Kenwood KVC85 Manual de usuario

TYPE KVC85

TYPE KVL85

Instructions

Istruzioni

Instrucciones

Bedienungsanleitungen

Gebruiksaanwijzing

Instrukcja obsługi

Instruções

English 2 - 13

Nederlands 14 - 26

Français 27 - 39

Deutsch 40 - 53

Italiano 54 - 66

Português 67 - 79

Español 80 - 91

Dansk 92 - 103

Svenska 104 - 115

Norsk 116 - 127

Suomi 128 - 139

Türkçe 140 - 151

Česky 152 - 163

Magyar 164 - 175

Polski 176 - 188

Eλληνικά 189 - 203

Slovenčina 204 - 215

Українська 216 - 228

ÝY

pqw-pp

KVC85 Chef

11 – Bowls

KVL85 Chef XL

3.5L

10 – Easy weigh scales

b ca

414

A B C

D E F

G H I

J K L

To Use Your Stand Mixer

To Use the Weighing Function

V W X

To Assemble the Creaming Beater

M N O

To Fit And Use Your Splashguard Tool Adjustment

P Q R

To Fit and Remove the Head Cover

S T U

Know Your Kenwood Stand Mixer

Congratulations on buying a Kenwood. With such a wide range of attachments available,

it is more than just a mixer. It is a state-of-the-art Stand Mixer. We hope you will enjoy it.

Robust. Reliable. Versatile. Kenwood.

Safety

ORead these instructions carefully and retain for

future reference.

ORemove all packaging and any labels.

OIf the plug or cord is damaged it must, for safety

reasons, be replaced by Kenwood or an authorised

Kenwood repairer in order to avoid a hazard.

OTurn the speed control to ‘O’ OFF position

and unplug before fitting or removing tools/

attachments, after use and before cleaning.

O

Keep body parts, hair and jewellery and loose clothing

away from moving parts and fitted attachments.

ONever leave the Stand Mixer unattended when it is

operating.

ONever use a damaged appliance. Get it checked or

repaired: see ‘Service and Customer Care’ section.

ONever operate the Stand Mixer with the head in the

raised position.

ONever put your fingers into the hinge mechanism.

ONever let the cord hang down where a child could

grab it.

ONever let the power unit, cord or plug get wet.

ONever use an unauthorised attachment or more than

one attachment at once.

ONever exceed the quantities stated in the maximum

capacity chart

OWhen using an attachment, read and follow the

safety instructions that are supplied with it.

OTake care when lifting this appliance as it is heavy.

Ensure the head is correctly latched in the down

position and that the bowl, tools, outlet covers and

cord are secure before lifting.

OTake care when removing bowl tools after extended

use as they may get hot.

English

OChildren should be supervised to ensure that they

do not play with the appliance.

ODo not move or raise the mixer head with an

attachment fitted as the Stand Mixer could become

unstable.

OWhen moving the appliance always pick up by the

pedestal base and mixer head. Do not lift or carry

the appliance by the bowl handle.

ODo not operate your appliance near the edge or

overhanging the work surface or apply force to an

attachment when fitted, as this may cause the unit

to become unstable and tip over, which may result

in injury.

OThe short power-supply cord is used to reduce risk

resulting from becoming entangled in or tripping.

Extension cords may be used if care is exercised in

their use. If an extension cord is used: 1) The marked

electrical rating of the extension cord should be

at least as great as the electrical rating of the

appliance; and 2) The cord should be arranged so

that it will not drape over the countertop or tabletop

where it can be pulled on by children or tripped

over unintentionally. 3) The extension cord should

be an earthed-type 3-wire cord. The electrical rating

of the appliance is listed on the bottom of the unit.

OAppliances can be used by persons with reduced

physical, sensory or mental capabilities or lack of

experience and knowledge if they have been given

supervision or instruction concerning use of the

appliance in a safe way and if they understand the

hazards involved.

OMisuse of your appliance can result in injury.

OThis appliance shall not be used by children. Keep

the appliance and its cord out of reach of children.

OThe maximum rating is based on the mini chopper/

mill attachment that draws the greatest load. Other

attachments may draw less power.

KVC85 only

ONever use the splashguard with the 3.5L bowl.

Splashguard only suitable for use with the 5L bowl

ODo not fit a bowl tool to the stand mixer when the

3.5L bowl is stacked in the 5L bowl.

