Kenwood FDM30 Manual de usuario

Instructions

TYPE: FDM30

10A Plastic blender C - standard

attachments

D - optional

attachments

10B Glass blender

11/12 14-15-16 17

50mm

30mm

19 21

22A

23+22

009

Safety

O

Read these instructions carefully and retain for future reference.

ORemove all packaging and any labels.

OIf the plug or cord is damaged it must, for safety reasons, be

replaced by Kenwood or an authorised Kenwood repairer in

order to avoid a hazard.

ODO NOT touch the sharp blades. The blades and discs are

very sharp, handle with care. Always hold by the finger grip

at the top, away from the cutting edge, when handling

the sharp cutting blades, emptying the bowl and during

cleaning.

ODO NOT process hot ingredients.

OBe careful if hot liquid is poured into the food processor

or blender as it can be ejected out of the appliance due to

sudden steaming.

ONever leave the appliance unattended when it is operating.

ODo not exceed the maximum capacities stated in the

recommended usage chart.

ODo not operate your appliance for longer than the

times specified below without a rest period. Processing

continuously for longer periods can damage your appliance.

Function/Attachment Maximum

Operation Time Rest Period

Between

Operations

Blender 60 secs Unplug the

appliance and

allow to cool

down for 15

minutes

Heavy mixtures in the

bowl (e.g. Dough) 60 secs

Mini Chopper/Mill 30 secs

Grinding Mill 60 secs

ODo not lift or carry the processor by the handle - or the handle

may break resulting in injury.

OAlways remove the knife blade before pouring contents from

the bowl.

OKeep hands and utensils out of the processor bowl and

blender goblet whilst connected to the power supply. If food

needs to be pushed down use a suitable utensil such as a

spatula.

OAlways switch off the appliance and disconnect from

the supply if it is left unattended and before assembling,

disassembling or cleaning.

ONever use your fingers to push food down the feed tube.

Always use the pusher supplied.

ONever fit the blade assembly to the power unit without the

goblet or mill jar/lid fitted.

OCAUTION: Before removing the lid from the bowl, blender or

mill from the power unit:

switch off;

wait until the attachment/blades have completely stopped;

be careful not to unscrew the blender goblet or mill jar from

the blade assembly.

ODo not use the lid to operate the processor, always use the

on/off speed control.

OThis appliance will be damaged and may cause injury if the

interlock mechanism is subjected to excessive force.

ONever use an unauthorised attachment.

ONever use a damaged appliance. Get it checked or repaired:

see ‘Service and customer care’.

ONever let the power unit, cord or plug get wet.

ODo not let excess cord hang over the edge of a table or

worktop or touch hot surfaces.

OChildren should be supervised to ensure that they do not play

with the appliance.

OThis appliance shall not be used by children. Keep the

appliance and its cord out of reach of children.

OAppliances can be used by persons with reduced physical,

sensory or mental capabilities or lack of experience and

knowledge if they have been given supervision or instruction

concerning use of the appliance in a safe way and if they

understand the hazards involved.

OOnly use the appliance for its intended domestic use.

Kenwood will not accept any liability if the appliance is subject

to improper use, or failure to comply with these instructions.

OMisuse of your processor, blender or mill can result in injury.

OThe maximum rating is based on the mini chopper/mill

attachment that draws the greatest load. Other attachments

may draw less power.

Blender

O DO NOT process hot ingredients.

O SCALD RISK: Hot ingredients must be allowed to cool to

room temperature before placing in the goblet or before

blending.

O Always take care when handling the blade assembly and avoid

touching the cutting edge of the blades when cleaning.

O Only operate the blender with the lid in place.

O Only use the goblet with the blade assembly supplied.

O Never run the blender empty.

O Smoothie recipes - never blend frozen ingredients that have

formed a solid mass during freezing, break it up before adding

to the goblet.

Mill Attachments

O Never fit the blade assembly to the power unit without the jar/

lid fitted.

O Never unscrew the jar/lid while the mill is fitted to your

appliance.

