KICKER PowerBar

KPB1 | KPB2

Ampliﬁed Weatherproof Bar-Mount Speaker System with Bluetooth

Sistema de alto-falantes Ampliﬁcado à prova de intempéries com Bluetooth

Système d’enceintes Ampliﬁées étanches à Montage sur Barre avec Bluetooth

Verstärktes Wetterfestes Bar-Mount-Lautsprechersystem mit Bluetooth

Owner’s Manual

Manual del Propietario

Manuel d’utilisation

Benutzerhandbuch

1English

Contents

Overview........................2

Speciﬁcations........................ 3

Installation ......................4

Wiring ................................... 4

Relay Install &

Battery Management ............. 5

Mounting............................... 6

Operation.......................8

Status LED............................ 8

Control Panel ........................ 9

Setting Input Source ............ 10

Line Output & AUX IN .......... 10

Broadcast Mode ................. 11

Remote Control Install.......... 12

Remote Control Operation ... 14

Troubleshooting............15

Warranty ......................16

2English

Overview

IMPORTANT SAFETY WARNING

PROLONGED CONTINUOUS OPERATION OF AN AMPLIFIER, SPEAKER, OR

SUBWOOFER IN A DISTORTED, CLIPPED OR OVER-POWERED MANNER

CAN CAUSE YOUR AUDIO SYSTEM TO OVERHEAT, POSSIBLY CATCHING

FIRE AND RESULTING IN SERIOUS DAMAGE TO YOUR COMPONENTS

AND/OR VEHICLE. AMPLIFIERS REQUIRE UP TO 4 INCHES (10CM) OPEN

VENTILATION. SUBWOOFERS SHOULD BE MOUNTED WITH AT LEAST 1

INCH (2.5CM) CLEARANCE BETWEEN THE FRONT OF THE SPEAKER AND

ANY SURFACE. KICKER PRODUCTS ARE CAPABLE OF PRODUCING SOUND

LEVELS THAT CAN PERMANENTLY DAMAGE YOUR HEARING! TURNING UP A

SYSTEM TO A LEVEL THAT HAS AUDIBLE DISTORTION IS MORE DAMAGING

TO YOUR EARS THAN LISTENING TO AN UNDISTORTED SYSTEM AT THE

SAME VOLUME LEVEL. THE THRESHOLD OF PAIN IS ALWAYS AN INDICATOR

THAT THE SOUND LEVEL IS TOO LOUD AND MAY PERMANENTLY DAMAGE

YOUR HEARING. PLEASE USE COMMON SENSE WHEN CONTROLLING

VOLUME.

The KICKER PowerBar-series of powered,

bar-mounted Bluetooth speakers provide you with

the power and clarity required for enjoying audio

in any outdoor and recreational setting. Featuring

an IP66 rating for weatherproof applications, the

PowerBars come with an easy-to-use control panel

and mountable remote control, so changing the

tunes is only a touch away. KICKER’s new Broadcast

Mode technology allows you to sync up two or more

KPB’s via Bluetooth, while AUX Input and Line Output

connections allow for any combination of use with

other devices. Use the KPB1 or the larger KPB2 on

the beach, the links, the patio, off-road, or anywhere

you’re missing the music.

Use the following instructions to install and operate

your KPB and KPB Remote.

3English

Model: KPB1 KPB2

Power Output

@ 14.4V, <10% THD+N

150W 300W

Total Speakers 6 10

Height [in, mm] 4-9/16, 115 4-9/16, 115

Width [in, mm] 21, 530 34-1/2, 880

Weight [lbs, kg] 16.3 7.39

Woofer [in, mm] 3, 76

Tweeter [in, mm] 1, 25

Wiring Harness Length [ft, m] 12, 3.66

Frequency Response [Hz] 65-20,000

Signal-to-Noise Ratio >75, A-weighted

re: rated power

Tweeter Magnet Material Neodymium

Tweeter Dome Material Titanium

Tweeter Design Dome

Woofer Cone Material Polypropolene

Woofer Surround Material Santoprene

Aux Input Stereo 3.5mm Female

0–1.0 V Sensitivity

Line Output Stereo 3.5mm Female

Buffered, 2.5V

Speciﬁcations

4English

Installation

Wiring

Disconnect the vehicle’s battery to avoid an electrical

short. Connect the KPB’s black ground wire to a

paint-and-corrosion-free, solid, metal area of the

vehicle’s chassis, or to the negative battery terminal.

