Keyspan TuneView Manual de usuario
..................................................Introduction!2
•Package Contents (TVI-200C)
•Requirements
............Setting Up Your TuneView for iPod!3
•Connecting Everything Together
.....................Using The TuneView Remote!7
•Using The TuneView Remote
•Setup Menu
•Language Settings
•Repeat Settings
•Scroll Thumb Settings
•Firmware
•The Wizard Button
...........................................Troubleshooting!10
•Sync Your Remote To Your Dock
•Reset To Factory Settings
•Menu Navigation Is Sluggish / Range Issues
•No Audio
•Error Message - iPod Busy
•Error Message - iPod Not Connected
•Message - Starting Player
....................................Support Information!12
•Support Options (US Based)
•International Support Options
..........................Specs - TuneView for iPod!13
•Package Contents (TVI-200C)
•Buttons On Remote
•Other Details
.....................Warranty Information [1 Year]!14
•Definitions
•Limited Warranty on Hardware:
•How To Obtain Warranty Service/Repair
.........................................................Notices!16
•United States FCC
•CE MARK DECLARATION OF CONFORMITY
•Canada Digital Apparatus EMI Standard
•Australia/New Zealand
•Copyright
•Trademarks
TuneView for iPod - User Manual (rev 11/22/06)!Page 1 of 18
TuneView for iPod
USER MANUAL
for
p/n TVI-200C
Introduction
TuneView for iPod provides a new wireless way to manage your music throughout your house or
office.!TuneView allows you to:
!!!!!!!
* Connect the iPod to a stereo or powered speakers using the line out jack
* Connect the iPod to a TV using the S-Video jack
* Charge the iPod from an AC outlet using the USB Power Adapter
* Browse and control the iPod from around the house with LCD remote.!
The TuneView dock may also be used to sync an iPod with a PC or Mac.
Both the TuneView dock and TuneView remote are USB devices that can be updated via a firm-
ware download (just like an iPod).!Over time we will release firmware updates that add new ca-
pabilities to TuneView.!
Package Contents (TVI-200C)
The Keyspan TuneView for iPod package (TVI-200C Package) contains the following items:
!• TuneView Dock!• Dock Adapters:
"• TuneView Remote" " iPod mini
"• USB Power Adapter" " iPod (20GB, U2)
"• USB Cable" " iPod with color display (20GB, 30GB, U2)
"• Audio Cable!• Batteries:
! ! (3.5mm stereo to dual RCA)" " Two AA Batteries
"
Requirements
"iPod mini
"with firmware v1.4.1 or greater
"4G Pod (BW Display)
"4th generation
"with firmware v3.1.1 or greater
"iPod Photo (aka iPod with Color Display)
"4th generation
"with firmware v1.2.1 or greater
!nano
"1st generation
"with firmware v1.2.0 or greater
!5G Pod
"5th generation (video)
"with firmware v1.2.0 or greater
"2G nano
"2nd generation (aluminum)
"with firmware v1.0.1 or greater
"
TuneView for iPod - User Manual (rev 11/22/06)!Page 2 of 18
Setting Up Your TuneView for iPod
Connecting Everything Together
Step 1 - Connect The Audio and Video Cables To Your Dock
Audio:
Connect the audio cable's 3.5mm stereo jack to the
LINE OUT port on the back of the TuneView Dock.
Next, connect the stereo cable's dual RCA connectors
to your stereo/speakers.
Video:
S-Video jack allows connection to a TV for viewing slideshows and video (if your iPod supports
these features). Connect one end of an S-Video cable (not included in the TVI-200C Package) to
the S-VIDEO OUT port on the TuneView Dock and then connect the other end into your TV.
Step 2 - Connect The USB Cable/Power Supply To Your Dock
Power Via Included USB Power Adapter:
Connect one end of the USB cable to the SYNC/POWER port
on the TuneView Dock. Connect the other end of the USB ca-
ble to the USB port on the USB Power Adapter.
Power Via Your Computer's USB Port:
You can also use your computer's USB port to power your dock
as well as to sync your iPod to your computer. To do this, con-
nect the one end of the USB cable to the SYNC/POWER port
on your do. Connect the other end of the USB cable to the
USB port on your computer.
Troubleshooting Tip:
When you turn on your TuneView Dock, it's status light will
turn on and then turn off indicating that the dock is working
and read to use.
TuneView for iPod - User Manual (rev 11/22/06)!Page 3 of 18
Step 3 - Insert Included Batteries Into The
TuneView Remote
Turn over your TuneView Remote and remove the bat-
tery cover. Then insert the the two AA batteries and re-
place the battery cover.
The TuneView LCD screen will now turn on. Your
remote establish communication with the dock.
For now, the LCD screen should display the message
'iPod Not Connected'.
If you see this message, Proceed to the next step.
If You Have Multiple TuneView Remotes/Docks:
The TuneView dock will automatically sync (aka pair)
with to the first TuneView remote it detects. If you have
multiple sets of TuneView docks and remotes, please turn
them on one at a time so that they can properly commu-
nicate with during setup. After setup, they will can all be
turned on at the same time and functioning at the same
time.
Step 4 - Insert Universal Dock Adapter and iPod Into The TuneView Dock
TuneView for iPod - User Manual (rev 11/22/06)!Page 4 of 18