O Do not touch the sharp blades – Keep the blade assembly

away from children.

O Never remove the mill until the blades have completely

stopped.

O The appliance will not work if the mill is incorrectly fitted.

O Do not process hot ingredients in the mill allow to cool down

to room temperature before processing.

Mini Chopper/Mill

O The processing of spices is not recommended as they may

damage the plastic parts.

Grinding Mill

O Do not process dried turmeric root as it is too hard and may

damage the blades.

Juice extractor

O Do not use the juicer if the filter, juicer lid or bowl are

damaged or has visible cracks.

O The cutting blades on the base of the filter drum are very

sharp, take care when handling and cleaning the drum.

O Only use the pusher supplied. Never put your fingers in the

feed tube. Unplug before unblocking the feed tube.

O Before removing the lid, switch off and wait for the filter to

stop.

Express Dice/Express Serve Attachment and Discs

O The cutting grid and discs are very sharp; handle with care

when fitting, removing and cleaning. Always hold by the

finger grip away from the cutting edge when handling

the sharp cutting blades, emptying the bowl and during

cleaning.

O Never use your fingers to push food down the feed tube. Only

use the pusher supplied.

O Do not use excessive force to push food down the feed tube –

you could damage your attachment.

O Before removing the lid, switch off wait until the cutting disc

has completely stopped.

O Do not pour hot liquids down the feed tube.

Express Serve

O Avoid contact with moving parts. Keep fingers out of the food

outlet opening.

O Do not operate when using the Dicer or Discs without the

slinger plate fitted. If the slinger plate is not fitted food will

clog under the plate and not exit the food outlet, resulting

in damage to your attachment.

O The citrus juicer is not designed to be used with the Express

Serve. Always use the citrus juicer with the main bowl.

Before plugging in

OMake sure your electricity supply is the same as the one shown on the underside of your appliance.

Important – Plug and Fuse Information

O The wires in the cord are coloured as follows:

Blue = Neutral

Brown = Live

O If the plug supplied with your appliance has a fuse fitted and the fuse fails it must be replaced with one of

the same rating.

O If the plug or cord requires replacing a new cord set should be fitted by an Authorised Kenwood Repairer.

Note:

O For non-rewireable plugs the fuse cover MUST be refitted when replacing the fuse. If the fuse cover is lost

then the plug must not be used until a replacement can be obtained. The correct fuse cover is identified by

colour and a replacement may be obtained from your Kenwood Authorised Repairer (see Service).

O If a non-rewireable plug is cut off it must be DESTROYED IMMEDIATELY. An electric shock hazard may arise

if an unwanted non-rewireable plug is inadvertently inserted into a socket outlet.

O This appliance conforms to EC Regulation 1935/2004 on materials and articles intended to come into

contact with food.

Before using for the first time

1 Remove the plastic blade covers from the knife blade. Take care the blades are very sharp. These

covers should be discarded as they are to protect the blade during manufacture and transit only.

2 Wash the parts see ‘care and cleaning’.

Cleaning

O Wipe the power unit and whisk drive head with a damp cloth,

then dry. Ensure that the interlock area is clear of food

debris.

O Do not immerse the power unit, blade assemblies or whisk

drive head in water.

O The bowl, lid, pusher and all attachment/tool apart from the

blade assemblies and whisk drive head are suitable for both

handwashing and dishwashing.

O The blade assemblies should be brushed clean and rinsed

under running water.

Key

Processor

1Pusher

2Feed tube

3Lid

4Bowl

5Detachable drive shaft

6Power unit

7Speed/pulse control

8Safety interlocks

9Cord storage (at back)

10A Plastic Blender (if supplied)

aBlade assembly

bSealing ring

cGoblet

dFiller cap

eLid

10B Glass Blender (if supplied)

aBlade assembly

bSealing ring

cGoblet

dLid

eFiller cap

C Standard Attachments

11 Knife blade

12 Dough tool

13 Dual whisk

14 4mm slicing/grating disc

15 2mm slicing/grating disc

16 Extra fine grating disc