Connect the KPB’s red power wire to the positive

battery terminal. The wire harness includes an inline

15A ATC fuse (KPB1) or 30A ATC fuse (KPB2), and

5/16” ring terminals. The ring terminals can be cut off

if they’re not needed, but the fuse should always be

kept within 18” of the battery.

Keep the audio signal cable away from factory wiring

harnesses and other power wiring. If you need to

cross this wiring, cross it at a 90-degree angle.

12V battery

WARNING: Do not

connect to +24V

battery systems.

to chassis ground or battery

IMPORTANT: The KPB draws a small amount

of power over time, even when off. If storing

the vehicle for two weeks or more, take

precautions to ensure the life of your vehicle’s

battery, such as disconnecting the fuse.

fuse

KPB1 - 15A ATC

KPB2 - 30A ATC

5English

12V

Relay Install & Battery Management

To increase battery longevity, it is good practice to

use a Battery Management System (BMS) for your

electric vehicles, as well as an accessory or relay

switch for your KPB. Relays and BMS are optional

and not included. Required current rating: 30A

Relay Pinouts

30 - Power Input

85 - Relay Ground

86 - Relay Trigger Input

87 - Power Output - Open Contact (ON)

87a - Disconnected

battery

fuse

KPB1 - 15A ATC

KPB2 - 30A ATC

87a

ground

KPB or other device

SPDT Bosch Relay

6English

Mounting

The KPB-series mounts out-of-the-box to round

bars with the included 1.5”, 1.75”, and 2” diameter

Bar Clamps. Use the KPB Square Clamps - sold

separately - to mount your KPB to square bars.

Choose a structurally sound location to mount the

KPB. The KPB may be mounted below or above

bars, and the Mounting Base may be rotated ±30° to

accommodate some curved bars. Make sure there

are no items interfering with the route of the wiring.

Installation tools are not provided. 5mm and 6mm

Allen Wrenches are required.

1. Screw the Mounting Bases to the PowerBar using

the Mounting Screws.

±30°

6mm Allen Wrench required

7English

2. Place the included rubber inserts in the Clamp

Rings for improved vibration dampening, then install

the Clamp Rings around your bar, securing them to

the Mounting Bases using the Clamp Screws.

The KPB2 may be mounted with the bases and

clamps in an inward, or outward conﬁguration.

KICKER does not recommend a combined

inward/outward conﬁguration.

5mm Allen

Wrench required

8English

Operation

Status LED

The LED color displays audio source, pairing status,

and warnings:

Bluetooth (Blue)

Off Power is off

Solid Bluetooth Mode

Rapid Blinking Bluetooth Pairing Mode

Alternate Red/Blue Waiting for Broadcast Mode

to connect

Long Blue + Short Red Broadcast Mode

Bluetooth Transmitter Active

AUX IN (Red)

Off Power is off

Solid AUX Mode

Alternate Red/Blue Waiting for Broadcast Mode

to connect

Long Red + Short Blue Broadcast Mode

AUX Transmitter Active

Other

Purple Broadcast Mode

Receiver Active

Red Rapid Blinking AMP FAULT Warning

(Overload, Undervoltage,

Overvoltage)

9English

Control Panel

Long Press - Power On/Off

Power on the KPB by

performing a long press of

the POWER Button

Status LED

Increase Volume Decrease Volume

Short Press - Previous Track

Long Press - Rewind

Short Press - Next Track

Long Press - Fast Forward

Short Press - Play/Pause or Mute

Very Long Press (10s) - Software Reset

Short Press - Change Input Source

Long Press - Enter Bluetooth Pairing Mode

Change EQ Presets - KICKER, LOUD,

SOUND QUALITY, & VOICE

10S

short press

long press

very long press