OFor kneading bread dough use the 5L bowl only.

KVL85 only

ONever use the splashguard with the 5L bowl.

Splashguard only suitable for use with the 7L bowl

ODo not fit a bowl tool to the stand mixer when the

5L bowl is stacked in the 7L bowl.

OFor kneading bread dough use the 7L bowl only.

OOnly use the appliance for its intended domestic

use. Kenwood will not accept any liability if the

appliance is subject to improper use, or failure to

comply with these instructions.

Before plugging in

O Make sure your electricity supply is the same as the one shown on the underside of your

appliance.

O This appliance conforms to EC Regulation 1935/2004 on materials and articles intended

to come into contact with food.

Before Using For The First Time

O Wash the parts: see ‘Care and

Cleaning’ section.

Key

Attachment Outlets

1High-speed outlet

2Slow-speed outlet

3Bowl tool socket

Mixer

4High speed outlet cover

5Mixer head

6Mixer ready indicator light

7Speed control dial

8Head release lever

9Power unit

10 Easyweigh scales

adisplay screen

b On/Zero button

c kg/lb button

11 Bowls

12 Slow speed outlet cover

13 Head Cover

14 K-beater

15 Whisk

16 Dough tool

17 Creaming beater

18 Spatula

19 Splashguard

Note: Spanner shown is for illustration

purposes only and is not supplied in

pack.

Optional Attachments

There are a range of optional

attachments available to use with

your Stand Mixer. See the attachment

leaflet included in your pack or visit

www.kenwoodworld.com to see the full

range and how to buy an attachment

not included in your pack.

Note: Slow Speed Outlet Attachments

The slow speed outlet on your Stand

Mixer model features the Twist

Connection System. It is designed

to accept Twist Connection System

attachments.

When purchasing new attachments for

the slow speed outlet you should check

compatibility with your Stand Mixer. All

Twist Connection System attachments

can be identified by the product code

which starts with KAX and also by

the Twist logo which is visible on

packaging. For more information visit

www.kenwoodworld.com/twist.

If you own attachments featuring the

Bar Connection System you will

need to use the KAT002ME adaptor to

connect these to the Twist Connection

System on your Stand Mixer.

For more information visit

www.kenwoodworld.com/twist.

To Use Your Stand Mixer

Refer to Illustrations A–I

1 Push the head-lift lever down and

raise the mixer head until it locks.

2 Fit the bowl, turn clockwise to lock.

3 Place the required tool into the

socket. Then push up and turn the

tool to lock into position.

Note: If the K-beater or Whisk are

not picking up ingredients from the

bottom of the bowl refer to the “Tool

Adjustment” section.

4 Lower the mixer head by pushing the

head release lever down and lower

the mixer head until it locks.

5 Plug into the power supply. Start

the machine by turning the speed

control to the desired speed setting.

Use the pulse (P) position for short

bursts of maximum speed.

6 After use, return the speed control

to ‘O’ OFF position and unplug your

Stand Mixer.

7 Release the tool by turning clockwise

to unlock from the tool socket and

then remove.

Hints

O The fold function can be used for

folding light ingredients into heavier

mixtures for example meringues,

mousses, fruit fools, Genoese

sponges and soufflés, and to slowly

incorporate flour and fruit into cake

mixtures. The mixer will operate at a

constant slow speed.

Important

Ensure that no bowl tools are fitted or

stored in the bowl when using other

outlets.

To Use The Weighing

Function

Refer to Illustrations J– L

1 Fit the bowl.

2 Press the on/zero button, the display

screen will flash ---- followed by 0.

3 Press the (kg/lb) button to select

either grams or ounces. The display

will default to kg/g when first

switched on.

* The unit weighs in 1g increments

and teaspoon/tablespoon measures

are recommended for weighing small

quantities.

* To zero press the on/zero button once.

4 Weigh the required ingredients

straight into the bowl.

Note: Always place the appliance on a

dry, flat, stable surface prior to weighing.

Do not apply pressure to the mixer or

bowl whilst weighing as this will affect

the accuracy of the scales. The weighing

function can be used with the mixer

head in either the down or up position.

Count up timer

O During operation the display screen

will automatically operate as a count

up timer.

O The timer will count up to 30

minutes and will pause (for up to 30

secs) when ever the speed control is

turned to the 'O' position.

O To reset the timer to zero when the

machine is running press the ON/

ZERO button.
