or anyone near the nailer wears the

above mentioned safety protection.

WARNING! Check and replace any damaged or worn components.

• Add one/two drops of 30W oil for air tools into the air inlet.

• Install a quick connect fitting to the nailer (if not installed).

• Connect the nailer to an air compressor using a 3/8” I.D. hose. ake sure the magazine does not contain

any nails and that the air hose has a rated working pressure exceeding 200 PSI and a female quick

coupler.

• Regulate the air pressure to obtain 85 PSI. Check the operation of the contact safety trip mechanism

following the instructions in this manual.

• Load magazine with nails following the instructions in this manual.

• Reconnect the air hose to the nailer air inlet.

• Test for proper nail penetration by driving nails into scrap wood. If the nails do not achieve the desired

penetration, regulate the air pressure to a higher setting until the desired penetration is achieved. Do

not exceed 120 PSI.

AINTENANCE & TROUBLESHOOTING

CLEANING YOUR NAILER

• Never use gasoline or other flammable liquids to clean the nailer. Vapors in the nailer will ignite

by a spark and cause the tool to explode and result in death or serious personal injury.

• Disconnect the air supply from the nailer.

• Remove tar buildup with #2 kerosene fuel oil or diesel fuel. Do not allow solvent to get into the cylinder

or dammage may occur. Dry off the tool completely before use.

• Air leaking at trigger valve

area.

• Air leaking between

housing and nose.

• Air leaking bewteen

housing and cap assembly.

• Nailer skips a nail.

• Nailer runs too slowly or

has loos of power.

• Jammed nails.

• O-rings in trigger valve are damaged.

• Loose screws in housing.

• Damaged O-rings.

• Bumper damage.

• Loose screws.

• Damaged seal.

• Worn bumper.

• Dirt in nailer nose.

• Dirt or damage prevents nails from

moving freely in the magazine.

• Inadequate air flow to nailer.

• Worn O-ring on piston or lack of

lubrication.

• Damaged O-rings on trigger valve.

• Air leaks.

• Cap seal is leaking.

• Nailer is not sufficiently lubricated.

• Broken spring in cap assembly.

• Exhaust port in cap is blocked.

• Driver guide worn or damaged.

• Nails are bent.

• agazine or nose screws are loose.

• Damaged driver.

• O-rings must be replaced and safety trip

mechanism must be verified.

• Screws need to be tightened.

• O-rings must be replaced.

• Bumper needs to be replaced.

• Screws need to be tightened.

• Seal must be replaced.

• Bumper needs to be replaced.

• Clean.

• agazine must be cleaned.

• Fitting hose and air compressor need to

be checked.

• O-rings must be replaced, lubricate.

• O-rings must be replaced.

• Screws and fittings need to be tightened.

• Seal needs to be replaced.

• Lubricate.

• Spring needs to be replaced.

• Damaged internal parts must be replaced.

• Replace driver guide.

• Replace with undamaged nails.

• Screws need to be tightened.

• Replace driver.

Problem Cause Solution

TROUBLESHOOTING CHART

WARNING: Stop using this tool immediately if any of the following problems occur. Serious personal injury could occur. Any repairs

or replacements must be done by a qualified person or an authorized service centre only.

REPLACE ENT DRIVER, BU PER & O-RING REPAIR KIT

After prolonged use of your Nailer, the internal O-rings, Bumper & Driver may have to be replaced

due to wear & tear. To repair, a complete Driver, Bumper & O-ring Replacement Accessory Kit is

available for your Nailer (model: KW-158). Contact your local King Canada distributor for more

information.

KW-158

Tabla de contenidos

Otros manuales de Pistola de clavos de King Canada

King Canada

King Canada 8260FSN-2 Manual de usuario

King Canada

King Canada 8225N Manual de usuario

King Canada

King Canada 8210NS Manual de usuario

King Canada

King Canada 8125N Manual de usuario

King Canada

King Canada 8235GFN Manual de usuario

King Canada

King Canada 8201N Manual de usuario

King Canada

King Canada PERFORMANCE PLUS 8200BN Manual de usuario

King Canada

King Canada 8228N Manual de usuario

King Canada

King Canada 8201N Manual de usuario

King Canada

King Canada 8202N Manual de usuario

King Canada

King Canada PERFORMANCE PLUS 8266FSN-3 Manual de usuario

King Canada

King Canada 8260FSN-2 Manual de usuario

King Canada

King Canada 8201NL Manual de usuario

King Canada

King Canada 8234 Manual de usuario

King Canada

King Canada 8228 Manual de usuario

King Canada

King Canada PERFOMANCE PLUS 8201NL Manual de usuario

Manuales populares de Pistola de clavos de otras marcas

Performance Tool

Performance Tool M643 Manual de usuario

Hitachi

Hitachi VH650 - Fencing Nailer, Full Head Manual de usuario

Parkside

Parkside PET 25 B1 Manual de usuario

Senco

Senco Fusion Technology F-35XP Manual de usuario

Grizzly

Grizzly G1847 Manual de usuario

Ryobi

Ryobi R18N18G Manual de usuario

Black & Decker

Black & Decker 492848-00 Manual de usuario

HOLZMANN MASCHINEN

HOLZMANN MASCHINEN TN90 Manual de usuario

Metabo HPT

Metabo HPT NR 3690DC Manual de instrucciones

Surtek

Surtek CN650 Dimensiones y guía de instalación

Makita

Makita GF600 Manual de usuario

Parkside

Parkside PET 25 B1 Manual de usuario

Senco

Senco AirFree 25 Manual de usuario

Freeman

Freeman P50LSLW Manual de usuario

Aicon PRO

Aicon PRO DAC4507 Manual de usuario

DAJ

DAJ XR150A Manual de usuario

Makita

Makita AN923 Manual de usuario

Grizzly

Grizzly T20644 Manual de usuario
