Statement

Jiangsu Keyland Laser Technology Co.,Ltd

Keyland Laser Technology Co.,Ltd reserves the right to modify the products in

this manual and product specifications document without prior notice.

Keyland Laser Technology Co.,Ltd does not assume caused by improper use of

the manual or the product directly, indirectly, incidentally or consequential loss

or liability.

Keyland Laser Technology Co.,Ltd has the products and software patents,

directly or indirectly copy, manufacture, processing, use of this product and its

associated parts

This product is designed and manufactured for general industrial applications

than expected and the use of human life or property caused by the significant

impact is not the scope of services

Keyland to ensure that: all "Gosun and keylandr" brand products will improve

service to the Company

46-2

Preface

Thank you for trust on Keyland Laser technology Co.,Ltd., welcome to use our

products!

Please read this user manual before using the product.This manual provides

detailed information for use firstly of this product relevant security matters, the

installation, describes the function , operation of the various components, the

routine maintenance necessary for the good condition of this product, and lists the

fault finding methods, techniques, support files, and more important content.

If you have any questions about the product or have any problems when using

this product, please contact us, our technical team will be ready to provide you with

professional support and advice. Please contace

JiangSu Keyland Laser Technology Co., Ltd. and service center

24-hour toll-free Hotline :400-6263-601

46-3

In order to ensure safe operation and best performance, please follow

these warnings and pay attention to other matters, as well as the manual to

operate.

"Dangerous" and "warning" symbol are marked in accordance with the extent of

the risk of accident.

Indicates a potentially hazardous situation , if not avoided, may

result in death or serious injury

Indicates a potentially hazardous situation if not avoided,

Will result in minor or moderate injury or material damage

The following symbols indicate which is prohibited must comply with

This flag indicates the operation of the "ban"

This flag indicates that the operation should be noted that

Finally, Please pay attention to the following matters:

Before power to the product, be sure to fully understand contain in this

manual on the safe operation of the laser and maintenance of the Note

If this manual does not mention, please not to adjust or modify the

product or its components, otherwise it may result in hazardous laser

46-4

radiation.

Contents

1. Security..........................................................................................................6

1.1 Basic information.................................................................................6

1.2 Optical Security....................................................................................6

1.3 Electrical safety....................................................................................8

1.4 Equipment safety standards ...............................................................9

2. Overview.....................................................................................................10

2.1 Introduction......................................................................................10

2.1.1 Character...................................................................................10

2.1.2 Application.................................................................................11

2.2 Operating principle and parameters..............................................11

2.3 System structure...............................................................................12

2.3.1 Appearance...................................................................................12

2.3.2 Main-operation-contro-panel......................................................14

2.3.3 CO2 Laser..................................................................................15

2.3.7 Working platform ........................................................................15

2.3.5 Thermostatic water-cooled machine ..........................................16

2.3.6 Electronic control board..............................................................16

2.3.7 Negative pressure vacuum fan....................................................17

3 Installation &adjustment and workflow...................................................18

3.1 Opening inspection.............................................................................18

3.2 Preparation before installation and adjustment.............................18

3.3 Venues and supporting facilities.......................................................18

3.4 Processing workflow..........................................................................19

3.5 Processing Notes.................................................................................20

46-5

4. Operating instructions................................................................................22

4.1 Booting process...................................................................................22

4.2 Use the operating................................................................................22

4.2.1 Operation panle............................................................................22

4.3 Shutdown process...............................................................................25

5. Maintenance service....................................................................................26

5.1 Maintenance and servicing of the optical system............................26

5.2 Maintenance and servicing of motion organizations......................27

5.3 Optical path adjustment and replacement of the laser tube..........27

5.4 Thermostatic water-cooled machine maintenance and servicing .31

5.5 Exhaust Fan and vacuum pipe maintenance and servicing...........32

6. Common problems and solutions............................................................33

6.1 The main equipment part..................................................................33

6.2 Thermostatic water-cooled machine part........................................35

7. Drawings ....................................................................................................37

7.1 Outline Drawing.................................................................................37

7.2 Electrical schematic...........................................................................39

7.3 Electrical wiring diagram..................................................................40

8. Consumable wearing parts.......................................................................45

8.1 Laser tube ...........................................................................................45

8.2 Optical Lens........................................................................................45

9. Sftware Operation Manual ..........................................................................46

9.1 Software Introduction......................................................................46

9.2 The installation of the software program ......................................46

9.3 Software Operation............................................................................46

46-6

1. Security

1.1 Basic information

The staff , who can be authorized after the relevant training and fully understand

the necessary safety procedures, can operate this laser productcan

Please allow only authorized person close to the laser product, set the

appropriate warning signs.

Please observe the safety regulations of the local device.

1.2 Optical Security

This laser products output more than 60W/80W/100W (according to different

models) infrared laser radiation at 10.6 μm wavelength range. Avoid eye and

skin exposure to the laser output directly to the issue or scattering the radiation.

The laser may cause the following incidents: (1) ignite surrounding

combustibles; (2) the processing of different objects may produce other

radioactive and toxic and harmful gases.

The optical path from second to third mirror without any protection, Please do

not into this optical path for your any body part in order not to cause harm

during engraving & cutting and debugging.

Laser processing may be at risk ,should be carefully considered by the

processing object, is suitable for laser operation. .

Prohibited any irrelevant total reflection or diffuse reflection object placed in

the device, to prevent the laser reflector to the human body or inflammable

materials.

Should wear the appropriate laser protective eyewear, the laser wavelength of

the laser protective eyewear should be issued to match.

Do not allow direct view of the main beam or the reflected

laser beam ,Even in the case of wear laser safety glasses -

can lead to blindness

Objects against the mirror into the laser radiation zone, to prevent due to the

46-7

specular reflection of accidental damage to the human eye or the human body.

Strongly recommended that the laser output port do not point to the entrance or

windows of the room when the product is placed

"Beware of the laser, do not close" words of warning signs should be set to

equipment workplace door or near the work area

Avoid inflammable and explosive materials into the direct laser radiation zone

Prohibits any person is free to adjust the optical system,even in shutdown,except

with the permission or authorization of the Company

Security identity and location

Paste in the laser output head

May lead to the occurrence of fires and other accidents

46-8

Paste on the laser front

1.3 Electrical safety

This product must be in the specified electrical conditions.

Connect the power line and ensure that the circuit wiring is correct.

When the normal operation of equipment does not exist electrical hazards, and

ensure proper grounding well.

When the equipment is not in use, should remove the key from key switch to

prevent unauthorized use.

When fault alarm sound or light, should be shut down and then check

troubleshooting in order to boot again.

During the laser tube rupture and laser power damage may occur due to a

serious fault, must immediately press the emergency stop button or cut off the

total power.

When meet abnormal situation, you should immediately stop work, cut off the

power, then please consult us.

Power supply is suddenly interrupted a great influence on the laser, make sure to

provide a continuous and stable power supply. To avoid the sudden change in

voltage caused by the equipment, electrical circuits, burned.It is recommended

that every single installation of more than 2000W power supply regulator

Such labels is very important to the safe operation, prohibit

demolition.

Any missing or defective, please contact us for spare parts

This device contains a fatal DC and AC voltage, even if powered off

This danger may still exist for some time

46-9

Avoid to boot work in thunder and lightning

Humidity too high cause high-pressure laser discharge, endangering personal

safety, will cause damage to the laser power

Must ensure that there is sufficient space and airflow

When the cooling water temperature is greater than the maximum allowable

value of 30 ° C, the laser energy output will decline rapidly; when the cooling

water temperature is less than the minimum allowed value to 0 ° C will cause

the cooling water freezes in the laser tube, resulting in the laser tube rupture.

Replacement of wearing parts, the relevant requirements of this manual

power-off operation must be maintained by a professional.

1.4 Equipment safety standards

This product is designed to the following national standards:

GB of 18217-2000 - laser safety signs

GB 7247.1-2001 - Radiation Safety of Laser Products, Equipment Classification,

Requirements and User's Guide

GB 10.32 thousand -1995 - laser equipment and facilities of the electrical safety

GB / T 5226.1-1996 - Electrical equipment of industrial machinery - Part 1:

General technical conditions

Prohibit unauthorized adjustment, demolition, replacement in

Unauthorized condition.

Doing so may result in injury or equipment damage

46-10

2. Overview

2.1 Introduction

The 1390 series laser cutting machine is widely used in non-metallic materials

cutting (such as acrylic, leather, cloth, etc.). The machine adopts the glass tube of

carbon dioxide laser as the light source, computer-controlled two-dimensional

platform for various pre-set graphics track precise movements. Laser of the model

set, automatic control, precision machinery, computer control software, and other

high-tech one, with high-tech, high cost performance characteristics.

The series of models in the optical system, control system has first-class core

technology, the speed, precision cutting close to the performance of similar foreign

products, with high practicality.

2.1.1 Character

1, CO2 light source of laser equipment, optical power according to current

regulation, the scope can be applied to the need for cutting different material

thickness. Advantage of its excellent processing performance through the use of

non-contact processing, will not damage the workpiece, the processing quality has

been greatly improved.

2, Two-dimensional table using the motor-driven two-tier structure, 17 rotary

encoders for precision motion control, PW closed-loop control mode, the system

Tabla de contenidos

Manuales populares de Impresora de otras marcas

Lexmark

Lexmark 1400 Series Manual

Canon

Canon i70 Series Manual de usuario

Evolis

Evolis Elypso Manual de usuario

Kyocera

Kyocera FS-9530DN Manual de usuario

Canon

Canon LASER SHOT LBP-1210 Manual de usuario

Samsung

Samsung BIXOLON SRP-350plusF Manual de usuario

Canon

Canon PIXMA PRO-1 Series Manual de usuario

Canon

Canon PIXMA G3560 Guía de configuración

Dell

Dell Color Laser Printer 2130cn Manual de usuario

Tektronix

Tektronix Phaser 840 Manual de usuario

Epson

Epson ET-7750 Instrucciones de funcionamiento

Canon

Canon CLBR 460ps Manual de usuario

Eltron

Eltron P210 Guide Manual de usuario

Ricoh

Ricoh MD-P1 Manual de usuario

Epson

Epson SC-F7100 series Manual de usuario

Epson

Epson Stylus C40UX Manual de usuario

Canon

Canon imagePASS-A2 Manual de usuario

Canon

Canon S820D Manual de usuario
